ENGLISH
Introduction 3 .....................................................................................................................................................................
Care and maintenance 3 ...................................................................................................................................................
Features 4 ...........................................................................................................................................................................
General features 4 ........................................................................................................................................................................
Technical specifications 4 .............................................................................................................................................................
Audio 4 ...........................................................................................................................................................................
Alarm function 4 .............................................................................................................................................................
Bluetooth connectivity 4 .................................................................................................................................................
Lights 4 ...........................................................................................................................................................................
Analogue inputs 4 ...........................................................................................................................................................
Battery 4 ........................................................................................................................................................................
Product content 5 ...............................................................................................................................................................
General overview 5 ............................................................................................................................................................
Main Functions 6 ................................................................................................................................................................
Switching on and off the device 6 ..................................................................................................................................
Light modes 6 .................................................................................................................................................................
Playback modes 6 ...........................................................................................................................................................
Clock --> Bluetooth --> FM radio --> AUX 6 .................................................................................................................................
Clock and alarms 6 .........................................................................................................................................................
Clock --> Alarm 1 --> Alarm 2 7 ...................................................................................................................................................
Playback control 7 ..........................................................................................................................................................
Call control 7 ..................................................................................................................................................................
Bluetooth (BT) 7 .............................................................................................................................................................
True Wireless Stereo 7 ...................................................................................................................................................
FM radio 7 .......................................................................................................................................................................
Auxiliary audio input (AUX) 8 ..........................................................................................................................................
Charging the battery 8 ...................................................................................................................................................
Warranty 8 ...........................................................................................................................................................................
Declaration of conformity 8 ..............................................................................................................................................
2/9 energysistem.com
3/9 energysistem.com
Introduction
Thank you for trusting our company and buying the new Clock Speaker 3 Light. We hope you enjoy it.
Speaker with radio alarm function and gradually increasing light to wake up naturally before the alarm or your
favourite radio station sounds.
Play music via Bluetooth. Decorate your bedside table thanks to the multicoloured RGB LEDs with touch control.
Before you start using your Clock Speaker 3 Light we strongly recommend reading this manual to get used to it.
Care and maintenance
Do not expose your Clock Speaker 3 Light to impacts, dust, humidity or high temperatures.
Use neither corrosive nor abrasive cleaning products.
Do not disassemble the device. All repair works should be carried out exclusively by qualified staff of Energy
Sistem Technology, S.A.
Please make sure your Clock Speaker 3 Light is off when you are not using it. Do not store the device with an
empty battery for long periods.
4/9 energysistem.com
Features
General features
Speaker with radio alarm function and multicoloured RGB LED lights.
8 W sound system for crystal clear, high-quality sound.
3 light modes (white, colour and rainbow) with touch control.
Wake-Up Light: the light intensity increases gradually before the alarm sounds.
Enjoy your favourite radio stations thanks to the built-in FM radio.
Dual alarm: set two alarms separately.
You can wake up to the standard alarm or listening to your favourite radio station.
Do not fall asleep if there is a power cut thanks to the built-in battery.
Bluetooth technology to connect your music player and listen to your favourite songs with the convenience of
wireless playback.
Furthermore, you can plug a music player into the 3.5 mm jack audio-in and enjoy your music.
Snooze function and alarm repetition every 5 minutes (Snooze).
Technical specifications
Audio
Sound system: mono (1.0)
Power: 8 W
1 full range speaker: 2.75'', 8 W
Passive radiators: 1 membrane
Frequency response: 50 Hz ~ 18 kHz
THD < 1%
S/N ratio: > 90 dB
Alarm function
Set 2 alarms separately
Sunrise simulation using light
Wake up to an alarm sound or the FM radio
Gradually increasing alarm volume
Snooze function
Bluetooth connectivity
Bluetooth 4.2, class 2
Frequency band: 2.4 GHz
Maximum output power: < 20,00 dBm
Compatible Bluetooh profiles: HSP / HFP / A2DP / AVRCP
Up to 10 m distance range
True Wireless Stereo (TWS) technology with a distance range of up to 10 m
Hands-free function
Lights
RGB LED lights
3 light modes: white, basic colours and Full Colour
Touch control panel
Analogue inputs
3.5 mm jack input (analogue stereo input)
Battery
Capacity: 1800 mAh / 3.7 V -Type: Li-Ion
Battery life at medium volume: 11 hours*
Battery life in clock mode: 45 hours
Battery life in white light mode: 4 hours
Charging time: 3 hours
Power supply: 5.0 V / 2 A
5/9 energysistem.com
Charging port: micro USB
Note: *This value is approximate. The battery life depends on the selected volume and the type of music.
Product content
Clock Speaker 3 Light
USB Type-A to micro USB cable
AC/DC power adapter (Europlug)
Quick guide
General overview
On/Off1.
Playback mode2.
Back/Volume -3.
Next/Volume +4.
Play/Pause5.
Touch panel6.
Display7.
3.5 mm jack audio-in8.
6/9 energysistem.com
Charging port9.
LED indicator10.
Main Functions
Switching on and off the device
To switch on or off the Clock Speaker 3 Light, slide the On/Off (1) switch up or down. The white LED mode is the mode
by default. At this point, the time appears on the Display (7).
Light modes
Your Clock Speaker 3 Light features multicoloured RGB lights. The Touch Control function allows you to control them
using the Touch panel (6). This way, you can decorate your bedside table.
Tap the Touch panel (6) to turn on or off the lights.
Press and hold the Touch panel (6) for 3 seconds when the lights are on to choose from 3 light modes: white, colour or
rainbow.
Once the white light mode is enabled, tap the Touch panel (6) to choose the light shade that suits your environment
best. You can choose from different shades of blue to yellow.
If colour mode is enabled, tap the Touch panel (6) to choose the colour you prefer for your bedside table.
If you enable rainbow mode, tap the Touch panel (6) once to pause colour transition. Tap again to continue.
Playback modes
Once the Clock Speaker 3 Light is on, you can choose the playback mode you prefer. To do so, press Playback mode (2)
until finding the preferred playback mode. You will see the following modes appear on the Display (7):
Clock --> Bluetooth --> FM radio --> AUX
Clock and alarms
Clock
Enable clock mode and press and hold Playback mode (2) for 2 seconds. You will see the hour digits flashing on the
Display (7). Press Back/Volume - (3) or Next/Volume + (4) to select the preferred hour. Press Playback mode (2) to
confirm. Repeat the steps above to select the minutes.
Alarms
Your Clock Speaker 3 Light allows you to set 2 alarms separately.
Enable clock mode and press Play/Pause (5) repeatedly. You will see the following options appear on the Display (7):
7/9 energysistem.com
Clock --> Alarm 1 --> Alarm 2
When selecting the first or second alarm, you will see the clock icon with the corresponding number flashing on the
Display (7).
Choose the alarm you want to set. Press and hold Play/Pause (5) for 2 seconds. You will see the mode changing from
Alarm off to time mode (hh:mm) on the Display (7). At this point, you can set/activate the alarm.
To set and activate an alarm, enter time mode (hh:mm). Press Playback mode (2) for 2 seconds. You will see the hours
flashing on the Display (7). Press Back/Volume - (3) or Next/Volume + (4) to select the preferred hour. Press Playback
mode (2) to confirm. Repeat the steps above to select the minutes. To select the type of alarm you prefer, "Beep" or
"Radio", press Back/Volume - (3) or Next/Volume + (4) and press Playback mode (2) to confirm. Press repeatedly
Play/Pause (5) to return to Clock mode.
You will know the alarm is set when the clock icon with its corresponding number is displayed permanently on the
Display (7).
The light intensity increases gradually before the alarm sounds. Tap the Touch panel (6) to repeat the alarm every 10
minutes or press and hold to stop it and deactivate the repeat mode.
Note: If you select the radio as alarm sound, you will wake up to the last listened radio station.
Playback control
Select the playback mode, and you will be able to control all playback functions from your Clock Speaker 3 Light.
Press Back/Volume - (3) or Next/Volume + (4) to adjust the volume level according to your preferences.
Press and hold Back/Volume - (3) or Next/Volume + (4) for 2 seconds to skip to the previous or next track.
Press Play/Pause (5) to play or pause a song.
Note: Bear in mind that you can only control playback from the connected music player while using AUX mode (audio-
in).
Call control
Press Play/Pause (5) to answer an incoming call or press and hold the very same button to reject it.
Bluetooth (BT)
To pair your speaker with a Bluetooth device, press Playback mode (2) until Bluetooth mode is enabled. You will see
both the Bluetooth icon and the LED indicator (10) flashing blue. A sound will confirm the device has entered search
mode.
At this point, access the Bluetooth settings on your device and search for the Clock Speaker 3 Light among the detected
devices. Select it to establish the connection. You will hear a sound confirming both devices are correctly paired.
Your Clock Speaker 3 Light will automatically pair with your source device when you turn the speaker on again, provided
that Bluetooth is enabled on the source device.
Press and hold Playback mode (2) for 2 seconds to disconnect the current device and pair the speaker with a new one.
True Wireless Stereo
This technology allows you to wirelessly connect another True Wireless Stereo device within a maximum distance range
of 10 metres to increase power and create a stereo system with separate left and right channels.
Switch on both devices and enable Bluetooth mode. Press and hold Play/Pause (5) on one of the devices for at least 2
seconds. Once the connection is established, you will hear a confirmation sound. From that moment on, both devices
will play the same content simultaneously.
To disable the TWS connection, press and hold Play/Pause (5) again for a few seconds until the connection ends.
FM radio
Select FM radio and press Playback mode (2) until a radio frequency appears on the Display (7).
8/9 energysistem.com
Automatic tuning
To carry out an automatic search of all radio stations, press and hold Playback mode (2) for 2 seconds. At this point,
your Clock Speaker 3 Light starts searching for radio stations and shows the saved frequencies on the Display (7).
Once the automatic search is complete, press and hold Back/Volume - (3) or Next/Volume + (4) for 2 seconds to switch
between the saved presets. Choose the one you want to hear.
Manual tuning
Press and hold Play/Pause (5) for 2 seconds if you prefer to carry out a manual search. At this point, you will see the
Display (7) flashing.
Press Back/Volume - (3) or Next/Volume + (4) to fine-tune the desired radio frequency. Press Play/Pause (5) to confirm.
Press Back/Volume - (3) or Next/Volume + (4) to select a radio station. Press Play/Pause (5) to confirm.
Auxiliary audio input (AUX)
You can also plug an external device into the 3.5 mm jack audio-in (8) of your Clock Speaker 3 Light using a 3.5 mm
mini-jack audio cable.
NOTE: It is not possible to control music playback from the speaker while using this mode. To control playback
functions, you will have to use the connected music player.
Charging the battery
When the battery level is low, you will hear a sound to remind you to charge the battery. Plug the micro USB end of the
provided USB cable into the Charging port (9) of your Clock Speaker 3 Light and the other USB end to any device with a
5 V USB charging port to provide energy (PC, USB wall charger, car charger, etc) to charge the battery. The LED
indicator (10) lights up red and switches off once the charging process is complete.
Important:
Use a 5 V 2 A power adapter.
Do not leave your Clock speaker 3 Light with an empty battery for a long time.
Warranty
You can check the warranty terms here
Declaration of conformity
Issuer's name: Energy Sistem Technology, S.A. - CIF: A53107488
Address: C/ Calpe, 1 - 03509 Finestrat, Alicante (Spain)
Tel: +34 966 830 324
We declare under our own exclusive responsibility that the product:
Description: Bluetooth speaker
Brand: Energy Sistem
Model: Clock Speaker 3 Light
Manufacturer: Energy Sistem Technology, S.A.
Manufacturing country: China
referred to in this declaration is in compliance with the following European Union directives:
Directive 2014/30/EU (EMC) of 29th March 2014
and essential norms and standards:
EN 62479:2010
EN 62368-1:2014+A11:2017
ETSI EN 301 489-1 V2.1.1 (2017-02)
9/9 energysistem.com
ETSI EN 301 489-17 V3.1.1 (2017-02)
EN 55015:2013+A1:2015
EN 61547:2009
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55032:2015
EN 55035:2017
ETSI EN 300 328 V2.2.2 (2017-03)
EN 303 345 V1.1.7 (2017-03)
in conformity with the provisions of the Directive 2014/53/EU of the European Parliament and of the Council of 16th
April 2014.
Finestrat, 1st November 2019
Javier Álvarez Rodríguez
Innovation and Technology Director
Table des matières
Autres manuels ENERGY SISTEM Intervenants
ENERGY SISTEM
ENERGY SISTEM Aquatic 2 Series Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM FS3 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Urban Box 6 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Music Box Z6 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Tower 2 Style Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Party 3 Go Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Urban Box Supernova Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM eco beech wood Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Music Box BZ6 Bluetooth Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Cinne 1000 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Music Box z30 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Music Box BZ2 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Tower 8 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Energy Tower 8 g2 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM ENERGY S100 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM studio monitor 4 Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM ESG S3 DUO Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM fabric box3+ Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM Energy Music Box CM1 Bluetooth Manuel utilisateur
ENERGY SISTEM
ENERGY SISTEM tower7 Manuel utilisateur
Manuels Intervenants populaires d'autres marques
Bowers & Wilkins
Bowers & Wilkins 4 Manuel utilisateur
Sonance
Sonance SONOS OUTDOOR Series Manuel utilisateur
Electro-Voice
Electro-Voice EVID FM4.2 Manuel utilisateur
Pioneer
Pioneer XW-HTD630 Manuel utilisateur
Onn
Onn BWA16AA002 Manuel utilisateur
HP
HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
