Installation Instructions Model: KTG-Series
3
QUANTITY By MODEL
ITEM DESCRIPTION 220 225 230 320 325 330 440 445
10 CENTRIS HEAD ASSEMBLY, Pole Mount 2
20 ARRAY ASSEMBLY, Dual, 27" 1 1 2
ARRAY ASSEMBLY, Dual, 34" 2
30 ARRAY ASSEMBLY, Triple, 42" 1 1
ARRAY ASSEMBLY, Triple, 54" 1
40 PIPE CAP, 1.75 OD 1 1 1 1 1 1 1 1
50 POLE, Freestand, 14" 1 1 1 1
60 POLE, Freestand, 28" 1 1 1 1
70* POLE, Freestand, 42"
80 SHEATH, Cable Management, 8" 1 1 2 1 1 2 2 2
90 N/A N/A N/A N/A N/A N/A N/A N/A
100 SCREW, Cable Management Grommet Mounting, 3/8-16 x 6" 1 1 1 1 1 1 1 1
110 GROMMET, Mounting 2 2 2 2 2 2 2 2
120 KEY, Hex, 5/32" 1 1 1 1 2 1 1 1
130 KEY, Hex, 3/16" 1 1 1 1 2 1 1 1
140 KEY, Hex, 7/32" 1
160** SCREW, Phillips Pan Head, M4 x 12mm 8 8 8 12 12 24 16 16
170** SCREW, Phillips Pan Head, M4 x 20mm 8 8 8 12 12 24 16 16
180** SCREW, Phillips Pan Head, M4 x 30mm 8 8 8 12 12 24 16 16
190** SPACER, Nylon, 3/8" (used with item 170) 8 8 8 12 12 24 16 16
200** SPACER, Nylon, 3/4" (used with item 180) 8 8 8 12 12 24 16 16
210 CLAMP, Front, Pole Mount 2
220 CLAMP, Rear, Pole Mount 2
230 SCREW, Button Head Cap, 1/4-20 x 1 1/4" 6 6
240 CLAMP, Back, Array mounting 1 1 1 1 2 2 2
250 WASHER, Flat, 1/4" 2 2 2 2 4 4 4
260 SCREW, Button Head Cap, 1/4-20 x 3/4" 2 2 2 2 4 4 4
* Indicates an available optional accessory not included with above models. For additional information pertaining to
available accessories contact a Chief Customer Service represenatative or visit us at www.chiefmfg.com.
** Quantity varies depending upon the number of displays being installed.
