Brief Operating Instructions

Liquiphant FTL64

Vibronic

HART

Point level switch for liquids in high-temperature

applications

These Brief Operating Instructions are not a substitute for the

Operating Instructions pertaining to the device.

Detailed information is provided in the Operating Instructions

and other documentation.

Available for all device versions via:

• Internet: www.endress.com/deviceviewer

• Smartphone/tablet: Endress+Hauser Operations app

KA01559F/00/EN/02.23-00

71630441

2023-11-30

Related documents Liquiphant FTL64 HART

2 Endress+Hauser

1 Related documents

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

Liquiphant FTL64 HART About this document

Endress+Hauser 3

2 About this document

2.1 Symbols

2.1.1 Safety symbols

DANGER

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

This symbol contains information on procedures and other facts which do not result in

personal injury.

2.1.2 Electrical symbols

Ground connection

Grounded clamp, which is grounded via a grounding system.

Protective earth (PE)

Ground terminals, which must be grounded prior to establishing any other connections. The

ground terminals are located on the inside and outside of the device.

2.1.3 Tool symbols

Flat-blade screwdriver

Allen key

Open-ended wrench

2.1.4 Communication-specific symbols

Bluetooth

Wireless data transmission between devices over a short distance.

2.1.5 Symbols for certain types of information

Permitted

Procedures, processes or actions that are permitted.

Forbidden

Procedures, processes or actions that are forbidden.

Tip

Indicates additional information

Basic safety instructions Liquiphant FTL64 HART

4 Endress+Hauser

Reference to documentation

Reference to another section

Series of steps

2.1.6 Symbols in graphics

A, B, C ... View

1, 2, 3 ... Item numbers

Hazardous area

Safe area (non-hazardous area)

2.1.7 Registered trademarks

HART®

Registered trademark of the FieldComm Group, Austin, Texas, USA

Bluetooth®

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG,

Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and

trade names are those of their respective owners.

Apple®

Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the

U.S. and other countries. App Store is a service mark of Apple Inc.

Android®

Android, Google Play and the Google Play logo are trademarks of Google Inc.

3 Basic safety instructions

3.1 Requirements for the personnel

The personnel must fulfill the following requirements to carry out the necessary tasks, e. g.,

commissioning and maintenance:

‣Trained, qualified specialists must have a relevant qualification for the specific function

and task

‣Are authorized by the plant owner/operator

‣Are familiar with federal/national regulations

‣Must have read and understood the instructions in the manual and supplementary

documentation

‣Follow instructions and comply with conditions

3.2 Intended use

• Only use the device for liquids

• Improper use can pose hazards

• Ensure that the measuring device is free of defects while it is in operation

Liquiphant FTL64 HART Basic safety instructions

Endress+Hauser 5

• Use the device only for media to which the wetted materials have an adequate level of

resistance

• Do not exceed or drop below the relevant limit values for the device

For more details, see the Technical Documentation

3.2.1 Incorrect use

The manufacturer is not liable for damage caused by improper or non-intended use.

Residual risks

Due to heat transfer from the process, the temperature of the electronics housing and the

assemblies contained therein may rise to 80 °C (176 °F) during operation.

Danger of burns from contact with surfaces!

‣If necessary, ensure protection against contact to prevent burns.

For requirements concerning functional safety in accordance with IEC 61508, the associated

SIL documentation must be observed.

3.3 Workplace safety

For work on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

3.4 Operational safety

Risk of injury!

‣Operate the device only if it is in proper technical condition, free from errors and faults.

‣The operator is responsible for ensuring the interference-free operation of the device.

Modifications to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers.

‣If, despite this, modifications are required, consult with Endress+Hauser.

Repair

To ensure continued operational safety and reliability:

‣Only perform repair work on the device if this is expressly permitted.

‣Observe federal/national regulations pertaining to the repair of an electrical device.

‣Use original spare parts and accessories from Endress+Hauser only.

Hazardous area

To eliminate danger to persons or the facility when the device is used in the hazardous area

(e.g. explosion protection):

‣Check the nameplate to verify whether the ordered device can be used for the intended

purpose in the hazardous area.

‣Observe the specifications in the separate supplementary documentation that is an integral

part of this manual.

Incoming acceptance and product identification Liquiphant FTL64 HART

6 Endress+Hauser

3.5 Product safety

This device is designed in accordance with good engineering practice to meet state-of-the-art

safety requirements, has been tested, and left the factory in a condition in which it is safe to

operate.

It meets the general safety standards and legal requirements. It also complies with the EU

directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms

this by affixing the CE mark to the device.

3.6 Functional Safety SIL (optional)

The Functional Safety Manual must be strictly observed for devices that are used in functional

safety applications.

3.7 IT security

For more information, see the Operating Instructions.

4 Incoming acceptance and product identification

4.1 Incoming acceptance

Check the following during incoming acceptance:

 Are the order codes on the delivery note and the product sticker identical?

 Are the goods undamaged?

 Do the data on the nameplate match the ordering information on the delivery note?

 If required (see nameplate): are the Safety Instructions e.g. XA provided?

If one of these conditions is not met, please contact the manufacturer's sales office.

4.2 Product identification

The device can be identified in the following ways:

• Nameplate specifications

• Extended order code with breakdown of the device features on the delivery note

• Enter serial number from nameplates in W@M Device Viewer

www.endress.com/deviceviewer. All of the information on the measuring device is

displayed along with an overview of the scope of technical documentation provided.

• Enter the serial number on the nameplate into the Endress+Hauser Operations app or scan

the 2-D matrix code on the nameplate with the Endress+Hauser Operations app

4.2.1 Electronic insert

Identify the electronic insert via the order code on the nameplate.

Liquiphant FTL64 HART Mounting

Endress+Hauser 7

4.2.2 Nameplate

The information that is required by law and is relevant to the device is shown on the

nameplate.

4.2.3 Manufacturer address

Endress+Hauser SE+Co. KG

Hauptstraße 1

79689 Maulburg, Germany

Place of manufacture: See nameplate.

4.3 Transporting the device

• Transport the device to the measuring point in the original packaging

• Hold the device by the housing, temperature spacer, process connection or extension pipe

• Do not bend, shorten or extend the tuning fork.

5 Mounting

Mounting instructions

• Any orientation for version with a pipe length of up to 500 mm (19.7 in) approx.

• Vertical orientation from above for device with long pipe

• Minimum distance between the tuning fork and the tank wall or pipe wall: 10 mm (0.39 in)

Mounting Liquiphant FTL64 HART

8 Endress+Hauser

A0042329

 1 Installation examples for a vessel, tank or pipe

5.1 Mounting requirements

NOTICE

Scratches or impacts damage the coated surface of the device.

‣Ensure the device is handled properly and professionally during all mounting work.

5.1.1 Pay attention to the temperature for devices with a PFA coating (conductive)

The difference in temperature between the outer and inner side of the flange may not exceed

60 °C (140 °F).

If necessary, use external insulation.

Liquiphant FTL64 HART Mounting

Endress+Hauser 9

A0042298

 2 Difference in temperature between outer and inner side of flange

1 Insulation

A Temperature of flange, outer side

B Temperature of flange, inner side, for PFA (conductive) maximum 230 °C (446 °F)

C Difference in temperature for PFA (conductive) maximum 60 °C (140 °F)

5.1.2 Take switch point into consideration

The following are typical switch points, depending on the orientation of the point level switch

Water +23 °C (+73 °F)

Minimum distance between the tuning fork and the tank wall or pipe wall:

10 mm (0.39 in)

~13 (0.5)

~5 (0.2)

~12.5 (0.49)

A B C

A0044069

 3 Typical switch points. Unit of measurement mm (in)

A Installation from above

B Installation from below

C Installation from the side

D Switch point

Mounting Liquiphant FTL64 HART

10 Endress+Hauser

5.1.3 Take viscosity into consideration

Viscosity values

• Low viscosity : < 2 000 mPa⋅s

• High viscosity: > 2 000 to 10 000 mPa⋅s

Low viscosity

Low viscosity, e.g. water: < 2 000 mPa⋅s

It is permitted to position the tuning fork within the installation socket.

> 25 (0.98)

> !50 (1.97)

A0042333

 4 Installation example for low-viscosity liquids. Unit of measurement mm (in)

High viscosity

NOTICE

Highly viscous liquids may cause switching delays.

‣Make sure that the liquid can run off the tuning fork easily.

‣Deburr the socket surface.

High viscosity, e.g. viscous oils: ≤ 10 000 mPa⋅s

The tuning fork must be located outside the installation socket!

> 40 (1.57)

A0042335

 5 Installation example for a highly viscous liquid. Unit of measurement mm (in)

Autres manuels pour Liquiphant FTL64

Table des matières

Autres manuels Endress+Hauser Changer

Endress+Hauser

Endress+Hauser Nivotester FTL325N-1 1 Manuel utilisateur

Endress+Hauser

Endress+Hauser minicap FTC 262 Manuel utilisateur

Endress+Hauser

Endress+Hauser OTR31 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiphant FTL51B Caractéristiques techniques

Endress+Hauser

Endress+Hauser Liquiphant FTL51B Caractéristiques techniques

Endress+Hauser

Endress+Hauser Cerabar PMP11 Manuel utilisateur

Endress+Hauser

Endress+Hauser Nivotester FTC325 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiphant FTL31 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquipoint T FTW32 Manuel utilisateur

Endress+Hauser

Endress+Hauser Thermophant T TTR 31 Manuel utilisateur

Endress+Hauser

Endress+Hauser Soliphant M FTM50 Manuel utilisateur

Endress+Hauser

Endress+Hauser nivotester FTL 325 P Manuel utilisateur

Endress+Hauser

Endress+Hauser OFTE20 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiphant S FTL70 Manuel utilisateur

Endress+Hauser

Endress+Hauser Thermophant T TTR31 Manuel utilisateur

Endress+Hauser

Endress+Hauser Nivector FTI26 Manuel

Endress+Hauser

Endress+Hauser Soliphant M FTM50 Manuel

Endress+Hauser

Endress+Hauser minicap FTC 262 Manuel utilisateur

Endress+Hauser

Endress+Hauser Soliphant M FTM52 Manuel utilisateur

Endress+Hauser

Endress+Hauser Soliphant M FTM52 Manuel utilisateur

Endress+Hauser

Endress+Hauser nivocompact FTC 731 Manuel utilisateur

Endress+Hauser

Endress+Hauser Nivotester FTC325 PFM Manuel utilisateur

Endress+Hauser

Endress+Hauser Flowphant T DTT31 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiphant FTL64 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
