ESP APKITG Manuel utilisateur

USER MANUAL

www.espuk.com

APKITG |COLOUR VIDEO DOOR ENTRY SYSTEM

APKITG Manual.indd 1 26/04/2017 09:43:25

System Cabling

All system cabling (excluding mains 240vAC supply) has been tested with Cat5E UTP PVC cable.

Part Number - A8NFORCE5EUTP

Find this product online:

elandcables.com | Cables & Accessories | LAN Cable | Cat 5E UTP PVC Cable

Contents

System Components ...............................................................3

Installation .......................................................................4

System Connections Example 1......................................................5

System Connections Example 2......................................................6

Lock Connections Example 1 ........................................................7

Lock Connections Example 2 ........................................................8

User Guide ........................................................................9

Monitor Overview.................................................................10

Setting Monitor as Master or Slave (Default Master)...................................11

Accessing Monitor Functions.......................................................12

Accessing Monitor Adjustments ....................................................13

Installer’s Guide ................................................................. 14

APKITG Manual.indd 2 26/04/2017 09:43:26

System Components

Door Station Monitor

EVBPSBB

Lock Power Supply

EV-EXIT

Push To Release

EV-EBG

Emergency Release

EV-ML-250/500XT

Electro-magnetic Lock

ENTERD

Electric Lock

Optional Accessories

System Power Supply

APKITG Manual.indd 3 26/04/2017 09:43:28

90。

1.2 m 1.5 m～

Site the door station a

recommended 1.5 meters from

the ground, or to suit application.

Avoid areas of high sunlight

and noise levels.

Surface mount the sunshield of the door station and

connect the system cabling. Mount the camera to the

sunshield by fixing with the supplied hex screw.

The camera needs to point in

the direction of where a visitor

will stand during operation.

Site the indoor monitor to suit application.

Monitor

1-Gang Mount Box

(if required, not supplied)

Surface mount the bracket of the monitor or if required onto a 1-gang mount box (not supplied).

Make the system connections to the back of the monitor and then slide the monitor onto the

bracket using the hooks to hold firmly in place.

Monitor Mounting

Bracket

Installation

Optional

door bell

connection

APKITG Manual.indd 4 26/04/2017 09:43:29

System Connections Example 1

The last monitor on the system line has

the rear ‘K1’ switched ON

APKITG Manual.indd 5 26/04/2017 09:43:30

System Connections Example 2

1. The last monitor on the system line

has the rear ‘K1’ switched ON.

All other monitors ‘K1’ switch to OFF

2. Please review page XXXX to set

monitor to MASTER or SLAVE.

3. If dierent types of Monitor /handset

are being used on the same system,

please refer to the supplied instructions

to adjust Master/ Slave settings .

11 to set

APKITG Manual.indd 6 26/04/2017 09:43:31

At the rear of the door station

ensure that the jumper links cover pins

1 and 2, on both J3 and J2 positions

J1 J2

Electro-magnetic lock Electronic lock

BUS

System Wiring

LOCK1

VCC

Image of

jumper link

Lock -release time

N.C for Electro-magnetic lock

N.O for Electronic lock

Lock Connections Example 1

APKITG Manual.indd 7 26/04/2017 09:43:32

The jumpers on the rear of the door station offer different

types of release modes for alternative applications

dependent on the jumper link settings. LOCK1 options;

N.O

N.C

N.O

Volt-free

12vDC300mA

MAX

Jumper 1 gives the option to set the release time;

sec. 3

sec.

The door station has a secondry switch. LOCK2 options;

Please refer to the operation guide for release instructions

J1J3 J2

N.O

N.C

N.O

Volt-free

12vDC300mA

MAX

J1J3 J2

Image of

jumper link

Image of

jumper link

Lock Connections Example 2

APKITG Manual.indd 8 26/04/2017 09:43:33

User Guide

A B C D

1 2

APKITG Manual.indd 9 26/04/2017 09:43:33

Monitor Overview

The following monitor instructions are designed to be a quick start guide alongside the informative general user

interface (GUI) . The instructions are not exhaustive and are designed to lead the user quickly to the most often

required aspects of the unit.

APKITG Manual.indd 10 26/04/2017 09:43:33
