DIP Switch Tables

* Only when DIP Switches 1-7 and 1-8 are on, the transmission

speed can be selected from one of seven speeds: 2400, 4800,

9600, 19200, 38400, 57600, and 115200 bps by control

commands. The default is 38400.

*1: For USB I/F, DIP Switches 1-3 and 1-4 are Undefined.

*2: For Parallel I/F, DIP Switch 1-8 is Undefined.

lps: lines per second dpi: dots per 25.4 mm (dots per inch)

DIP switch 1 (Serial Interface)

SW Function ON OFF

1-1 Data receive error Ignored Prints “?”

1-2 Receive buffer capacity 45 bytes 4KB

1-3 Handshaking XON/XOFF DTR/DSR

1-4 Data word length 7 bits 8 bits

1-5 Parity check Enabled Disabled

1-6 Parity selection Even Odd

1-7

1-8

Transmission speed (See table A.)

Table A

Transmission speed (bps)-bits per second SW1-7 SW1-8

Adjustable by control commands* ON ON

4800 OFF ON

9600 ON OFF

19200 OFF OFF

DIP switch 1 (Parallel/USB Interface)

SW Function ON OFF

1-1 Auto line feed Always

enabled

Always disabled

1-2 Receive buffer capacity 45 bytes 4KB

1-3*1 Select paper sensors to

output paper-end signals

(default value of a

command) from parallel

I/F.

Disabled Roll Paper end

sensor enabled,

Roll Paper near-

end sensor

enabled

1-4*1 Error signal output from

parallel I/F

Disabled Enabled

1-5~

1-7

Undefined

1-8*2 Power saving function for

USB

Disabled Enabled

DIP switch 2 (Serial/Parallel/USB Interface)

SW Function ON OFF

2-1 Handshaking

(BUSY condition)

Receive buffer full Offline or

Receive buffer full

2-2 Do not change settings Fixed to OFF

2-3

2-4

Print density/

Low power

consumption mode

See Table B

2-5 Release condition of

receive buffer BUSY (If

receive buffer capacity

set to 4KB.)

Releases BUSY

when remaining

receive buffer

capacity reaches

138 bytes.

Releases BUSY

when remaining

receive buffer

capacity reaches

256 bytes.

2-6 Do not change

settings.

Fixed to OFF

DIP switch 2-7, 2-8 (Serial Interface)

SW Function ON OFF

2-7 I/F pin 6 reset Enabled Disabled

2-8 I/F pin 25 reset Enabled Disabled

DIP switch 2-7, 2-8 (Parallel/USB Interface)

SW Function ON OFF

2-7 Do not change Fixed to OFF

2-8 Do not change Fixed to ON

Table B

Print density/low power SW2-3 SW2-4

– Low power consumption mode ON ON

Print density “Normal” OFF OFF

Print density “Medium” ON OFF

Print density “Dark” OFF ON

TM-T88IV User’s Manual 1

English

User’s Manual

DIP Switch Table

The DIP switch table is at the beginning of this manual.

Illustrations

All of the illustrations are at the beginning of this manual. They are identified by letters (A, B, C . . .). Some of the

illustrations have numbers in them. See the list below for the meaning of the numbers.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means,

electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson

Corporation. No patent liability is assumed with respect to the use of the information contained herein. While every

precaution has been taken in the preparation of this book, Seiko Epson Corporation assumes no responsibility for errors or

omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages,

losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or

unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko

Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any options or any

consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson

Corporation.

EPSON is a registered trademark of Seiko Epson Corporation.

Exceed Your Vision is a registered trademark or trademark of Seiko Epson Corporation.

All other trademarks are the property of their respective owners and used for identification purpose only. Product

information is subject to change without due notice.

NOTICE: The contents of this manual are subject to change without notice.

Illustration A: Illustration C:

1. Printer cover 5. Hook

2. Cutter cover 6. Bottom of the printer

3. Cover open button

4. Control panel

2TM-T88IV User’s Manual

Safety Precautions

This section presents important information intended to ensure safe and effective use of

this product. Please read this section carefully and store it in an accessible location.

WARNING:

Shut down your equipment immediately if it produces smoke, a strange odor, or unusual noise.

Continued use may lead to fire. Immediately unplug the equipment and contact your dealer or a

Seiko Epson service center for advice.

Never attempt to repair this product yourself. Improper repair work can be dangerous.

Never disassemble or modify this product. Tampering with this product may result in injury or fire.

Do not use this product with any voltage other than the specified one. Doing so may lead to fire or

electric shock.

Do not allow foreign matter to fall into the equipment. Penetration by foreign objects may lead to

fire.

If water or other liquid spills into this equipment, unplug the power cord immediately, and then

contact your dealer or a Seiko Epson service center for advice. Continued usage may lead to fire.

If you open the DIP switch cover, be sure to close the cover and tighten the screw after adjusting

the DIP switch. Using this product with the cover open may cause fire or electric shock.

Do not use aerosol sprayers containing flammable gas inside or around this product. Doing so

may cause fire.

Do not connect a telephone line to the drawer kick-out connector; otherwise, the printer and the

telephone line may be damaged.

CAUTION:

Do not connect cables in ways other than those mentioned in this manual. Different connections

may cause equipment damage and burning.

Be sure to set this equipment on a firm, stable, horizontal surface. The product may break or

cause injury if it falls.

Do not use in locations subject to high humidity or dust levels. Excessive humidity and dust may

cause equipment damage or fire.

Do not place heavy objects on top of this product. Never stand or lean on this product. Equipment

may fall or collapse, causing breakage and possible injury.

Take care not to injure your fingers on the manual cutter

• When you remove printed paper

• When you perform other operations such as loading/replacing roll paper

To ensure safety, unplug this product before leaving it unused for an extended period.

TM-T88IV User’s Manual 3

Caution Labels

The caution labels on the product indicate the following precautions.

CAUTION:

The thermal head is hot.

CAUTION:

Touching the manual cutter may cause injury.

Restriction of Use

When this product is used for applications requiring high reliability/safety such as

transportation devices related to aviation, rail, marine, automotive etc.; disaster prevention

devices; various safety devices etc; or functional/precision devices etc, you should use this

product only after giving consideration to including fail-safes and redundancies into your

design to maintain safety and total system reliability. Because this product was not

intended for use in applications requiring extremely high reliability/safety such as

aerospace equipment, main communication equipment, nuclear power control equipment,

or medical equipment related to direct medical care etc, please make your own judgment

on this product’s suitability after a full evaluation.

Unpacking

The following items are included with the standard specification printer. If any item is

damaged, contact your dealer.

❏Printer ❑Roll Paper

❏Power switch cover ❑Connector cover *

❏AC adapter *

* May not be included with your printer.

Precautions When Installing the Power Supply Box

A description of EMI standards is on the bottom of the printer. When the optional power

supply box (OT-BX88) is installed, it is hard to check it. In such case, uninstall the power

supply box if necessary.

Important Installation Notes

❏For a serial interface, use a null modem cable.

❏For a parallel interface, use an IEEE 1284 cable.

❏For a USB interface, install the driver before connecting the printer.

Downloading Drivers, Utilities, and Manuals

Drivers, utilities, and manuals can be downloaded from the following URL.

http://download.epson-biz.com/?service=pos

4TM-T88IV User’s Manual

Installing the Printer Horizontally or Vertically

You can install the printer horizontally on a flat surface (with the paper exit on top) or

vertically (with the paper exit at the front) by hanging it on a wall, using the optional WH-

10 hanging bracket set.

WARNING:

When hanging the printer on the wall with the hanging bracket set, be sure to attach a connector

cover to the printer.

Control Panel

FEED button

This button feeds paper.

(Power) LED

This LED is on when the printer is on.

ERROR LED

This indicates an error.

PAPER OUT LED

On indicates a paper near end or out. Flashing indicates standby.

Using the Power Switch Cover

WARNING:

If an accident occurs with the power switch cover attached, unplug the power cord immediately.

Continued use may cause fire or shock.

The enclosed power switch cover ensures that the power switch is not pressed accidentally.

To use this cover, install it as shown in illustration B.

Attaching and Removing the Connector Cover

These instructions apply if a connector cover is packed with your printer to protect your

cables. To attach it, follow the steps below:

1. First, connect all the cables. The connector cover has three possible cable exits: on the

right, left, and back.

2. Position the two hooks on the connector cover so that they hook the printer case, as

shown in illustration C.

3. Push the connector cover down to click onto the printer case.

To remove the connector cover, turn the printer over, and push the connector cover down

while pushing both sides of the connector cover inward to detach the hooks from the

printer case. See illustration D.

Installing Roll Paper

1. Press the button to open the cover. See illustration E.

2. Remove the used roll paper core, and insert the roll paper. See illustration F.

3. The correct direction of the paper is shown in illustration G.

4. Pull out some paper, as shown in illustration H. Close the cover, and tear off the

paper, as shown in illustration I.

TM-T88IV User’s Manual 5

Troubleshooting

No lights on the control panel

Check the power supply cable connections and the power outlet.

ERROR LED on (not flashing) with no printing

If PAPER OUT is on, the roll paper is not installed or is near the end.

If PAPER OUT is off, the printer cover is not closed properly.

ERROR LED flashing with no printing (and no paper jam)

Printing stops if the head overheats and resumes automatically when it cools.

If overheating is not the cause, turn the printer off, and after 10 seconds, back on.

Removing Jammed Paper

CAUTION:

Do not touch the thermal head because it can be very hot after printing.

1. Turn the printer off and press the cover open button.

2. Remove jammed paper, reinstall the roll, and close the cover.

3. If paper is caught in the cutter and you cannot open the printer cover, open the cutter

cover as shown in illustration J.

4. Turn the knob until you see a triangle in the opening. This returns the cutter blade to

the normal position. There is a label near the cutter to assist you. See illustration K.

5. Close the cutter cover.

6. Open the printer cover and remove the jammed paper.

Cleaning the Thermal Head

CAUTION:

After printing, the thermal head can be very hot. Be careful not to touch it and to let it cool before

you clean it. Do not damage the thermal head by touching it with your fingers or any hard object.

Turn off the printer, open the printer cover, and clean the thermal elements of the thermal

head with a cotton swab moistened with an alcohol solvent (ethanol or IPA).

Epson recommends cleaning the thermal head periodically (generally every 3 months) to

maintain receipt print quality.

Specifications

Printing method Thermal line printing

Dot density 180 dpi ×180 dpi [dots per 25.4 mm {1"}]

Printing direction Unidirectional with friction feed

Printing width 72 mm, 512 dot positions

Characters per line

(default)

Font A: 42; Font B: 56

Special Font A: 42; Special Font B; 56

Character spacing

(default)

Font A: 0.28 mm (2 dots), Font B: 0.28 mm (2 dots)

Special Font A, Special Font B: 0.28 mm (2 dots)

6TM-T88IV User’s Manual

lps: lines per second dpi: dots per 25.4 mm (dots per inch)

*1: The values in the brackets are for Thai characters, and can be selected by control commands.

*2: Be sure to use a safety-standards-applied power source that meets the following specifications.

Rated output: 24 V/2.0 to 10.0 A

Maximum output: 240 VA or less

Character size*1 Font A and Special Font A:

1.41 × 3.38 (1.41 × 10.15)/1.41 × 6.76(1.41 × 20.30)/2.82 × 3.38 (2.82 × 10.15)

/2.82 × 6.76 (2.82 × 20.30) mm

Font B: 0.99 × 2.40 (0.99 × 7.19)/0.99 × 4.80 (0.99 × 14.38)

/1.98 × 2.40 (1.98 × 7.19)/1.98 × 4.80 (1.98 × 14.38) mm

Special Font B: 0.99 × 3.38 (0.99 × 10.15)/0.99 × 6.76 (0.99 × 20.30)

/1.98 × 3.38 (1.98 × 10.15)/1.98 × 6.76 (1.98 × 20.30) mm

Character structure Font A (default): 12 × 24; Font B: 9 × 17

Special Font A: 12 × 24; Special Font B: 9 × 24

Number of characters Alphanumeric characters: 95; International characters: 1

Extended graphics: 128 × 1 table

Thai characters: 128 × 3 pages (133 character types)/

Vietnam characters: 128 × 2 pages (135 character types)

Printing speed High-speed mode:

200 mm/s max.; 47.2 lps (4.23 mm feed)

Ladder bar code and 2D code: 100mm/s

Low-power consumption mode:

150 mm/s max.; 35.5 lps (4.23 mm feed)

Bit image, Ladder bar code, 2D code and Page mode: 60mm/s

The above speed values are approximate.

The values are when the printer prints with density "Normal" at 24 V and 25°C

Speed is adjusted automatically depending on the voltage applied and head

temperature.

Paper feed speed Approx. 200 mm/s continuous paper feed

Line spacing (default) 4.23 mm

Roll Paper (single-ply) Size: 80 mm paper width model: 79.5 mm ± 0.5 mm,

Maximum outside diameter: 83 mm

Roll Paper spool diameter: Inside: 12 mm; Outside: 18 mm

Thermal paper type Specified: NTP080-80

Interface

(compatible)

Serial (RS-232)/Parallel (IEEE1284)/

USB [compliance: USB 2.0, communication speed: Full-Speed(12Mbps)]

Receive buffer 4KB/45 bytes

Cash drawer function 2 drives

Supply voltage*2 DC + 24 V ± 7%

Current consumption High-speed mode: 1.8 A

Low-power consumption mode: 1.1 A

Temperature Operating: 5 to 45°C

Storage: –10 to 50°C, except for paper

Humidity Operating: 10 to 90% RH

Storage: 10 to 90% RH, except for paper

Overall dimensions 148 × 145 × 195 mm (H × W × D)

Weight (mass) Approx. 1.8 kg

Autres manuels pour TM-T88IV ReStick

Table des matières

Langues :

Autres manuels Epson Imprimante

Epson

Epson TM-U200 Series Manuel utilisateur

Epson

Epson WorkForce Pro WP-4540 Manuel utilisateur

Epson

Epson AcuLaser C8500 Manuel utilisateur

Epson

Epson SureColor SC-F7000 Manuel utilisateur

Epson

Epson 2000P - Stylus Photo Color Inkjet Printer Manuel utilisateur

Epson

Epson WorkForce Pro WF-C879RBAM Manuel utilisateur

Epson

Epson Stylus Photo R285 Manuel utilisateur

Epson

Epson XP-422 Instructions d'installation et d'entretien

Epson

Epson AcuLaser C8600 Manuel utilisateur

Epson

Epson DFX-9000 Manuel utilisateur

Epson

Epson TM H6000V-213P1 Manuel utilisateur

Epson

Epson Epson Stylus Photo P50 Series Mode d’emploi

Epson

Epson WorkForce AL-M200DN Manuel utilisateur

Epson

Epson TM-T88III series Manuel utilisateur

Epson

Epson R320 - Stylus Photo Color Inkjet Printer Manuel utilisateur

Epson

Epson Stylus Photo PX710W Series Instructions de montage

Epson

Epson R280 - Stylus Photo Color Inkjet Printer Manuel utilisateur

Epson

Epson Stylus Photo 700 Manuel utilisateur

Epson

Epson R300 - Stylus Photo Color Inkjet Printer Manuel utilisateur

Epson

Epson FX-880+ Manuel utilisateur

Epson

Epson Stylus Pro 3880 Graphic Arts Edition Manuel de programmation

Epson

Epson C2800 Manuel utilisateur

Epson

Epson L130 Mode d’emploi

Epson

Epson AcuLaser CX17 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur
