EPSON OPOS ADK MANUAL

APPLICATION DEVELOPMENT

GUIDE

POSPrinter

(TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM

-T83IIIM)

Version 3.00 Apr. 2021

Notes

(1) Reproduction of any part of this documentation by any means is prohibited.

(2) The contents of this documentation are subject to change without notice.

(3) Comments and notification of any mistakes in this documentation are gratefully

accepted.

(4) This software cannot be used with other equipment that the specified.

(5) EPSON will not be responsible for any consequences resulting from the use of any

information in this documentation.

Trademarks

Microsoft®, Windows®, Windows Server®, Visual Basic® and Visual C++® are

trademarks or registered trademarks of Microsoft Corporation in the United States and/or

other countries.

QR Code is a registered trademark of Denso Wave Incorporated.

EPSON® and ESC/POS® are registered trademarks of Seiko Epson Corporation.

Other product and company names used herein are for identification purposes only and

may be trademarks or registered trademarks of their respective companies.

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

iii

Contents

SECTION 1. INTRODUCTION .......................................................................................1

SECTION 2. DETAILS ON SETTINGS ..........................................................................2

2.1 References of Firmware Versions ..............................................................................2

2.2 Settings of DIP Switches ............................................................................................2

2.3 Port Information..........................................................................................................2

2.4 Device Settings ............................................................................................................3

2.4.1 Usable Device Specific Settings...........................................................................3

2.4.2 Multilingual font Setting ...........エラー! ブックマークが定義されていません。

SECTION 3. FUNCTION DETAILS................................................................................4

3.1 Property Set Values and Default Values...................................................................4

3.1.1 Capability Set Values...........................................................................................4

3.1.2 List Properties ......................................................................................................6

3.1.3 Width and Height Properties...............................................................................9

3.1.4 Common Property Strings .................................................................................10

3.1.5 PageMode Print Properties................................................................................10

3.2 Methods......................................................................................................................11

3.3 Escape Sequences......................................................................................................12

3.4 Printable Barcode Type ............................................................................................13

3.5 MAXI CODE Printing...............................................................................................14

3.5.1 Symbology Parameter ........................................................................................14

3.5.2 Printing Size .......................................................................................................14

3.5.3 Printing Position.................................................................................................14

3.5.4 Data Format........................................................................................................14

3.6 QR CODE Printing....................................................................................................16

3.6.1 QR CODE Printing.............................................................................................16

3.6.2 Printing Size .......................................................................................................16

3.6.3 Error Correction Level .......................................................................................16

3.6.4 Printing Position.................................................................................................16

3.7 GS1 Printing (two dimension)..................................................................................17

3.7.1 Symbology Parameter ........................................................................................17

3.7.2 Printing Size .......................................................................................................17

3.7.3 Printing Position.................................................................................................17

3.7.4 Data Format........................................................................................................17

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

3.8 COMPOSITE Printing ..............................................................................................18

3.8.1 Symbology Parameter ........................................................................................18

3.8.2 Printing Size .......................................................................................................18

3.8.3 Printing Position.................................................................................................18

3.8.4 Data Format........................................................................................................19

3.9 Power Condition Reports..........................................................................................20

3.10 Synchronous Processing .........................................................................................20

3.11 Printing Positions....................................................................................................20

3.12 Electronic Logo Function (NVRAM) ......................................................................21

3.13 Printable bitmap types and sizes...........................................................................21

3.14 Maintenance Counter .............................................................................................22

3.15 Automatic Recovery Function ................................................................................22

3.16 Output without Flow Control on the USB/Ethernet Interfaces ..........................22

SECTION 4. WARNINGS ..............................................................................................23

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

Section 1. Introduction

This manual describes the method of use and related items, as well as machine-specific

precautions, when the EPSON TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III Series POS

Printers are used with the EPSON OPOS ADK program.

This manual applies to the following devices.

Device List

Serial

USB

Ethernet

TM-T82XM

TM-T82XMU

TM-T82XME

TM-T81IIIM

TM-T81IIIMU

TM-T81IIIME

TM-T82IIIL

TM-T82IIILU

TM-T82IIILE

TM-T83IIIM

TM-T83IIIMU

TM-T83IIIME

Before reading the manual, see the following explanation about the characteristic of the

TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III printers.

•TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III

Station: Receipt (Line Thermal 203 dpi X 203 dpi)

Compatibility mode

The compatibility mode for upward compatibility was added in OPOS Ver2.60.

For the details of the compatibility mode, please refer to “EPSON OPOS ADK MANUAL

APPLICATION DEVELOPMENT GUIDE Compatibility Mode”.

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

Section 2. Details on Settings

This section describes connection configurations and how to make the settings for the

TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III Series printers.

2.1 References of Firmware Versions

Refer to the release notes (Relnote.txt/SupportedDevicesList.txt).

2.2 Settings of Memory Switches

Please check device specification sheet.

2.3 Port Information

1) Port information when serial port is used

The port information that can be set with the SetupPOS utility is as follows.

Item

Setting range

Baud rate [bps]

2400, 4800, 9600, 19200, 38400,57600,

115200

Bit length [bit]

Parity

NONE, ODD, EVEN

Stop bit [bit]

Handshake

DTR/DSR

The default settings are as shown in the following table.

Item

Setting range

Baud rate [bps]

38400

Bit length [bit]

Parity

NONE

Stop bit [bit]

Handshake

DTR/DSR

The baud rate setting of device is set using the Utility.

For details, please refer to the “Utility User's Manual”.

2) Port information when using USB port

Not applicable

3) Port information when using Ethernet port

Not applicable

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

2.4 Device Settings

The following explanation is about the settings for the

TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III models.

2.4.1 Usable Device Specific Settings

For the TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM models, the following

device specific settings are settable by the SetupPOS utility. For the detail, please

refer to the corresponding part of the Section 2 of “EPSON OPOS ADK MANUAL

APPLICATION DEVELOPMENT GUIDE POSPrinter (TM Series)”

Tab

Settings

General

Disable panel buttons

Assume print complete when data output finishes

Homogenize Error Codes *1

Ignore firmware version check

Output complete timeout [s]

Paper

Paper Type

Paper Width [mm]: LineWidth [dot]: LineCharsList

Bitmap

TMFlogo...

NVRAM

Color Bitmap

Halftone: Method

Halftone: Brightness

Color: Primary

Status Log

ERROR

OFFLINE

Log file name (full path name)

Maximum file size [KB]

Default Value

Multilingual font

Printing Properties

Receipt Characters per Line

Receipt Line Spacing [dots]

CharacterSet [CodePage Number]

*1 The settings can be changed when using a connection other than serial.

2.4.2 Multilingual font Setting

The TM-T82XM/TM-T81IIIM/TM-T83IIIM supports the following font type.

•CHINA GB18030

•TAIWAN BIG-5 (TM-T82XM only)

•VIETNAMESE

•THAI 3 PASS

•THAI 1 PASS

The default font type is set to CHINA GB18030.

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

Section 3. Function Details

This section describes the functions of the

TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM models in details. Supplementary

explanation of the parts not described in detail in the "UPOS" is also given here.

3.1 Property Set Values and Default Values

The following explanation is about the property set values and the default values.

3.1.1 Capability Set Values

The following values are the Capability set values.

Capability Name

Setting Value

CapTransaction

TRUE

CapCoverSensor

TRUE

CapConcurrentRecSlp

FALSE

CapConcurrentJrnSlp

FALSE

CapConcurrentJrnRec

FALSE

CapConcurrentPageMode

FALSE

CapCharacterSet

PTR_CCS_KANJI

CapMapCharacterSet

FALSE

CapJrnUnderline

FALSE

CapJrnNearEndSensor

FALSE

CapJrnItalic

FALSE

CapJrnEmptySensor

FALSE

CapJrnDwideDhigh

FALSE

CapJrnDwide

FALSE

CapJrnDhigh

FALSE

CapJrnColor

CapJrnCartridgeSensor

CapJrnBold

FALSE

CapJrn2Color

FALSE

CapJrnPresent

FALSE

CapRecPageMode

TRUE

CapRecRuledLine

FALSE

CapRecUnderline

TRUE

CapRecStamp

FALSE

CapRecRotate180

TRUE

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

CapRecRight90

TRUE

CapRecPapercut

TRUE

CapRecNearEndSensor

FALSE

CapRecMarkFeed

CapRecLeft90

TRUE

CapRecItalic

FALSE

CapRecEmptySensor

TRUE

CapRecDwideDhigh

TRUE

CapRecDwide

TRUE

CapRecDhigh

TRUE

CapRecColor

PTR_COLOR_PRIMARY

CapRecCartridgeSensor

CapRecBold

TRUE

CapRecBitmap

TRUE

CapRecBarCode

TRUE

CapRec2Color

FALSE

CapRecPresent

TRUE

CapSlpUnderline

FALSE

CapSlpRotate180

FALSE

CapSlpRight90

FALSE

CapSlpNearEndSensor

FALSE

CapSlpLeft90

FALSE

CapSlpItalic

FALSE

CapSlpEmptySensor

FALSE

CapSlpDwideDhigh

FALSE

CapSlpDwide

FALSE

CapSlpDhigh

FALSE

CapSlpColor

CapSlpCartridgeSensor

CapSlpBothSidesPrint

FALSE

CapSlpBold

FALSE

CapSlpBitmap

FALSE

CapSlpBarCode

FALSE

CapSlp2Color

FALSE

CapSlpFullslip

FALSE

CapSlpPresent

FALSE

CapSlpPageMode

FALSE

CapSlpRuledLine

FALSE

*1 If Thai 3 Pass character model or VIETNAMESE character model,

“PTR_CCS_UNICODE” is set.

*2 If Thai 3 Pass character model or VIETNAMESE character model, “TRUE” is set.

Version 3.00 Apr. 2021

APPLICATION DEVELOPMENT GUIDE

POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)

3.1.2 List Properties

The List Properties are explained in the following.

TM-T82XM:

List Property

Settings

CharacterSetList (Simplified Chinese)

”120, 121, 126, 130, 131, 150, 151, 152, 153, 154, 155,

255, 437, 720, 737, 775, 850, 851, 852, 853, 855, 857,

858, 860, 861, 862, 863, 864, 865, 866, 869, 936, 998,

999, 1098, 1125, 1250, 1251, 1252, 1253, 1254, 1255,

1256, 1257, 1258”

(Traditional Chinese)

”120, 121, 126, 130, 131, 150, 151, 152, 153, 154, 155,

255, 437, 720, 737, 775, 850, 851, 852, 853, 855, 857,

858, 860, 861, 862, 863, 864, 865, 866, 869, 950, 998,

999, 1098, 1125, 1250, 1251, 1252, 1253, 1254, 1255,

1256, 1257, 1258”

(Thai1 Pass)

“437, 874”

(Thai3 Pass and Vietnamese)

“120,121,126,130,131,437,997

”

JrnLineCharsList

“”

RecLineCharsList 79.5mm: (Font A) “48”

(Font B) “64”

57.5mm: (Font A) “35”

(Font B) “46”

SlpLineCharsList

“”

RecBarCodeRotationList

“0, R90, L90, 180”

RecBitmapRotationList

”0, R90, L90, 180”

SlpBarCodeRotationList

“”

SlpBitmapRotationList

“”

FontTypefaceList

“”

*1 All characters loaded in the device are allocated to Unicode for printing. However, the

BinaryConversion property should be set to "OPOS_BC_NONE" when printing with

Unicode.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Epson Imprimante

Epson

Epson C1100 - AcuLaser Color Laser Printer Manuel utilisateur

Epson

Epson 1400 - Stylus Photo Color Inkjet Printer Manuel utilisateur

Epson

Epson FX-2175II Manuel utilisateur

Epson

Epson FX-286 - Impact Printer Manuel utilisateur

Epson

Epson AcuLaser M7000N series Manuel utilisateur

Epson

Epson WF-C5310 Manuel utilisateur

Epson

Epson LQ-570e Manuel utilisateur

Epson

Epson WF-7211 Manuel utilisateur

Epson

Epson Stylus Color 850 Caractéristiques techniques

Epson

Epson Stylus Color 800 Manuel utilisateur

Epson

Epson Stylus Pro 10000 Series Manuel de la liste des pièces

Epson

Epson TM-U200 Series Manuel utilisateur

Epson

Epson TM-S9000MJ Manuel utilisateur

Epson

Epson WF-C579R Series Manuel utilisateur

Epson

Epson TM-U210 Manuel utilisateur

Epson

Epson Stylus COLOR 1160 Guide d'installation

Epson

Epson 3800 - Stylus Pro Color Inkjet Printer Manuel utilisateur

Epson

Epson C31CA26031 - TM C3400 SecurColor Color Inkjet... Manuel d'utilisation et d'entretien

Epson

Epson 5700i - EPL B/W Laser Printer Manuel utilisateur

Epson

Epson TM-H6000II M147B Manuel utilisateur

Epson

Epson B-510DN - Business Color Ink Jet Printer Manuel utilisateur

Epson

Epson workforce wf-2630 Manuel utilisateur

Epson

Epson Expression Home XP-305 Instructions de montage

Epson

Epson Stylus Pro 4880 ColorBurst Edition - Stylus Pro 4880... Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur
