Brief Operating Instructions

Levelflex FMP53

HART

Guided Level Radar

These Instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Detailed information about the device can be found in the

Operating Instructions and the other documentation:

Available for all device versions via:

– Internet: www.endress.com/deviceviewer

– Smart phone/tablet: Endress+Hauser Operations App

Description of the procedure (→  12)

KA01078F/00/EN/15.13

71226724

Table of contents Levelflex FMP53 HART

2 Endress+Hauser

Table of contents

1 Important document information ................................................ 3

1.1 Symbols ............................................................................ 3

2 Basic safety instructions ......................................................... 6

2.1 Requirements for the personnel ........................................................... 6

2.2 Designated use ....................................................................... 6

2.3 Workplace safety ...................................................................... 7

2.4 Operational safety ..................................................................... 7

2.5 Product safety ........................................................................ 7

3 Product description .............................................................. 8

3.1 Design ............................................................................. 8

4 Incoming acceptance and product identification ................................. 10

4.1 Incoming acceptance .................................................................. 10

4.2 Product identification ................................................................. 11

4.3 Device documentation ................................................................. 12

5 Storage, Transport .............................................................. 13

5.1 Storage conditions .................................................................... 13

5.2 Transport product to the measuring point ................................................... 13

6 Mounting ....................................................................... 14

6.1 Mounting requirements ................................................................ 14

6.2 Mounting the device .................................................................. 19

6.3 Post-installation check ................................................................. 25

7 Electrical connection ............................................................ 26

7.1 Connection conditions ................................................................. 26

7.2 Connecting the device ................................................................. 44

7.3 Post-connection check ................................................................. 47

8 Commissioning (via operating menu) ........................................... 48

8.1 Display and operating module ........................................................... 48

8.2 Operating menu ..................................................................... 51

8.3 Unlock the device .................................................................... 52

8.4 Setting the operating language .......................................................... 52

8.5 Configuration of a level measurement ..................................................... 53

8.6 User-specific applications ............................................................... 55

Levelflex FMP53 HART Important document information

Endress+Hauser 3

1 Important document information

1.1 Symbols

1.1.1 Safety symbols

Symbol Meaning

DANGER

A0011189-EN

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

A0011190-EN

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

A0011191-EN

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

A0011192-EN

NOTICE!

This symbol contains information on procedures and other facts which do not result in personal

injury.

1.1.2 Electrical symbols

Symbol Meaning

A0011197

Direct current

A terminal to which DC voltage is applied or through which direct current flows.

A0011198

Alternating current

A terminal to which alternating voltage is applied or through which alternating current flows.

A0017381

Direct current and alternating current

• A terminal to which alternating voltage or DC voltage is applied.

• A terminal through which alternating current or direct current flows.

A0011200

Ground connection

A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.

A0011199

Protective ground connection

A terminal which must be connected to ground prior to establishing any other connections.

A0011201

Equipotential connection

A connection that has to be connected to the plant grounding system: This may be a potential

equalization line or a star grounding system depending on national or company codes of practice.

Important document information Levelflex FMP53 HART

4 Endress+Hauser

1.1.3 Tool symbols

A0011219 A0011220 A0013442 A0011221 A0011222

Cross-head

screwdriver

Flat blade

screwdriver Torx screwdriver Allen key Hexagon wrench

1.1.4 Symbols for certain types of information

Symbol Meaning

A0011182

Allowed

Indicates procedures, processes or actions that are allowed.

A0011183

Preferred

Indicates procedures, processes or actions that are preferred.

A0011184

Forbidden

Indicates procedures, processes or actions that are forbidden.

A0011193

Tip

Indicates additional information.

A0011194

Reference to documentation

Refers to the corresponding device documentation.

A0011195

Reference to page

Refers to the corresponding page number.

A0011196

Reference to graphic

Refers to the corresponding graphic number and page number.

,…

Series of steps

Result of a sequence of actions

1.1.5 Symbols in graphics

Symbol Meaning

1, 2, 3 ... Item numbers

,…

Series of steps

A, B, C, ... Views

A-A, B-B, C-C, ... Sections

Levelflex FMP53 HART Important document information

Endress+Hauser 5

Symbol Meaning

A0011187

Hazardous area

Indicates a hazardous area.

A0011188

Safe area (non-hazardous area)

Indicates a non-hazardous location.

1.1.6 Symbols at the device

Symbol Meaning

Safety instructions

Observe the safety instructions contained in the associated Operating Instructions.

Temperature resistance of the connection cables

Specifies the minimum value of the temperature resistance of the connection cables.

Basic safety instructions Levelflex FMP53 HART

6 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for the personnel

The personnel must fulfill the following requirements for its tasks:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task

‣Are authorized by the plant owner/operator

‣Are familiar with federal/national regulations

‣Before beginning work, the specialist staff must have read and understood the instructions

in the Operating Instructions and supplementary documentation as well as in the

certificates (depending on the application)

‣Following instructions and basic conditions

2.2 Designated use

Application and measured materials

The measuring device described in these Operating Instructions is intended only for level

measurement of liquids. Depending on the version ordered the device can also measure

potentially explosive, flammable, poisonous and oxidizing materials.

Observing the limit values specified in the "Technical data" and listed in the Operating

Instructions and supplementary documentation, the measuring device may be used for the

following measurements only:

‣Measured process variables: level

‣Calculated process variables: Volume or mass in arbitrarily shaped vessels (calculated from

the level by the linearization functionality)

To ensure that the measuring device remains in proper condition for the operation time:

‣Use the measuring device only for measured materials against which the process-wetted

materials are adequately resistant.

‣Observe the limit values in "Technical data".

Incorrect use

The manufacturer is not liable for damage caused by improper or non-designated use.

Verification for borderline cases:

‣For special measured materials and cleaning agents, Endress+Hauser is glad to provide

assistance in verifying the corrosion resistance of wetted materials, but does not accept any

warranty or liability.

Residual risk

The electronics housing and its built-in components such as display module, main electronics

module and I/O electronics module may heat to 80 °C (176 °F) during operation through heat

transfer from the process as well as power dissipation within the electronics. During operation

the sensor may assume a temperature near the temperature of the measured material.

Danger of burns due to heated surfaces!

‣For high process temperatures: Install protection against contact in order to prevent burns.

Levelflex FMP53 HART Basic safety instructions

Endress+Hauser 7

2.3 Workplace safety

For work on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

With divisible probe rods, medium may penetrate into the joints between the indivual parts of

the rod. This medium may escape when loosening the joints. In the case of dangerous (e.g.

aggressive or toxic) media this may cause injuries.

‣When loosening the joints between the individual parts of the probe rod: Wear appropriate

protective equipment according to the medium.

2.4 Operational safety

Risk of injury.

‣Operate the device in proper technical condition and fail-safe condition only.

‣The operator is responsible for interference-free operation of the device.

Conversions to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers.

‣If, despite this, modifications are required, consult with the manufacturer.

Repair

To ensure continued operational safety and reliability,

‣Carry out repairs on the device only if they are expressly permitted.

‣Observe federal/national regulations pertaining to repair of an electrical device.

‣Use original spare parts and accessories from the manufacturer only.

Hazardous area

To eliminate a danger for persons or for the facility when the device is used in the hazardous

area (e.g. explosion protection, pressure vessel safety):

‣Based on the nameplate, check whether the ordered device is permitted for the intended

use in the hazardous area.

‣Observe the specifications in the separate supplementary documentation that is an integral

part of these Instructions.

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which

they are safe to operate.

It meets general safety standards and legal requirements. It also complies with the EC

directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms

this by affixing the CE mark to the device.

Product description Levelflex FMP53 HART

8 Endress+Hauser

3 Product description

3.1 Design

3.1.1 Levelflex FMP53

A0013421

 1 Design of the Levelflex

1 Electronics housing

2 Process connection

3 Rod probe

Levelflex FMP53 HART Product description

Endress+Hauser 9

3.1.2 Electronics housing

Esc

–+E

123

A0012422

 2 Design of the electronics housing

1 Electronics compartment cover

2 Display module

3 Main electronics module

4 Cable glands (1 or 2, depending on instrument version)

5 Nameplate

6 I/O electronics module

7 Terminals (pluggable spring terminals)

8 Connection compartment cover

9 Grounding terminal

Incoming acceptance and product identification Levelflex FMP53 HART

10 Endress+Hauser

4 Incoming acceptance and product identification

4.1 Incoming acceptance

A0015502

DELIVERY NOTE

1 = 2

A0022480

Is the order code on the

delivery note (1) identical to

the order code on the

product sticker (2)?

A0022486

A0015502

A0022489

Are the goods undamaged?

A0015502

DELIVERY NOTE

Made in Germany, 79689 Maulburg

A0022491

Do the nameplate data

match the ordering

information on the delivery

note?

A0015502

A0022494

Is the DVD (operating tool)

present?

If required (see nameplate):

Are the Safety Instructions

(XA) present?

If one of the conditions does not comply, contact your Endress+Hauser distributor.

Table des matières

Autres manuels Endress+Hauser Instrument de mesure

Endress+Hauser

Endress+Hauser FMU 40 Manuel de la liste des pièces

Endress+Hauser

Endress+Hauser Proline Promag H 200 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Levelflex M FMP41C Manuel utilisateur

Endress+Hauser

Endress+Hauser Prosonic T FMU30 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Proline Promass I 300 PROFIBUS PA Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag D 400 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Proline Promag L 400 Manuel utilisateur

Endress+Hauser

Endress+Hauser RIA452 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquiline System CA80CR Manuel utilisateur

Endress+Hauser

Endress+Hauser dosimass Manuel utilisateur

Endress+Hauser

Endress+Hauser Hart Micropilot FMR60B Manuel

Endress+Hauser

Endress+Hauser Deltabar S PMD75 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Master Meter System Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 55 Manuel utilisateur

Endress+Hauser

Endress+Hauser IO-Link Liquipoint FTW23 Manuel utilisateur

Endress+Hauser

Endress+Hauser Waterpilot FMX21 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Ecograph T Caractéristiques techniques

Endress+Hauser

Endress+Hauser Levelflex FMP53 Manuel utilisateur

Endress+Hauser

Endress+Hauser RIA16 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Cleanfit W CPA450 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass 83 Manuel de la liste des pièces

Endress+Hauser

Endress+Hauser Liquiline CA80FE Caractéristiques techniques

Endress+Hauser

Endress+Hauser Conducal CLY421 Manuel utilisateur

Endress+Hauser

Endress+Hauser Gammapilot FMG50 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur

Acterna

Acterna MS1400 Manuel utilisateur

R&S

R&S ZPH Manuel utilisateur
