EPH Controls COMBIPACK4 Mode d'emploi

Installation and Operation Guide

COMBIPACK4

RFRP-OT Room Thermostat

Installation Instructions

Factory Default Settings

Specications

How your programmable thermostat works

RF1A Wireless Receiver

RFRP-OT Room Thermostat

Installation Instructions

Operating Instructions

Table of contents

Frost Protection

Mounting & Installation

Resetting the thermostat

Keypad lock and unlock

Setting the date, time and programming mode

Specications & Wiring

Button Description

LCD Symbol Description

Factory Program Setting

Installer menu

Frost Protection

TPI

PO 2 Setting high & low limits

PO 3 Hysteresis H On and H O

Optimum Start

Normal

PO 1 Operating Mode

Adjust the program setting in 5/2 Day mode

Copy Function

Temporary Override

Permanent Override

Boost Function

Holiday Function

Battery low warning

Backlight mode selection

Replacing the batteries

PO 4 Calibrate the thermostat

Programming Modes

PO 5 Frost Protection

PO 6 Exit

RFRP-OT Room Thermostat (Continued)

Installer menu - OpenTherm

PO 6 Setting DHW temperature

PO 8 DHOP

PO 9 Set OpenTherm® parameters

Controlling an OpenTherm Boiler with multiple CombiPack 4-OT

RF1A Wireless Receiver

Operating Instructions

Table of contents (Continued)

PO 7 OpenTherm® Information

Exit

System Architecture

LED Description

To disconnect the RFRP-OT thermostat to an RF1A-OT receiver

Button / LED Description

To connect the RFRP-OT thermostat to an RF1A-OT receiver

RFRP-OT Room Thermostat

Installation Instructions

6RFRP-OT Room Thermostat CombiPack4

RFRP-OT Room Thermostat

Factory Default Settings

Temperature indicator: ˚C

Switching dierential: 0.4˚C

In built frost protection: 5˚C - Not adjustable

Clock: 24 hours

Keypad lock: O

Operating mode: 5/2 day

Frost Protection 5˚C

Frost protection is built into this thermostat.

It is pre xed at 5°C and is not adjustable.

It will only be activated when the thermostat is in the OFF mode and the

room temperature falls below 5°C.

RFRP-OT Room Thermostat CombiPack4

Specications

Power supply: 2 x AA Alkaline Battery

Power consumption: 2 mW

Battery replacement: Once a year

Temp. control range: 5 … 35˚C

Ambient temperature: 0 … 45˚C

Dimensions: 130 x 99 x 25mm

Temperature sensor: NTC 100K Ohm @ 25˚C

Temperature indication: ˚C

Switching dierential: 0.4˚C

Frost protection: Only operational in O mode

Pollution degree: Pollution degree 2

8RFRP-OT Room Thermostat CombiPack4

When the thermostat is in the AUTO mode, it will operate according

to the times and temperatures that have been programmed. The user

can select from 6 dierent programs per day - each with a time and a

temperature.

There is no OFF time, only a higher and a lower temperature.

If the user wants the thermostat to be OFF at a certain time, set the

temperature for this time to be low. The thermostat will turn ON if the

room temperature is lower than the setpoint for the current period.

Example: If P1 is set to be 21˚C at 6am, and if P2 is set to be 10˚C at

8am, the thermostat will look for the temperature to be 21˚C between

6am and 8am.

How your programmable thermostat works

RFRP-OT Room Thermostat CombiPack4

Mounting & Installation

Caution!

Installation and connection should only be carried out by a qualied person.

Only qualied electricians or authorised service sta are permitted to open the

thermostat.

If the thermostat is used in a way not specied by the manufacturer, its safety may be

impaired.

Prior to setting the thermostat, it is necessary to complete all required settings

described in the section.

This thermostat can be mounted in the following ways:

1) Directly mounted on wall

2) Free standing - Stand Included

10 RFRP-OT Room Thermostat CombiPack4

1) The mounting height should be 1.5 metres above the oor level.

2) The thermostat should be wall mounted in the room where the

heating is to be controlled.

The place of installation should be chosen so that the sensor can

measure the room temperature as accurately as possible.

Choose the mounting location to prevent direct exposure to

sunlight or other heating / cooling sources when mounted.

3) Fix the mounting plate directly to the wall with the screws provided.

4) Attach the thermostat to the mounting plate.

5) Lower the ap at the front of the thermostat. There is a battery

compartment located below the buttons. Apply downward

pressure to remove the cover.

6) Insert the 2 x AA batteries and the thermostat will turn on.

Close the battery compartment.

Mounting & Installation (Continued)
