MANUAL

Model X

Step-Thru Electric Bike

STEP-THRU EBIKE CITY ROBIN X

BATTERY 15

DISPLAY 20

WARRANTY 26

OUR MISSION: TO DESIGN EBIKES THAT ARE SO COMFORTABLE AND

INNOVATIVE THAT THEY BECOME YOUR PRIMARY COMMUTING

OPTION AND TO TREAT EVERY CUSTOMER LIKE THEY ARE THE FIRST

CUSTOMER WE’VE EVER HAD.

An American Company

BASED OUT OF HOUSTON, TEXAS.

3 | CITY ROBIN X

EUPHREE

2 | CITY ROBIN X

TABLE OF CONTENT 02

MANUAL

Model X

EBIKE ASSEMBLY 8

Disclaimer:

The specications, information and performance of Euphree electric bicycles (ebikes) featured in this

manual may change without notice. It is the sole responsibility of the buyer and/or the rider to deter-

mine safety of use and to check the ebike before each and every use. Any liability which may be in-

curred as a result of the use of the Euphree City Robin is limited to the cost of repairing or placing the

failed component at the discretion of Euphree, and does not extend to any loss or damage which may

be caused by misuse or failure of the product. Any and all damages to the ebike, components, prop-

erty or persons is the sole responsibility of the buyer and/or rider. By using this product, you are stat-

ing that you have read the disclaimer and this owner’s manual in entirety and agree to hold Euphree,

its owner/s and any Euphree employees or contractors free from all liabilities, that you agree you are

operating the product at your own risk, and that no warranties or guarantees are made by Euphree,

expressed or implied, on performance or operation. Because it is impossible to anticipate every situa-

tion or condition that can occur while assembling, operating, or riding an ebike, this manual makes no

representation about the safe use of bicycles under all conditions. There are risks associated with the

use of any bicycle which cannot be predicted or avoided and are the sole responsibility of the rider.

Keep this manual and any documents that were included with your ebike for future reference.

All content in this manual is subject to change without notice. Euphree makes every eort to ensure

accuracy and assumes no responsibility or liability if any errors or inaccuracies appear within.

General warnings:

Bicycling, including ebike operation and riding, involves risk of damage, injury and/or death. Risks are

increased when operating a bicycle in urban environments. By choosing to ride and operate an ebike,

the user assumes responsibility for any and all risks associated with bicycle riding. All users must

know, understand and practice safe and responsible ebike riding practices and procedures. To re-

duce risk of damage, injury and/or death, proper use and maintenance is essential. Incorrect assem-

bly, maintenance, or use of your ebike can cause component or performance failure, loss of control,

accidents, serious injury or death. All riders regardless of experience level must read and understand

the Owner’s Manual and any documentation provided for accessories and components before riding.

Your insurance may not provide coverage for accidents involving the use of this bicycle. Contact your

insurance company or agent to determine if coverage is provided.

Intended use:

Euphree City Robin is an electric bicycle designed for commuting or simple riding in fair weather and

only at safe and appropriate speeds in urban and suburban environments. The City Robin is intended

for use on paved roads or surfaces only. Inappropriate use will invalidate your warranty. Using your

City Robin in the wrong manner may impact the lifetime of the product and can be dangerous, can

result in damage to the ebike, to property, injury, and death. The City Robin is not a mountain ebike

or racing ebike. Riders must not perform jumping, stunts, wheelies and/or ebike tricks while riding

this electric ebike. Putting undue or unnecessary stress on ebike parts, components, frame, brakes,

handlebars, stem, or forks can cause components and/or ebike to fail, causing damage to the ebike,

damage to property, loss of control, accidents, serious injury and/or death.

The Euphree City Robin is intended for use by physically competent riders. Consult your doctor be-

fore riding or operating an electric bicycle. Do not ride or operate this ebike if you are an inexperi-

enced ebike rider. The City Robin is designed for use only by persons of age 18 and older. Riders must

have the mental capacity, reaction time and physical condition to manage sudden situations associat-

ed with bicycle riding and operating a bicycle or vehicle in urban environments. If you have an impair-

ment or disability such as a visual impairment, hearing impairment, cognitive impairment, language

impairment or physical impairment, or a seizure disorder, or any other physical or mental condition

that could impact your ability to safely operate a bicycle or a vehicle, consult your physician before

riding or operating any ebike.

Using this manual:

This manual contains important details of the product, components and equipment, and information

and tips on operation and maintenance. This manual contains many warnings and cautions concern-

ing safe operation and consequences if proper setup, operation and maintenance are not performed.

Carefully review all information in this manual and immediately contact Euphree if you have any

questions.

The note “WARNING” within this manual should be given special care. Users should also pay careful

attention to information in this manual that begins with NOTICE.

Keep this manual along with any other documents that were included with your ebike for future

reference. All content in this manual is subject to change or withdrawal without notice. Assembly and

rst adjustment of your ebike from Euphree requires special tools and skills. It is recommended that

assembly and rst adjustment be completed by a certied, reputable ebike mechanic unless you are

mechanically inclined.

General information:

Euphree recommends having a certied, reputable ebike mechanic to assemble your ebike. If you are

not sure you have the experience, skills, and tools to correctly perform all assembly steps, consult

a certied reputable bicycle mechanic. Even if you have the experience, skill, and tools to complete

assembly, Euphree recommends that a certied, reputable ebike mechanic completes and/or checks

your assembly before your rst ride. We recommend that a certied, reputable ebike mechanic com-

plete future adjustments, maintenance or tuning. The cables, spokes and chain will stretch and bolted

connections can loosen after an initial 50-100 miles (80-160 km) (depending on riding conditions such

as total weight, terrain, riding style). Regular inspections by a certied, reputable ebike mechanic are

important for ensuring the safety of your ebike.

Be sure to follow all laws for using an electric ebike in your region. These laws may limit where you

can ride your ebike and may specify mandatory equipment and use of hand signaling when riding.

Changing components or attaching accessories: The use of non-original components, spare parts, or

accessories can jeopardize your safety, the safety of your ebike and can void your warranty.

Replacing original components or installation for third-party accessories or accessories from Euphree

not explicitly recommended for your ebike model is at your own risk. Using aftermarket components

or accessories may void your warranty. Using aftermarket components or accessories may create un-

safe riding conditions, damage to property or to your ebike, or result in serious injury and/or death.

Safety check before each ride: Inspect your ebike prior to every use. Failure to thoroughly inspect

could result in serious injury or even death. If you are unsure of how to conduct a complete check of

the condition of your ebike before every ride, consult a certied, reputable ebike mechanic.

Electrical system:

In addition to a complete safety check, it is critical that you familiarize yourself with all aspects of your

ebike’s electrical system and check for proper operation before every ride. The front and rear brake

levers contain safety power cuto switches. When the brake levers are applied, the hub’s motor assis-

tance is disabled. Both levers should be checked for correct operation before every ride. The throttle

should provide smooth acceleration when gradually applied. If the throttle, brake lever cuto switch-

es, pedal assistance or lighting are functioning abnormally or not working, immediately discontinue

use of your ebike and contact Euphree for assistance. Before every ride, ensure the battery is ade-

quately charged and operating properly. Ensure that the battery charger is unplugged from the outlet

and battery, and make sure to store the charger in a safe location before riding. The battery MUST be

locked onto the frame battery mount correctly before use. Do not operate the electrical system if the

battery is removed.

Accessories and hardware:

Before every ride, ensure all hardware is secured and approved accessories are properly attached

per manufacturer’s instructions. If you do discover something you are unsure about, have it checked

by a certied, reputable ebike mechanic.

Tires and wheels:

Your wheels should always spin straight and must be repaired or replaced if they wobble when spin-

ning. If you notice a side-to-side wobble or up-and-down wobble, or if your wheels become untrue or

spokes loosen (which can happen with normal use), we recommend a certied, reputable ebike me-

chanic to perform all wheel tuning operations. Do not attempt to true wheels or tighten spokes unless

you have adequate knowledge, tools and experience. Even if you have adequate knowledge, tools

and experience, we recommend that a certied, reputable ebike mechanic check your work. Before

every ride, always ensure the tires and inner tubes have the correct amount of air pressure and are in

good working condition without any visual damage.

Always replace tires and inner tubes with punctures, cuts or damage before you ride. Tires without

the correct amount of air pressure can increase tire and component wear and make unsafe riding

conditions.

Suspension, handlebar, grips and seat adjustments:

The suspension fork on your ebike will aect your ebike’s handling and should be properly adjusted

for your weight and terrain. Ensure the handlebar and handlebar stem are properly aligned, secured

to recommended torque values and tted to the user. Loose, worn or damaged handlebar grips

should be replaced before you ride. The seat and seatpost should be properly aligned and tted to

the user with seatpost quick release properly tightened, fully closed and safety secured before riding.

Any major or minor impact to your City Robin can compromise the integrity of the frame, electronics

and components. If your City Robin has experienced an impact, do not ride your ebike until it has

been inspected by a certied, reputable ebike mechanic.

Hydraulic braking systems must be “bedded in” upon rst use. When fully squeezing the brake levers,

ensure that neither the front nor the back brake lever touches the handlebar.

The City Robin has been designed with a maximum weight limit of 286 lbs (130 kg) for total payload

(rider, clothing, luggage, ebike accessories, cargo). Exceeding the weight limit will void all warranties

and may result in unsafe operating conditions, damage to ebike or property, injury and/or death.

To reduce the risk of damage to your ebike and injury to yourself and/or others, keep children away

from the ebike and under close supervision when the product is in use near children.

Safeguard against corrosion and rust.

Your ebike has electric components. Damage to the electrical system caused in any manner, including

water damage, can lead to electrical system malfunction, failure of battery, or electrical re and con-

sequent injury, property damage or death.

Minimize the chance of water damage by following all recommendations.

• Tore ebike in an upright position and under shelter. Do not leave the ebike in the rain. Do not

leave the ebike exposed to corrosive substances. Corrosive substances can include water, salt, or

de-icing substances. If your ebike is exposed to rain or other weather elements, dry your ebike

immediately afterward and apply anti-rust treatment to the chain

• Before cleaning your ebike, turn o the ebike and turn o the battery. Wipe the frame with a

clean, damp cloth. If needed, a mild mixture of non-corrosive detergent can be used with a damp

cloth to wipe the frame of your ebike. Dry by wiping with a clean, dry cloth. Do not use high-pres-

sure water on your ebike. Do frequently wipe down your ebike.

• Do frequently spray unpainted mechanical parts with anti-rust treatment.

• Use touch up paint or nail polish on scratched or chipped painted metal surfaces to minimize

rusting.

• Never submerge ebike or components in water or liquid. Immersion in any liquid can damage the

electrical system.

Damage from corrosion is not covered under warranty. Avoid exposing your ebike to corrosive sub-

stances. Avoid riding on the beach, in environments with high-salinity, fog, or on surfaces treated with

de-icing compounds such as salt. Riding in these conditions exposes your ebike to corrosive sub-

stances. Corrosion of electrical components can lead to irreversible damage that can cause electrical

system malfunction, failure of battery, or electrical re.

• Ebike

• Pedals (2)

• Charger

• Front wheel

• Front wheel skewer

• Front wheel fender

• Seat post

• Saddle

9 | CITY ROBIN X EUPHREE

City Robin

Model X

ebike manual

The City Robin X

includes the following

Open the ebike box

Components included in shipment, if there are any missing parts, please contact Euphree

HOW TO

ASSEMBLE YOUR CITY ROBIN X

NOTICE:

THE FOLLOWING STEPS ARE ONLY A GENERAL GUIDE TO ASSIST IN THE ASSEM-

BLY OF YOUR EBIKE. THIS MANUAL IS NOT A COMPLETE NOR COMPREHENSIVE

MANUAL OF ALL ASPECTS OF ASSEMBLY, MAINTENANCE AND REPAIR. CON-

SULT A CERTIFIED, REPUTABLE EBIKE MECHANIC TO ASSIST WITH ASSEMBLY,

Step 2:

Install the handlebar onto the stem

• Loosen the stem cap and clamp bolts

• Rotate the forks 180 degrees to face forward

• Unbolt the stem clamp and place the handlebars on the stem

• Tighten the handlebars once they are at the proper angle

Step 3:

Install the front wheel

• Insert the front wheel skewer through the ebike front wheel. Lightly tighten the skewer cap on

the front wheel. There should be plenty of space on both sides for the forks to slide into the

front wheel.

• Make sure the quick connection is on the same side as the brake disk. ● Lift the front forks and

position the front wheel into place.

• Tighten the skewer into a locked position.

WARNING: The Skewer must be locked very tight to ensure safe riding.

WARNING: Never touch the brake rotor, especially when the wheel and/or ebike is in

motion, or serious injury could occur. Do not touch the brake rotor while inspecting, open-

ing, or closing the quick release lever. Hand oils can cause squeaking and decrease brake

performance.

WARNING: An improperly secured front wheel and/or handlebar stem can cause loss of

control, accidents, serious injuury or death.

Step 4:

Perform a handlebar twist to ensure the handlebar stem is secure.

1. Brace the front wheel. Stand at the front of the ebike, facing the handlebar, and brace the front

wheel between your feet and lower legs.

2. Attempt to twist the handlebar. Hold both handlebar grips and push forward with one hand

while pulling back with the other. Push and pull at the same time with about 20 lb of force with

each hand.

3. Check that the handlebar and wheel stay properly aligned. The handlebar and handlebar stem

should be tightly secured perpendicular to the front wheel.

4. Repeat the twist test with opposite hands.

5. If needed, align the handlebar and stem and torque the stem clamp bolts evenly to the speci-

cation for the handlebar stem clamp bolts listed in the Recommended Torque values tablebe-

low. After making any adjustments, perform the twist test again. If the handlebar still moves,

contact Euphree or consult a local, certied ebike mechanic.

WARNING: If you are not sure you have the experience, skills, ability and tools to secure

and verify security and safety of the handlebar, front and rear wheels, and handlebar

stem, you must consult a certied, reputable ebike mechanic. An improperly secured

wheel or handlebar stem can cause loss of control, serious injury or death. Check that

wheels and handlebar stem are secured and safe to operate before each ride.

Step 5:

Install the pedals

• The pedals have a small A (right pedal - drive side) or B (left pedal - non drive side) on the front.

• Place each pedal on the corresponding crank.

• Pedals are left handed threads.

Warning: Pedals should easily screw into cranks. If they don’t then you have the wrong

pedal. Do not strip the crank threads.

Step 6:

Install the front fender and headlight

• Unscrew the bolt on the front fork

• Screw in the front headlight and fender with the same bolt onto the front fork

• Screw in the side fender arms on the bolt connection on the front forks

Step 7:

Inate the tires

• Inate tires to the appropriate PSI marked on the side of the tire

Step 8:

Set the desired seat height

• Place a small amount of grease on the seat post and place into the seat tube

• Do not place the seat post above the required minimum height marked on the seat post.

Step 9:

Make sure that all hardware is tightened properly following recommended torque

values.

Hardware Location Hardware Torque required(Nm)

Handlebar area Handlebar stem clamp bolts 10

Handlebar area Stem faceplate bolts 6

Handlebar area Brake lever clamp bolt 6

Handlebar area Shifter clamp screw 6

Handlebar area Angle adjustment bolt 18

Brakes Caliper adapter to frame 6-8

Brakes Caliper to adapter 6-8

Brakes Brake cable to caliper clamp 6-8

Handlebar area Handlebar stem clamp bolts 10

Handlebar area Stem faceplate bolts 6

Handlebar area Brake lever clamp bolt 6

Brakes Disc brake rotor to hub 7

Seatpost area Seat angle adjustment bolt 20

Rear dropout area Rear acle nuts 40

Rear dropout area Rear torque arm bolts 5

Rear dropout area Derailleur hanger mounting bolt 6

Rear dropout area Derailleur mounting bolt 10

Rear dropout area Derailleur cable pinch bolt 6-8

Rear dropout area Kickstand mounting bolts 8

Bottom bracket & crank area Bottom bracket and lockring 60

Bottom bracket & crank area Crank arm bolt into bottom

bracket spindle

Bottom bracket & crank area Pedal into crank arm 35

Bottom bracket & crank area Chainring bolts 10

Bottom bracket & crank area Controller mounting bolts 6

Fenders All fender mounting bolts and

hardware

WARNING: Ensure that all hardware is properly tightened, all components are secured, and per-

form all safety checks before your rst ride. Failure to properly assemble your bike can cause

damage to property, serious injury and/or death. Check that all components including handlebar

stem, seatpost or seat saddle DO NOT extend beyond any minimum insertion marking etched in

components.

WARNING: Both wheels must be properly secured before operating your bike. It is critical to

check the tightness of the rear wheel axle nuts, as mechanisms and components may become

loose during shipment or over time. Upon arrival and on a regular basis, you should inspect the

torque and security of all wheel mounting hardware.

WARNING: After assembly, before your rst ride, before all rides and after any time your ebike is

left unsupervised, always check to ensure that all latches, levers and quick releases are secured

and undamaged. Handlebar stem and/or seat post may become loose and can result in loss of

control, damage to property, serious injury and/or death.

Adjusting the seat height:

For most users, the seat height should be set by placing the ball of their foot on the pedal when

the crank is at its lowest point. In this orientation, the leg should be almost fully extended, with

a slight bend at the knee. Correct seat height should not allow leg strain from overextension and

hips should not rock from side to side when pedaling.

To adjust seat height:

1. Open the quick release lever by swinging the lever open and outward fully (pictured below).

2. Move the seat up and down by sliding the seatpost in or out of the seat tube to set to desired

seat height.

3. After tightening the adjustment nut (located opposite of the quick release lever), close the quick

release lever fully so that the seat cannot move up, down or to the left or right.

WARNING: A loose seat clamp or seatpost adjustment bolt can cause damage to the ebike, loss of

control, serious injury and/or death. Regularly check to make sure that the seat clamp is tightened.

Prior to rst use, properly tighten the seat clamp via the seat adjustment bolt.

WARNING: DO NOT raise the seatpost beyond the minimum insertion marking etched into the seat-

post tube If the seatpost is raised beyond the minimum insertion point, the seatpost or frame may

break, which could cause a rider to lose control and fall, resulting in damage to the ebike, to property,

or serious injury and/or death. Ensure the minimum insertion markings on the seatpost are inside the

seat tube of the frame.

Adjusting the seat position and angle is critical for rider comfort and posture. please use side adjust-

ments on the seat post to achieve the optimum angle. the seat should be horizontal or slightly down-

ward.

Adjusting the suspension fork: the suspension fork can move up and down up to cushion bumps in

the riding surface. if desired, the suspension fork can be locked out as a rigid fork which will generally

yield higher pedaling eciency.

• The right suspension fork has a actuator dial on it for adjusting the suspension rigidity

• A rigid suspension fork is not as comfortable as a compressible fork

Rider comfort:

• Depending on the rider’s preference, ability and experience with ebike riding, lowering the seat so

the rider can put one or both feet on the ground without dismounting from the seat may oer a

safer and more comfortable riding experience.

• For maximum comfort, the rider should not overextend arms’ reach when riding. ensure the han-

dlebar and brake lever angles allow for a comfortable arm position and relatively straight line from

forearms, wrists and hands. ensure handlebar angle allows the handlebar to remain clear of the

rider’s body while turning.

• A ebike tting professional should be consulted to ensure a proper t. if you have questions re-

garding proper t, consult a certied, reputable ebike mechanic.

Battery:

WARNING: Do not use a damaged battery or charger. Use of a damaged battery or charger can cre-

ate additional damage to your ebike and is a re hazard.

Do not use your battery and charger and immediately contact Euphree if you experience any

of the following:

1. Your charger’s power cord or output cable or any electrical cables on your ebike have any signs of

damage, including by not limited to fraying, broken insulation, or any other signs of damage.

2. Your battery or charger is damaged, non-functional or performing abnormally

3. Your battery or charger experienced a signicant impact (i.e. from a fall, from a crash, from a drop,

etc.) with or without signs of damage

4. Your charger will get warm with normal use. If your charger becomes too hot to touch, is emitting a

smell, or shows signs of overheating.

Store any damaged battery or charger in a safe location and recycle/dispose of it according to

local rules. Contact Euphree with questions or to purchase compatible replacements.

Connect only to a circuit provided with 10 amperes maximum branch circuit overcurrent pro-

tection that is in accordance with the National Electrical Code, ANSI/NFPA 70.

Battery charging procedure:

WARNING: Only charge the battery with the originally supplied charger supplied by Euphree, or with

a charger purchased directly from Euphree that is designed for your ebike model. Never use an after-

market charger. Use of an aftermarket charger can result in damage, serious injury and/or death. An

inappropriate charger may cause damage, serious injury or death through re or electric shock.

WARNING: Do not use your battery or charger if the battery is damaged, non-functional, performing

abnormally. Do not use your battery or charger if involved in a fall or crash, with or without signs of

damage.

Before initiating charge, ensure the charger is on a hard, at, re-resistant surface in an open

space. Never cover or obstruct the charger. Use the charger only with the indicator lights fac-

ing upwards. Never use the charger inverted. Use of an inverted charger can inhibit charging

and decrease the lifespan of your charger.

Follow these steps for charging your ebike from Euphree:

1. Make sure that the ebike is turned o

2. Remove the rubber cover on the charging port on the side of the downtube.

3. Plug the charger into the battery’s charging port. Place the charger in a at, secure place with blink-

ing light side up. Connect to the DC output plug from the charger to the charging port on the side of

the battery

4. Plug the charger into a power outlet. Connect the charger input plug (110/220-volt plug) to a power

outlet. Charging should initiate. To indicate charging, the LED charge status lights on the charger will

turn red.

5. Unplug the charger from the outlet, then the charging port. When fully charged, unplug the charger

from the wall outlet rst and then remove the charger output plug from the battery charging port.

The charging indicator on the ebike charger will turn from red to green.

Battery Charging Best Practices:

• Check the charger, charger cables, all electrical cables, battery, and battery holder for damage

before initiating each charge.

• Only charge in a safe area that is cool, dry, and indoors. Only charge in a safe area that is away

from direct sun, dirt, debris and is away in a clear area to prevent tripping on cords and to prevent

damage occurring to ebike, battery or charging equipment while charging.

• Always charge your battery in temperatures between 50 °F – 77 °F (10 °C – 25 °C). ● The battery

should be recharged after each use so that you are fully prepared for your next ride. This battery

has no memory eect, therefore charging the battery after short rides will not cause damage to

your battery.

• Remove the charger from the battery within one hour of the green indicator light turning on (indi-

cated completed charge)

• Unnecessary wear of the charging components could occur if the charger is left attached to the

battery and connected to a power source.

• Never charge a battery for more than 12 hours at a time.

Do not leave a charging battery unattended.

WARNING: Avoid damage to battery connector terminals. Battery connector terminals are exposed

when the battery is removed from the ebike frame. In case of damage to the battery mounts or to the

terminals, do not use your battery and do not use your charger, and contact Euphree immediately.

Removing the battery:

1. Make sure that the ebike and battery are turned o

2. Insert the key into the keyhole and turn to unlock

3. Once unlocked, turn the bottom lever and push down to remove the battery

Installing the battery onto the ebike:

1. Turn the key in the keyhole to the unlocked position

2. Insert the battery into position and squeeze to lock into place

3. Turn key to lock in the keyhole

Long term battery storage:

Be sure to follow all instructions for storing ebike and battery. Failure to follow ebike and battery stor-

age procedures can result in a non-functional battery, and replacement is not covered under

warranty.

If storing your Euphree ebike for longer than two weeks at a time, follow instructions to help maintain

health and longevity of your battery.

• Charge (or discharge) battery to approximately 75% charged

• Power o the battery either locked to the frame or unlocked and removed from the frame. ● Store

batteries in a dry, climate controlled, indoor environment between 50 °F – 77 °F (10 °C – 25 °C).

• Check the battery every month. If necessary, use the charger from Euphree to charge the battery

to 75% charged.

WARNING: Opening the battery housing will void the warranty. Do not open the battery housing.

Opening of the battery housing can result in damage to the battery, to property and can cause seri-

ous injury and/or death.

Charing time:

When properly connecting the input and output plugs of the charger, two red charging indicator

lights should illuminate if the battery is not fully charged. When charging is complete, the red light will

turn green. The time for full charge will depend on factors including distance traveled, payload, riding

characteristics, terrain and battery age.

If your battery does not seem to be charging normally, is taking longer than expected to charge, or

you’ve noticed a substantial reduction in range between charges, discontinue use and contact Eu-

phree immediately. Note that the battery may take longer to charge when fully depleted, when very

new, and after 3-5 years of use.

Charger safety:

Failure to follow charging procedures can result in damage to your ebike, damage to the battery, the

charger or personal property, and can cause serious injury and/or death.

• Do not drop or otherwise cause an impact to your battery. Any impact can damage the battery

and cause it to overheat, rupture, leak or ignite.

• Do not expose the battery to re or high temperatures over 100F.

• Avoid charger contact with liquids, dirt, debris or metal objects.

• Do not cover the charger while in use.

• The charger should only be used only indoors in a cool, dry, ventilated area on a at, stable, hard

surface

• The charger works on 110/220 V 50/60 Hz AC power outlets. The charger automatically detects

and accounts for incoming voltage. Do not open the charger or modify the voltage input.

• Do not yank or pull on the cables of the charger. Only unplug by pulling on the plastic plugs direct-

ly and not by pulling on the cables.

• The charger will get hot when operating as designed. If the charger gets too hot to touch, emits a

strange smell or has any other indication of overheating, immediately discontinue use of the char-

ger and contact Euphree for support.

WARNING: Take special care in charging your ebike by reading, understanding and following the pro-

cedures and safety information detailed in this manual. Failure to follow proper charging procedures

can result in damage to your ebike, the charger, property, and/or cause serious injury or death.

Balancing the battery:

When you rst receive your ebike and for the rst 3 times you charge the battery, follow the proce-

dure below to ensure the battery cells are fully balanced and operating as eciently as possible.

The battery will arrive with approximately 50-75% charge. It can be ridden without initial charging or

can be charged before riding.

• After the rst, second and third ride, charge the battery and leave it on the charge for as close to

12 hours as possible (but no longer than 12 hours). This may require leaving the charger attached

to the battery and outlet even after the charger illuminates a green light indicating a full battery.

• Disconnect the charger from the battery and outlet once each balance charge is complete (long

charge as close to but not longer than 12 hours). Store the ebike for the next ride.

• Ride the ebike to discharge part or all of the battery and prepare for the next balance charge. Re-

peat steps 1-3 for at least three dierent times. After this you may charge the battery normally.

Normal Charging Procedure

1. Connect the charger to the battery and outlet

2. Charge your city robin until the charger indicator light turns green (2-3 hours).

3. Never leave the battery charging for more than 12 hour

4. Never leave the battery / charger unattended while charging

BRAKES:

WARNING: Do not touch the brake rotor. The brake rotor has sharp edges and can get hot while

riding. Touching the brake rotor can cause serious injury, slicing damage, or burns. Do not touch the

brake rotor with bare skin, as natural oils can transfer to the rotor, decreasing braking performance.

Touch the brake rotor only for necessary maintenance, only while wearing gloves or protective equip-

ment, and only when the brake rotor is cool and not moving.

WARNING: Never use the front brake by itself. First apply the rear brake, then second apply the front

brake. Use both brakes for all braking operations. Braking with only the front brake can cause loss of

control, injury and/or death. Braking with only the front brake excessively stresses components and

can cause damage to the ebike and parts.

WARNING: Ensure brakes are working correctly and that all braking system components are free

from damage. Ensure that when you fully squeeze the brake levers that neither the front nor the rear

brake levers make any contact with the handlebar. Perform this check before every ride. If you nd a

problem, take your ebike to a certied, reputable mechanic to have the brakes repaired.

WARNING: Hydraulic brake uid can be an irritant when it contacts human tissue. If contact with skin

occurs, immediately wash o brake uid. If contact with eye(s) occurs, immediately ush eyes with

fresh water continuously for 15 minutes. Consult with medical personnel.

Operation section:

Do not attempt to operate your ebike until you have read and understood all sections of this manual.

The safety warnings throughout the manual must be followed to prevent accidents, damage to ebike

and/or property, injury and/or death. Damage caused by failing to read, understand and follow all in-

structions is not covered under warranty. Contact Euphree if you have questions regarding assembly

or operation.

Users must fully understand the ebike’s power systems before operating. Users must take extra care

when rst applying the throttle mechanism. Throttle allows for full power to be applied from a stop.

Pedal assistance should also be fully researched and understood before rst use. Failure to take care

and familiarize yourself, and failure to practice the operation of the power systems on your ebike can

lead to damage, serious injury and/or death.

Table des matières

Autres manuels Euphree Scooter

Euphree

Euphree CITY ROBIN 2022 Manuel utilisateur

Euphree

Euphree CITY ROBIN X+ Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
