Professional Imaging SureColor®S-Series Maintenance Guide

Supplies

Follow the instructions below to perform short- and long-term maintenance of an Epson® SureColor S-Series printer.

For more information, see your User’s Guide, view instructional videos at www.proimaging.epson.com,

or visit epson.com/support.

Maintenance is performed on the schedule below or if ink drops, head strikes, or other print quality issues arise.

Standard User: Every 4 days Time: Approximately 10-15 minutes

Medium User: Every 2 days Supplies Required: Large cleaning sticks, ink cleaner kit, T-wiper, wiper cleaner, lint-free cloths.

Heavy User: Once a day Process: With large cleaning stick soaked in ink cleaning uid, follow the guide below.

Routine Maintenance

Large cleaning sticks

(x25)

Gloves

(x2)

T-wiper Flushing pads

(x2)

Wipers

(x2)

Wiper cleaners

(x2)

Ink cleaner kit (part #T699300) Cleaning cartridge (part #T699000)

Lint-free cloths

(not supplied by Epson; check with

your dealer for the correct cloth)

Clean platen and media

edge guides.

Clean print head(s) and

surrounding areas. Be careful

not to touch ink channels as

you clean from back to front.

Clean wiper(s). Remove

wiper(s) and clean

attachment area(s).

Clean capping stations and

remove any debris from

around the caps.

Clean wiper rail(s).

Clean print head surface(s).

Starting from the inside, move

the T-wiper towards you.

To prevent damage to the

print head, do not move the

T-wiper back and forth.

Maintenance is performed on the schedule below or if ink drops, head strikes, or unrecoverable print quality issues arise.

Standard User: Every 5-6 months Time: Approximately 10-15 minutes

Medium User: Every 3-4 months Supplies Required: Flushing pads, wiper cleaner, wipers.

Heavy User: Every 1-2 months Process: Replace parts and empty the waste ink bottle (as required).

Long-term Maintenance

Replace flushing pad

Replace wiper cleaner(s)

Empty waste ink bottle

Replace wiper(s)

Head washing should only be performed if a standard head cleaning (progressive up to heavy cleaning) and head

maintenance did not solve unrecoverable nozzles or degraded print quality due to deected or missing nozzles.

Head washing is performed on one or more channels. Performing head washing will completely drain the ink from the

selected channels, ll the channels with cleaning solution, and then reinitialize the ink channel.

Time: approximately 40 minutes

Supplies Required: Cleaning cartridges, one per channel that needs cleaning. Note that cleaning cartridges can be used

at least 2 times, depending on previous use.

Process: With the printer powered on, select Head Washing from the Maintenance menu, and follow the instructions on

the printer’s control panel.

Head Washing

EPSON and SureColor are registered trademarks of Seiko Epson Corporation.

General Notice: Other product names used herein are for identication purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights

in those marks.

This information is subject to change without notice.
