User Manual
1/2.8” HD Camera, Day&Night,
1920x1080, Infrared, WDR,
12/24V, IP67
MPB-72M2812M0A
MPB-72M0550M0A
Safety Precaution
03
MPB-72MxxxxM0A
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent electric shocks and risk of fire hazards, do NOT use other than
specific power source.
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
Warning :
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Caution :
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
Mains power quality should be that of a typical commercial environment. If the user
of the model requires continued operation during power mains interruptions, it is
recommended that the model be powered from an uninterruptible power supply
(UPS) or a battery.
MPB-72MxxxxM0A
Safety Precaution
04
NOTICE
The image used in this instruction manual are processed to help comprehension
and may differ from actual video of the camera.
Avoid installing areas where has shock or vibration which results in the problems.
Pay attention to safety when laying the connection cable and observe that the cable
is not subjected to heavy loads, kinks or damage and no moisture can get in.
The warranty becomes void if repairs are undertaken by unauthorized persons.
Maintenance and repair have to be carried out only by authorized service centers.
Use only a mild detergent to clean the housing.
The camera should never be operated beyond the technical specifications.
This can lead to destruction.
The camera should never be operated in water.
MPB-72MxxxxM0A
Contents
05
Safety Precaution
p.03~04
Contents
p.05
Features
p.06
Composition
p.07
Dimensions
p.07
Part Names
p.08
Installation Instructions
p.09~11
Operating Instructions
p.12~28
Specifications
p.29
MPB-72MxxxxM0A
Features
Key Features
06
• Full-HD 2Mega pixel CAMERA, 1920x1080(30p/25p)
• The best low light performance with SONY’s STARVIS sensor
•
Video output EX-SDI 1.0,2.0 / HD-SDI / TVI mode / AHD mode / CVI mode
or CVBS Selectable
• TVI mode / AHD mode / CVI mode, Video Transmission Distance
over Coax.; 500M
• f=2.8~12mm F1.4, 5Mega pixel Motorized zoom lens (MPB-72M2812M0A)
•f=5~50mm F1.6, Mega pixel Motorized zoom lens (MPB-72M0550M0A)
• Automatically removable IR Cut filter by Dual filter switcher
• SNAP Focus by Motorized Zoom lens
• Motorized Zoom & Focus Adjustment
• Sensitivity of Color 0.08 Lux(LED off), B/W 0.005 Lux (LED off)
• True WDR (Wide Dynamic Range), 30/25fps
• ROI (Region of Interest) WDR mode:
- Proper compensation of exposure for each inside and outside of
interested area.
- Better contrast and No motion ghost effect
• Improved Noise figure with the enhanced 3D-NR
• Motion Detection, Privacy Mask, Defog, Sens-up(~x32), ACE(D-WDR),
Sharpness, Mirror/Flip, BLC/HLC, Anti-Saturation, Smart IR, Title Set
• Top performance at low light sensitivity (Sens-up On)
• Selectable Digital output 1080p or 720p
• OSD Menu & Video Sub-out port for easy installation & maintenance
• Circuit protection against faulty connection in power polarity
• Isolated power supply against ground loop problem
• UTC control through HD-TVI (Pelco-C, Hikvision) / AHD
• Built-in 5pcs High power LED : Equivalent to 50 IR-LEDs
• Dual Window
• One-touch 3-Axis locking bracket, Easy installation pad
• IP67 protection
07
Composition
MPB-72MxxxxM0A
Dimensions
(unit : mm)
Video Sub-out
Cable (1pc)
Mounting
Template
Operating
Instruction
Torque Wrench:
3mm (1pc)
Camera
Easy
Bracket
Mounting Screw:
4 x 30mm (4pcs)
Plastic Anchor:
6 x 30mm (4pcs)
Assembly Screw:
4 x 15mm (4pcs)
267
108
87.30
100
86.40
75.90
80
190
MPB-72MxxxxM0A
Part Names
08
■Adjustment of viewing angle with a bracket
Torque
wrench
Lock/Unlock
Screw
• Extreme care should be taken NOT to
scratch the window in front of lens.
• Care should be taken the cable is NOT
to be damaged, kinked or exposed in
the hazardous area.
• Do not expose the camera directly to
a strong light source such as the sun
or spot light.
CAUTION
Power/Video
Cable
Sunshield
Sunshield Bold
Easy
Bracket
OSD Setup
Control Cover
Bracket
Lock/Unlock
Screw
MPB-72MxxxxM0A
Installation Instructions
09
Torque Wrench
Assembly Screw
: 4x15mm
Mounting Screw
: 4x30mm
1. Locate the mounting template at the installation position and drill the ceiling or
wall if needed. ( *The easy bracket can not be installed on the ceiling)
2. Place the easy bracket on pre-drilled position and fix it through using mounting
screws (4x30mm). Skip this step when an easy bracket is not installed.
3. Route the Power cable to the connecting place.
Hook up the camera bracket with the easy bracket as illustrated below.
4. Fix the camera bracket through using assembly screws (4x15mm).
5. Set the camera’s viewing angle.
6. Put the sunshield to the camera unit and tighten the sunshield-bolts.
REAR VIEW
1
2
3
4
Cable exit
MPB-72MxxxxM0A
Installation Instructions
10
Pan & Tilt adjustments
1) Pan limit:
Pan is limited to +/- 90°.
3) Inclination limit
(Horizontal image alignment):
Inclination limited to +/-90° max.
2) Tilt limit:
Tilt is limited to 0°(2°) min ~ 90° max.
for wall(ceiling) installation respectively
with reference to the wall(ceiling) when
the inclination of camera module is 0°,
that is, the image is aligned horizontally.
90° 90°
•Unlock the screw on the camera bracket through using the torque wrench supplied
• Set the camera’s viewing angle then lock the screw on the bracket.
88°90°
±90°
•on the wall •on the ceiling
