Introduction

This package contains all you need for professional quality

color scanning:

An Epson ES-600C™ color scanner

Adobe

Photoshop™ 2.5 LE, a powerful image-editing

program

ScanTastic,™ a plug-in that enables you to scan images into

Photoshop

a SCSI system cable.

This booklet tells you how to set up your scanner, install the

two software programs, and scan a picture. If you need

detailed information after you begin scanning, you can consult

the individual manuals for the ES-600C Scanner, Adobe

Photoshop, and ScanTastic.

Setting Up the Scanner

Take the scanner out of the box.

Place the scanner on a flat, stable surface with its rear panel

facing you.

Locate the round screw knob in the middle of the rear panel

under the word

CLAMP.

Turn the screw counterclockwise and remove it.

Push the screw into the storage hole on the right under the

word

STOCK.

Just push it in; it does not screw in. This keeps

it handy in case you ever want to ship your scanner.

Connect the power cable to the power inlet on the rear of the

scanner and the other end into an appropriately grounded

outlet as shown below.

If the scanner comes on when you plug it in, turn it off by

pressing the

OPERATE

button.

Connecting the Scanner to Your

Macintosh®

Warning:

Be sure that your Macintosh, scanner, and any other SCSI

devices are turned off before you unplug or plug in any cables.

You connect the scanner to your Macintosh with the SCSI cable

included in the box. This cable has a 25-pin connector on one

end and a 50-pin connector on the other.

Plug the 25-pin connector into the SCSI port on the Mac.

This port has a

icon above it.

Note:

If you are already using the SCSI port on your Macintosh

for

another SCSI device, such as an external hard disk, you will need

a SCSI cable with 50-pin connectors

on both

ends.

You

can

then

connect the scanner to your other SCSI device, following the

instructions in Chapter 2

your

ES-600C User’s Guide.

Connect the 50-pin end of the cable to either the right or left

SCSI connector of the scanner; then fasten the connector

with the wire clamps on its side.

Turn on the scanner, then the Macintosh. (Always turn the

scanner on before you turn on the computer.)

lnstalling the Software

Now that you have connected the scanner and the Macintosh,

you’re ready to install the software and start scanning. To

install Adobe Photoshop and ScanTastic just follow the steps

below.

Note:

You will need about 10MB

hard disk space to install the software.

Turn off any virus-protection software that you are using

until you finish installing Photoshop and ScanTastic.

Insert the Photoshop Installer Disk 1 in the Mac and double

click the Adobe Photoshop’” Installer icon.

When the installer screen appears, click

to continue.

A dialog box appears. Click the

Install

button to install the

entire program from the diskettes to your hard disk. Follow

the instructions on the screen that tell you when to insert

different diskettes.

When a message appears telling you that the installation

was successful, click

Quit

to exit the installer.

Eject the installer diskette.

Note:

If you have SuperMatch,™ NEC

AccuColor,™ or another monitor

calibration utility installed, skip to step 8.

Open the Adobe Photoshop™ LE folder. Then drag the

Gamma Control Device icon into your System folder. If you

see a message asking if you want to put “Gamma” in the

Control Panels folder, click

OK.

8. Restart your Macintosh.

Open the Adobe Photoshop folder if it is not already open,

and double click the Adobe Photoshop program icon.

10. Type your name in the box. If you wish, also type the name

of your organization.

11. Type the serial number of the Photoshop program. You can

find it on the Photoshop registration card and on the very

first page of the

Adobe Photoshop User Guide & Tutorial.

12. Click OK.

Save XS

Save As...

Acquire

Export

Page Setup...

Print . . .

Preferences

13. Choose

Quit

from the File menu in the upper left corner of

the screen.

:‘:’

:::

:.:.:.::.::::::,:::::::,:,:::.:.:.::::.i

:.:::.j:>:::.i:/

.:.,.:.:

:/:yy:;,//:

:.:::

iiiiiiiii,,i,,,,,,,,,,.,

This will close Photoshop so that you can install ScanTastic,

which will enable you to scan from within Photoshop.

lnstalling ScanTastic

Insert the ScanTastic diskette into your Macintosh.

Double-click on the diskette icon.

Drag the ScanTastic™ps icon into the Plug-ins folder in the

Photoshop folder.

Eject the ScanTastic diskette.

Turn off the Macintosh.

Your First Scan

First, choose an image to scan. The best choice is a color

photograph. Printed pictures, such as those in magazines, do

not scan as well as photographs because of the dot patterns

used in the printing process.

After you choose an image, follow these steps:

Turn on your scanner.

Turn on your Macintosh.

Double click the Adobe Photoshop icon.

Raise the document cover on the scanner and place the

image face down on the glass surface.

Carefully close the document cover so that you do not

disturb the position of the photograph on the glass.

From the file menu in Photoshop choose ScanTastic from

the Acquire pop-up menu under the File menu.

Edit Mode ImageFilter Select Window

““‘i”=!d-l

(AGEI,

l:l)

You see the following screen:

Output Device

Res HT

Manual

Hardware

Image Type

Width: 8.42”

Brightness:

[18,909]

Height: 11.67”

Width: 8.42” Height: 11.67” Space: 4.90 MBytes Units.

-rrc)r

~~~~

Click the Preview button.

A preview of your image appears on the screen. Use your

mouse to click and drag a rectangle to select the area you want

to scan.

Output Device

Res HT

Image Type :

Scale

1100%

[18,9091

Width: 6.06” Height: 7.47”

Brightness.

Width: 6.06”

Height: 7.47” Space: 2.26 MBytes

Units :

mlnchps

To change your selected area, move the pointer to the edge of

the selection rectangle and click and drag the edge of the

rectangle to a new location.

When you have defined the portion of the image on the screen

that you want to scan, click the Scan button. In a few moments

the scanned image appears on your screen.
