Eton ZoneGuard+ Manuel utilisateur

Owner’s manual

The Flashing, Dashing Wireless Weather Alert,

Alarm Clock Radio System

ZONEGUARD OWNER’S MANUAL

NEED HELP? CONTACT US.

Etón Corporation, 1015 Corporation Way, Palo Alto, CA

94303, USA. 1-800-872-2228 (U.S.); 1-800-637-1648

(Canada); 650-903-3866 (worldwide); M-F, 8:00-4:30,

Pacic Standard Time; www.etoncorp.com.

WARNING

Do not expose this appliance to rain or moisture.•

Do not submerge or expose for extended period to water.•

Protect from high humidity and rain.•

Only operate within specied temperature range •

(0 °C to 40 °C).

Unplug immediately if liquid has been spilled or any•

object has fallen into the apparatus.

Clean only with a dry cloth. Do not use detergents or•

chemical solvents as this might damage the nish.

Unplug and disconnect external antennas during•

lightning storms.

Do not remove cover [or back].•

Refer servicing to qualied service personnel.•

ENVIRONMENT

Disposal

According to the European Directive 2002/96/EC all

electrical and electronic products must be collected

separately by a local collection system.

Please act according to your local rules and do not dispose

of your old products with your normal household waste.

Please dispose of all types of batteries per your

Government, State or Local rules and/or regulations.

If you are unsure, please call the appropriate local authority

to nd out how to dispose of them safely and help protect

the environment.

ZONEGUARD OWNER’S MANUAL

ZONEGUARD

Thank you for purchasing the Etón ZoneGuard . We want

you to thoroughly enjoy the use of this product. To take

advantage of its many excellent and unique features,

we urge you to carefully read the Owner’s Manual.

1WEATHER BAND ALERT

Button

2WEATHER BAND Button

3AM/FM

4TEST Button

5Display

6Select Button

7Power Button

8Alert Off

9Speaker

611

FRONT

ZONEGUARD OWNER’S MANUAL

LEFT SIDE RIGHT SIDE

10 Warning Light

11 Menu Button

12 Alarm On/Off

13 SNOOZE Button

14 Memory Location 1-6

15 Antenna

16 Battery Compartment

17 V+

18 V-

19 Backstand

20 DC in

ZONEGUARD OWNER’S MANUAL

POWER SUPPLY

Battery Power

(3 AA Batteries)

Install 3 AA batteries with

correct polarity shown in

the compartment(on the

back of the radio).

DC-IN 5V AC Adapter

Plug in the AC adapter

(5V, 150mA) to the DC IN

socket.

TURNING THE UNIT ON/OFF

The unit is powered with 3 AA batteries and AC adapter.

Press the < > button to turn ON/OFF the unit.

VOLUME CONTROL

Press the <V+> or <V-> button (located on the right side of

the unit) to adjust volume.

AA Battery Compartment

ZONEGUARD OWNER’S MANUAL

LISTEN TO AM/FM

Select Band

Press the <AM/FM> button to listen to AM/FM band,

repeatedly press it to shift between AM and FM.

Tuning in Stations

1. Manual Tuning: Press the < > or < > button

repeatedly to tune into your desired

station.

2. Auto Scan Tuning: Press and hold the < > or < >

button until frequency starts

scanning to auto tune into the next

available station. If the signal is

not strong enough, you can tune

manually to get a better reception.

Storing Stations

When listening to AM/FM band, tune into your desired

station, press the <MENU> button, the LCD will display

<STORE-->. then press either of the 6 <Memory Location>

button, (located on the front of the unit, beyond the

speakers. You can directly press the corresponding memory

location to listen to the station next time.

When listen to FM, adjust the length of the antenna and go

near a window to get better reception,

When listen to AM, rotate the unit to have better reception

of AM.

ZONEGUARD OWNER’S MANUAL

SETTING THE CLOCK

1. In the unit off mode, press <MENU> button shortly to

enter “SET UP-TIME” mode.

2. Press the < > or < > button. When the hour ashes,

press the < > or < > button to adjust the hour.

3. After adjusting the hour, press < > or < >.

When the minute ashes, press < > or < >

to adjust the minute.

4. Press the <MENU> button to conrm.

NOTE: The clock mode is 12 hours; <AM> displays in

the morning and <PM> displays in the afternoon.

ZONEGUARD OWNER’S MANUAL

SETTING THE ALARM

Setting The Alarm Time

1. In radio OFF mode, press the <MENU> button, then press

the < > or < > button to enter <SETUP ALARM>

mode.

2. In the <SETUP ALARM> mode, press the < > or < >

button. When the hour ashes, press the < > or < >

button the adjust the hour.

3. After adjusting the hour, press the < > or < > button,

when the minute ashes, press < > or < > to adjust

the minute.

4. Press the <MENU> button to conrm.

Activating and deactivating the alarm

Press the < > button to activate or deactivate

the alarm. If the alarm function is activated, the symbol <

> will show on the display. When the alarm time is reached,

the unit will beep. If the alarm function is deactivated, the

alarm symbol < > will disappear.

ZONEGUARD OWNER’S MANUAL

SNOOZE FUNCTION

When the alarm activates, press the <SNOOZE> button to

snooze for 5 minutes (the symbol < > will appear in the

display). After 5 minutes, the unit will start to beep again.

Press the < > button to turn off the Snooze function.

LISTEN TO WEATHER BAND

1. Turn on the radio, press <WB> button shortly to receive

the weather band. You can also press the <WB ALERT>

button (the rst button on the left side of the unit)

shortly to enter standby mode to receive weather band.

The symbol <ALERT.WB> appears in the display if the

unit is in standby mode.

2. Press the button < > or < > to select the weather

station(CH1-CH7 is available).

WB ALERT: Receiving alert in silent, no sound when not

receiving any messages.
