EtherWAN EM120 Manuel utilisateur

Media Converter

User’s Manual 1

Preface

This manual describes how to install and use the Fast Ethernet Media

Converter. The Converter introduced here provides one channel media

conversion between:

100Base-FX or WDM 100Base-FX ←→ 100Base-FX or WDM 100Base-FX

The Converter fully complies with IEEE802.3u 100Base-FX standards.

In this manual, you will find:

yProduct overview

yFeatures on the media converter

yIllustrative LED functions

yInstallation instructions

ySpecifications

Media Converter

2 User’s Manual

Table of Contents

PREFACE...................................................................................1

TABLE OF CONTENTS ..............................................................2

INTRODUCTION ........................................................................3

PRODUCT OVERVIEW ...................................................3

PRODUCT FEATURES ...................................................3

PACKING LIST ..............................................................4

ONE-CHANNEL MEDIA CONVERTER .....................................5

PORTS.........................................................................5

FRONT PANEL &LEDS.................................................5

INSTALLATION .........................................................................6

SELECTING A SITE FOR THE EQUIPMENT .......................6

CONNECTING TO POWER..............................................6

INSTALLING IN A CHASSIS .............................................7

SPECIFICATIONS ......................................................................8

ORDERING INFORMATION ......................................................9

Media Converter

User’s Manual 3

Introduction

The media converter provides one channel for media conversion between:

100Base-FX or WDM 100Base-FX ←→ 100Base-FX or WDM 100Base-FX

It can be used as a stand-alone device or with a standard 19” chassis as

shown below.

Product Overview

<NOTE> The chassis is to be ordered separately.

Product Features

yOne-channel media conversion between:

100Base-FX or WDM 100Base-FX ←→ 100Base-FX or WDM

100Base-FX

yFiber media allows:

Multi-mode fiber using SC, ST, VF-45, MT-RJ, or LC connector

up to 2km

Single-mode fiber using SC connector up to 100km

WDM single-fiber (bi-direction) transceiver: Single-mode WDM

fiber uses SC connector up to 40km

A type: WDM single-fiber (bi-direction) transceiver

transmits with 1310nm wavelength and receives with

1550nm wavelength

B type: WDM single-fiber (bi-direction) transceiver

transmits with 1550nm wavelength and receives with

13100nm wavelength

yFull wire-speed forwarding rate

Media Converter

4 User’s Manual

yFront panel status LEDs

yUsed as a stand-alone device or with a chassis

yHot-swappable when used with a chassis

Packing List

When you unpack this product package, you will find the items listed

below. Please inspect the contents, and report any apparent damage or

missing items immediately to our authorized reseller.

yThe Media Converter

yUser’s Manual

yAC to DC Power Adaptor

Media Converter

User’s Manual 5

One-Channel Media Converter

Ports

For the FX port, it provides options of multi-mode using ST, SC, VF-45,

MT-RJ, or LC connector; single-mode fiber using SC connector; or single

strand fiber WDM single-mode using single SC connector.

Front Panel & LEDs

100Base-FX or WDM 100Base-FX ←→ 100Base-FX or WDM 100Base-FX

LED Indicators

The LED indicators give you instant feedback on status of the converter:

100Base-FX or WDM 100Base-FX ←→ 100Base-FX or WDM 100Base-FX

LEDs State Indication

Steady Power onPWR

Off Power off

Steady

valid network connection established,

Transmitting and Receiving

SDA/ SDB

(100FX)

Off Neither valid network connection nor transmitting established

Media Converter

6 User’s Manual

Installation

This chapter gives step-by-step installation instructions for the

Converter.

Selecting a Site for the Equipment

As with any electric device, you should place the equipment where it will

not be subjected to extreme temperatures, humidity, or electromagnetic

interference. Specifically, the site you select should meet the following

requirements:

- The ambient temperature should be between 32 and 113 degrees

Fahrenheit (0 to 45 degrees Celsius).

- The relative humidity should be less than 95 percent, non-condensing.

- Surrounding electrical devices should not exceed the electromagnetic

field (RFC) standards for IEC 801-3, Level 2 (3V/M) field strength.

- Make sure that the equipment receives adequate ventilation. Do not

block the ventilation holes on each side of the equipment or the fan

exhaust port on the side or rear of the equipment.

- The power outlet should be within 1.8 meters of the equipment.

Connecting to Power

yThis Converter is a plug-and-play device.

yConnect the supplied AC to DC power adaptor to the receptacle on the

rear panel of the converter, and then attach the plug into a standard AC

outlet.

Media Converter

User’s Manual 7

Installing in a Chassis

The Converter can be fit into any of the expansion slots on a special

designed chassis.

yFirst, install the converter onto a carrier supplied with the chassis:

Step 1- Unscrew the carrier from the desired expansion slot on the chassis.

Step 2- Fit the converter onto the carrier.

yWhen the converter is completely seated onto the carrier, insert the carrier

to the guide rails of the expansion slot.

yCarefully slide in the carrier until it is fully and firmly fit the chassis. Fasten

the screws on the carrier.

<NOTE> Never insert any converter into the chassis directly without using the

supplied carriers. The carriers allow secure and consistent placement

of the converters into the chassis’ backplane without causing any

damage.

Media Converter

8 User’s Manual

Specifications

Applicable Standards IEEE 802.3u 100Base-FX

Fixed Ports 2 FX port or WDM FX port

Speed – 100Base-FX 100/200Mbps for half/full-duplex

Forwarding rate 148,810pps for 100Mbps

LED Indicators 2 FX port or WDM FX port:

Per Unit- (1 LED): PWR

FX Port- (2 LEDs): SDA; SDB

Dimensions 80.3mm (W) × 109.2mm (D) × 23.8mm (H)

(3.16” (W) x 4.30” (D) x 0.94” (H))

Weight 150g (0.33lb.)

Power External power adaptor

0.23A @ 12VDC

Power Consumption 2.76W Max.

Operating Temperature 0℃~ 45℃(32℉~ 113℉)

Storage Temperature -10℃~ 70℃(14℉~ 158℉)

Humidity 5 ~ 95%, non-condensing

Emissions FCC Part 15 Class A, CE Mark Class A

Media Converter

User’s Manual 9

Ordering Information

FX port

Connector Type Cabling Segment Distance

SC Multi-Mode Fiber Max. 2 km

ST Multi-Mode Fiber Max. 2 km

VF-45 Multi-Mode Fiber Max. 2 km

MT-RJ Multi-Mode Fiber Max. 2 km

LC Multi-Mode Fiber Max. 2 km

SC Single-Mode Fiber Max. 15 km

SC Single-Mode Fiber Max. 40 km

SC Single-Mode Fiber Max. 75 km

SC Single-Mode Fiber Max. 100 km

Single SC Single fiber strand Single-Mode Fiber Max. 20 km

Single SC Single fiber strand Single-Mode Fiber Max. 40 km
