EMW990F

1080p FHD Mobile IR Mini Wedge Camera

User’s Manual

Release Date: December, 2018

All the images including product pictures or screen shots in this document are for example only. The images may

vary depending on the product and software version. Information contained in this document is subject to change

without notice.

Precautions

1. Do not install the camera near electric or magnetic fields. Install the camera away from

TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the

electromagnetic fields generated from these devices may distort the video image or otherwise

interfere with camera operation.

2. Never disassemble the camera beyond the recommendations in this manual nor introduce

materials other than those recommended herein. Improper disassembly or introduction of

corrosive materials may result in equipment failure or other damage.

3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may

cause permanent damage to the sensor and/or internal circuits, as well as creating unbalanced

illumination beyond the capability of the camera to compensate.

4. Keep the power cable away from water and other liquids and never touch the power cord

with wet hands. Touching a wet power cord with your hands or touching the power cord with

wet hands may result in electric shock.

5. Never install the camera in areas exposed to oil, gas or solvents. Oil, gas or solvents may result

in equipment failure, electric shock or, in extreme cases, fire.

6. Cleaning. For cameras with interchangeable lenses, do not touch the surface of the sensor

directly with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the

sensor and the camera lens. Use a damp soft cloth to remove any dirt from the camera body.

Please do not use complex solvents, corrosive or abrasive agents for cleaning of any part of the

camera.

7. Do not operate the camera beyond the specified temperature, humidity or power source

ratings. This camera is suitable for indoor operation only. Use the camera at temperatures

within -20°C~50°C (-4°F~122°F) and humidity less than 80%; this device is not rated as

submersible. The input power source is 12VDC. Be sure to connect the proper + / - polarity and

voltage, as incorrect polarity or too high a voltage will likely cause the camera to fail, and such

damage is not covered by the warranty.

8. Mounting. Use care in selecting a solid mounting surface which will support the weight of the

camera plus any wind, snow, ice or other loading, and securely attach the camera to the

mounting surface using screws and anchors which will properly support the camera. If

necessary (e.g. when mounting to drop ceilings) use a safety wire to provide additional support

for the camera.

Safety Notice

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

1. Introduction

Equipped with a 1080p Sony Starvis CMOS sensor, the EMW990F is one of the EverFocus eZ.HD

series cameras, providing 1080p full HD image quality. Featured with True Wide Dynamic Range

(T-WDR) function, the camera can provide clear images even under backlight circumstances where

intensity of illumination can vary excessively. The EMW990F supports both NTSC and PAL scanning

systems and is IP66 certified. The 4 IR LEDs enable night vision up to 10m (~33ft.). EMW990F is the

ideal solution for your mobile surveillance needs.

1.1 Packing List

1.2 Features

1080p Full HD with high flexibility and performance for astounding image

Adopts Sony Starvis CMOS sensor, delivering amazing high sensitivity

Astounding image quality from the 2.8mm lens

Extended IR range up to 10m / 33ft. with 4 LEDs (depends on scene IR reflectivity)

True-WDR to improve the visibility under high contrast scene

Supports 3D-Noise Reduction function

Flexible angle viewing with 3-Axis rotation design

Supports UTC function: Control camera OSD settings directly from DVR end

1.3 Cable Description

Name

Descriptions

1Power Cable Connects to a 12VDC power source.

2Video Output 1080p output, using a 75 Ohm BNC-type coaxial cable.

3 DC Power Pigtail Cable Optional power pigtail cable. The red wire is positive (+);

while the black wire is negative (-).



Camera x 1



Screw x 2



Hexagon Wrench x 1



Anchor x 2



DC Power Pigtail Cable x 1



User Manual x 1

1.4 Dimensions

75.5mm / 3" 68.8mm / 2.7"

78.6mm / 3.1"

3. Installation

Screw Hole

Optionally thread the

cable through this hole

Loosen to adjust Sunshield / Camera Angle

4Loosen to adjust Sunshield / Camera Angle

Loosen to adjust Bracket Angle

Power Cable

Video Output Cable

1. Attach the Camera Bracket to the surface where you want to mount the camera and mark the

Screw Hole locations on the surface. Drill two screw holes on the surface and insert the

supplied two Anchors to the holes. Screw the Camera Bracket to the surface using the supplied

two Screws.

2. Optionally drill another hole in the middle between the two screw holes only if you want to

thread the cables through the surface.

3. Connect the camera to a 12VDC power source using the supplied DC Power Pigtail Cable or

power adapter. Connect the video output cable to the monitor.

4. To adjust the Sunshield or Camera angle, loosen the two screws on both sides and then adjust

the angle.

5. To adjust the Bracket angle, loosen the screw on both sides and then adjust the angle.

4. Configuration in the OSD Menu

You can configure camera settings in the OSD menu from DVR end. OSD menu structure is listed on

the below table:

No.

Main

Sub Menu

Sub Menu / Function

Lens

Manual

2 Exposure

Shutter

NTSC: 1/30, 1/60, FLK, 1/240, 1/480, 1/1000, 1/2000, 1/5000,

1/10000, 1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto

PAL: 1/25, 1/50, FLK, 1/200, 1/400, 1/1000, 1/2000, 1/5000,

1/10000, 1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto

AGC

0-15

Sens-up

Off

Auto

Sens-up

X2, X4, X6, X8, X10, X15, X20, X25, X30

Brightness

1-100(50 default)

D-WDR

Off

Level

0-8

Auto

Defog

Off

Auto

Pos/Size

Position, Size,↑,↓,→,←

Gradation

0-2

Default

3 Backlight

Off

BLC

Level Middle, High, Low

Area

Position, Size,↑,↓,→,←

Default

HSBLC

Select

Area1, Area2, Area3, Area4

Display

Off

Position, Size,↑,↓,→,←

Black Mask

On/Off

Level

0-100

Mode

All Day

Night

AGC Level

0-255

Default

WDR

Level 0-4

D&N Mode

Off / Auto

4 White

Balance

ATW

AWC→SET

Indoor

Outdoor

Manual

Blue

0-100

Red 0-100

AWB

5 Day &

Night

Ext

D→N(Delay)

0-60

N→D(Delay)

0-60

Auto

D→N(CDS)

1-255

D→N(Delay)

0-60

N→D(CDS

1-255

N→D(Delay)

0-60

Color

B/W

Burst

Off/On

IR Smart

Off

Level

0-15

Area

Position, Size,↑,↓,→,←

6 NR

2DNR

Middle/Low/Off/High

3DNR

Middle/Low/Off/High

7 Special

Cam Title

Off

On 0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ▶→

←↑↓()ˉ-_▊/=&:~,.

D-effect

Freeze

Off/On

Mirror Off, Mirror, V-flip, Rotate

Neg. Image

Off/On

Motion

Off

Select

Area1,Area2,Area3,Area4

Display

Position, Size,↑,↓,→,←

Off

Sensitivity

0-100

Color

Green, Blue, White, Red

Trans

1.00,0.75,0.50,

0.25

Alarm

View Type

Off, Block, Outline, All

OSD View

On/Off

Alarm Out

On/Off

Time

0-15

Default

Privacy

Off

Select

Area1,Area2,Area3,Area4

Display

Off

Color

Position, Size,↑,↓,→,←

Mosaic Position, Size,↑,↓,→,←

Inv

Position, Size,↑,↓,→,←

Color White, Black, Red, Blue, CYAN, Yellow,

Green, User

Trans

1.00,0.75,0.50,0.25

Default

Language

ENG/CHN1/CHN2/GER/FRA/ITA/SPA/POL/RUS/POR/NED/TUR/KOR/

JPN/HEB/ARB

Defect

Live DPC

Off

AGC level

0-255

Level

0-100

White DPC

Off

Pos/Size

Position, Size,↑,↓,→,←

Start

Close the iris then press

DPC View

Off/On

Level

0-60

AGC

0-14

Sens-up

x2, x4, x6, x8,x10, x15,

x20, x25, x30

Black DPC

Off

Pos/Siz

Position, Size,↑,↓,→,←

Start

Press Enter

DPC View

Off/On

Level 0-100

RS485

CAM ID

0-255

ID Display

Off/On

Baud Rate

2400,4800,9600,19200,38400

8 Adjust

Sharpness

Off

Auto

Level

0-10

Start AGC

0-255

End AGC

0-255

Monitor

Gamma User,0.45,0.50,0.55,0.60,0.65,0.70,0.75,0.80,0.85,

0.90, 0.95,1.00

Blue Gain

0-100

Red Gain 0-100

LSC

Off/On

Video.

Out PAL/NTSC

Exit

Save&END /Reset/Not Save

5. Specification

Model Name EMW990F

Pickup Device 1080p Sony Starvis CMOS sensor

Video Format NTSC / PAL

Effective Pixels 1920 (H) x 1080 (V)

Scanning System Progressive Scan

Sensitivity 0 Lux with IR On

Electronic Shutter Auto / Manual (x30 ~ 1/50,000)

Gamma Correction 0.45 ~ 100

Lens Type 2.8mm fixed lens

FOV H=120°, V=80°, D=140°

BLC OFF / BLC / HSBLC / WDR Selectable

AGC 0 ~ 15 Levels

White Balance ATW / AWC-SET / Indoor / Outdoor / Manual / AWB

Sync Mode Internal

Day/Night Ext, Auto, Color, B/W

IR LED 4 Units

IR Distance Up to 10m / 33ft. (depends on scene IR reflectivity)

S/N Ratio >50dB (AGC off)

OSD Languages

English / Simplified Chinese / Traditional Chinese / German / French /

Italian / Spanish / Polish / Russian / Portuguese / Netherlands /

Turkish / Korean / Japanese / Hebrew / Arabic

DNR 2DNR / 3DNR, Off

DEFOG Off / Auto

T-WDR On / Off / Auto (120dB)

Sens-up Off / Auto (x2 ~ x30)

Mirror Off / Mirror / V-Flip / Rotate

Motion Detection Off / On for 4 selectable zones

Privacy Mask Off / On for 4 selectable zones

Environment IP66 Weather Resistant

Power Source 12VDC

Power Consumption 2.9W max.

Operating Temperature -20°C ~ 50°C / -4°F ~ 122°F

Humidity Less than 80%

Dimensions (W x D x H) 75.5 x 68.8 x 78.6mm / 3" x 2.7” x 3.1"

Weight 280g / 0.62lb (with bracket)

200g / 0.44lb (without bracket)

Certifications CE, FCC, RoHS

EverFocus Electronics Corp.

EverFocus Taiwan:

2F., No.12, Ln. 270, Sec. 3, Beishen Rd.,

Shenkeng Dist., New Taipei City 222, Taiwan

TEL: +886 2 2662 2338

FAX: +886 2 2662 3632

www.everfocus.com.tw

mark[email protected]

EverFocus China - Shenzhen:

3F,Building 7,Longcheng Industrial

Park,No.440,Longguan Road,

Dalang Street, Longhua, Shenzhen,

Guangdong, China

TEL: +86 755 2765 1313

FAX: +86 755 2765 0337

www.everfocus.com.cn

marketing@everfocus.com.cn

EverFocus China - Beijing:

Room 609, Technology Trade Building,

Shangdi Information Industry Base,

Haidian District, Beijing 100085, China

TEL: +86 10 6297 3336~39

FAX: +86 10 6297 1423

www.everfocus.com.cn

mark[email protected]

EverFocus Japan:

3F, Kuramochi, Building II

2-2-3 Koto-Bashi, Sumida-Ku,

Tokyo, 130-0022, Japan

TEL: +81 3 5625 8188

FAX: +81 3 5625 8189

www.everfocus.co.jp

info@everfocus.co.jp

EverFocus USA - California:

1801 Highland Avenue, Unit A, Duarte, CA

91010, USA

TEL: +1 626 844 8888

FAX: +1 626 844 8838

www.everfocus.com

sales@everfocus.com

Your EverFocus product is designed

and manufactured with high quality

materials and components which can

be recycled and reused.

This symbol means that electrical and

electronic equipment, at their

end-of-life, should be disposed of

separately from your household waste.

Please, dispose of this equipment at

your local community waste

collection/recycling centre.

In the European Union there are

separate collection systems for used

electrical and electronic product.

Please, help us to conserve the

environment we live in!

Ihr EverFocus Produkt wurde entwickelt

und hergestellt mit qualitativ

hochwertigen Materialien und

Komponenten, die recycelt und wieder

verwendet werden können.

Dieses Symbol bedeutet, dass

elektrische und elektronische Geräte am

Ende ihrer Nutzungsdauer vom

Hausmüll getrennt entsorgt werden

sollen.

Bitte entsorgen Sie dieses Gerät bei

Ihrer örtlichen kommunalen

Sammelstelle oder im Recycling Centre.

Helfen Sie uns bitte, die Umwelt zu

erhalten, in der wir leben!

P/N:

4605W099002001C

Table des matières

Autres manuels EverFocus Caméra de sécurité

EverFocus

EverFocus SG Series Manuel utilisateur

EverFocus

EverFocus H.265 VANGUARD II Series Manuel utilisateur

EverFocus

EverFocus NeVio EAN800A Manuel utilisateur

EverFocus

EverFocus EZN268 Manuel utilisateur

EverFocus

EverFocus eZ.HD Series Manuel utilisateur

EverFocus

EverFocus eZ Tracker EFN3320 Manuel utilisateur

EverFocus

EverFocus EZ430 Manuel technique

EverFocus

EverFocus EZA1840 eZ.HD Series Manuel utilisateur

EverFocus

EverFocus EPN4122 Manuel utilisateur

EverFocus

EverFocus EAN-1350 Manuel utilisateur

EverFocus

EverFocus ED610 Manuel utilisateur

EverFocus

EverFocus Weatherproof Long Range IR Camera 235E Manuel utilisateur

EverFocus

EverFocus ECD360AV Manuel utilisateur

EverFocus

EverFocus ED910 Manuel utilisateur

EverFocus

EverFocus ED700W Manuel utilisateur

EverFocus

EverFocus EQ350HQ Manuel utilisateur

EverFocus

EverFocus EHN3200 Manuel utilisateur

EverFocus

EverFocus EQ-2250 Manuel utilisateur

EverFocus

EverFocus EBN288 Manuel utilisateur

EverFocus

EverFocus eZ.HD EBD930F Manuel utilisateur

EverFocus

EverFocus ECD900F Manuel utilisateur

EverFocus

EverFocus Color Rugged Dome Camera EHD350 Manuel utilisateur

EverFocus

EverFocus EZ-VF325NH Manuel utilisateur

EverFocus

EverFocus EQ610x Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
