LBI-38901E

Installation Manual

Orion™Mobile Radio

TABLE OF CONTENTS

INTRODUCTION............................................................................3

UNPACKING AND CHECKING EQUIPMENT.............................3

PLANNING THE INSTALLATION................................................6

EQUIPMENT REQUIRED..............................................................8

INSTALLATION IN VEHICLES POWERED BY LIQUEFIED

(LP) GAS.........................................................................................9

INSTALLATION.............................................................................9

RUNNING CABLES...............................................................9

Power Cable.................................................................... 12

Accessory Cable.............................................................. 13

Ignition Sense................................................................. 20

Control Cable (Remote Mount Only) .............................. 21

CONTROL UNIT MOUNTING (REMOTE APPLICATIONS

ONLY)........................................................................... 21

SPEAKER D2LS1F............................................................... 26

MICROPHONE HANGER AND/OR HOOKSWITCH

MOUNTING......................................................................... 26

RADIO MOUNTING AND FINAL HOOK-UP..................... 27

Front Mount ................................................................... 27

Remote Mount Installation.............................................. 29

Cassette Mounting (EURO Only).................................... 30

Cassette Assembly Mounting.......................................... 31

DUAL CONTROL UNITS............................................................. 34

PREINSTALLATION PROGRAMMING PROCEDURE

-- FRONT MOUNT........................................................ 34

PREINSTALLATION PROGRAMMING PROCEDURE

-- REMOTE MOUNT..................................................... 36

INSTALLATION PROGRAMMING FOR FRONT MOUNT

DUAL CONTROL UNITS.............................................. 38

INSTALLATION INSTRUCTIONS FOR REMOTE MOUNT

DUAL CONTROL UNITS.............................................. 39

DUAL RADIO UNITS..................................................................... 43

This manual is published by Ericsson Inc., without any warranty. Improvements and changes

to this manual necessitated by typographical errors, inaccuracies of current information, or

improvements to programs and/or equipment, may be made byEricsson Inc., at any time and

without notice. Such changes will be incorporated into new editions of this manual. No part of

this manual may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying and recording, for any purpose, without the express

written permission of Ericsson Inc.

INTRODUCTION

This manual contains installation instructions for the Orion Mobile

Radio Unit and associated accessories. These instructions cover the

mounting and cabling of the radio; interconnection and wiring diagrams

are provided for reference. Before installation the radio should be

programmed using an IBM compatible personal computer and the

following items:

Serial/Flash Programming Interface Module TQ3370

Programming Cable TQ3377

EDACS Programming Software TQ3374

Conventional Programming Software TQ3367

IMPORTANT NOTICE

ORION UHF MOBILES

The PC programmer automatically defaults the receiver oscillator shift

to position No. 2. When field programming the receive frequencies for

ORION UHF mobiles, the oscillator shift must be programmed to

position No. 1 or No. 3. Enter the CONVENTIONAL and/or

TRUNKED FREQUENCY SET screen of the PC programmer and set

the values in the “OS” column to “1” or “3”.

UNPACKING AND CHECKING EQUIPMENT

Carefully unpack the radio and identify each item in the shipping

container as listed below. If damage has occurred to the equipment

during shipment, file a claim with the carrier immediately. The

available options for the Orion Mobile Radio are covered in Table 1.

•Orion Mobile Radio Unit

•Microphone D2MC3W or D2MC3Z

•Speaker D2LS1F or D2LS1H

•Power Cable D2CE1V

•Fuse Kit D2PD1J

•Control Cable D2CE1Y

•Front Mount Bracket Kit D2MA3N

•Remote Mount Kit D2MA3R

with

•Control Unit Mount Kit D2MA3J

•Operator's Manual LBI-38888

•Installation Manual LBI-38901

Figure 1 - Orion Mobile Radio Components And Mounting

Hardware

Figure 2 - Rear View Of Radios

USA EURO

Figure 3 - Cables

Table 1 - Orion Mobile Radio Optional Accessories

Option Description

Part Number

D2AN1M 900 MHz, 1/4 Wave Whip Antenna

19B801182P3

D2AN1L 800 MHz 1/4 Wave Whip Antenna

19B209568P5

D2AN1R VHF/UHF, 1/4 Wave Whip Antenna

19B209568P6

D2CE1V Power Cable, 7.5 M

19B802622P1

D2CE1W Accessory Cable, Front Mount

19B802554P1

D2CE1X Accessory Cable, Rear Mount

19B802554P6

D2CE1Y Control Cable, Remote Mount, 5.5 M

19B802554P3

D2CE1Z Accessory Cable, Front Mount EURO

19B802554P11

D2CE5R Extended Option Accessory Cable Front Mount

19B802554P2

D2CE5S EXT Option Control Cable, Remote Mount, 5.5 M

19B802554P4

D2CE5T EXT Option Accessory Cable, Remote Mount

19B802554P7

D2CE5U EXT Option Accessory Cable, Front Mount, EURO

19B802554P12

D2CE5V Control Cable, Remote Mount, EURO, 5.5 M

19B802554P13

D2CE5W EXT Option Control Cable, Remote Mount, 5.5 M

19B802554P14

D2CE5Z Dual Control Cable, Remote Mount, 9.0 M

19B802554P9

D2CE7A Dual Radio Cable, Remote Mount, 2.0 M

19B802554P10

D2CE7B Dual Control Cable, Remote Mount, 9.0 M, EURO

D2CE7C Dual Radio Cable, Remote Mount, 2.0 M, EURO

D2LS1F Speaker, GE Label

19A149590P1

D2LS1H Speaker, ERICSSON Label

19A149590P11

D2MA3J Mounting Bracket Kit, Remote Control Unit

344A4584G2

D2MA3N Mounting Bracket Kit, Front Mount Radio

19B802672P1

D2MA3R Mounting Bracket Kit, Remote Mount Radio

19B802673P1

D2MA3W Mounting Bracket Kit, Remote Mount Radio, EURO

19B802672P1

D2MA3X Cassette Mounting Bracket Kit, Front Mount, EURO

19B852366P1

D2MC3W Microphone, GE Label

D2MC3Z Microphone, Ericsson Label

D2MK3E Keycap Kit, SCAN Control Unit

19C852359P101

D2MK3F Keycap Kit, SYSTEM Control Unit

19C852359P102

D2MN1A Microphone Hanger

7141414G2

D2PD1J Transmit Fuse Holder Kit, 20/30A (USA Only)

19A149701G2

PLANNING THE INSTALLATION

Figure 4 provides an example of a typical mobile radio installation.

Before starting, plan the radio installation carefully so that it will be:

•safe for the operator and passengers

•convenient for the operator to use

•neat

•protected from water damage

•easy to service

•out of the way of auto mechanics

•out of the way of passengers

Figure 4 - Typical Installation (Remote Mount Shown)

It is suggested that the radio be installed by one of the many authorized

General Electric Service Stations located throughout the United States.

These experienced service stations can provide a proper radio

installation and make any final adjustments that may be needed.

WARNING

•Vehicular Electronics-Electronic fuel injection systems, electronic

anti-skid braking systems, electronic cruise control systems, etc.,

are typical of the types of electronic devices which may be prone

to malfunction due to the lack of protection from radio frequency

energy present when a radio is transmitting. If the vehicle

contains such equipment, consult the dealer to determine if such

electronic equipment will perform normally when the radio is

transmitting.

•For passenger safety, mount the radio securely so that the unit

will not break loose in the event of a collision. This is especially

important in station wagons, vans and similar type installations

where a loose radio could be extremely dangerous to the vehicle

occupants.

EQUIPMENT REQUIRED

The equipment required for installing the Orion Mobile Radio is listed

below:

•Crimping Tool for fuse holder

•Electric drill for drilling mounting holes

•Drills and circle cutters as follows:

No. 31 (1/8-inch) drill

No. 27 (9/64-inch) drill

5/8-inch drill or circle cutter

3/4-inch circle cutter, hole saw or socket punch

•Phillips and flat-blade screwdrivers

•POZIDRIV driver

•No. 20 Torx driver

Torx is a registered trademark of CAMCAR Division TEXTRON, Inc.

POZIDRIV is a registered trademark of Phillips International Company.

CAUTION

•Be careful to avoid damaging some vital part (fuel tank,

transmission housing, etc.) of the vehicle when drilling mounting

holes. Always check to see how far the mounting screws will

extend below the mounting surface before installing.

•If pilot holes must be drilled, remove all metal shavings from

drilling holes before installing screws.

INSTALLATION IN VEHICLES POWERED

BY LIQUEFIED (LP) GAS

Radio installation in vehicles powered by liquefied petroleum gas

with the LP gas container in the trunk or other sealed-off space

within the interior of the vehicle must conform to the National Fire

Protection Association Standard NFPA 58 which requires that:

•Space containing radio equipment shall be isolated by a seal from

the space containing the LP gas container and its fittings.

•Outside filling connections shall be used for the LP gas container.

•The LP gas container space shall be vented to the outside of the

vehicle.

INSTALLATION

RUNNING CABLES

To assure the feasibility of the planned cable routings, it is suggested

that the cables be run before mounting the radio. The Orion mobile

radio may be installed as a Front Mount, Remote Mount or Cassette

Mount. The type of mount, the application and the options to be

installed should be considered when planning the cable runs. Figures 5-

12 provide Interconnection Diagrams for typical installations. Figures

5-12 should be referenced throughout this manual and throughout the

installation.

Be sure to leave some slack in each cable going to the radio so that the

radio may be pulled out for servicing with the power applied and

antenna attached. Coil any surplus cables and secure them out of the

way. Try to route the cables away from locations where they will be

exposed to heat (exhaust pipes, mufflers, tailpipes, etc.), battery acid,

sharp edges or mechanical damage or where they will be a nuisance to

automobile mechanics, the driver or passengers. Keep wiring away from

electronic computer modules, other electronic modules and ignition

circuits to help prevent interference to these components and radio

equipment.

In addition, try to utilize existing holes in the firewall, trunk wall and

the channels above or beneath doors. Channels through door and

window columns that are convenient for running cables may also be

used, unless rigid or flexible conduit is to be installed for cable runs.

Figure 5 - Front Mount Basic Accessory Interconnections (USA

Models Only)

Figure 6 - Front Mount Basic Accessory Interconnections (EURO

Models Only)

Figure 7 - Front Mount Extended Option Accessory

Interconnections (USA Models Only)

Autres manuels pour ORION

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ericsson Radio

Ericsson

Ericsson MGM 450 Manuel utilisateur

Ericsson

Ericsson DUAL FORMAT MDX LBI-38848D Manuel utilisateur

Ericsson

Ericsson MINI-LINK TN R3 ETSI Manuel de la liste des pièces

Ericsson

Ericsson mRRUS 12 Manuel utilisateur

Ericsson

Ericsson Orion 38901E Manuel utilisateur

Ericsson

Ericsson MOBITEX BRU3 Manuel utilisateur

Ericsson

Ericsson LBI-38836B Manuel utilisateur

Ericsson

Ericsson EDACS PRISM HP Manuel utilisateur

Ericsson

Ericsson 2203 Instructions d'utilisation et d'installation

Ericsson

Ericsson EDACS ORION Manuel utilisateur

Ericsson

Ericsson TRUNKED MDX Manuel utilisateur

Ericsson

Ericsson ORION Manuel utilisateur

Ericsson

Ericsson MDX LBI-39015C Manuel utilisateur

Ericsson

Ericsson KME-200 Manuel utilisateur

Ericsson

Ericsson MOBITEX BRU3 Instructions d'installation

Ericsson

Ericsson LBI-38701 Manuel utilisateur

Ericsson

Ericsson ORION Manuel utilisateur

Ericsson

Ericsson LBI-38848E Manuel utilisateur

Ericsson

Ericsson MDX LBI-39015 Manuel utilisateur

Ericsson

Ericsson M-RK I Instructions d'installation

Ericsson

Ericsson 4408 Instructions d'utilisation et d'installation

Ericsson

Ericsson LBI-39014B Manuel utilisateur

Ericsson

Ericsson MDX SERIES Manuel utilisateur

Ericsson

Ericsson LBI-39015B Manuel utilisateur

Manuels Radio populaires d'autres marques

EisSound

EisSound KBSound iSelect Manuel utilisateur

Midland

Midland 1001LWX Manuel utilisateur

Konig

Konig HAV-SR41 Manuel utilisateur

Roberts

Roberts exprssion Manuel utilisateur

VDigi

VDigi DD3.0 Manuel utilisateur

Radio Shack

Radio Shack 21-1863 Manuel utilisateur

Roberts

Roberts Stream 207 Manuel utilisateur

Sony

Sony Walkman SRF-M97 Manuel utilisateur

Stanley

Stanley FatMax FMC770 Manuel utilisateur

auna

auna DAB-Radio 10026947 Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR190 Manuel utilisateur

HYT

HYT TC-320 Manuel utilisateur

auna multimedia

auna multimedia Yellowstone 10026851 Manuel utilisateur

B-Tech

B-Tech GMRS-V2 Manuel utilisateur

Weierwei

Weierwei VEV-V8 Manuel utilisateur

SOUNDMASTER

SOUNDMASTER DAB750 Manuel utilisateur

Telefunken

Telefunken TF-1505 Manuel utilisateur

Makita

Makita LXRM03 Manuel utilisateur
