Brief Operating Instructions

Proline Promass P 100

Coriolis Mass Flow Measuring System

These Instructions are Brief Operating Instructions; they do not replace the

Operating Instructions included in the scope of supply.

For detailed information, refer to the Operating Instructions and other

documentation on the CD-ROM provided or visit "www.endress.com/

deviceviewer".

KA01118D/06/EN/01.12

71185340

Table of contents Proline Promass P 100

2 Endress+Hauser

Table of contents

1 Document information ...................................... 3

1.1 Symbols used ................................................ 3

2 Basic safety instructions ...................................... 5

2.1 Requirements for the personnel ....................................... 5

2.2 Designated use ............................................... 5

2.3 Workplace safety .............................................. 6

2.4 Operational safety .............................................. 6

2.5 Product safety ................................................ 7

3 Product description ......................................... 7

3.1 Product design ............................................... 7

4 Incoming acceptance and product identification ..................... 9

4.1 Incoming acceptance ............................................ 9

4.2 Product identification ........................................... 10

5 Storage and transport ...................................... 11

5.1 Storage conditions ............................................. 11

5.2 Transporting the product .......................................... 11

6 Mounting ............................................... 13

6.1 Mounting requirements .......................................... 13

6.2 Mounting the measuring device ...................................... 19

6.3 Post-mounting check ............................................ 20

7 Electrical connection ....................................... 21

7.1 Connection conditions ........................................... 21

7.2 Connecting the measuring device ...................................... 26

7.3 Hardware settings ............................................. 28

7.4 Ensuring the degree of protection ...................................... 31

7.5 Post-connection check ........................................... 32

8 Operation options ......................................... 33

8.1 Structure and function of the operating menu ................................ 33

8.2 Access to the operating menu via the Web browser ............................. 33

8.3 Access to the operating menu via the operating tool ............................. 36

9 System integration ........................................ 39

10 Commissioning ........................................... 39

10.1 Function check .............................................. 39

10.2 Establishing a connection via FieldCare ................................... 40

10.3 Configuring the device address via software ................................. 40

10.4 Configuring the measuring device ..................................... 40

10.5 Defining the tag name ........................................... 40

10.6 Protecting settings from unauthorized access ................................ 41

11 Diagnostic information ...................................... 43

Proline Promass P 100 Document information

Endress+Hauser 3

1 Document information

1.1 Symbols used

1.1.1 Safety symbols

Symbol Meaning

DANGER

A0011189-EN

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious

or fatal injury.

WARNING

A0011190-EN

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious

or fatal injury.

CAUTION

A0011191-EN

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in minor

or medium injury.

NOTICE

A0011192-EN

NOTICE!

This symbol contains information on procedures and other facts which do not result in personal

injury.

1.1.2 Electrical symbols

Symbol Meaning

A0011197

Direct current

A terminal to which DC voltage is applied or through which direct current flows.

A0011198

Alternating current

A terminal to which alternating voltage is applied or through which alternating current flows.

A0017381

Direct current and alternating current

• A terminal to which alternating voltage or DC voltage is applied.

• A terminal through which alternating current or direct current flows.

)

A0011200

Ground connection

A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.

A0011199

Protective ground connection

A terminal which must be connected to ground prior to establishing any other connections.

A0011201

Equipotential connection

A connection that has to be connected to the plant grounding system: This may be a potential equalization

line or a star grounding system depending on national or company codes of practice.

1.1.3 Tool symbols

Symbol Meaning

A0011221

Allen key

Document information Proline Promass P 100

4 Endress+Hauser

A0011222

Open-ended wrench

1.1.4 Symbols for certain types of information

Symbol Meaning

A0011182

Allowed

Indicates procedures, processes or actions that are allowed.

A0011183

Preferred

Indicates procedures, processes or actions that are preferred.

A0011184

Forbidden

Indicates procedures, processes or actions that are forbidden.

A0011193

Tip

Indicates additional information.

A0011194

Reference to documentation

Refers to the corresponding device documentation.

A0011195

Reference to page

Refers to the corresponding page number.

A0011196

Reference to graphic

Refers to the corresponding graphic number and page number.

,…

Series of steps

ÃResult of a sequence of actions

1.1.5 Symbols in graphics

Symbol Meaning

1, 2, 3,... Item numbers

,…

Series of steps

A, B, C, ... Views

A-A, B-B, C-C, ... Sections

A0013441

Flow direction

A0011187

Hazardous area

Indicates a hazardous area.

A0011188

Safe area (non-hazardous area)

Indicates a non-hazardous area.

Proline Promass P 100 Basic safety instructions

Endress+Hauser 5

2 Basic safety instructions

2.1 Requirements for the personnel

The personnel must fulfill the following requirements for its tasks:

►Trained, qualified specialists must have a relevant qualification for this specific function and

task

►Are authorized by the plant owner/operator

►Are familiar with federal/national regulations

►Before beginning work, the specialist staff must have read and understood the instructions in

the Operating Instructions and supplementary documentation as well as in the certificates

(depending on the application)

►Following instructions and basic conditions

2.2 Designated use

Application and fluids

The measuring device described in these Instructions is intended only for flow measurement of

liquids and gases. Depending on the version ordered, the measuring device can also measure

potentially explosive, flammable, poisonous and oxidizing fluids.

Observing the limit values specified in the "Technical data" and listed in the Operating

Instructions and supplementary documentation, the measuring device may be used for the

following measurements only:

►Measured process variables: mass flow, density, temperature

►Calculated process variables: volume flow, corrected volume flow, reference density

To ensure that the measuring device remains in proper condition for the operation time:

►Use the measuring device only for fluids against which the process-wetted materials are

adequately resistant.

►Observe the limit values in "Technical data".

Incorrect use

The manufacturer is not liable for damage caused by improper or non-designated use.

NOTICE

Danger of breakage of the measuring tube due to corrosive or abrasive fluids.

Housing breakage due to mechanical overload possible!

►Verify the compatibility of the process fluid with the measuring tube material.

►Ensure the resistance of all fluid-wetted materials in the process.

►Observe the specified maximum process pressure.

Verification for borderline cases:

►For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in

verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty

or liability.

Basic safety instructions Proline Promass P 100

6 Endress+Hauser

Residual risks

!WARNING

Danger of housing breaking due to measuring tube breakage!

►In the event of a measuring tube breakage for a device version without rupture disk it is

possible for the pressure loading capacity of the sensor housing to be exceeded. This can lead

to rupture or failure of the sensor housing.

External surface temperature of the transmitter can increase by 20 K due to power consumption

of internal electronical components. Hot process fluids passing through the measuring device

will further increase the surface temperature of the measuring device. Especially the surface of

the sensor can reach temperatures which are close to process temperature.

Possible burn hazard due to fluid temperatures!

►For elevated fluid temperature, ensure protection against contact to prevent burns.

2.3 Workplace safety

For work on and with the device:

►Wear the required personal protective equipment according to federal/national regulations.

For welding work on the piping:

►Do not ground the welding unit via the measuring device.

2.4 Operational safety

Risk of injury.

►Operate the device in proper technical condition and fail-safe condition only.

►The operator is responsible for interference-free operation of the device.

Conversions to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers.

►If, despite this, modifications are required, consult with Endress+Hauser.

Repair

To ensure continued operational safety and reliability,

►Carry out repairs on the device only if they are expressly permitted.

►Observe federal/national regulations pertaining to repair of an electrical device.

►Use original spare parts and accessories from Endress+Hauser only.

Hazardous area

To eliminate a danger for persons or for the facility when the device is used in the hazardous

area (e.g. explosion protection, pressure vessel safety):

►Based on the nameplate, check whether the ordered device is permitted for the intended use

in the hazardous area.

►Observe the specifications in the separate supplementary documentation that is an integral

part of these Instructions.

Proline Promass P 100 Product description

Endress+Hauser 7

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which they

are safe to operate.

It fulfills general safety requirements and legal requirements. It also conforms to the EC directives

listed in the device-specific EC declaration of conformity. Endress+Hauser confirms this fact by

applying the CE mark.

3 Product description

3.1 Product design

A0017609

å 1 Important components of a measuring device

1Transmitter housing cover

2 Main electronics module for Modbus RS485

3 Transmitter housing

4 Sensor

Product description Proline Promass P 100

8 Endress+Hauser

In the case of the device version with Modbus RS485 intrinsically safe, the Safety Barrier

Promass 100 forms part of the scope of supply.

A0017257

å 2 Important components of a measuring device

1Transmitter housing cover

2 I/O electronics module for EtherNet/IP

3 Main electronics module

4 Transmitter housing

5 Sensor

Proline Promass P 100 Incoming acceptance and product identification

Endress+Hauser 9

4 Incoming acceptance and product identification

4.1 Incoming acceptance

A0015502

A0013843

A0013695

A0015502

A0013698

A0015502

A0013699

Incoming acceptance and product identification Proline Promass P 100

10 Endress+Hauser

A0015502

A0013697

If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center.

4.2 Product identification

The following options are available for identification of the measuring device:

• Nameplate specifications

• Order code with breakdown of the device features on the delivery note

•Enter serial numbers from nameplates in W@M Device Viewer

(www.endress.com/deviceviewer): All information about the measuring device is displayed.

For an overview of the scope of the Technical Documentation provided, refer to the following:

The W@M Device Viewer : Enter the serial number from the nameplate

(www.endress.com/deviceviewer)

Order code:

Ext. ord. cd.:

Ser. no.:

A0014053

å 3 Example of a nameplate

1Order code

2 Serial number (Ser. no.)

3 Extended order code (Ext. ord. cd.)

For detailed information about interpreting the nameplate specifications, refer to the

Operating Instructions for the device on the CD-ROM provided

Autres manuels pour Proline Promag P 100

Table des matières

Autres manuels Endress+Hauser Instrument de mesure

Endress+Hauser

Endress+Hauser FMU 40 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 10D Manuel

Endress+Hauser

Endress+Hauser Proline 10 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Raman Rxn4 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiline System CA80HA Caractéristiques techniques

Endress+Hauser

Endress+Hauser Proline 500 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Tankvision Gauge Link NXA20 Manuel utilisateur

Endress+Hauser

Endress+Hauser SpectraSensors SS500e Mode d’emploi

Endress+Hauser

Endress+Hauser Analytikjena SELECT Head 8/250 ml Manuel utilisateur

Endress+Hauser

Endress+Hauser prosonic flow 92 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline t-mass 65 MODBUS RS485 Manuel utilisateur

Endress+Hauser

Endress+Hauser CE 4 Manuel utilisateur

Endress+Hauser

Endress+Hauser Waterpilot FMX21 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass 40 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Proline Promag W 400 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Prosonic Flow B 200 Manuel utilisateur

Endress+Hauser

Endress+Hauser Gammapilot M FMG60 Caractéristiques techniques

Endress+Hauser

Endress+Hauser HART Proline t-mass I 300 Manuel utilisateur

Endress+Hauser

Endress+Hauser Solicap M FTI55 Instructions d'installation

Endress+Hauser

Endress+Hauser Liquiline Control CDC90 Manuel utilisateur

Endress+Hauser

Endress+Hauser Tankvision Multi Scan NXA83B Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquistation CSF33 Manuel utilisateur

Endress+Hauser

Endress+Hauser Prosonic T FMU 130 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot M FMR231 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur

Acterna

Acterna MS1400 Manuel utilisateur

R&S

R&S ZPH Manuel utilisateur
