The Ericsson – W20 – is the ideal solution for providing

broadband using mobile networks. It offers a highly cost

efficient and flexible solution utilizing deployed WCDMA

networks. With the W20 Fixed Wireless Terminal residential

and small office / home office users can be offered

high-speed data services.

Thanks to utilizing radio technology, broadband can be

provisioned to users that fixed line technologies cannot

address. This state-of-the-art WCDMA/HSDPA terminal

with high quality and performance supports the latest

deployed communication standards. The W20 offers data

capabilities comparable to fixed broadband offerings.



With the high-speed data connectivity for Internet access

with “Always connected” capability and home networking

support, the W20 is the definitive terminal for Mobile

Broadband.

The benefit of the Fixed Wireless Terminal is that it

provides wired or wireless connectivity options to the

user. Additionally, the Fixed Wireless Terminal enables the

possibility of simultaneous HSDPA data access for multiple

users. Thanks to the W20’s integrated WLAN access point,

WLAN enabled PC’s can be located at a distance from the

W20 thus giving the user local mobility.

The simplicity of the W20 enables the installation to be

carried out in a matter of minutes by the end user. Last

but not least, the built in software auto update functionality

makes sure that the W20 will have the latest software

installed without users having to manually perform software

upgrades.

Fixed Wireless Terminal

for WCDMA/HSDPA Networks





















• Two frequency band models

– W20e 2100MHz

– W20a 850/1900 MHz

• HSDPA, Category 11 and 12, up to 1.8 mbps

(downlink)

• WCDMA, up to 384 kbps

• EDGE, multi-slot class 10 (4+1, 3+2) up to 237 kbps

(downlink)

• GPRS, multi-slot class 10 (4+1, 3+2) up to 86.2 kbps

(downlink)

• Two USB 2.0 ports (Print server and Mass storage)

• Wireless LAN Access Point IEEE 802.11 b/g

• Four ports Ethernet switch (RJ45)

• Protocols

– Routing, NAT, ALG, DHCP and DNS Server

• Security

– Internet security: Firewall, Packet filtering, etc…

– Wireless security: WEP, WPA/WPA2,

• SW auto update

• Remote Management capability



• Indoor/Outdoor Window mounted omni-directional

antenna

• Outdoor roof mounted directional antenna

• Mechanical anti-theft kit



• W20 unit

• AC/DC Power supply

• Ethernet cable

• Quick Installation Guide

• CD with User Guide

Ericsson Enterprise AB

SE-126 25 Stockholm

Sweden

www.ericsson.com/enterprise

287 01-FGC 101 0080 Uen

Subject to alterations without notice. Produced in Sweden on Eco-labeled paper XGS ComPrint

Technical specification for W20

 244x149x48mm

 470 g

: 100 – 240 VAC,

50 – 60 Hz

t 12 VDC

 10-28 VDC

 14 W

 AU/EU/US/UK

 0ºC to +50ºC

 5 – 95 %

 -45ºC to +85ºC

 10 – 100%

 Standard USIM, 3V











WLAN

Ehternet
