Operating Instructions

Oxymax COS22D

Dissolved oxygen sensor

Notes for using this manual

Warning instructions and their meaning

The structure, signal words and safety colors of the signs comply with the specifications of ANSI Z535.6

("Product safety information in product manuals, instructions and other collateral materials").

Cross-references in the document

Safety message structure Meaning

DANGER

Cause (/consequences)

Consequences if safety

message is not heeded

►Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the situation will result in a fatal or serious injury.

WARNING

Cause (/consequences)

Consequences if safety

message is not heeded

►Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the situation can result in a fatal or serious injury.

CAUTION

Cause (/consequences)

Consequences if safety

message is not heeded

►Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid this situation can result in minor or medium injury.

NOTICE

Cause/situation

Consequences if safety

message is not heeded

►Action/note

This symbol alerts you to situations that can result in damage to

property and equipment.

È ä 1 This symbol stands for a cross-reference to a specific page (e.g. Page 1).

È å 2 This symbol stands for a cross-reference to a specific graphic (e.g. Fig. 2).

Endress+Hauser

Table of contents

1 Safety instructions . . . . . . . . . . 4

1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Installation, commissioning and operation . 4

1.3 Operational safety . . . . . . . . . . . . . . . . . . . 5

1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Identification . . . . . . . . . . . . . . 5

2.1 Interpreting an order code . . . . . . . . . . . . . 5

2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . 5

2.3 Certificates and approvals . . . . . . . . . . . . . . 6

3 Installation . . . . . . . . . . . . . . . . 8

3.1 Incoming acceptance, transport, storage . . . 8

3.2 Installation conditions . . . . . . . . . . . . . . . . 8

3.3 Installation instructions . . . . . . . . . . . . . . . 9

3.4 Installation examples . . . . . . . . . . . . . . . . 11

3.5 Post-installation check . . . . . . . . . . . . . . . 13

4 Wiring . . . . . . . . . . . . . . . . . . 14

4.1 Sensor design for hazardous area

applications . . . . . . . . . . . . . . . . . . . . . . . 14

4.2 Connection at the transmitter . . . . . . . . . . 16

4.3 Post-connection check . . . . . . . . . . . . . . . 16

5 Function . . . . . . . . . . . . . . . . . 17

5.1 Measuring principle . . . . . . . . . . . . . . . . . 17

5.2 Calibration . . . . . . . . . . . . . . . . . . . . . . . . 19

6 Commissioning. . . . . . . . . . . . 22

6.1 Function check . . . . . . . . . . . . . . . . . . . . 22

6.2 Polarization . . . . . . . . . . . . . . . . . . . . . . . 22

6.3 Calibration . . . . . . . . . . . . . . . . . . . . . . . . 23

7 Maintenance. . . . . . . . . . . . . . 24

7.1 Maintenance tasks . . . . . . . . . . . . . . . . . . 24

7.2 Maintenance intervals . . . . . . . . . . . . . . . 24

7.3 Cleaning the sensor . . . . . . . . . . . . . . . . . 25

7.4 Wear parts and consumables . . . . . . . . . . 25

8 Accessories. . . . . . . . . . . . . . . 29

8.1 Connection accessories . . . . . . . . . . . . . . 29

8.2 Installation accessories . . . . . . . . . . . . . . . 29

9 Troubleshooting . . . . . . . . . . . 30

9.1 Troubleshooting instructions . . . . . . . . . . . 30

9.2 Spare parts and consumables . . . . . . . . . . . 31

9.3 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

9.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . 31

10 Technical data. . . . . . . . . . . . . 32

10.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

10.2 Performance characteristics . . . . . . . . . . . . 32

10.3 Environment . . . . . . . . . . . . . . . . . . . . . . 34

10.4 Process . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

10.5 Mechanical construction . . . . . . . . . . . . . . 35

Index. . . . . . . . . . . . . . . . . . . . 37

Safety instructions

4Endress+Hauser

1 Safety instructions

1.1 Designated use

The oxygen sensor is suitable for continuous measurement of dissolved oxygen in water.

The specific suitability depends on the sensor design:

• COS22D-1 (standard, measuring range 0.01 to 60 mg/l)

– Measuring, monitoring and regulating the oxygen content in fermenters

– Monitoring the oxygen content in biotechnology facilities

• COS22D-3 (trace measurement, measuring range 0.001 to 10 mg/l, preferred operational range

0.001 to 2 mg/l), also suitable for high CO2partial pressure

– Monitoring inertization equipment in the food industry

– Monitoring the residual oxygen content in carbonated fluids of the beverage industry

– Trace measurement in industrial applications such as inertizations

– Monitoring the residual oxygen content in boiler feedwater

– Monitoring, measuring and regulating the oxygen content in chemical processes

NOTICE

Molecular hydrogen

Hydrogen causes sensitivity in other substances and leads to false low readings or, at the worst, total

failure of the sensor.

►Do not use the sensor in media containing hydrogen.

The COS22D sensor has to be connected with the CYK10 measuring cable for non-contact, digital data

transmission to the digital input of the Liquiline transmitter.

Any other use than the one described here compromises the safety of persons and the entire measuring

system and is, therefore, not permitted.

The manufacturer is not liable for damage caused by improper or non-designated use.

1.2 Installation, commissioning and operation

Please note the following items:

• Installation, electrical connection, commissioning, operation and maintenance of the measuring

system must only be carried out by trained technical personnel.

The technical personnel must be authorized to perform such tasks by the owner-operator.

• The electrical connection must only be performed by an electrical technician.

• Technical personnel must have read and understood these Operating Instructions and must adhere

to them.

• Before commissioning the entire measuring point, check all the connections for correctness. Ensure

that electrical cables and hose connections are not damaged.

• Do not operate damaged products and secure them against unintentional commissioning. Mark the

damaged product as being defective.

• Measuring point faults may only be rectified by authorized and specially trained personnel.

• If faults cannot be rectified, the products must be taken out of service and secured against

unintentional commissioning.

Identification

Endress+Hauser 5

• Repairs not described in these Operating Instructions may only be carried out at the manufacturer’s

or by the service organization.

1.3 Operational safety

The sensor has been designed and tested according to the state of the art and left the factory in perfect

functioning order.

Relevant regulations and European standards have been met.

As the user, you are responsible for complying with the following safety conditions:

• Installation instructions

• Local standards and regulations.

1.4 Return

If the device requires repair, please send it cleaned to the sales center responsible.

Please use the original packaging, if possible.

Before returning the device, please clarify all formalities - such as obtaining an identification number -

with your sales center.

Please enclose the completed "Declaration of Contamination" (copy the second last page of these

Operating Instructions) with the packaging and the transportation documents. No repair without

completed "Declaration of contamination"!

2 Identification

2.1 Interpreting an order code

To discover the version of your device, enter the order code from the nameplate into the search

screen at the following address: www.products.endress.com/order-ident

2.2 Scope of delivery

The following items are included in the delivery:

• Oxygen sensor with watering cap (filled with tap water) for protecting the membrane

• Electrolyte, 1 bottle, 10 ml (0.34 fl.oz.)

• Brief Operating Instructions

• Operating Instructions on CD

If you have any questions, please contact your supplier or your sales center responsible.

Identification

6Endress+Hauser

2.3 Certificates and approvals

2.3.1 Approval for use in hazardous areas

Version COS22D-BA

ATEX 1G Ex ia IIC T3/T4/T6 Ga

Designated authority

EXAM BBG Prüf- und Zertifizier GmbH

Bochum

a0014925

Identification

Endress+Hauser 7

2.3.2 FDA compatibility

The manufacturer declares the use of FDA-listed materials.

Ask your local sales center for the certificates.

Note for hazardous area versions:

For operation in FDA processes, another FDA-approved seal must be installed before the process seal

(e.g. CPA442). Doing so will sufficiently separate the process from the Ex connection.

Product FDA certificate for

COS22D-****22 Membrane, O-rings, process seal

COS22Z-*2*2 Membrane, O-rings, process seal

COS22D-****23 Membrane, O-rings

COS22Z-*2*3 Membrane, O-rings

Installation

8Endress+Hauser

3 Installation

3.1 Incoming acceptance, transport, storage

►Make sure the packaging is undamaged!

►Inform the supplier about damage to the packaging. Keep the damaged packaging until the matter

has been settled.

►Make sure the contents are undamaged!

►Inform the supplier about damage to the delivery contents. Keep the damaged products until the

matter has been settled.

►Check that the scope of delivery is complete and agrees with your order and the shipping

documents.

►The packaging material used to store or to transport the product must provide shock protection and

humidity protection. The original packaging offers the best protection. Also, keep to the approved

ambient conditions (see "Technical data").

►If you have any questions, please contact your supplier or your sales center responsible.

3.2 Installation conditions

3.2.1 Orientation

The sensor must be installed with an inclination angle of at least 10 ˚to the horizontal in an assembly,

support or a corresponding process connection. Other inclination angles are not permitted. Do not

install the sensor overhead.

Observe the instructions for installing sensors in the Operating Instructions for the assembly used.

a0005584-de

Fig. 1: Permitted installation angle

10° 10° Not permissible!

Not permissible!

Permissible angle of installation

Installation

Endress+Hauser 9

3.2.2 Mounting location

• Select the installation location so that there is easy access for later calibration.

• Make sure that upright posts and assemblies are secured safely and vibration-free.

• Select an installation location which produces a typical oxygen concentration for the individual

application.

3.3 Installation instructions

3.3.1 Measuring system

A complete measuring system comprises:

• An Oxymax COS22D oxygen sensor

• A transmitter, e.g. Liquiline CM42

• A corresponding measuring cable, e.g. CYK10

• Optional: an assembly, e.g. permanent installation assembly CPA442, flow assembly CPA240, or

retractable assembly CPA475

a0001398

Fig. 2: Example of a measuring system with COS22D

1 Liquiline CM42

2 Measuring cable CYK10

3 Digital oxygen sensor Oxymax COS22D

4 Permanent installation assembly CPA442

Installation

10 Endress+Hauser

3.3.2 Installing a measuring point

WARNING

Electrical voltage

In the event of a fault, non-grounded metallic assemblies may be under voltage and then are not

touchable.

►When using metallic assemblies and installation equipment, observe the national grounding

provisions.

For a complete installation of a measuring point, proceed as follows:

1. Install a retractable or a flow assembly (if used) into the process.

2. Connect the water supply to the rinse connections (if you use an assembly with cleaning function).

3. Install and connect the oxygen sensor.

NOTICE

Installation error

Cable break, loss of the sensor due to cable separation, unscrewing of the membrane cap

►Do not install the sensor suspended from the cable.

►Screw the sensor into the assembly so that the cable is not twisted.

►When installing or uninstalling the sensor body, hold it tightly. Turn it by the threaded end only.

Otherwise you might unscrew the membrane cap. This will then remain in the assembly or process.

►Avoid exerting excessive tensile force on the cable (e.g. from jerky pulling).

►Select an installation location that is easy to access for later calibrations.

Autres manuels pour Oxymax COS22D

Table des matières

Autres manuels Endress+Hauser Accessoires

Endress+Hauser

Endress+Hauser Oxymax COS61 Manuel

Endress+Hauser

Endress+Hauser Deltapilot M FMB50 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Proline 800 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Oxymax COS22D Caractéristiques techniques

Endress+Hauser

Endress+Hauser Turbimax CUS71D Manuel utilisateur

Endress+Hauser

Endress+Hauser Oxymax H COS21D Manuel utilisateur

Endress+Hauser

Endress+Hauser OxyMax W COS 71 Manuel utilisateur

Endress+Hauser

Endress+Hauser Memosens COL37E Manuel utilisateur

Endress+Hauser

Endress+Hauser Solitrend MMP42 Caractéristiques techniques

Endress+Hauser

Endress+Hauser CCS140 Manuel utilisateur

Endress+Hauser

Endress+Hauser Prosonic S Series Manuel

Endress+Hauser

Endress+Hauser Memosens COS81D Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline 100 Modbus RS485 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Nivector FTI26 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Liquipoint T Series Manuel

Endress+Hauser

Endress+Hauser Oxymax W COS51D Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltapilot S FMB70 Instructions d'installation

Endress+Hauser

Endress+Hauser Soliwave FQR56 Manuel utilisateur

Endress+Hauser

Endress+Hauser Cleanfit P CPA472 Manuel utilisateur

Endress+Hauser

Endress+Hauser CCS240 Manuel utilisateur

Endress+Hauser

Endress+Hauser Chloromax CCS142D Manuel utilisateur

Endress+Hauser

Endress+Hauser Dipfit W CLA111 Manuel utilisateur

Endress+Hauser

Endress+Hauser Indumax CLS54 Manuel utilisateur

Endress+Hauser

Endress+Hauser Oxymax W COS51D Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
