EPSON AMERICA, INC.

EPSON

Product Support Bulletin

Subject: Epson LQ Color Driver for Microsoft Windows 3.0 and 3.1

Date: 4/3/92 PSB No: P-0087

Page(s): 1 of 3

Originator: RSS

The purpose of this bulletin is to announce the availability of an additional color

driver for the LQ-860, LQ-2500, and LQ-2550 for the Microsoft Windows 3.0 and

3.1 environments. This driver is primarily intended to provide Device Independent

Bitmap (DIB) support for Windows based application software. The most popular of

these is Paintbrush which is included with Windows 3.0 and 3.1.

When upgrading to Microsoft Windows version 3.1, it is recommended to use the

Epson driver that is included with that version of Windows. The Microsoft Windows

version 3.1 drivers have DIB support built-in, in addition to new enhancements.

This bulletin also contains information regarding how the driver is being distributed.

In addition, specifications on the color driver and instructions on how to install the

driver into your Windows Package are included.

DISTRIBUTION

The Microsoft Windows LQ Color Driver is available from the following sources:

The driver can be ordered from Accessory Marketing. The part number is

WINCOLOR. To place an order with Accessory Marketing call (800) 922-

8911.

For a limited time the driver is being distributed free of charge.

2) The driver is available from CompuServe. After logging into CompuServe,

to access the Epson Forum, type ‘GO EPSON” at the prompt.

The Epson Bulletin Board is the final means for accessing the driver. The

Epson BBS number for consumers is (310) 782-4531.

SPEClFlCATlONS

The driver consists of 3 files:

GENDRV.DLL, EPSON24C.DRV, and

OEMSETUP.INF.

PSB No: P-0087

Page: 2 of 3

The fonts supported are:

Graphic densities supported:

(Horizontal x Vertical)

Paper Sources:

Cartridge or Optional Fonts:

Paper Size:

Courier, Roman, San Serif, Prestige, Script, OCR-A,

OCR-B, Orator, Orator-S.

360 x 180, 180 x 180, 120 x 180.

Tractor, Bin 1, Bin 2, Manual.

Multi-font Cartridge

Letter, 8 1/2 x 11 in.

Letter, 11 x 8 1/2 in.

Legal, 8 1/2 x 14 in.

Fanfold, 14 7/8 x 11 in.

Tabloid, 11 x 17 in.

A4, 210 x 297 mm

A3, 297 x 420 mm

Fanfold, 210 x 305 mm

Fanfold, 358 x 305 mm

#6 envelope, 6 1/2 x 3 5/8 in.

#10 envelope, 9 1/2 x 4 1/8 in.

INSTALLATION INSTRUCTIONS

Choose Control Panel from the Main Group window in Program Manager.

The Control Panel window appears.

Choose the Printers icon. The Printers dialogue box appears.

Choose the Add Printer button. The dialogue box expands to display a list of

printer-driver files.

Select ‘Unlisted Printer” at the end of the display.

Choose Install.

Select the correct drive and path to find the Windows driver.

Select the ‘EPSON LQ COLOR” and choose OK.

PSB No: P-0087

Page: 3 of 3

Define the new driver as ACTIVE to begin using it immediately.

Refer to the MS Windows User’s Manual for further information about printer-driver

installation.

NOTES

The LQ-2500 is only supported with tractor paper. This is because in single sheet

mode or CSF mode the printer has a large top and bottom non-printable area.

For best results you should print at 360 x 180 DPI for normal printing and 180 x

180 DPI for draft printing.

EPSON AMERICA, INC.

EPSON

Product Support Bulletin

Subject:

24 Pin Printer Error and Beep Codes

Date: 4/3/91

PSB No: P-0076

Page(s): 1 of 4 Originator JV

Epson printers issue beep tones when certain error conditions exist. Those beeps

can assist you in locating and repairing customer’s printers. The following error

codes are listed by product name.

NOTE:

Most of the beeps issued by the printers are of .1 second duration with a .1

second pause between beeps. Where the beeps or the pauses are longer,

it has been noted in the text. The description “3 Beeps x 2” means two sets

of three beeps.

LQ-200/AP-3000

1 beep: BEL code

1 beep: A Control Panel setting is accepted.

3 beeps: Paper End detected

5 beeps: Abnormal carriage movement

On-Line light is flashing:

Printhead is over heated. Carriage will stop until

the printhead cools down.

LQ-500, LQ-510, LQ-1010, LQ-850, LQ-950, LQ-1050,

L1000, AP-4000, AP-4500

1 beep:

BEL code (.5 set beep)

1 beep: A Control Panel setting is accepted

3 beeps: Paper End detected

5 beeps: Abnormal carriage movement

PSB No: P-0076

Page: 2 of 4

LQ-800, LQ-1000, L750

1 beep: BEL code

1 beep: A Control Panel setting is accepted

3 beeps: Paper End detected

5 beeps:

Abnormal carriage movement

(.5 sec. pause between beeps)

5 beeps:

LQ-860

+35V supply is abnormal

1 beep: BEL code (.5 sec. beep)

1 beep:

A Control Panel setting is accepted

3 beeps: Paper End detected

5 beeps:

Color select mechanism error

(.5 sec. beep, .5 sec between beeps)

5 beeps:

Abnormal carriage movement

(.5 sec. beep, .5 sec between beeps)

5 beeps:

CG ROM failure

(.5 sec. beep, .5 sec between beeps)

LQ-1500

1 beep:

BEL code

5 beeps: Paper End detected

5 beeps: Abnormal carriage movement

(.5 sec. pause between beeps)

PSB No: P-0076

Page: 3 of

LQ-2500

NOTE:

Printers with LCD displays use error messages along with beeps to

inform the user of problems. The following messages will help you to

troubleshoot problems.

A blank LCD screen with the Power-on LED lit can be caused by a bent

pin on one of the PROM

or jumper J1 may be set incorrectly.

1 beep: BEL code

5 beeps: Abnormal voltage-

5 beeps: Abnormal carriage movement

(.5 sec. pause between beeps)

LQ-2500 LCD Codes:

00 Invalid ID request to CGROM

EEROM read/write error

LQ-2550

Abnormal carriage movement

1 beep: BEL code

3 beeps:

Paper End detected

5 beeps: Abnormal carriage movement (.5 sec. pause between

beeps)

5 beeps: Platen Gap adjustment error (.5 sec. pause between

beeps)

5 beeps: Case open

LQ-2550 LCD Codes:

00 (1)

The font could not be found. The printer’s internal program could not

find the target font.

(2)

Missing or damaged 7A ROM

Internal ROM check does not match. The versions may have been mixed.

PSB No: P-0076

Page:

LQ-2550 cont.

A ‘Verify After Write” check to the SRAM has failed. The SRAM could be bad.

This is a motor control error. Four possible areas of failure are:

a. CR home condition not detected at power up

b. Platen gap motor HP not detected correctly

c. Friction/Tractor feed switching error

d. Physical obstruction such as a jammed ribbon

Skewed paper detect error. Since the initial reading upon loading a single

sheet paper, the paper has skewed. This is a printhead wire protection

feature.

Illegal paper positioning.

(1)

If the paper is loaded using the knob instead of the LOAD/EJECT switch,

this error condition will occur. This is a printhead wire protection feature.

(2)

PE sensor may have failed or is not connected.

CPU error. An undefined op-code was detected.

NOTES:

Error codes 11 and 12 are usually caused by new operators who are

un-familiar with the machine. Both of these errors are corrected by

turning the printer off, taking out the paper and turning the printer back

on. Both features were added to ensure proper paper handling and

prevent paper jams, which can result in printhead failures.

Incorrect jumper settings on the ROMA board may cause errors 10 or

20. The correct settings are documented in the Service Manual (page

A-54, figure A-52) and on TIB LQ2550-005.

Errors 0,2, 3, 10, and 20 may require a repair, adjustment or

replacement.

EPSON AMERICA INC.

EPSON

Product Support Bulletin

Subject: Quick Reference for Current Dot-Matrix Printer Print Speeds

Date: 10/9/92

Page(s): 1 of 1 PSB No: P-0030C

Originator: SLS

9-PIN PRINTERS

l%Y

D”:,“n”-“,““c”p4

legal

llLFPl

Model

AP-2250

200

CPS 240 CPS n/a

CPS

LX-810

200

CPS 240 CPS n/a

CPS

Model

AP-3250

LQ-570/1070

LQ-860

LQ-870/1170

LQ-2550

24-PIN PRINTERS

Draft

10 CPI Draft

12 CPI

167 CPS

200 CPS

210 CPS 252 CPS

246 CPS 295 CPS

275 CPS

330 CPS

333 CPS I 400 CPS

High-Speed

Draft 10 CPI

ICZPI

IEPI

n/a

60 CPS

72 CPS

225

CPS

300

CPS

300 CPS

92 CPS

110 CPS

n/a

111 CPS

133 CPS

GLOSSARY OF TERMS

CPI:

Characters Per Inch

CPS: Characters Per Second

Draft:

Draft uses a minimum number of dots per character for high-speed printing.

Elite:

12 Characters Per Inch (12 CPI)

Pica:

10 Characters Per Inch (10 CPI)

LQ:

Letter Quality reduces the print speed and increases the number of dots per

character to increase the print quality. (24-pin printers only)

NLQ:

Near Letter Quality reduces the print speed and increase the number of dots

per character to increase the print quality. NLQ printing requires two passes

per character. (9-pin printers only)

EPSON AMERICA,

NC.

EPSON

Product Support Bulletin

Subject: Quick Reference for 9/24 Pin Printer Paper Specifications

Date: 10/9/92

Page(s): 1 of 1 PSB No: P-0022D

Originator: SLS

This PSB provides a quick reference for the paper specifications on Epson’s current

line of Q-pin and 24-pin dot-matrix printers when using continuous paper. The

‘Maximum No. of Copies” is the maximum allowable number of copies when using

continuous multi-part carbonless paper. The “Total” number is the maximum

allowable number of copies including the original. The ‘Maximum Total Thickness”

is the maximum allowable total thickness including the original plus any copies.

9-PIN PRINTERS

Model

Orig. + Maximum No.

of Copies Total Maximum Total

Thickness

AP-2250 *

0.0098” (0.25mm)

LX-810

0.0098” (0.25mm)

FX-870/1170

0.0126” (0.32mm)

DFX-5000

(Front Tractor)

(Rear Tractor)

360.018" (0.46mm)

0.012” (0.30mm)

DFX-8000

(Front Tractor)

(Rear Tractor)

0.018" (0.46mm)

0.012” (0.30mm)

24-PIN PRINTERS

Model

Orig. + Maximum No.

Total Maximum Total

of Copies Thickness

AP-3250 *

0.0071” (0.18mm)

LQ-570/1070

0.0126” (0.32mm)

LQ-860

0.0126” (0.32mm)

LQ-870/1170

0.0126” (0.32mm)

LQ-2550

0.018" (0.46mm)

* Note:

The AP-2250 and AP-3250 require an optional push tractor to use

continuous paper.

EPSON AMERICA, INC.

EPSON

Product Support Bulletin

Subject: Quick Reference for Printer Acoustic Noise Levels

Date: 6/5/91

PSB No: P-0016D

Page(s): 1 of 2

Originator: SLS

Sound intensity is measured in units called Bels (named after Alexander Graham Bell,)

or more commonly in tenths of this fundamental unit: decibels. In making noise

measurements a weighting network is applied in an attempt to match the frequency

response of the instrument to that of the human ear. The most common is the A

weighting network, with resulting measurements expressed in dB(A).

The following is a list of current product’s noise levels tested in accordance with

standards set by the International Standards Organization (ISO). The acoustic noise

levels for the 9 pin printers are averages while printing in Near Letter Quality (NLQ)

mode using continuous paper and are not guaranteed figures. The acoustic noise

levels for the 24 pin printers are averages while printing in Letter Quality (LQ) mode

using continuous paper and are not guaranteed figures. The acoustic noise levels for

the laser printers are averages while using single sheet paper and are not guaranteed

figures.

9 PIN PRINTERS

MODEL

NOISE LEVEL

LX-810

56 dB(A)

FX-850

FX-1050

56 dB(A)

DFX-5000

55 dB(A)

DFX-8000

55 dB(A)

24 PIN PRINTERS

LQ-510

LQ-1010

56 dB(A)

LQ-850

56 dB(A)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Epson Logiciel

Epson

Epson BrightLink 455Wi Manuel utilisateur

Epson

Epson 4012033-00 XXX Manuel utilisateur

Epson

Epson Scanner A3 Manuel utilisateur

Epson

Epson Zip-100S (SCSI Manuel utilisateur

Epson

Epson Panorama Stitcher Light EP and QuickTime 5 Manuel utilisateur

Epson

Epson 3800 - Stylus Pro Color Inkjet Printer Manuel utilisateur

Epson

Epson C12C842862 - StylusRIP Professional - Mac Manuel utilisateur

Epson

Epson M00002104 Manuel

Epson

Epson BrightLink 455Wi Manuel utilisateur

Epson

Epson ChromaBlast v1.0 Manuel utilisateur

Epson

Epson EpsonTalk LP Manuel utilisateur

Epson

Epson Stylus Pro 9880 ColorBurst Edition - Stylus Pro 9880... Manuel utilisateur

Epson

Epson PowerLite 1835 Manuel utilisateur

Epson

Epson 1640XL - Expression Graphic Arts Dimensions

Epson

Epson Stylus Pro 10000 Series Manuel utilisateur

Epson

Epson MACLQ (Talk I/F for LQ Printers) Manuel utilisateur

Epson

Epson Stylus Scan 2000 Manuel utilisateur

Epson

Epson 10600 - Stylus Pro Color Inkjet Printer Manuel utilisateur

Epson

Epson PowerLite Pro Z8250NL Manuel utilisateur

Epson

Epson 836XL - Expression - Flatbed Scanner Manuel utilisateur

Epson

Epson PowerLite 4650 Manuel utilisateur

Epson

Epson 7900p - PowerLite XGA LCD Projector Dimensions

Epson

Epson DS-30 WorkForce DS-30 Manuel utilisateur

Epson

Epson Software Film Factory v2.5 Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
