EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 1 of 62
EnGenius Mesh AP
M8000
User Manual & Configuration Guide
Version : 1.0
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 2 of 62
Table of Content
Table of Content 2
1 Docu ent History 4
2 Overview 5
3 EnGenius Mesh Web-based Interface 6
4 Syste 9
.1
System > System 9
.2
System > Syslog 10
.3
System > Advance 11
5 Network 13
5.1
Network > Network 13
5.2
Network > VLAN 1
5.3
Network > Mesh 16
5.
Network > Wireless 20
5.5
Network > Route 23
6 Service 25
6.1
Service > MAC Access 25
6.2
Service > NTP 27
6.3
Service > RADIUS 28
6.
Service > Linux Kernel Watchdog 31
6.5
Service > SSHD 32
6.6
Service > WME 33
6.7
Service > DHCP Relay 35
7 Manage ent 37
7.1
Management > HTTPD 37
7.2
Management > Configuration 39
7.3
Management > SNMP 2
7.
Management > Firmware 5
7.5
Management > Trap 6
7.6
Management > NMS Addresses 9
7.7
Management > Reboot 51
8 Tools 52
8.1
Tools > Ping 52
8.2
Tools > Ifconfig 53
8.3
Tools > Route 5
8.
Tools > TFTP 55
9 Status 56
9.1
Status > Status 56
9.2
Status > Interfaces 57
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 3 of 62
9.3
Status > Services 59
9.
Status > System Log 60
9.5
Status > Neighbor 61
10 Help 61
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page of 62
1Docu ent History
Revision
Date Re arks Authors
1.0 2008-0 -07 Draft Release
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 5 of 62
2Overview
The purpose of this document is to describe the detail features of EnGenius Mesh
Access Point (M8000), and also the procedure and methodology of configuring and
the use of EnGenius MAP.
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 6 of 62
3EnGenius Mesh Web-based Interface
Web-based configuration interface is accessible with computer with TCP/IP capability
and web browser (e.g. Mozilla or IE).To access web-based configuration interface,
enter
https://192.168.0.1/.
In the browser URL/Location field.
You will see an authentication page display as shown in Figure 3.1.1.
Figure 3.1.1: Windows authentication page
Type “ad in” in User Name and Password field, then click OK button.
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 7 of 62
EnGenius Mesh page has six main menus: System, Network, Services, Management,
Tools and Status. Each main menu also will have its submenu.
Welcome
System
System System settings
Syslog Syslog settings
Advance Advance tuning
Network
Network Network settings
VLAN VLAN settings
Mesh Mesh settings
Wireless Wireless settings
Route Route settings
Services
MAC Access Filter MAC address
NT Network Time rotocol
RADIUS RADIUS client settings
Linux Kernel Watchdog Linux Kernel Watchdog settings
SSHD SSHD Configuration
WME WME Settings
DHC Relay DHC relay settings
Management
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 8 of 62
HTT D Internal webserver settings
Configuration Configuration management
SNM SNM settings
Firmware Firmware maintenance
Trap Trap settings
NMS Addresses Network Management System notifying settings.
Reboot Reboot device
Tools
ing ing
Ifconfig Ifconfig
Route Route
TFT TFT
Status
Status System status
Interfaces Interfaces statistics
Services Services status
System Log System logging
Neighbor Mesh node status
Help
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 9 of 62
4Syste
4.1 Syste > Syste
MAP 1000 is a layer 2 mesh network that supports gateway and relay operation
mode. Figure .1.1 illustrates the system information configuration page.
Figure 4.1.1: Syste Infor ation Configuration page
System Information Configuration page contains the following parameters:
•Na e – Name of the device.
•Location – Location name that device located.
•Contact Na e – Name of the contact person for consulting about the device.
•Contact E ail – Email address of the contact person.
•Contact Phone – Phone number of the contact person.
•Description – Description of the device.
•Object ID – Display SNMP MIB object identification (OID) of the device.
•Operation Mode – Type of operation mode such as “Layer 2 Gateway” &
“ Layer 2 Relay”
•“Apply” button to save any changes made. New settings are active after the
device reboot.
EnGenius Mesh AP - M8000 User Manual & Configuration Guide
EnGenius Mesh AP - M8000 User Manual & Configuration Guide Page 10 of 62
4.2 Syste > Syslog
Certain system message is useful to understand the problem behind any undesired
result. Mesh AP 000 is enabled with syslog server that can log message locally and
remotely. Figure .2.1 illustrates the Syslog configuration page.
Figure 4.2.1: Syslog configuration page
Syslog contains the following parameters:
•Active – Enable or disable system logging feature.
•Klog – Enable or disable kernel logging feature.
•Level – 8 levels of logging : emergency, alert, critical, error, warning, notice,
info and debug.
•Re ote Syslog – Enable or disable remote syslog server.
•Re ote Server Address – Address of remote syslog server when remote
syslog is enabled.
•“Apply” button to save any changes made. New settings are active after the
device reboot.
