Epson PictureMate - Compact Photo Printer Mode d’emploi

Using PictureMate

With a Computer

CPD-17895R2

Printed in XXXXXX XX.XX-XX XXX

Follow These Easy Steps

To use PictureMate™ with your computer, you’ll need to:

Install the software on your computer

from the PictureMate CD.

Follow the steps in this booklet.

Connect PictureMate to your computer.

The steps here tell you how and when

to connect.

View the on-screen

User’s Guide

Click PictureMate User’s Guide right on

your computer screen for steps on using

PictureMate with your computer. It’s your

comprehensive guide to PictureMate.

Where To Get Help

If you need additional help with PictureMate, see “Where To Get Help”

in the Using PictureMate Without a Computer book.

PictureMate Accessories

You can purchase a PictureMate Print Pack

(with 100 sheets of PictureMate Photo Paper

and a PictureMate Photo Cartridge), a USB

cable, and other PictureMate accessories

from the Epson StoreSM at (800) 873-7766 or

visit www.epsonstore.com (U.S. sales only).

In Canada, please call (800) 463-7766 for

dealer referral.

Installing Software and Connecting PictureMate

To connect PictureMate, you’ll need this cable:

If you don’t already have a USB cable, you can buy one from your local

computer dealer or from Epson.

®See the inside back cover for details.

When you’re ready to start, see the section for your computer system:

■For Windows,

®see below.

■For Macintosh,

®see page 6.

Install PictureMate for Windows

First make sure PictureMate is NOT CONNECTED to your computer,

and REMOVE your memory card, if it’s inserted. Then:

1. Load a sheet of PictureMate Photo Paper,

glossy side up, against the right edge of the

paper feeder. Slide the edge guide against

the paper and open the output tray.

2. Press the POn button to turn on PictureMate.

3. Turn on your computer.

Type A to B

USB cable

4. Wait a minute for your computer to

start up, then insert the PictureMate

CD in your CD-ROM or DVD drive.

5. After a moment, you see this screen:

Read the license agreement and click

AGREE.

Note:

If you see a screen like this,

remove your memory card from

PictureMate and click the Xin the

upper right corner to close the screen,

if necessary.

Note:

If you see a screen like this,

click Cancel and disconnect

PictureMate from your computer.

Then turn off your computer and

begin again at step 3.

If you see a New Hardware Found

message at the bottom of your screen,

click the Xin the box to close it.

6. When you see this screen, click OK to begin installing your software.

7. When you see this screen, connect the square end of your USB cable to

PictureMate. Then connect the flat end of the USB cable to your

computer. (You can connect it to any open USB port.)

Note:

Make sure the PictureMate handle is pushed all the way down in back

before connecting the USB cable.

On Windows 98SE, you see an Add New Hardware Wizard screen. Click

Next, select the Search for option, and select CD-ROM drive. Follow the

on-screen instructions to finish installing the necessary software.

8. When you see this screen, click OK to print a 4 × 6-inch sample photo.

You see a progress screen as it prints. (If it doesn’t print, see page 12.)

Wait until printing finishes before continuing with step 9.

9. When printing finishes, click Next to install the on-screen User’s Guide

and more software.

10. When you see this screen, you can install additional photo software:

Click Epson Software Film Factory, then click Install on the next

screen and follow the on-screen instructions.

Note:

If you are asked if you want to install QuickTime,

®click Yes and follow the

on-screen instructions; you don’t need a registration number. Also

uncheck the boxes for launching QuickTime and Film Factory™at the end

of their installations.

11. When you’re done installing software, click Exit. The registration screen

appears. Follow the on-screen instructions to register PictureMate.

12. You see a prompt to restart your computer. Click OK, then restart your

computer.

13. Remove and store your PictureMate CD.

You’re ready to store or print your photos! Insert your memory card or

open your photo file on your computer, as described in the on-screen

User’s Guide.

Double-click the PictureMate User’s Guide icon on your screen to view

the User’s Guide. Follow the steps there to use PictureMate with your

computer.

Install PictureMate for Macintosh

1. If you inserted a memory card, remove it from PictureMate.

2. Connect the square end of your USB cable to PictureMate. Then

connect the flat end of the USB cable to any open USB port on your

Macintosh.

3. Press the POn button to turn on PictureMate.

4. Turn on your Macintosh and wait a minute for it to start up.

5. Insert the PictureMate CD in your CD-ROM or DVD drive.

6. Double-click the PictureMate CD icon, if necessary, then

double-click PictureMate.

7. After a moment, you see this screen:

Read the license agreement and click AGREE.

8. When you see the Install Menu, click Install Printer Driver and

Utilities. Follow the on-screen instructions to install several programs.

Note:

With OS X, you’ll need to enter your password several times as you

install.

9. When you return to the Install Menu, click Install Optional Software.

You see this menu:

10. Click Epson Software Film Factory, then click Install on the next

screen and follow the on-screen instructions.

11. When you return from the Film Factory installation screens, click Back.

12. At the Install Menu, click Install Printer Manual to install your

on-screen User’s Guide.

13. When you’re done installing software, click Exit. The registration screen

appears. Follow the on-screen instructions to register PictureMate.

14. You see a prompt to restart your Macintosh. Click OK, then restart

your Macintosh.

After restarting, you must select PictureMate as your Macintosh printer.

See page 9 (Mac®OS X) or page 11 (Mac OS 9).
