EverMore ST-K700 Manuel utilisateur

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

ST-K700/ GM-R700

GPS Receiver User’s Manual

EverMoreTechnologyInc.

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

Not to be reproduced in whole or part for any purpose without written permission of EverMore Technology Inc.

Information provided by EverMore Technology Inc. is believed to be accurate and reliable. However, no

responsibility is assumed by EverMore Technology Inc. for its use. EverMore Technology Inc. reserves the right to

change specification at any time without notice.

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

Contents

1. INTRODUCTION............................................................................................... 5

1.1 Overview ............................................................................................................................. 5

1.2 Features ............................................................................................................................... 6

1.3 Applications......................................................................................................................... 6

1.4 Start-up Modes ................................................................................................................... 7

2. TECHNICAL SPECIFICATIONS................................................................... 8

2.1 Electrical Characteristics ..................................................................................................8

2.2 Environmental Characteristics ......................................................................................... 9

2.3 Physical Characteristics..................................................................................................... 9

3. HARDWARE INTERFACE ........................................................................... 10

3.1 ST-K700 PS/2 Female Connector (standard type) ........................................................ 10

3.2 ST-K700 Female PS/2 Connector Interface ................................................................... 11

3.3 ST-K700 Accessories.........................................................................................................12

3.3.1 DB9 9 Pins Female and PS/2 Male Connector .................................................................. 12

3.3.2 USB Connector .............................................................................................................. 13

3.4 ST-K700 Dimensions ........................................................................................................ 14

3.5 ST-K700 Appearance Diagram ....................................................................................... 14

4 ST-K700 USB DRIVER INSTALLATION.................................................... 15

5. OPERATION AND TEST .............................................................................. 16

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

6. SOFTWARE SPECIFICATION .................................................................... 17

6.1 ST-K700 NMEA Protocol................................................................................................. 17

6.2 General NMEA Format ................................................................................................... 17

6.3 $GPGGA ........................................................................................................................... 18

6.4 $GPGLL............................................................................................................................ 19

6.5 $GPGSA ............................................................................................................................ 19

6.6 $GPGSV ............................................................................................................................ 20

6.7 $GPRMC........................................................................................................................... 21

6.8 $GPVTG............................................................................................................................ 21

6.9 $GPZDA............................................................................................................................ 22

7. LIMITED WARRANTY................................................................................... 22

8. ORDERING INFORMATION ........................................................................ 23

8.1 Standard Type Cable (Female PS/2)............................................................................... 23

8.2 Optional Types Cable....................................................................................................... 24

8.2.1 Male PS/2 Cable............................................................................................................. 24

8.2.2 SP6P Cable .................................................................................................................... 25

8.2.3 RS-232 Cable (DB9 9 Pins Female + PS/2 Male).............................................................. 26

8.2.4 USB Cable (With USB Bridge Controller IC) ................................................................... 27

8.3 Car Charger List .............................................................................................................. 28

9. SERIES PRODUCTS INFORMATION....................................................... 29

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

10. APPENDIX ................................... FEHLER! TEXTMARKE NICHT DEFINIERT.

1. Introduction

1.1 Overview

EverMore series GPS module ST-K700 is a high sensitivity ultra low power consumption cost

efficient, compact size; plug & play GPS module board designed for a broad spectrum of OEM system

applications. This product is based on the proven technology found in 16 channel GPS receivers and

NEMERIX chipset solution. The GPS module receiver will track up to 16 satellites at a time while

providing fast time-to-first-fix and 1Hz navigation updates. It is far reaching capability meets the

sensitivity & accuracy requirements of car navigation as well as other location-based applications,

such as AVL system. Handheld navigator, PDA, pocket PC, or any battery operated navigation system.

The ST-K700 design utilizes the latest surface mount technology and high level circuit

integration to achieve superior performance while minimizing dimension and power consumption. This

hardware capability combined with software intelligence makes the board easy to be integrated and

used in all kinds of navigation applications or products. The module communicates with application

system via RS-232 level with NMEA0183 protocol.

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

1.2 Features

The ST-K700 GPS engine board offers following features:

zBuilt-in high performance NEMERIX chipset.

zAverage Cold Start in 50 seconds.

zUltra low power consumption.

z16 channels “All-in-View” tracking.

zSupport standard NMEA-0183 V3.0

zMulti-path mitigation hardware

zOptimum clock drift adjustment

zBuilt-in patch antenna

zOn-board rechargeable battery sustained real-time clock and memory for fast satellite

acquisition during power-up

zCompact board Size ST-K700 51mm x 42.5mm x 17.3mm (2.01”x1.67”x0.68”)

for easy integration into hand-held device.

1.3 Applications

ST-K700 engine board receiver is a high performance, ultra low power consumption, plug &play

product. These applications are as follow.

zCar navigation system for portable device and car device

zWrist watch

zSolar operated device

zMarine Navigation

zFleet management

zAVL and location-based services

zRadar detector with GPS function

zHand-held device for personal positioning and navigation

zIdeal for PDA, pocket PC and other computing devices at GPS application

zAsset tracking

zTiming reference

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

1.4 Start-up Modes

Definitions

DESCRIPTION

Cold Start

The Cold Start takes the longest startup time among EMT GPS receivers. In

this scenario, the receiver has no acknowledgment on the last position, time,

and satellite constellation. The receiver is initiated to search blindly for satellite

signals in the cold start mode.

nother situation is that when no backup battery is connected, the GPS

receiver will be in the cold start mode and there is no data stored in SRAM.

Execute cold start of the test tool when first use. By this way can speed up

position fix time.

Warm Start

In this scenario, the receiver was off less than one week but more than 2-hour

time.

The receiver knows its last position, time and almanac because it has a

backup battery to keep current almanac, position and time stored in SRAM.

In the warm start mode, the receiver can quickly acquire satellites and get a

position fix faster than it does in the cold start mode.

Hot Start

In this scenario, the receiver was off less than 2-hour time. With the back up

battery connected and the current almanac, position, time and ephemeris

stored in SRAM, the receiver applies its last ephemeris data to calculate and

get a position fix.

Reacquisition

In the reacquisition mode, the receiver takes time to lock on satellites if

buildings or obstacles are blocking the signals for a short while.

This is very common in urban areas, but please be noted that reacquisition

time has nothing to do with the time-to-first-fix (TTFF).

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

2. Technical Specifications

2.1 Electrical Characteristics

2.1.1 General

Frequency L1, 1575.42 MHz

C/A code 1.023 MHz chip rate

Channels 16

2.1.2 Sensitivity

Tracking -152dBm type

2.1.3 Accuracy

Position 3-25 meters CEP (90%) horizontal, SA off.

Velocity 0.1 meters/second

Time ±100 ns synchronized to GPS time

2.1.4 Datum

Default WGS-84

Other Support different datum by request

2.1.5 Acquisition Rate (Open sky, stationary requirements)

Hot start 7 sec, average

Warm start 38 sec, average

Cold start 50 sec, average

2.1.6 Dynamic Conditions

Altitude 18,000 meters max

Horizontal Velocity 300 kilometers/hour max

Vertical Velocity 36 kilometers/hour max

Acceleration 2g, max

Jerk 4 meters/second3, max

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

2.1.7 Power

Main power input 5V ± 0.5Vp-p DC input.

Supply Current Typical 33 mA

2.1.8 Serial Port

Electrical interface one full duplex serial communication, RS-232 interface

Protocol message NMEA-0183, version 3.0

Default NMEA GGA, GSA, GSV, RMC and VTG. 9600 baud rate,

8 bits data, 1 start, 1 stop, no parity.

(Option baud rate: 4800,19200, 38400)

2.2 Environmental Characteristics

Operating temperature range -40 ℃to +80 ℃

Storage temperature range -50 ℃to +90 ℃

2.3 Physical Characteristics

Dimension: 51mm x 42.5mm x 17.3mm (2.01”x1.67”x0.68”)

Weight: 78g (2.75oz)

Interface connector: PS/2 female connector

GM-R700 User’s Manual

EverMore Technology Inc.

2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.

3. Hardware Interface

3.1 ST-K700 PS/2 Female Connector (standard type)

ST-K700 Real Picture

PS/2 Female Connector Pin Assignment

Pin Function Input/Output Level

1 VCC Power Supply 5V

2 GND

3 RX Input 12V, RS232

4 RXD Input 3.3V, LVTTL

5 TXD Output 3.3V, LVTTL

6 TX Output 12V, RS232

3RX 5

TXD

1VCC

PS/2(Female)

2GND attheST-K700

4RXD 6

PS/2 female connector (standard type)
