Brief Operating Instructions

RID14

Fieldbus indicator

with PROFIBUS® PA protocol

These Brief Operating Instructions are not a substitute for the

Operating Instructions pertaining to the device.

Detailed information is provided in the Operating Instructions

and other documentation.

Available for all device versions via:

• Internet: www.endress.com/deviceviewer

• Smartphone/tablet: Endress+Hauser Operations app

KA01156K/09/EN/03.22-00

71593374

2022-08-03

RID14

2 Endress+Hauser

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

RID14 Table of contents

Endress+Hauser 3

Table of contents

1 Document information ............................................................ 4

1.1 Document conventions .................................................................. 4

2 Safety instructions ................................................................ 6

2.1 Requirements for personnel .............................................................. 6

2.2 Designated use ........................................................................ 6

2.3 Workplace safety ...................................................................... 6

2.4 Operational safety ......................................................................6

2.5 Product safety ......................................................................... 7

3 Identification ..................................................................... 7

3.1 Device designation ..................................................................... 7

3.2 Scope of delivery ....................................................................... 8

3.3 Certificates and approvals ................................................................ 8

4 Installation ....................................................................... 8

4.1 Incoming acceptance, transport, storage ..................................................... 8

4.2 Installation conditions ................................................................... 9

4.3 Installation instructions ..................................................................9

4.4 Post-installation check ................................................................. 11

5 Wiring ........................................................................... 11

5.1 Connecting the cable to the field indicator ................................................... 12

5.2 Connection to PROFIBUS® PA ............................................................ 13

5.3 Degree of protection ................................................................... 16

5.4 Post-connection check ..................................................................17

6 Operating the field indicator ..................................................... 17

6.1 Quick operation guide .................................................................. 17

6.2 Display and operating elements ........................................................... 19

6.3 Configuration of the field indicator ........................................................ 20

6.4 Hardware settings ..................................................................... 20

6.5 Device configuration ................................................................... 22

Document information RID14

4 Endress+Hauser

1 Document information

1.1 Document conventions

1.1.1 Safety symbols

Symbol Meaning

DANGER

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

NOTE!

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.1.2 Electrical symbols

Symbol Meaning

A0011197

Direct current

A terminal to which DC voltage is applied or through which direct current flows.

A0011198

Alternating current

A terminal to which alternating voltage is applied or through which alternating current flows.

A0017381

Direct current and alternating current

• A terminal to which alternating voltage or DC voltage is applied.

• A terminal through which alternating current or direct current flows.

A0011200

Ground connection

A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.

A0011199

Protective ground connection

A terminal which must be connected to ground prior to establishing any other connections.

A0011201

Equipotential connection

A connection that has to be connected to the plant grounding system: This may be a potential

equalization line or a star grounding system depending on national or company codes of practice.

A0012751

ESD - Electrostatic discharge

Protect the terminals against electrostatic discharge. Failure to comply with this instruction can result

in the destruction of parts or malffunction of the electronics.

RID14 Document information

Endress+Hauser 5

1.1.3 Symbols for certain types of information

Symbol Meaning Symbol Meaning

Permitted

Procedures, processes or actions that

are permitted.

Preferred

Procedures, processes or actions that

are preferred.

Forbidden

Procedures, processes or actions that

are forbidden.

Tip

Indicates additional information.

Reference to documentation Reference to page

Reference to graphic

,…

Series of steps

Result of a step Visual inspection

1.1.4 Symbols in graphics

Symbol Meaning

1, 2, 3,... Item numbers

,…

Series of steps

A, B, C, ... Views

A-A, B-B, C-C, ... Sections

A0013441

Flow direction

A0011187

Hazardous area

Indicates a hazardous area.

A0011188

Safe area (non-hazardous area)

Indicates a non-hazardous area.

1.1.5 Tool symbols

Symbol Meaning

A0011220

Flat blade screwdriver

A0011221

Allen key

Safety instructions RID14

6 Endress+Hauser

Symbol Meaning

A0011222

Open-ended wrench

A0013442

Torx screwdriver

2 Safety instructions

2.1 Requirements for personnel

The personnel must fulfill the following requirements for its tasks:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task.

‣Are authorized by the plant owner/operator.

‣Are familiar with federal/national regulations.

‣Before starting work, read and understand the instructions in the manual and

supplementary documentation as well as the certificates (depending on the application).

‣Follow instructions and comply with basic conditions.

2.2 Designated use

• The device is a field indicator designed for connection to a fieldbus.

• The device is designed for installation in the field.

• The manufacturer accepts no liability for damages resulting from incorrect use or use other

than that designated.

• Safe operation is only guaranteed if operators comply strictly with the Operating

Instructions.

• Only operate the device in the designated temperature range.

2.3 Workplace safety

For work on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

2.4 Operational safety

Risk of injury.

‣Operate the device in proper technical condition and fail-safe condition only.

‣The operator is responsible for interference-free operation of the device.

RID14 Identification

Endress+Hauser 7

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which it

is safe to operate.

It meets general safety standards and legal requirements. It also complies with the EC

directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms

this by affixing the CE mark to the device.

3 Identification

3.1 Device designation

3.1.1 Nameplate

The right device?

Compare the order code on the nameplate of the device to that on the delivery papers.

Made in Germany 2013

D-87484 Nesselwang

Order code: RID14-xxxxxxx

Ser. no.: xxxxxxxxxxx

Ext. ord. cd.: xxxxxxxxxxxxxxxxxx

9 - 32 V

Ta = -40 ...+80°C

FW: XX.XX.XX DevRev: X

IP67 NEMA4X

Type 4X

RID14

A0021495

 1 Nameplate of the field indicator (example)

1 Designation, order code and serial number of the device

2 Power supply

3 Ambient temperature range

4 Firmware version and device revision

5 Degree of protection and type of approval

6 Approvals

Installation RID14

8 Endress+Hauser

3.2 Scope of delivery

The scope of delivery of the field indicator comprises:

• Field indicator

• Brief Operating Instructions as hard copy

• ATEX - safety instructions for using a device approved for hazardous areas, optional

• Optional accessories (e.g. pipe mounting bracket), see 'Accessories' section in the Operating

instructions.

3.3 Certificates and approvals

3.3.1 CE mark

The measuring system meets the legal requirements of the applicable EC guidelines. These are

listed in the corresponding EC Declaration of Conformity together with the standards applied.

The manufacturer confirms successful testing of the device by affixing to it the CE mark.

3.3.2 UL approval

UL recognized component (see www.ul.com/database, search for Keyword "E225237")

3.3.3 EAC mark

The product meets the legal requirements of the EEU guidelines. The manufacturer confirms

the successful testing of the product by affixing the EAC mark.

3.3.4 CSA

CSA General Purpose

4 Installation

4.1 Incoming acceptance, transport, storage

The permitted ambient and storage conditions must be observed. The precise specifications

can be found in Section "Technical data" in the Operating Instructions.

4.1.1 Incoming acceptance

On receipt of the goods, check the following points:

• Are the packaging or contents damaged?

• Is anything missing from the delivery? Compare the scope of delivery with the information

you specified in the order. See also section "Scope of delivery" →  8.

4.1.2 Transportation and storage

Note the following points:

• Pack the device so that is protected against impact for storage and transportation. The

original packaging provides optimum protection.

• The permitted storage temperature range is –40 to +80 °C (–40 to +176 °F); it is possible to

store the device in the limit temperature ranges for a limited period (maximum 48 hours).

RID14 Installation

Endress+Hauser 9

4.2 Installation conditions

The process indicator is designed to be used in the field.

The orientation is determined by the readability of the display.

Operational temperature range:

–40 to +80 °C (–40 to +176 °F)

NOTICE

Shorter display operating life at higher temperatures

‣Where possible do not operate the device in the higher temperature range.

The display can react slowly at temperatures < –20 °C (–4 °F).

The readability of the display is no longer guaranteed at temperatures < –30 °C (–22 °F).

4.2.1 Dimensions

132 (5.2)

135 (5.3)

112 (4.4)

166 (6.5)

106 (4.2) 121 (4.8)

121 (4.8)

!6.4

(0.25)

A0011152

 2 Dimension of the filed indicator in mm (in)

4.2.2 Installation location

Information on conditions that must be present at the installation location to mount the

device correctly can be found in Section 'Technical data' in the Operating Instructions. These

include the ambient temperature, degree of protection, climate class etc.

4.3 Installation instructions

The device can be mounted directly on the wall →  10. A mounting bracket is available for

mounting on a pipe →  4,  11.

The backlit display can be mounted in 4 different positions →  10.

Installation RID14

10 Endress+Hauser

4.3.1 Turning the display

Pos. 1

90°

90° 90°

Pos. 2 Pos. 3 Pos. 4

A0023724

 3 Field indicator, 4 display positions, can be fitted in 90° stages

The display unit can be turned in 90 ° stages.

1. First remove the cover clamp (1) and the housing cover (2).

2. Then disconnect the display (3) from the electronics unit (4).

3. Turn the display to the desired position and then fit it onto the electronics unit.

4.3.2 Mounting directly on the wall

Proceed as follows to mount the device directly on the wall:

1. Drill 2 holes

2. Fit the device on the wall with 2 screws (⌀5 mm (0.2 in)).

4.3.3 Pipe mounting

The mounting bracket is suitable for pipes with a diameter between 1.5" to 3.3".

The additional mounting plate must be used for pipes with a diameter between 1.5" to 2.2".

The mounting plate is not needed for pipes with a diameter between 2.2" to 3.3".

Proceed as follows to mount the device on a pipe:

Autres manuels pour RID14

Table des matières

Autres manuels Endress+Hauser Instrument de mesure

Endress+Hauser

Endress+Hauser Tankvision Multi Scan NXA83 Manuel utilisateur

Endress+Hauser

Endress+Hauser Cerabar M PMC41 Manuel utilisateur

Endress+Hauser

Endress+Hauser Promass 40 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Cubemass C 500 Manuel

Endress+Hauser

Endress+Hauser Proline Cubemass C 300 Manuel utilisateur

Endress+Hauser

Endress+Hauser Solicap M FTI55 Instructions d'installation

Endress+Hauser

Endress+Hauser LT1100 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquitrend QMW43 Manuel utilisateur

Endress+Hauser

Endress+Hauser StamoLys CA 71 CU Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiline System CAT860 Manuel utilisateur

Endress+Hauser

Endress+Hauser Cerabar M PMC51? Cerabar M PMP51 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag W 500 Manuel

Endress+Hauser

Endress+Hauser Proline Promass 83 Manuel utilisateur

Endress+Hauser

Endress+Hauser Prosonic M FMU44 Manuel utilisateur

Endress+Hauser

Endress+Hauser Prosonic FMU 860 Manuel

Endress+Hauser

Endress+Hauser Memocheck CYP02D Manuel utilisateur

Endress+Hauser

Endress+Hauser silopilot FMM 460 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass E 500 PROFINET Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass F 100 Mode d’emploi

Endress+Hauser

Endress+Hauser Liquiphant FTL64 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass 80H Manuel

Endress+Hauser

Endress+Hauser Micropilot S FMR540 Manuel utilisateur

Endress+Hauser

Endress+Hauser SpectraSensors SS2100 Mise à jour du firmware

Endress+Hauser

Endress+Hauser Deltapilot S FMB70 Instructions d'utilisation

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur

Acterna

Acterna MS1400 Manuel utilisateur

R&S

R&S ZPH Manuel utilisateur
