Epson Stylus Pro 7890 Series Manuel utilisateur

Our Next Generation.

Epson Professional Imaging Division | Product Presentation

Version 1.2 ae

What Deﬁnes an Epson Stylus® Pro Branded Printer?

“To develop printing technology that exceeds the

expectations of Creative Professionals.”

“To allow any print to be sold.”

Product Feature Set Highlights

Contact your local reseller for the latest pricing information.

(Pricing shown is MSRP)

Epson Stylus Pro 7890 – 24” $2,995

Epson Stylus Pro 9890 – 44” $4,995

Printer ships with printer stand,

media catch bin, and 110 ml

starter ink cartridges.

Eight-Channel MicroPiezo® TFP® Print Head

Epson UltraChrome K3® with Vivid Magenta Ink Technology

Nine Individual High-Capacity Ink Cartridges – up to 700 ml

Automatic Black Ink Mode Switching

Handles Roll or Cut-Sheet Media from Letter up to 44” wide

ePlaten™ Media Loading Technology

Spindle-Free Roll Media Loading

Roll Media Length Tracking & Identiﬁcation System

BorderFree® Roll Printing from 10-Inch up to 44-Inch Wide

Accepts Media up to 1.5 mm Thick Poster board

Built-in Automatic Rotary Media Cutting System

Maximum Resolution of 2880 x 1440 dpi at 3.5 Picoliter

AccuPhoto™ HD Screening Technology

Pressurized Ink Cartridge Technology

Automatic Nozzle Veriﬁcation Technology

Automatic Head Alignment & Cleaning Systems

Standard USB 2.0 & 10/100 BaseT Ethernet

Large 2.5-Inch Color LCD Control Panel

PreciseColor™ Manufacturing Process

myEpsonPrinter.comsm Compatible

Optional SpectroProofer® Spectrophotometer

Optional Automatic Take-Up Reel System (9890 Only)

New Low Noise Design for Extremely Quiet Operation

One-Year Epson Preferredsm Protection Plan

Epson Stylus Pro 9890 Printer Shown Above

NEW

Product Shipping December 2010

NEW

Epson Stylus® Pro 7890 / 9890 Series

Epson Stylus Pro 9890

73.4”(W) x 26.3”(D) x 48”(H) | 256 lb.

Front View

Photo Walkthrough

Epson Stylus Pro 7890

53.4”(W) x 26.3”(D) x 48”(H) | 187 lb.

24” 44”

Epson Stylus® Pro 7890 / 9890 Series

Epson Stylus Pro 9890 Shown

Right Ink Bay Door

Front Control Panel

Robust Print Stand

Front View

Photo Walkthrough

Left Ink Bay Door

Fabric Catch Bin

Roll Media Loader

Front Printer Door Cut Sheet Loader

Rotary Cutter

2.5” Color LCD

VM LK LLK VLM

YLC MK PK

Epson Stylus® Pro 7890 / 9890 Series

Front Control Panel View

2.5-Inch Color LCD Initiate Black Ink Switch ePlaten Release

Electronic Ink Door Covers Rotary Cutter

Photo Walkthrough

Delete or Cancel Job Button

Epson MicroPiezo TFP Print Head Technology

The World’s Most Advanced Inkjet Print Head Technology

Epson MicroPiezo TFP Print Head Technology

Variable Droplet Piezo | Advanced Thin Film Piezo (TFP) | 360 Nozzles x 8 Channels | 3.5 Picoliters

One-Inch Wide Print Head

Ink Repelling Coating Technology

Epson Stylus Pro 7890/9890 Series

8-Channel Print Head Technology

360 Nozzles Per Inch

Epson Stylus Pro 7890/9890 Series

Auto-Sharing Black Channel

Epson MicroPiezo TFP Print Head Technology

Perfectly Round & Consistent DropletsExtreme Dot Placement Accuracy

~ 210X Magnification

~ 1,420X Magnification

Source: Seiko Epson Engineering

Low Vibration Meniscus and High Impact Control Technology Examples Shown Above

Print Head Direction

The World’s Most Advanced Inkjet Print Head Technology

Actual Ink Droplet on Paper

Epson MicroPiezo TFP print head technology allows the printer to share the same

physical ink channel between both Matte and Photo Black inks

The correct black ink mode is automatically used depending upon the printer driver

or front control panel settings

The process of switching between black ink modes is automatic

To reduce user errors, the user must confirm the switch at the front control panel

This technology is similar to the auto-switching process of the Epson Stylus Pro 7900

and 9900 Series printers

Black Ink Conversion

Conversion Time

Ink Used

Photo Black to Matte Black

~2:07 min:sec

~1.13 ml

Matte Black to Photo Black

~2:55 min:sec

~3.34 ml

Epson MicroPiezo TFP Print Head Technology

User Verified Automatic Black Ink Mode Switching
