EverFocus EMV401 Manuel utilisateur

EMV401 / 801 / 1601 Hybrid Mobile DVR

4 / 8 / 16CH, H.264, Real Time at D1/WD1/1080P

Quick Installation Guide

Release Date: October, 2014

Notice: This content is subject to be changed without notice.

EMV401/801/1601

1. Introduction

The latest EverFocus hybrid digital video recorder generation is based on H.264 compression

technology, resulting in enhanced recording capacity and improved network image

transmission speed with high image quality.

The hybrid mobile DVR EMV401 / 801 / 1601 can support 4 / 8 / 16 channels in combination of

analog and IP cameras, (EMV1601 supports maximum 8 channels of IP cameras). EMV401 / 801

/ 1601 can deliver and record at real-time WD1 resolution of each analog camera and real-time

1080p resolution of each IP camera.

Its comprehensive features along with the embedded 3-axis g-sensor function enable the

almost universal application of this mobile DVR series. With EMV401 / 801 / 1601, you can

install either one 3.5”hard disk or one 2.5” hard disk as an option. It supports various interfaces

such as three USB ports / RS-485 / RS-232 / Panic Button / CAN bus / GPS, 3G, 4G and Wi-Fi

Antenna. The design of RCA video/audio outputs at front panel makes your installation easy.

The User Interface has been specially designed to fit mobile small-sized monitor.

EMV401 / 801 / 1601 are anti-shock and vibration due to the Molex connectors equipped. The

power supply supports voltage regulator, and delay on/off. In addition, EMV401 / 801 / 1601

can be equipped with an explosion-proof black box to keep the last minute recording clip for

testimony.

System Requirements

Before installing, please check that your computer meets the following system requirements.

Operating System

Windows XP (32-bit) / Win7 (32 and 64-bit)

CPU

Intel Core 2 Duo, 2.6GHz

RAM

2GB

VGA

AGP or PCI-Express, 800x600 (1280x1024 recommended), 32-bit

color

LAN Speed

10 / 100 / 1000 Mbps (RJ45)

Web Browser

Windows (IE 8, 9, 10, Chrome, Firefox), MAC (TBD)

Other Remote

Application

1. EverFocus’ CMS: Genie XMS xFleet (Server System) and EF xFleet

Lite (Windows AP)

2. EverFocus’ mobile app: MobileFocus for iOS and Android devices

MobileFocusHD for iPad

EMV401/801/1601

Packing List

•EMV401 / 801 / 1601 Hybrid Digital Video Recorder x 1

•HDD Tray (with 2 keys and 8 screws for 3.5” HDD, 6 screws for 2.5” HDD) x 1

•Z-Type Bracket x 2

•Long Screw (with 4 washers) x 4

•Short Screw (with 4 washers) x 4

•IR Remote Control (with two AAA batteries) x 1

•Power Harness Cable x 1

•Video Cable x 4 (EMV1601); x2 (EMV801); x1 (EMV401)

•Audio Cable x 4 (EMV1601); x2 (EMV801); x1 (EMV401)

•Alarm Cable x 1

•RS232/485 Cable x 1

•CD x 1 (Please see Note 3.)

•Quick Installation Guide x 1

Optional Accessories

•3G Receiver: For using 3G network function.

•4G Receiver: For using 4G LTE network function.

•GPS Receiver: For using GPS function.

•Wi-Fi Antenna: For using Wi-Fi function.

Note:

1. Equipment configurations and supplied accessories vary by country. Please consult your

local EverFocus office or agents for more information. Please also keep the shipping

carton for possible future use.

2. Contact the shipper if any items appear to have been damaged in the shipping process.

3. The CD contains the IP Utility software, User Manual and Quick Installation Guide.

4. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries

according to the instructions.

a. Use only two AAA dry cell batteries.

b. Do not dispose of the batteries in a fire as it may explode.

EMV401/801/1601

Front Panel

1 2 3 4 6 7 8 9

No.

Name

Description

USB2.0

Port

Two USB2.0 ports for connecting to the 3G USB dongle, USB storage

device or mouse.

2 Audio Out

RCA audio output for connecting to the speakers. The audio output only

works during playback.

3 Main

Monitor

RCA video output for connecting to a monitor for live view, playback and

displaying OSD.

Note this mobile DVR has two Main Monitor outputs (one on the front

panel and the other on the rear panel). All of the Main Monitor ports can

be connected simultaneously.

IR Receiver

Receives data from the infrared remote control.

SD Card

(TBD) Insert a SD card for data storage. It is currently reserved.

HDD Drive

Tray Installs a 3.5” or 2.5” HDD for recording.

HDD Key

Lock Locks and unlocks the HDD tray.

8 Ethernet

Port

Two RJ-45 ports for connecting to the network.

It’s recommended to use LAN 1 for connecting to the IP cameras via a

hub or switch, and use LAN 2 for WAN connection.

8 System

LEDs

•

GPS LED: Turns on when the mobile DVR is receiving the GPS data.

•Power LED: Turns on when the power is supplied.

•Copy LED: Turns on when the mobile DVR is archiving data to the USB

storage device.

•HDD R/W LED: Turns on when the HDD is reading or writing.

•System Fail LED: Turns on when these events occur: HDD Full / Fan

Fail / HD Temperature.

•

Heater LED: Turns on when the mobile DVR is overheating.

EMV401/801/1601

Rear Panel

710

911 12

123456

No. Name Description

1 Antenna 1 (3G/4G) Connects to the 3G or 4G Receiver for using 3G / 4G LTE function.

2 DC Power Input

Power harness cable for connecting to 12 VDC ~ 24 VDC power

source. For details, please refer to 2.4.1 Power Harness Cable of

the User’s Manual.

3 Antenna 2 (GPS) Connects to the GPS Receiver for using GPS function.

4 RS-232/485

Connects to RS-232 (CAN bus) or RS-485 device (such as analog PTZ

cameras), please refer to 2.4.5 RS-232 / RS-485 cable of the User’s

Manual.

5 Main Monitor

(VGA)

VGA video output for connecting to the main monitor for live view,

playback and displaying OSD.

6 Antenna 3 (Wi-Fi) Connects to the Wi-Fi antenna for using Wi-Fi function.

7 Main Monitor

(BNC)

BNC video output for connecting to the main monitor for live view,

playback and displaying OSD.

Note this mobile DVR has 3 Main Monitor outputs (one on the

front panel and the other 2 on the rear panel). All of the Main

Monitor ports can be connected simultaneously.

8 Call Monitor

(BNC)

BNC video output for connecting to the call monitor for displaying

the live view.

9 Alarm In / Out D-Sub connector for connecting to the supplied Alarm Cable. For

details, please refer to 2.4.4 Alarm Cable of the User’s Manual.

10 USB2.0 Port USB2.0 ports for connecting to the 3G USB dongle, USB storage

device or mouse.

11 Video Input M12 connector for connecting to the supplied Video Cable. For

details, please refer to 2.4.2 Video Cable of the User’s Manual.

12 Audio Input M12 connector for connecting to the supplied Audio Cable. For

details, please refer to 2.4.3 Audio Cable of the User’s Manual.

EMV401/801/1601

2. Getting Started

2.1 Installation

Before installation, choose a location in the vehicle where it can:

•Provide convenient access for installing or removing the hard disk

•Allow air to flow around the fan vents. Inadequate or improper air flow can impede proper

operation of the hybrid mobile DVR

Please avoid installing the hybrid mobile DVR to the following locations in the vehicle:

•That is subject to high vibration / sunlight levels

•That is subject to be drenched of the rain

•Where passengers can interfere with the hybrid mobile DVR

•Next to a heater duct

The following table lists the recommended location options in the vehicle:

Location Convenient

Operation

Easy to

Install

Low

Vibration

Good

Air Flow

Bottom of glove box- horizontal mount

Yes Yes Yes Yes

Bottom of passenger seat next to the driver

No Yes Yes Yes

Underneath bulkhead-horizontal mount

Yes Yes No Yes

Front of bulkhead-horizontal mount Yes Yes Yes Yes

Beside deriver seat-horizontal mount

Yes Yes Yes Yes

Note: Do not install the hybrid mobile DVR on the floor or on the transmission access hatch.

These locations have the highest levels of vibration and may be subject to water damage.

EMV401/801/1601

2.1.1 Mounting

The EMV401 / 801 /1601 can be mounted horizontally. Two mounting types are available:

Support-Mount and Suspend-Mount.

Support-Mount Suspend-Mount

To install the L-type brackets to the hybrid mobile DVR for mounting:

1. Attach the supplied two L-Type Brackets to the Fixing Bracket on the hybrid mobile

DVR. Use the supplied four short screws with washers to screw the L-Type Brackets to

the Fixing Bracket.

L-Type Bracket

Fixing Bracket

2. Screw the hybrid mobile DVR to the interface using the supplied four Long Screws with

washers.

EMV401/801/1601

2.2 Hard Disk Installation

The EMV401 / 801 / 1601 supply with a 3.5” HDD tray for inserting a Hard Disk for video

recordings. Please follow the steps below to install the Hard Disk.

Note:

1. If you want to use a 2.5” HDD, make sure to use the supplied 2.5” HDD tray screws to

secure the HDD to the HDD tray.

2. The EMV401 / 801 / 1601 does not support hot swap for the hard disk. Ensure to power

off the hybrid mobile DVR before removing the hard disk. Also ensure to remove the

hard disk only after the power was completely shut off. This would protect and extend

the operating life of the hard disk.

1. Make sure the hybrid mobile DVR is power-off.

2. Place the hard disk in the HDD tray, secure the HDD with the supplied HDD Screws (8 for

3.5” HDD and 6 for 2.5” HDD) on the bottom of the HDD tray.

3. Insert the HDD tray to the hybrid mobile DVR.

EMV401/801/1601

4. Push the Latch to fasten it to the HDD tray.

5. Lock the HDD tray using the supplied key.

Locked

Unlocked

6. To remove the HDD tray, slightly push the Lock Clip to loosen the Latch of the HDD tray.

Lock ClipLatch

7. Pull out the HDD tray.

Hard Disk Tray

EMV401/801/1601

3. Basic Connection

After installing the EMV401 / 801 / 1601 in the vehicle, you can start connecting the hybrid

mobile DVR to the external devices. The instructions below describe the basic connection to the

EMV401 / 801 / 1601. For details on cable connections, please refer to the following sections.

Front View Rear View

Mouse

Speaker

Main Monitor Notebook / PC

Power Supply

Analog Camera

Audio Input

2.5"or

3.5" HDD

WAN

CMS (Client PC)

1 2 3 4 7 8 9

3G USB

Dongle

(PoE) Hub / SwitchIP Cameras

Audio Cable

Video Cable

Power Harness Cable

1. To record videos, insert a 2.5” or 3.5” HDD to the HDD tray. Remember to lock the HDD Key

Lock after inserting the HDD or the recording will not start (see 2.2 Hard Disk Installation).

2. To control the system, connect a mouse to the hybrid mobile DVR or use the supplied IR

Remote Control.

3. To listen to audio of video source, connect a speaker to the Audio-out RCA socket. Note

that the speaker with a (built-in) amplifier and external power is required.

4. To view videos, connect a monitor to the RCA port using the RCA cable supplied by the

monitor manufacturer. You can also connect other video out ports, please refer to 2.5

Monitor Connection of the User’s Manual.

5. To manage the hybrid mobile DVR over network:

a. Use a standard RJ-45 cable to connect the hybrid mobile DVR to the network.

b. Connect a 3G USB dongle to the USB port on the hybrid mobile DVR. For details on 3G

wireless network settings, please refer to 6.6.3 Mobile of the User’s Manual.

6. You can optionally connect a (PoE) switch / hub to the LAN1 port of the hybrid mobile DVR

using a standard RJ-45 Ethernet cable for connecting the IP cameras.

7. Connect the supplied Power Harness Cable to the power supply in the vehicle for powering

the hybrid mobile DVR and the connected cameras. For details on vehicle connection,

please refer to 2.3 Vehicle Connection of the User’s Manual.

8. Connect the cameras to the hybrid mobile DVR using the supplied Video Cable.

9. Connect the audio input devices to the hybrid mobile DVR using the supplied Audio Cable

Autres manuels pour EMV401

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels EverFocus DVR

EverFocus

EverFocus VANGUARD II 8x4H Manuel utilisateur

EverFocus

EverFocus EMV400 Manuel utilisateur

EverFocus

EverFocus ECOR264 Manuel utilisateur

EverFocus

EverFocus EDR HD-4H4 Manuel utilisateur

EverFocus

EverFocus IRONGUARD II 16 POE Manuel utilisateur

EverFocus

EverFocus EDSR400H Manuel utilisateur

EverFocus

EverFocus ENVR8304D-8CH Manuel du propriétaire

EverFocus

EverFocus PowerPlex EDR-1640 Manuel utilisateur

EverFocus

EverFocus Paragon 264X4 32CH Manuel utilisateur

EverFocus

EverFocus VANGUARD 16x8H Plus Manuel utilisateur

EverFocus

EverFocus EDR410M Manuel utilisateur

EverFocus

EverFocus eNVP-JNN-IV-V0008 Manuel utilisateur

EverFocus

EverFocus EDVR SERIES Guide d'installation

EverFocus

EverFocus EPHD08 Manuel utilisateur

EverFocus

EverFocus Nevio ENVS1600 Manuel utilisateur

EverFocus

EverFocus ECOR 264-8/4 F2 Manuel utilisateur

EverFocus

EverFocus PARAGON Manuel utilisateur

EverFocus

EverFocus EMV400 Manuel utilisateur

EverFocus

EverFocus EMV400 FHD Manuel utilisateur

EverFocus

EverFocus ECOR264 Series Manuel utilisateur

EverFocus

EverFocus ECOR 264x1-16 Manuel utilisateur

EverFocus

EverFocus EDVR16D1/250 Manuel utilisateur

EverFocus

EverFocus VANGUARD 4x2H Manuel utilisateur

EverFocus

EverFocus 920 Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur
