Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

Revision 1.1

TABLE OF CONTENTS

1. OVERVIEW.......................................................................................................................................... 1

2. INSTALLATION................................................................................................................................... 3

3. SPECIFICATIONS............................................................................................................................... 4

3.1. SERIAL VIDEO INPUT ............................................................................................................... 4

3.2. SERIAL VIDEO OUTPUTS......................................................................................................... 4

3.3. ELECTRICAL ............................................................................................................................. 4

3.4. PHYSICAL.................................................................................................................................. 4

4. STATUS LEDS .................................................................................................................................... 5

4.1. INPUT 1 INDICATORS ............................................................................................................... 5

4.2. INPUT 2 INDICATORS ............................................................................................................... 6

5. LOCATION OF LEDS AND JUMPERS .............................................................................................. 6

5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED

BY THE GLOBAL FRAME STATUS.......................................................................................... 7

5.2. SELECTING THE OPERATING MODE ..................................................................................... 7

5.3. SELECTING NON-RECLOCK MODE ........................................................................................ 7

5.4. SELECTING THE RECLOCKING RATE ................................................................................... 8

Figures

Figure 1: 500DA2Q-HD Block Diagram ................................................................................................................2

Figure 2: 500DA2Q-HD Rear Panel Overlay ........................................................................................................3

Figure 3: LED and Jumper Locations....................................................................................................................6

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

Revision 1.1

REVISION HISTORY

REVISION DESCRIPTION DATE

1.0 Original Version Feb 03

1.1 Changed Cable length specification Mar 03

Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for

the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of

Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by

Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.

Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is

granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.

Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,

please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or

specifications.

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

Revision 1.1 500DA2Q-HD-1

1. OVERVIEW

The Evertz 500DA2Q-HD Dual HD Reclocking Distribution Amplifier provides the highest density DA in the

industry allowing up to 32 HD or SDI Distribution amplifiers in a 3RU space. It provides inexpensive

distribution of your SMPTE 292M (1.5 Gb/s), SMPTE 259M (143 to 360 Mb/s), SMPTE 344M (540 Mb/s),

DVB-ASI or SMPTE 310M (19.4 Mb/s) or any other SDI signal within the 143 Mb/s to 1.5 Gb/s range. The

500DA2Q-HD features two auto-equalized inputs and can be configured either as a single DA with eight

reclocked outputs or as two separate DAs with four outputs each. In the case of dual operation, each DA

can be individually set via jumpers for either reclocking or non-reclocking.

The 500DA2Q-HD is housed in the 500FR Frame that will hold up to 16 modules.

Features:

•Normal mode for SMPTE 292M (1.5 Gb/s) SMPTE 259M (143 to 360 Mb/s) or SMPTE 344M

(540 Mb/s) signals - autodetects correct bit rate

•Jumper selectable mode for DVB-ASI

•Jumper selectable non-reclock mode for SMPTE 310M (19.4 Mb/s) signals or any other SDI signal

within the 143 Mb/s to 1.5 Gb/s range

•Configurable as 1 DA with 8 outputs or 2 DAs with 4 outputs each.

•Fully hot-swappable from front of frame with no BNC disconnect required

•Independent isolated output drivers to ensure no cross channel loading effects (i.e. no need to

terminate unused outputs)

•Module health and 2 x 4 Mode Status LEDs

•Reclocker(s) Locked, Carrier Present and Video Standard LEDs for each DA channel

•Tally output on Frame Status bus upon loss of input signal

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

500DA2Q-HD-2 Revision 1.1

2x4

Operation

Equalizer

Carrier

Present

Equalizer

Serial Input

(143Mb/s to 1.5Gb/s)

Carrier

Present

Reclocker Bypass

143Mb/s-1.5Gb/s

Reclocker

Cable Drivers

Serial Output

143Mb/s to 1.5Gb/s

(SMPTE 259M, 344M or

292M)

270 1.5G

Reclocker

Locked

Reclocker

Bypassed

Reclocker Bypass

143Mb/s-1.5Gb/s

Reclocker

Cable Drivers

Serial Output

143Mb/s to 1.5Gb/s

(SMPTE 259M, 344M or

292M)

270 1.5G

Reclocker

Locked

Reclocker

Bypassed

Serial Input

(143Mb/s to 1.5Gb/s)

1x8 / 2x4

Mux

Control &

Indicators

Module

Health

Figure 1: 500DA2Q-HD Block Diagram

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

Revision 1.1 500DA2Q-HD-3

2. INSTALLATION

The 500DA2Q-HD comes with a companion rear panel overlay that can be placed over the rear panel

BNC connectors to identify their function. For information on inserting the module into the frame see the

500FR chapter section 3.

Figure 2: 500DA2Q-HD Rear Panel Overlay

IN A & IN B Input BNC connectors for 10-bit serial digital video signals compatible with the

SMPTE 292M, SMPTE 259M, SMPTE 344M and SMPTE 310M (19.4 Mb/s) standards or any

SDI signal between the range of 143Mb/s to 1.5 Gb/s.

OUT 1A to 4A These four BNC connectors are used to output reclocked serial component video from IN

(A).

OUT 1B to 4B These four BNC connectors can be configured to output reclocked serial component video

from IN (A) when jumper J7 is set to SINGLE 1x8 mode. When jumper J7 is set to DUAL 1x4

mode, these connectors output reclocked serial component video from IN (B) See Figure 3 for

the location of J7.

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

500DA2Q-HD-4 Revision 1.1

3. SPECIFICATIONS

3.1. SERIAL VIDEO INPUT

Standards:

Reclocked: SMPTE 292M (1.5 Gb/s).

SMPTE 259M (143 to 360 Mb/s).

SMPTE 344M (540 Mb/s)

DVB-ASI

Non-reclocked: SMPTE 310M (19.4 Mb/s)

Any SDI signal in the143Mb/s to 1.5 Gb/s range

Connectors: 2 BNC per IEC 169-8

Equalization: Automatic to 100m @ 1.5 Gb/s with Belden 1694A or equivalent cable on input A

Automatic to 90m @ 1.5 Gb/s with Belden 1694A or equivalent cable on input B

Return Loss: >10 dB up to 1.5 Gb/s

3.2. SERIAL VIDEO OUTPUTS

Number of Outputs: (mode set by J7)

2 x 4 Mode: 4 reclocked from each input

Reclockers can by bypassed separately for each input

1 x 8 Mode: 8 reclocked from Input A (1)

Reclockers can by bypassed

Connector: BNC per IEC 169-8

Signal Level: 800mV nominal

DC Offset: 0V ±0.5V

Rise and Fall Time: 200ps nominal

Overshoot: <10% of amplitude

Return Loss: >10 dB up to 1.5 Gb/s

Jitter: < 0.2 UI

3.3. ELECTRICAL

Voltage: + 12VDC

Power: 6 Watts

EMI/RFI: Complies with FCC Part 15 Class A, EU EMC Directive

3.4. PHYSICAL

Number of slots: 1

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

Revision 1.1 500DA2Q-HD-5

4. STATUS LEDS

The 500DA2Q-HD has thirteen LED Status indicators on the front card edge to show operational status of

the card at a glance. Error! Reference source not found. shows the location of the LEDs.

Two large LEDs on the front of the board indicate the general health of the module

STATUS: This Red LED indicates poor module health and will be On during the absence of a

valid input signal or if a local input power fault exists (i.e.: a blown fuse). The

STATUS indication can also be reported to the frame by setting the FRAME

STATUS jumper J1 to the ON position.

MODULE OK: This Green LED indicates good module health. It will be On when a valid input

signal is present at either reclocker (signal present on input 1 in 1x8 mode, signal

present on input 1 or input 2 in dual 1x4 mode), and board power is good.

There are three small LEDs at the top of the module that indicate the status of the reclockers and the

mode of the DA.

INPUT 1 RECLOCKER LOCKED: This Green LED will be On when reclocker 1 is locked to a valid

signal present at the module input 1.

INPUT 2 RECLOCKER LOCKED: This Green LED will be On when reclocker 2 is locked to a valid

signal present at the module input 2 when the module is in Dual 1x4 mode. It will be

on when reclocker 2 is locked to a valid signal present at the module input 1 when

the module is in Dual 1x4 mode.

DUAL 1x4 MODE: This Green LED will be On when the DUAL 1x4 mode is set via J7.

4.1. INPUT 1 INDICATORS

There are three small LEDs in the middle of the module that indicate the status of equalizer for input 1 and

the reclocker 1 rate.

CARRIER PRESENT: This Green LED will be On when cable equalizer 1 detects that there is a

signal present at input 1.

270 Mb/s: This Green LED will be On when reclocker 1 is locked to a valid SMPTE 259M-C

(270 Mb/s) SDI signal.

1.5 Gb/s: This Green LED will be On when reclocker 1 is locked to a valid SMPTE 292M (1.5

Gb/s) HD SDI signal.

RECLOCKER BYPASS: This Green LED will be when reclocker 1 is in the bypass (non-reclock)

mode.

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

500DA2Q-HD-6 Revision 1.1

4.2. INPUT 2 INDICATORS

There are three small LEDs at the bottom of the module that indicate the status of equalizer for input 2 and

the reclocker 2 rate.

CARRIER PRESENT: This Green LED will be On when cable equalizer 2 detects that there is a

signal present at input 2.

270 Mb/s: This Green LED will be On when reclocker 2 is locked to a valid SMPTE 259M-C

(270 Mb/s) SDI signal.

1.5 Gb/s: This Green LED will be On when reclocker 2 is locked to a valid SMPTE 292M (1.5

Gb/s) HD SDI signal.

RECLOCKER BYPASS: This Green LED will be when reclocker 2 is in the bypass (non-reclock)

mode.

5. LOCATION OF LEDs AND JUMPERS

FRAME STATUS

INPUT 1 RECLOCKER LOCKED

MODULE STATUS (RED & GREEN LED)

J1 ON

OFF

INPUT 2 RECLOCKER LOCKED

DUAL 1X4 MODE

INPUT 1

270Mb/s

1.5 Gb/s

RECLOCKER

BYPASS

INPUT 2

270Mb/s

1.5 Gb/s

RECLOCKER

BYPASS

SINGLE 1X8

DUAL 1X4

RECLOCK

BYPASS

177

DVB

INPUT 2

RECLOCKER

CONFIG.

RECLOCK

BYPASS

177

DVB

INPUT 1

RECLOCKER

CONFIG.

CARRIER PRESENT

(A)500DA2Q-HD

Figure 3: LED and Jumper Locations

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

Revision 1.1 500DA2Q-HD-7

5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED

BY THE GLOBAL FRAME STATUS

The FRAME STATUS jumper J1, located at the front of the module determines whether local faults (as

shown by the Local Fault indicator) will be connected to the 500FR frame's global status bus.

FRAME STATUS: To monitor faults on this module with the frame status indicators (on the power

supply’s FRAME STATUS LED's and on the Frame's Fault Tally output) install this

jumper in the On position.

When this jumper is installed in the Off position local faults on this module will not

be monitored.

5.2. SELECTING THE OPERATING MODE

DA CONFIG: To configure the 500DA2Q-HD for four outputs from Input 1 and four outputs from

Input 2, move the jumper J7 to the DUAL 1x4 position. The DUAL 1x4 LED will be

On.

To configure the 500DA2Q-HD for eight outputs from Input 1, move the jumper J7 to

the SINGLE 1x8 position. The DUAL 1x4 LED will be Off.

!When the module is operated in the single 1 x 8 mode, both of the reclocker mode

jumpers (J2 and J5) should be set the same. If these jumpers are set to reclock

mode then both of the reclocker rate jumpers (J3 and J6) should be set to the same

rate.

5.3. SELECTING NON-RECLOCK MODE

Two jumpers located near the front of the module, determine whether the each half of the module will

operate as a reclocking amplifier for SMPTE 292M (1.5 Gb/s), SMPTE 259M (143 to 360 Mb/s),

SMPTE 344M (540 Mb/s) or DVB-ASI video signals or as a non-reclocking distribution amplifier with other

data rates. J2 controls the bypass for reclocker 1 and J5 controls the bypass for reclocker 2.

!When the module is operated in the single 1 x 8 mode, both of these jumpers

should be set the same.

BYPASS SELECT: To operate the module in reclocking mode install the jumper in the RECLOCK

position. The RATE jumper associated with the respective reclocker must be set to

match the signal being reclocked. (See section 5.4)

To operate the module in non-reclocking mode install the jumper in the BYPASS

position.

Frame Manual

500DA2Q-HD Dual HD Reclocking Distribution Amplifier

500DA2Q-HD-8 Revision 1.1

5.4. SELECTING THE RECLOCKING RATE

Two jumpers located near the front of the module, determine whether the each half of the module will

operate as a reclocking distribution amplifier SMPTE 292M (1.5 Gb/s), SMPTE 259M (143 to 360 Mb/s) or

SMPTE 344M (540 Mb/s) or DVB-ASI video signals. J3 controls the rate for reclocker 1 and J6 controls

the rate for reclocker 2. These jumpers have no effect if the associated reclocker is operating in non-

reclock mode.

!When the module is operated in the single 1 x 8 mode, and the reclocker jumpers

are set to reclock mode, then both of these jumpers should be set to the same rate.

RATE: To set the reclocker to operate with SMPTE 292M (1.5 Gb/s), SMPTE 259M (143 to

360 Mb/s) or SMPTE 344M (540 Mb/s) signals install the jumper in the 177 position.

The reclocker will automatically detect the correct rate in the range of 143 Mb/s to

1.5 Gb/s.

To set reclocker to operate with DVB-ASI signals install the jumper in the DVB

position.

Table des matières

Autres manuels evertz Amplificateur

evertz

evertz 9000EDFA-D-AGC Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7800DA8-12G Manuel utilisateur

evertz

evertz exponent 500ADA-EQ Manuel utilisateur

evertz

evertz exponent 500ADA-W Manuel utilisateur

evertz

evertz exponent 520DARS-W Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz exponent 500DA-L Manuel utilisateur

evertz

evertz 500DA Manuel utilisateur

evertz

evertz 500DA2Q-AESU Manuel utilisateur

evertz

evertz 7700ADA7-EQ MultiFrame Manuel utilisateur

evertz

evertz exponent 500ADA-EQ-L Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700DA6-L Manuel utilisateur

evertz

evertz 7700DA-HD Manuel utilisateur

evertz

evertz exponent 500ADA-AUD Manuel utilisateur

evertz

evertz exponent 500DA-AESU-L Manuel utilisateur

evertz

evertz exponent 500DA-AESU Manuel utilisateur

evertz

evertz exponent 500ADA Manuel utilisateur

evertz

evertz 7700DA7-HD Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7700 Series Manuel utilisateur

evertz

evertz 7815VPDA Series Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur

evertz exponent 500DA2Q-HD Manuel utilisateur

Manuels Amplificateur populaires d'autres marques
