EAN600

User’s Manual V2.0

Release: May 2005

EAN600

ntroduction

Product Name : EAN 600 EverFocus Advance Network Cameras

Model Number(s) : EAN600

FCC Notice "Declaration of Conformity Information"

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

Installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications made to this equipment, not expressly

approved by Toshiba or parties authorized by Toshiba could void the

user's authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference

that may cause undesired operation.

EverFocus Electronics Corp.

12F, No. 79, Sec. 1, Shin-Tai Wu Rd., His-Chi,

Taipei Hsien, Taiwan, R.O.C.

EAN600 complies with BSMI, CE, FCC, UL, and class B of EMC.

EAN600

TABLE OF CONTENTS

TABLE OF CONTENTS ..............................................................................................3

Introduction....................................................................................................................4

Terms and Trademarks...............................................................................................4

Accessories ................................................................................................................5

Assembly Diagram.....................................................................................................5

Important Safety Instructions.....................................................................................6

Safety Precautions......................................................................................................8

About the AC adaptor ..............................................................................................12

Installation and Operation............................................................................................14

Setting up the Hardware connection........................................................................14

Software configuration: ...........................................................................................15

1. Setup the IP address of your local PC..............................................................15

2.Setting up the Browser......................................................................................17

3. Viewing the live video steps............................................................................18

Detail Description Of Operation When Logged In As “Admin”.............................21

Firmware Upgrade.......................................................................................................24

What is CamTool .....................................................................................................24

How to Upgrade Firmware ......................................................................................27

Step 1 Set network configuration on you local PC..............................................27

Step 2 Setting up the Hardware connection.........................................................28

Step 3 Choose the correct interface......................................................................31

Step 4 Confirm the firmware’s location...............................................................33

Step 5 Input the password....................................................................................34

Troubleshooting:..........................................................................................................38

EAN600

Introduction

Thank you for purchasing the EverFocus Advance Network Camera. Before you start

using this camera, read this User's Guide carefully to ensure correct usage. Once you

have finished reading this User's Guide, keep it in a convenient place for future

reference. The design, specifications, software, and User's Guide contents are subject

to change without prior notice. EAN600 A is designed for indoor-use only.

Terms and Trademarks

The term "OS" is used in this manual to indicate operating systems

compatible with this product.

－Windows 2000: Microsoft® Windows® 2000 operating system

－Windows XP: Microsoft® Windows® XP operating system

The formal name of Windows® is Microsoft® Windows® Operating System.

Microsoft® and Windows® are trademarks or registered trademarks of

Microsoft® Corporation in the United States and other countries.

Other product names appearing in this User's Guide may be trademarks or

registered trademarks of their respective holders. JavaTM and all Java-related

logos and trademarks are trademarks or registered trademarks of Sun

Microsystems, Inc. in the United States and other countries.

Introduction

EAN600

Accessories

Confirm that all of the following accessories have been supplied with the

network

camera.

Accessories :

Network Camera (x1).

Accessory packet(x1).

Power cord (x1)

Basic User's Guide (x1)

Quick Start Guide (x1)

Assembly Diagram

EAN600

Important Safety Instructions

When using this camera, always follow basic safety precautions to reduce the risk

of fire, electric shock, or personal injury.

1. Read and understand all the instructions.

2. Keep the User’s Guide for future reference.

3. Heed all warnings.

4. Follow all the instructions.

5. Wipe off any dust on the camera lens with a lens-

EAN600

WARNING

TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Note:

These limits are designed to provide reasonable protection. This equipment

generates, uses and can radiated radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in

a particular installation If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures: -Reorient or relocate the receiving antenna.

-Increase these separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

The changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Notice:

The information in this manual was current when published. The manufacturer

reserves the right to revise and improve its products. All specifications are therefore

subject to change without notice.

EAN600

Safety Precautions

Refer all work related to the installation of this product to qualified service

personnel or system installers.

Do not block the ventilation opening or slots on the cover.

Do not drop metallic parts through slots This could permanently damage the

appliance. Turn the power off immediately and contact qualified service

personnel for service.

Do not attempt to disassemble the appliance To prevent electric shock, do not

remove screws or covers. There are no user-serviceable parts inside. Contact

qualified service personnel for maintenance. Handle the appliance with care. Do

not strike or shake, as this may damage the appliance.

Do not expose the appliance to water or moisture, nor try to operate it in wet areas.

Do take immediate action if the appliance becomes wet. Turn the power off and

refer servicing to qualified service personnel. Moisture may damage the appliance

and also cause electric shock.

Do not use strong or abrasive detergents when cleaning the appliance body. Use a

dry cloth to clean the appliance when it is dirty. When the dirt is hard to remove,

use a mild detergent and wipe gently.

EAN600

Do not overload outlets and extension cords as this may result in a risk of fire or

electric shock.

Do not operate the appliance beyond its specified temperature, humidity or power

source ratings. Do not use the appliance in an extreme environment where high

temperature or high humidity exists. Use the appliance at temperature within 0oC ~

+50oC and a humidity below 90%. The input power source for this appliance is

AC90~265V.

The lightning flash with an arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of un-insulated ” dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons

The exclamation point within an equilateral triangle is intended to alert the user to

presence of important operating and maintenance (servicing)instructions in the

literature accompanying the appliance.

Warning:

To prevent fire or shock hazard, do not expose units not specifically designed for

outdoor use to rain or moisture.

Attention:

Installation should be performed by qualified service personnel only in accordance

with the National Electrical Code or applicable local codes.

EAN600

Power Disconnect:

Units with or without ON-OFF switches have power supplied to the unit whenever

the power code is inserted into the power source; however, the unit is operational

only when the ON-OFF switch is in the ON position. The power cord is the main

power disconnect for all units.

External Power Supplies

Use only the recommended power supplies. Power supplies must comply with the

requirement of

the latest version of IEC 60065/CNS 13439. Substitutions may damage the unit or

cause a fire or shock hazard

110V,60Hz Power Cords

110V,60Hz power cords, input and output, must comply with the latest versions of

IEC 60065/CNS 13439

Warning:

Electrostatic-sensitive device. Use proper CMOS/MOSFET handing precautions to

avoid electrostatic discharge.

UNPACKING

Unpack carefully.

This is electronic equipment and should be handled carefully.

Check to ensure that the following items are included;

•1. EAN600

•2. User’s manual

•3. Quick Installation Guide

•4. Power Cord

If an item appears to have been damaged in shipment, replace it properly in its

carton and notify the shipper. If any items are missing, notify your Everfocus
