Equinox Systems Fusion Orbit Manuel utilisateur

Order code: EQLED018

Fusion Orbit

User Manual

www.prolight.co.uk Fusion Orbit User Manual 2

Safety advice

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL

CAREFULLY BEFORE YOUR INITIAL START-UP!

• Before your initial start-up, please make sure that there is no damage caused during transportation.

• Should there be any damage, consult your dealer and do not use the equipment.

• To maintain the equipment in good working condition and to ensure safe operation, it is necessary

for the user to follow the safety instructions and warning notes written in this manual.

• Please note that damages caused by user modications to this equipment are not subject to warranty.

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance

of this manual or any unauthorised modication to the equipment.

OPERATING DETERMINATIONS

If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and

the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.

Do not endanger your own safety and the safety of others!

Incorrect installation or use can cause serious damage to people and/or property.

CAUTION!

KEEP THIS EQUIPMENT

AWAY FROM RAIN,

MOISTURE AND LIQUIDS

CAUTION!

TAKE CARE USING

THIS EQUIPMENT!

HIGH VOLTAGE-RISK

OF ELECTRIC SHOCK!!

• Never let the power cable come into contact with other

cables. Handle the power cable and all mains voltage

connections with particular caution!

• Never remove warning or informative labels from the unit.

• Do not open the equipment and do not modify the unit.

• Do not connect this equipment to a dimmer pack.

• Do not switch the equipment on and off in short intervals,

as this will reduce the system’s life.

• Only use the equipment indoors.

• Do not expose to ammable sources, liquids or gases.

• Always disconnect the power from the mains when

equipment is not in use or before cleaning! Only handle

the power-cable by the plug. Never pull out the plug by

pulling the power-cable.

• Make sure that the available mains supply voltage is

between 100~240V AC, 50/60Hz.

• Make sure that the power cable is never crimped or

damaged. Check the equipment and the power cable

periodically.

• If the equipment is dropped or damaged, disconnect the

mains power supply immediately and have a qualied

engineer inspect the equipment before operating again.

• If the equipment has been exposed to drastic

temperature uctuation (e.g. after transportation),

do not connect power or switch it on immediately.

The arising condensation might damage the equipment.

Leave the equipment switched off until it has reached

room temperature.

• If your product fails to function correctly, stop use

immediately. Pack the unit securely (preferably in the

original packing material), and return it to your Pro Light

dealer for service.

• Only use fuses of same type and rating.

• Repairs, servicing and power connection must only be

carried out by a qualied technician. THIS UNIT CONTAINS

NO USER SERVICEABLE PARTS.

• This lighting xture is for professional use only - it is

not designed for or suitable for household use. The

product must be installed by a qualied technician in

accordance with local territory regulations. The safety of

the installation is the responsibility of the installer. The

xture presents risks of severe injury or death due to re

hazards, electric shock and falls.

• Warning! Risk Group 2 LED product according to

EN 62471. Do not view the light output with optical

instruments or any device that may concentrate the beam.

• WARRANTY: One year from date of purchase.

www.prolight.co.uk Fusion Orbit User Manual 3

0m 1m 2m 3m 4m 5m

4° - Lux

FULL ON

89600

18500

32100

8240

33000

22403

4626

8030

2055

8248

9960

2060

3570

916

3670

4°

5600

1160

2010

515

2060

3580

741

1280

330

1320

Product overview & technical specications

Fusion Orbit is a compact, powerful moving head producing a tightly

focused 4° aerial beam effect from the 60W RGBW quad-colour LED.

It is surrounded by an RGB LED ring which changes colour and chases,

producing mesmerising effects. With multiple built-in on-board functions

this unit can either work in auto, sound active or DMX modes.

• 1 x 60W quad-colour

LED (RGBW)

• 12 x tri-colour 5050 SMD

LEDs (RGB)

• Beam angle: 4°

• 22,403 Lux @ 2m

• DMX channels: 2/7/16

or 37 selectable

• Auto, sound active and

master/slave modes

• Pan: 540°, Tilt: 210°

• 0-100% dimming and

variable strobe

• Supplied with hanging bracket

• 4 push button menu

with LED display

• IEC power input

• 3-Pin XLR input/output

• Fan cooled

Fusion Orbit

Specications

Power consumption 75W

Power supply 100~240V, 50/60Hz

Fuse F2A 250W

Dimensions 238 x 172 x 146mm

Weight 2.5kg

Order code EQLED018

172mm 146mm

238mm

www.prolight.co.uk Fusion Orbit User Manual 4

Technical specications

MENU DOWN UP ENTER MIC

RBIT

FUSION

DMX INPUT DMX OUTPUT

POWER INPUT:

100-240V~50/60Hz

FUSE: F2A 250V

www.prolight.co.uk

01 02 04 05 06 080703

01 - LED display

02 - Function buttons

03 - Microphone

04 - 3-Pin DMX input

05 - 3-Pin DMX output

06 - IEC power input

07 - Fuse F2A 250V

08 - Fan cooling vents

In the box: 1 x xture,

1 x power cable,

& 1 x user manual

www.prolight.co.uk Fusion Orbit User Manual 5

Operating instructionsOperating instructionsOperating instructions

A 0 0 1

A 5 1 2

A d d r

DMX address setting

2CH

7CH

16CH

37CH

C H A n

Channel modes

N A s t

S L 1

S L 2

SLNd

Master/slave mode

H I s P

L o S P

S P N d

Pan/tilt speed setting

S h 1

S h 5

SHNd

Show modes

o F F

o n

S o u n

Sound mode on/off

o F F

o n

PAn

Pan invert

o F F

o n

t I L

Tilt invert

o F F

o n

d I S P

Display invert

000

100

S E n S

Sound sensitivity

o F F

o n

d E F A

Reset factory settings

0 0 0

2 5 5

0 0 0

2 5 5

0 0 0

2 5 5

d E L t

0 0 0

2 5 5

0 0 0

2 5 5

0 0 0

2 5 5

r S t

Motor reset

A d t

Calibration setting

www.prolight.co.uk Fusion Orbit User Manual 6

DMX mode:

Operating in a DMX control mode environment gives the user the greatest exibility when it comes

to customising or creating a show. In this mode you will be able to control each individual trait of

the xture and each xture independently.

To access the DMX address mode, press the “MENU” button and use the “UP” and “DOWN” buttons to

show Addr on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons

to set the required DMX address. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

DMX channel mode:

To access the DMX channel mode, press the “MENU” button and use the “UP” and “DOWN” buttons to

show CHAn on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons

to choose one of the 2/7/16 or 37 DMX channel modes. Press the “ENTER” button to conrm the set-

ting. To exit out of any of the above options, press the “MENU” button.

Operating instructions

2 channel mode:

Channel Value Function

CH1

000-015 No function

016-064 Show 1

065-114 Show 2

115-164 Show 3

165-214 Show 4 (forward facing show)

215-255 Show 5 (no strobe)

CH2 000-255 Sound sensitivity (low-high)

7 channel mode:

Channel Value Function

CH1

000-015 No function

016-075 Pan/Tilt auto program 1

076-135 Pan/Tilt auto program 2

136-195 Pan/Tilt auto program 3

196-255 Pan/Tilt auto program 4

CH2 000-255 Master dimmer (0-100%) - beam only

CH3 000-255 Colour macros - beam only

CH4 000-255 Master dimmer (0-100%) - ring only

CH5 000-255 Colour macros - ring only

CH6 000-255 Macro programs - ring only

CH7 000-255 Macro program speed (slow-fast)

16 channel mode:

Channel Value Function

CH1 000-255 Pan 0-540°

CH2 000-255 Tilt 0-210°

CH3 000-255 Pan/tilt speed (slow-fast)

CH4 000-255 Master dimmer

(0-100%)

LED beam

CH5 000-009 No function

010-255 Strobe (slow-fast)

CH6 000-255 Red dimmer (0-100%)

CH7 000-255 Green dimmer (0-100%)

CH8 000-255 Blue dimmer (0-100%)

CH9 000-255 White dimmer (0-100%)

CH10 000-255 Master dimmer

(0-100%)

LED ring

CH11 000-009 No function

010-250 Strobe (slow-fast)

CH12 000-255 Red dimmer (0-100%)

CH13 000-255 Green dimmer (0-100%)

CH14 000-255 Blue dimmer (0-100%)

CH15

000-015 No function

016-064 Show 1

065-114 Show 2

115-164 Show 3

165-214 Show 4 (forward facing show)

215-255 Show 5 (no strobe)

CH16 000-255 Sound sensitivity (low-high)

www.prolight.co.uk Fusion Orbit User Manual 7

37 channel mode:

Channel Value Function

CH1 000-255 Pan 0-540°

CH2 000-255 Pan ne

CH3 000-255 Tilt 0-210°

CH4 000-255 Tilt ne

CH5 000-255 Pan/tilt speed (slow-fast)

CH6 000-255 Master dimmer

(0-100%)

LED

beam

CH7 000-009 No function

010-255 Strobe (slow-fast)

CH8 000-255 Colour macros

CH9 000-255 Red dimmer (0-100%)

CH10 000-255 Green dimmer (0-100%)

CH11 000-255 Blue dimmer (0-100%)

CH12 000-255 White dimmer (0-100%)

CH13 000-255 Master dimmer

(0-100%)

LED

ring

CH14 000-009 No function

010-250 Strobe (slow-fast)

CH15 000-255 Colour macros

CH16 000-255 Macro programs

CH17 000-255 Macro program speed

(slow-fast)

CH18 000-255 Red dimmer 1 (0-100%)

CH19 000-255 Green dimmer 1 (0-100%)

CH20 000-255 Blue dimmer 1 (0-100%)

Channel Value Function

CH21 000-255 Red dimmer 2 (0-100%)

LED

ring

CH22 000-255 Green dimmer 2 (0-100%)

CH23 000-255 Blue dimmer 2 (0-100%)

CH24 000-255 Red dimmer 3 (0-100%)

CH25 000-255 Green dimmer 3 (0-100%)

CH26 000-255 Blue dimmer 3 (0-100%)

CH27 000-255 Red dimmer 4 (0-100%)

CH28 000-255 Green dimmer 4 (0-100%)

CH29 000-255 Blue dimmer 4 (0-100%)

CH30 000-255 Red dimmer 5 (0-100%)

CH31 000-255 Green dimmer 5 (0-100%)

CH32 000-255 Blue dimmer 5 (0-100%)

CH33 000-255 Red dimmer 6 (0-100%)

CH34 000-255 Green dimmer 6 (0-100%)

CH35 000-255 Blue dimmer 6 (0-100%)

CH36

000-015 No function

016-064 Show 1

065-114 Show 2

115-164 Show 3

165-214 Show 4 (forward facing show)

215-255 Show 5 (no strobe)

CH37 000-255 Sound sensitivity (low-high)

Operating instructions

www.prolight.co.uk Fusion Orbit User Manual 8

Operating instructions

Pan/tilt speed setting:

To access the pan/tilt speed setting, press the “UP” button on the front of the unit to show SPNd

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

between HISP (fast) or LoSP (slow). Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Master/slave mode:

To set the master unit, press the “UP” button on the front of the master unit to show SLNd on the LED

display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose Nast. Press

the “ENTER” button to conrm the setting. Then select your desired program (sound active or one of the

show modes).

To set the other units in slave mode, press the “UP” button on the front of the unit to show SLNd

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

either SL 1 or SL 2. Press the “ENTER” button to conrm the setting.

SL 1 – the unit will copy the master

SL 2 – the unit will mirror the master

To exit out of any of the above options, press the “MENU” button.

Please ensure that all slave units are set to the same DMX channel mode as the master unit.

Show mode:

To access the show modes, press the “UP” button on the front of the unit to show SHNd

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

between Sh 1 ~ Sh 4. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Sh 1 – full show

Sh 2 – beam only show

Sh 3 – ring only show

Sh 4 – forward facing show

Sh 5 – full show (no strobe)

Sound/sound sensitivity:

To turn the sound mode on or off, press the “UP” button on the front of the unit to show Soun on the

LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose between

on or oFF. Press the “ENTER” button to conrm the setting.

To adjust the sound sensitivity, press the “UP” button on the front of the unit to show SEns on the

LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose between

000 ~100. Value: 000 - 100 (000 = low, 100 = high)

To exit out of any of the above options, press the “MENU” button.

www.prolight.co.uk Fusion Orbit User Manual 9

Operating instructions

Pan invert setting:

To access the pan invert setting, press the “UP” button on the front of the unit to show PAn

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

between on or off. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Tilt invert setting:

To access the tilt invert setting, press the “UP” button on the front of the unit to show tIL

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

between on or off. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Display invert setting:

To access the display invert setting, press the “UP” button on the front of the unit to show dISP

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

between on or off. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Reset factory settings:

To reset the units factory settings, press the “UP” button on the front of the unit to show dEFa

on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose

between on (reset) or ofF. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Pan/Tilt/Colour calibration:

To access the pan/tilt/colour calibration setting, press the “UP” button on the front of the unit to show

Ad t on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to

select dELt (default home position), P(pan home position), t(tilt home position),

r(red), G(green), b(blue), and u(white).

When on dELt, press the “ENTER” button and the units home positions will be reset to the factory

default (000).

When on P, t, r, G, bor u, press the “ENTER” button and use the “UP” and “DOWN” buttons to

adjust the value between 000 ~ 255. Press the “ENTER” button to conrm the setting.

To exit out of any of the above options, press the “MENU” button.

Motor reset:

To reset the motors, press the “UP” button on the front of the unit to show rSt on the LED display.

Press the “ENTER” button to perform the reset.

To exit out of any of the above options, press the “MENU” button.

www.prolight.co.uk Fusion Orbit User Manual 10

Setting the DMX address:

The DMX mode enables the use of a universal DMX controller. Each xture requires a “start address”

from 1- 512. A xture requiring one or more channels for control begins to read the data on the channel

indicated by the start address. For example, a xture that occupies or uses 7 channels of DMX and was

addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104,

105 and 106. Choose a start address so that the channels used do not overlap. E.g. the next unit in

the chain starts at 107.

DMX 512:

DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent

xtures and controllers. A DMX controller sends DMX data instructions form the controller to the xture.

DMX data is sent as serial data that travels from xture to xture via the DATA “IN” and DATA “OUT”

XLR terminals located on all DMX xtures (most controllers only have a data “out” terminal).

DMX linking:

DMX is a language allowing all makes and models of different manufactures to be linked together

and operate from a single controller, as long as all xtures and the controller are DMX compliant.

To ensure proper DMX data transmission, when using several DMX xtures try to use the shortest

cable path possible. The order in which xtures are connected in a DMX line does not inuence the

DMX addressing. For example; a xture assigned to a DMX address of 1 may be placed anywhere in

a DMX line, at the beginning, at the end, or anywhere in the middle. When a xture is assigned a

DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit,

no matter where it is located in the DMX chain.

DATA cable (DMX cable) requirements (for DMX operation):

This xture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit.

Your unit requires either a standard 3-pin or 5-pin XLR connector for data input/output,

see images below.

Also remember that DMX cable must be daisy chained and cannot be split.

DMX setup

Further DMX cables can be purchased from all good sound and lighting suppliers or Prolight Concepts dealers.

Please quote: CABL10 – 2m CABL11 – 5m CABL12 – 10m3-Pin:

CABL185 – 2m CABL187 – 5m CABL188 – 10m5-Pin:

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Equinox Systems Matériel de DJ

Equinox Systems

Equinox Systems Midas Spot Manuel utilisateur

Equinox Systems

Equinox Systems TAURUS Manuel utilisateur

Equinox Systems

Equinox Systems Twin Shot MKII Electric Confetti Launcher Manuel utilisateur

Equinox Systems

Equinox Systems MaxiPar Quad Manuel utilisateur

Equinox Systems

Equinox Systems Six Shooter MKII Manuel utilisateur

Equinox Systems

Equinox Systems FXbar18 Manuel utilisateur

Equinox Systems

Equinox Systems EQLED162 Manuel d'installation et d'exploitation

Equinox Systems

Equinox Systems Truss Booth LED Starcloth System CW MKII Manuel utilisateur

Equinox Systems

Equinox Systems SpectraPix Batten Manuel utilisateur

Equinox Systems

Equinox Systems Stratos Duo RGB Manuel utilisateur

Equinox Systems

Equinox Systems BLITZER Manuel utilisateur

Equinox Systems

Equinox Systems Beamtastic Manuel utilisateur

Equinox Systems

Equinox Systems Power Par 54 MKII Manuel utilisateur

Equinox Systems

Equinox Systems Spark Stream Manuel utilisateur

Equinox Systems

Equinox Systems EQLED064 Manuel utilisateur

Equinox Systems

Equinox Systems Blitzer RGB Strobe Manuel utilisateur

Equinox Systems

Equinox Systems Viper Manuel utilisateur

Equinox Systems

Equinox Systems Colour Raider Uplighter Pack Manuel utilisateur

Equinox Systems

Equinox Systems EQLED054 Manuel utilisateur

Equinox Systems

Equinox Systems EQLED135 Manuel utilisateur

Equinox Systems

Equinox Systems Confetti Burst EQLED400 Manuel utilisateur

Equinox Systems

Equinox Systems Ultra LED Scan EQLED75 Manuel utilisateur

Equinox Systems

Equinox Systems Power Par 54 MKIII Manuel utilisateur

Equinox Systems

Equinox Systems Waterwave 50W Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
