Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
1.) Ensure the network cable is connected to the printer and the printer is powered ON. To nd your IP
address, press the Right (menu) button located on the control panel of the printer (see FIGURE 1)
FIGURE 1
2.) Press the Down button to locate/highlight NETWORK SETUP, then Press the Right button to select
NETWORK SETUP (see FIGURE 2).
FIGURE 2
NOTE: DHCP must be enabled in your network conguration. In a DHCP environment, the IP
address may change periodically. As a result, this procedure will need to be repeated each time
the IP address changes.
IMPORTANT: Before proceeding, please ensure the Epson (OEM) printer driver and Sawgrass
PowerDriver or Winprole have been installed. For assistance with driver or prole installation, please
refer to the Installation Guide.
1
2
1
PAGE 2 of 9 >>
Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
3.) Press the Right button to select NETWORK SETUP (see FIGURE 3).
FIGURE 3
1
4.) Press the Down button to locate/highlight ENABLE, then Press the OK button to select ENABLE (see
FIGURE 4).
FIGURE 4
2
1
5.) Press the Left button to return to the previous screen (see FIGURE 5).
FIGURE 5
1
PAGE 3 of 9 >>
Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
6.) Press the Down button to locate/highlight IP ADDRESS SETTING, then Press the Right button to select
IP ADDRESS SETTING (see FIGURE 6).
FIGURE 6
7.) Press the Down button to locate/highlight PANEL, then Press the OK button to select PANEL (see
FIGURE 7).
FIGURE 7
2
1
8.) Press the Left button to return to the previous screen (see FIGURE 8).
FIGURE 8
1
2
1
PAGE 4 of 9 >>
Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
9.) Press the Down button to locate/highlight IP,SM,DG SETTING, then Press the Right button to select
IP,SM,DG SETTING (see FIGURE 9).
FIGURE 9
10.) Record the IP address number as this will be needed for conguring the port later (see FIGURE 10).
FIGURE 10
2
1
PAGE 5 of 9 >>
SubliJet-E Professional & SubliJet IQ Pro Photo: Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
11.) In the bottom left-hand corner of your desktop, click the Start icon and select Devices and Printers
(see FIGURE 11).
NOTE: If you are using an older version of Windows OS, you will instead select Printers and
Faxes.
1
2
FIGURE 11
12.) In the Devices and Printers folder, right-click the Epson Stylus Pro 7700/9700 or Epson Stylus Pro
7890/9890 icon and select Printer Properties (see FIGURE 12). This will open the Epson Stylus Pro
Properties window (see FIGURE 13).
FIGURE 12
1
2
PAGE 6 of 9 >>
SubliJet-E Professional & SubliJet IQ Pro Photo: Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
13.) In the Properties window, click the Ports tab and click Add Port... (see FIGURE 13).
FIGURE 13
2
1
14.) In the Printer Ports window, select Standard TCP/IP Port and click New Port... (see FIGURE 14).
FIGURE 14
2
1
NOTE: When printing to multiple printers, simultaneously and from one work station, you will
need to install PowerDriver-E and assign a new “Local Port” for each printer.
PAGE 7 of 9 >>
SubliJet-E Professional & SubliJet IQ Pro Photo: Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
xx.x.x.xxx
Type Custom Name Here
15.) The following window will appear instructing you to power ON the printer and ensure the network is
connected and congured. Click Next to continue (see FIGURE 15).
16.) In the Printer Name or IP Address eld, type in your IP address from Step 10. In the Port Name eld,
name your port for easy identication. When nished, click Next to continue (see FIGURE 16).
FIGURE 16
2
3
1
FIGURE 15
NOTE: You will need to drop any preceding 0’s from your IP address. For example, if your IP
address is 010.000.000.073, you will need to enter 10.0.0.73 instead.
PAGE 8 of 9 >>
SubliJet-E Professional & SubliJet IQ Pro Photo: Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
17.) Click Finish to complete the setup (see FIGURE 17).
FIGURE 17
18.) Click Close to exit the Printer Ports wizard (see FIGURE 18).
FIGURE 18
SubliJet-E Professional & SubliJet IQ Pro Photo: Epson Stylus Pro 7700/9700/7890/9890
Network Printer Sharing
PAGE 9 of 9 >>
19.) Click Apply to save your changes and click Close (see FIGURE 19).
FIGURE 19
1
Congratulations! You have successfully congured the Epson Stylus Pro driver for printing over a network.
For the absolute latest information and updates on all products, materials, processes and/or
procedures relative to all offerings by or through Sawgrass Technologies, Inc., refer to our website:
www.sawgrassink.com
