Epson WorkForce Pro WP-4015 DN Manuel utilisateur

PAGE 1 of 8 >>

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

v20130501

FIGURE 2

There are two different driver settings, one for photographic images and one for graphics. The Photo driver settings should

be used primarily for photographic images as it produces natural / realistic results. The Graphics driver settings should be

used primarily for vector based artwork such as logos and designs as it will produce a more vibrant result. When printing

from your graphics software choose the appropriate driver settings that you require.

CONFIGURING PHOTO DRIVER SETTINGS

Note: Ensure that the latest version of the OEM driver is installed, please see the Installation Guide for further instructions.

1.) To open Devices and Printers hold down the Windows logo key on your keyboard, then press the let-

ter “x”. This will open the screen below. Select Control Panel (see FIGURE 1A). Then select Devices

and Printers in the Control Panel window (see FIGURE 1B).

2.) In the Devices and Printers folder, right-click on the EPSON WP-4015 Series printer driver icon and

select Printing Preferences (see FIGURE 2). This will open the Printing Preferences window (see FIG-

URE 3).

FIGURE 1A FIGURE 1B

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

PAGE 2 of 8 >>

3.) In the EPSON WP-4015 Series Printing Preferences window, click the Main tab and match your

settings to those shown below: (see FIGURE 3)

FIGURE 3

A. Paper Source: Rear MP Tray

B. Document Size: A4 210 x 297 mm

Note: You may wish to create a conguration for each document size that you will be using.

C. Orientation: Portrait or Landscape

Note: You may wish to create a conguration for each orientation.

D. Paper Type: Epson Matte

E. Quality: Quality

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

PAGE 3 of 8 >>

4.) In the EPSON WP-4015 Series Printing Preferences window, click the More Options tab and match

your settings to those shown below (see FIGURE 4):

FIGURE 4

A. Check Mirror Image

B. Check High Speed

E. Click Add/Remove Presets...

C. Check Custom

D. Click Advanced to open the Color Correction window (see FIGURE 5)

FIGURE 5

1. Check No Color Management

2. Click OK

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

PAGE 4 of 8 >>

FIGURE 6

5.) In the Custom Settings window, call the setting Photo and click Save (see FIGURE 6).

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

PAGE 5 of 8 >>

CONFIGURING GRAPHICS DRIVER SETTINGS

6.) In the EPSON WP-4015 Series Printing Preferences window, click the Main tab and match your

settings to those shown below: (see FIGURE 7)

FIGURE 7

A. Paper Source: Rear MP Tray

B. Document Size: A4 210 x 297 mm

Note: You may wish to create a conguration for each document size that you will be using.

C. Orientation: Portrait or Landscape

Note: You may wish to create a conguration for each orientation.

D. Paper Type: Epson Matte

E. Quality: Quality

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

PAGE 6 of 8 >>

7.) In the EPSON WP-4015 Series Printing Preferences window, click the More Options tab and match

your settings to those shown below: (see FIGURE 8)

FIGURE 8

A. Check Mirror Image

B. Check High Speed

C. Check Custom

D. Click Advanced to open the Color Correction window (see FIGURE 9)

FIGURE 9

1. Check No Color Management

2. Click OK

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

PAGE 7 of 8 >>

9.) In the Extended Settings window, match your settings to those shown below: (see FIGURE 11).

FIGURE 11

A. Print Density: 20%

B. Click OK

8.) In the EPSON WP-4015 Series Printing Preferences window, click the Maintenance tab and click

Extended Settings (see FIGURE 10).

FIGURE 10

PAGE 8 of 8 >>

Epson WorkForce Pro WP-4015 DN

Conguration Guide - Windows 8

FIGURE 13

11.) In the Custom Settings window, call the setting Graphics and click Save (see FIGURE 13).

Congratulations! The SubliJet-IQ Epson WP-4015 DN WinProle conguration is now complete. Please

proceed to the Print Setup Guide that corresponds with your printer model and graphics software.

10.) In the EPSON WP-4015 Series Printing Preferences window, click the More Options tab and click

Add/Remove Presets...: (see FIGURE 12)

FIGURE 12
