Epcom XMR401HD Manuel utilisateur

User manual for XMR401HD

User Manual

For

;05+'

Mobile Digital Video Recorder



User manual for XMR401HD

Notice

The information in this manual was current when published. The manufacturer reserves the right to

revise and improve its products. All specifications are therefore subject to change without any notice.

The purpose of this manual is to kindly aid the user for the operation for our MDVR. The user should

have a basic understanding of computer operation and basic knowledge of how to connect peripherals

and make some settings.

Under copyright laws, the content of this manual may not be copied, photocopied, reproduced,

translated or reduced to any electronic medium or machine- readable form, in whole or in part, without

prior written consent of Streamax Technology Co., Ltd. Copyright (2013-2015)

User manual for XMR401HD

Guarantee & Warnings

1) Electrical Apparatus Safety

All installation and operation should comply with local electrical safety norms.

2) Transportation

In the process of transportation, storage and installation, please avoid heavy stress, violent vibration,

impact and water splashing.

3) Installation

Install the equipment in accordance with the requirements, handle carefully. Do not heavily press the

equipment before the MDVR installation is finished.

4) Requirements on Engineers & Technicians

All the work of checking and maintenance should be done by qualified technicians and engineers.

We do not undertake any responsibility caused by unauthorized modifications.

5) Requirements on Environment

The equipment should be installed and stored in a cool and dry place, away from direct sunlight,

flammable or explosive substances, etc. Keep gaps not less than 3cm around the device to facilitate

ventilation for cooling.

6) Accessories

Make sure to use accessories from the manufacturer recommended in the attachment.

Insulate circuit ground and metal shell for all the peripherals.

Before installation, please open the package and ensure that all parts are included.

If there are any problems, please contact us as soon as possible.

User manual for XMR401HD

1. PRODUCT CHARACTERISTICS

1.1. OVERVIEW

XMR401HD is a functional Mobile Digital Video Recorder specially designed for vehicle

video surveillance. It has a high-speed processor and embedded operating system, combining with the

most advanced H.264 video compression / decompression technology, GPS positioning technology. It

supports video recording in 720P, WD1, WHD1, WCIF, D1, HD1 and CIF formats. It is easy to use with

simple design, multi-functions, superior anti-vibration, flexible installation and high reliability.

1.2. SPECIFICATIONS

Function Overview

Preview, Recording, Playback, Locating

System

Linux 3.0.8

Control Mode

Easy Check, CP4, mouse

Video

Input

4 channels WD1+1 channel 720P

Output

1 channel

Total Resource

(4x25)FPS WD1 @ PAL / (4x30)FPS WD1 @ NTSC

+30FPS 720P

Video Signal Standard

Electrical level: 1Vpp Impedance: 75Ω NTSC/PAL

Optional

Audio

Input

5channels (1 channel IPC audio input)

Output

1channel

Audio Signal Standard

Electrical level: 2Vpp Input impedance: 4.7kΩ

Display

Display Split

1/4/9

OSD

GPS information, alarm, vehicle No., speed,

date/time

Operation Interface

Semi-transparent GUI

Recording

Video/Audio Compression

Video: H.264

Audio: ADPCM, G.711A G.711U

Image Resolution

Analog:

PAL:

WD1(928X576),WHD1(928X288),

WCIF(464X288),D1(704X576),

HD1(704x288), CIF(352x288);

NTSC:

WD1(928X480),WHD1(928X240),

WCIF(464X240),D1(704x480),

HD1(704x240), CIF(352x240);

Digital:

720P(1280X720);

Image Quality

1-8 levels adjustable (1 is the best)

Recording Mode

Boot up/Manual/Schedule/Alarm

User manual for XMR401HD

Pre-recording

0-60minutes

Post-recording

0-30 minutes

Mirror/Dual Recording

Support

Playback

Playback Channel

1 channel by local playback

Search Mode

Date/time, channel, event

IPC Ethernet

6-pin DJ M12(100M x 1, PON power supply)

Locating

GPS

Location tracking, speed detection and time sync

Storage

SD card x 2

Interface

USB

USB2.0 x 1

RS232

RS232 × 1

Sensor

8 inputs, 2 outputs

Speed

1 channel pulse speed detection

Intercommunication

I MIC interface

Power

Input

DC8-36V, Ignition signal

Output

5V@500mA

Max Power Consumption

29W

Standby Power Consumption

≈0W

Physical

Characteristic

Dimension (L × W × H)(mm)

167.3 x 146.3 x 54.1

Weight

0.83Kg

Environment

Operating Temperature

-40℃- +70℃

Operating Relative Humidity

8%-90%（No Condense）

User manual for XMR401HD

1.3. SYSTEM DIAGRAM

1.4. EXTERNAL INTERFACE

DIMENSION (Unit: mm)

User manual for XMR401HD

FRONT PANEL

REAR PANEL

Serial No.

Description

Power

DC 8-36 V Power Input

Sensor&Serial

The Interfaces of Serial Port and Switch

A/V IN1~4

Audio & Video Input 1-4

A/V OUT

Audio & Video Output

IPC

The Interface of PON Power Supply

GPS Antenna Interface

User manual for XMR401HD

1.5. DEFINITION AND PICTURES OF EXTERNAL CABLES

ALARM CABLE DEFINITION

Alarm and Serial Cables A/V OUT Cable

2. FREQUENTLY ASKED QUESTIONS

1) The system can’t start?

Usually this problem results from the incorrect power connection. Please follow below steps to

check the power connection:

1. Check the input power, whether the power wire is connected correctly, whether the ground wire is

connected back to the battery, and whether the fuse on the power wire is in good condition.

2. Check whether the ACC signal wire input to the power is with voltage higher than 7 V.

3. Check whether the device key is closed.

2) The MDVR restarts uninterruptedly?

Please follow below steps to check it:

1. Check whether the voltage of MDVR is insufficient. If the voltage is less than the start-up voltage of

the device, the device would always restart.

2. The problem in hard disk/SD card may cause the failure to start. Take off the storage part and check

User manual for XMR401HD

whether it is broken down.

3) The device can’t record?

Usually this problem results from the storage disk or camera. Please follow below steps to check it:

1. Check whether the storage disk is installed, whether it is in good contact, and whether the disk can

be read normally in computer.

2. Check whether the storage disk is formatted. The storage disk should be formatted before normally

storing record files.

3. Check whether there is video signal input into the device from camera, and whether there is

video/image on the screen.

4) There is no voice in record file?

Please follow below steps to check it:

1. Check whether there is an external pickup, or whether the camera features with the function of

audio collection.

2. Access to Video Channel Settings, check if Audio is set on.

3. There must be video input into the channel for recording and it must record normally.

5) The GPS works abnormally?

Please follow below steps to check it:

1. Check whether the GPS antenna is installed correctly. There is a silk print logo on the GPS antenna

holder behind the host device.

2. Check whether the antenna receiver is sheltered. It should not be covered by any stuff, which may

cause it not to receive signals.

3. Environmental influence such as tree shades, being inside tunnel, driving near tall building or

elevated roads, thunderstorms or other weather influence, etc. can also cause signal loss or

receiving wrong signals.

6) The device can’t shutdown in ignition switch mode?

Please follow below steps to check it:

1. Check if the ACC line connection mode is correct; and check whether there is voltage on ACC

yellow line when the key is turned off.

2. If the device has been set with schedule recording, it can’t shutdown if it is still during recording time

of the task table.
