Where to Find Information

This User’s Guide

Provides you with all the information you need to use your

EPSON STYLUS PHOTO 700, and their consumable products,

from setting up to troubleshooting.

Online Help

Provides you with detailed information and instructions on the

printer software that controls your printer (online help will be

automatically installed when you install the printer software).

EPSON Answers (for Windows®95 and 3.1)

Provides Windows 95 and 3.1 users with additional information

on using your printer and printing with colors. Here’s what you’ll

find in EPSON Answers:

How To displays a step-by-step guide for using your printer,

information about printer maintenance, and instructions on

replacing consumable products.

Problem Solver helps you fix common printing problems

when you encounter them.

Test Print lets you print a test page to check the results of

settings you have made, and provides links to other sections of

EPSON Answers based on the results.

Color Guide explains the ABC’s of color printing, and shows

you how to get impressive results from your printer.

(A printed Color Guide is also included with your printer.)

Color Guide

Explains how color printing works and shows you how to get

impressive results from your printer.

LComoro+

Rev.C

A5 size cover-2

12-05-97 DR, pass 0

Color Ink Jet Printer

system, or transmitted in any form or by any means, electronic, mechanical, photocopying,

recording, or otherwise, without the prior written permission of SEIKO EPSON

CORPORATION. The information contained herein is designed only for use with this

EPSON printer. EPSON is not responsible for any use of this information as applied to

other printers.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of

this product or third parties for damages, losses, costs, or expenses incurred by the

purchaser or third parties as a result of: accident, misuse, or abuse of this product or

unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.)

failure to strictly comply with SEIKO EPSON CORPORATION’s operating and

maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable for any damages or problems arising

from the use of any options or any consumable products other than those designated as

Original EPSON Products or EPSON Approved Products by SEIKO EPSON

CORPORATION.

EPSON and EPSON ESC/P are registered trademarks and EPSON ESC/P Raster and

EPSON Stylus are trademarks of SEIKO EPSON CORPORATION.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

General Notice: Other product names used herein are for identification purposes only and may be

trademarks of their respective owners. EPSON disclaims any and all rights in those marks.
