INSTALLATION AND INSTRUCTION MANUAL FOR
eaReefPro 1800S / 1500S / 1200S / 900S / 600SCube Aquariums
Evolution Aqua Ltd. - Evolution House - Kellet Close - Wigan - Lancashire - United Kingdom - WN5 0LP
UK
English
EAREEFPRO11501181MAN
PLEASE READ all of the instruction manual before attempting
to set-up your new eaReefPro Aquarium
IMPORTANT
Never attempt to clean the aquarium with a sharp,
blade-like object as this may damage the silicone bond
and invalidate the warranty.
CARE
This product requires Manual Handling.
Know your limitations before lifting!
For guidance please refer to: hse.gov.uk/toolbox/manual.htm
IMPORTANT
It is important to ensure that any water that is spilled
onto the cabinet is wiped off and dried immediately.
Failure to do so will invalidate the warranty
WARNING: PLEASE READ THE FOLLOWING
SAFETY INFORMATION FIRST.
DANGER: To avoid a possible electric shock, ensure all electrical devices are
switched off when carrying out maintenance. Take extra care when handling a
wet aquarium. Do not attempt repairs yourself; return the appliance to the place
of purchase for service or dispose of the appliance.
• To avoid the possibility of the appliance plug or socket
getting wet, position the aquarium cabinet and tank to
one side of a wall mounted socket to prevent water
from dripping onto the socket or plug. You should
create a “drip loop” for each cord connecting an
aquarium appliance to a socket. The “drip loop” is
that part of the cord below the level of the socket, or
the connector. Use an extension cord, if necessary,
to prevent water travelling along the cord and coming
into contact with the socket.
• Always unplug an appliance from an outlet when not in use, before putting on or taking off
parts, and before cleaning. Never pull the cord itself to remove the plug from the outlet.
Hold the plug and pull to disconnect.
• If the plug or socket does get wet, DO NOT unplug the cord. Disconnect the fuse or circuit
breaker that supplies power to the appliance. Then unplug the device and examine for presence
of water in the socket.
• Close supervision is necessary when any appliance is used by or near children.
• Do not use an appliance for anything other than its intended use. The use of attachments not
recommended or sold by the appliance manufacturer may cause an unsafe condition.
• Do not install or store the appliance where it will be exposed to the weather or to temperatures
below freezing point.
• Make sure an appliance mounted on a tank is securely installed before operating it.
Read carefully all the important notices on the appliance and the corresponding instruction manual.
NOTE: A cord rated for less amperes or watts than the appliance rating may overheat. Care should
be taken to arrange the cord so that it cannot be tripped over or pulled accidentally.
DRIP LOOP
IMPORTANT
It is important to ensure that any water that is spilled
onto the cabinet is wiped off and dried immediately.
Failure to do so will invalidate the warranty.
INTRODUCTION
Congratulations on purchasing an Evolution Aqua aquarium. The eaReefPro aquarium
range has been professionally designed for today’s reefkeepers. eaReefPro is suitable
for beginners right through to those at the cutting edge of the hobby, and combines
practicality with modern looks, durability with premium quality.
Along with eaReef, eaReefPro has been designed for marine hobbyists who like to
choose and add their own equipment, building a bespoke sump-based saltwater system
which is tailored exactly to their own methods, taste, experience and budget.
The aquarium, cabinet and sump are built from the highest quality materials,
ready to be installed and equipped at your convenience. Please read this manual
carefully before setting up your new eaReefPro aquarium.
4
CONTENTS
eaReefPro parts list PAGE 6
Specifications and dimensions PAGE 7
How the aquarium works PAGE 12
Installation instructions PAGE 14
Completing the installation and equipment PAGE 18
Setting the weir running height PAGE 19
How to get the best from your eaReefPro aquarium PAGE 21
Troubleshooting PAGE 23
Warranty PAGE 24
5
EAREEFPRO PARTS LIST
Your eaReefPro Aquarium comes complete with the following items:
2) Cabinet.
5) Removable acrylic
weir comb.
8) COMPONENT 3 -
Emergency overflow pipe.
1) eaReefPro Aquarium
with base mat fitted.
4) Adjustable baffle plates,
plastic bolts and nuts.
7) COMPONENT 2 - Outlet
assembly with double
union ball valve.
10) COMPONENT 5 - Inlet
assembly with elbow and
flare nozzle.
11) COMPONENT 6 -
Threaded hosetail.
SUMP
SIDE
SUMP
SIDE
SUMP
SIDE
WEIR
SIDE
WEIR
SIDE
WEIR
SIDE
3) Glass sump with base
mat fitted. Adjustable
baffles not factory fitted.
*eaReefPro1800 has a
separate reservoir tank
6) COMPONENT 1 - Outlet
assembly with strainer
and tank connector.
9) COMPONENT 4 -
Emergency overflow
sump side.
12) Hose for connecting
sump pump to inlet
6
SPECIFICATION eaReefPro600SCube
Aquarium dimensions 600mm(L) x 600mm(W) x 600mm(H)
Sump dimensions 500mm(L) x 380mm(W) x 400mm(H)
Cabinet dimensions 600mm(L) x 600mm(W) x 900mm(H)
Total system volume (nett) 198 litres adjustable upwards
Display tank volume (nett) 168 litres
Sump running volume (nett) 25 litres adjustable upwards
Sump top-up reservoir volume 17 litres
Skimmer chamber running height 190mm adjustable upwards
Skimmer chamber internal dimensions 240 x 180mm
Pump chamber internal dimensions 240 x 180mm
Reactor/refugium chamber internal dimensions 240 x 180mm
Top-up chamber internal dimensions 240 x 180 x 394mm
Recommended pump flow rate (not supplied) 4000lph maximum from an adjustable pump
Aquarium specifications 10mm glass all round. Low iron on five sides, black vinyl wrap background
SPECIFICATIONS AND DIMENSIONS
eaReefPro600SCube
600mm
600mm
600mm
900mm
VIEW FROM
FRONT OF TANK
7
SPECIFICATION eaReefPro900S
Aquarium dimensions 900mm(L) x 500mm(W) x 600mm(H)
Sump dimensions 800mm(L) x 350mm(W) x 400mm(H)
Cabinet dimensions 900mm(L) x 500mm(W) x 830mm(H)
Total system volume (nett) 267 litres adjustable upwards
Display tank volume (nett) 236 litres
Sump running volume (nett) 31 litres adjustable upwards
Sump top-up reservoir volume 19 litres
Skimmer chamber running height 190mm adjustable upwards
Skimmer chamber internal dimensions 250 x 338mm
Pump chamber internal dimensions 150 x 338mm
Reactor/refugium chamber internal dimensions 216 x 338mm
Top-up chamber internal dimensions 150 x 338 x 394mm
Recommended pump flow rate (not supplied) 3000lph maximum from an adjustable pump
Aquarium specifications 12mm glass all round. Low iron on five sides, black vinyl wrap background
SPECIFICATIONS AND DIMENSIONS
eaReefPro900S
VIEW FROM
FRONT OF TANK
900mm
600mm
500mm
830mm
8
SPECIFICATIONS
eaReefPro1200S
SPECIFICATION eaReefPro1200S
Aquarium dimensions 1200mm(L) x 600mm(W) x 600mm(H)
Sump dimensions 800mm(L) x 450mm(W) x 450mm(H)
Cabinet dimensions 1200mm(L) x 600mm(W) x 900mm(H)
Total system volume (nett) 441 litres adjustable upwards
Display tank volume (nett) 396 litres
Sump running volume (nett) 45 litres adjustable upwards
Sump top-up reservoir volume 24.3 litres
Skimmer chamber running height 190mm adjustable upwards
Skimmer chamber internal dimensions 250 x 438mm
Pump chamber internal dimensions 150 x 438mm
Reactor/refugium chamber internal dimensions 241 x 438mm
Top-up chamber internal dimensions 125 x 438 x 444mm
Recommended pump flow rate (not supplied) 5000lph maximum from an adjustable pump
Aquarium specifications 15mm front, 12mm all other sides. Low iron on five sides. Black vinyl wrap.
1200mm
600mm
600mm
900mm
9
SPECIFICATIONS
eaReefPro1500S
SPECIFICATION eaReefPro1500S
Aquarium dimensions 1500mm(L) x 600mm(W) x 600mm(H)
Sump dimensions 900mm(L) x 450mm(W) x 450mm(H)
Cabinet dimensions 1500mm(L) x 600mm(W) x 900mm(H)
Total system volume (nett) 536 litres adjustable upwards
Display tank volume (nett) 490 litres
Sump running volume (nett) 46 litres adjustable upwards
Sump top-up reservoir volume 29.17 litres
Skimmer chamber running height 190mm adjustable upwards
Skimmer chamber internal dimensions 300 x 438mm
Pump chamber internal dimensions 150 x 438mm
Reactor/refugium chamber internal dimensions 266 x 438mm
Top-up chamber internal dimensions 150 x 438 x 444mm
Recommended pump flow rate (not supplied) 6000lph maximum from an adjustable pump
Aquarium specifications 15mm glass all round. Low iron on five sides. Black vinyl wrap background.
1500mm
600mm
600mm
900mm
10
