Page 1

Log sets comply with ANSI Z21.11.2 Unvented Heaters

and also comply with ANSI Z21.60 Decorative Vented

Appliances for Solid Fuel Burning Fireplaces. State or

local codes may only allow operation of log sets in a

vented conguration. Check your state or local codes.

DRIFTWOOD

�

WARNING

FIRE OR EXPLOSION HAZARD

If the information in these instructions is

not followed exactly, a re or explosion

may result causing property damage,

personal injury or loss of life.

— Do not store or use gasoline or other

ammable vapors and liquids in the

vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do

not use any phone in your building.

• Leave the building immediately.

• Immediately call your gas supplier

from a neighbor’s phone. Follow the

gas supplier’s instructions.

• If you cannot reach your gas supplier,

call the re department.

— Installation and service must be

performed by a qualied installer,

service agency or the gas supplier.

INSTALLER:

Leave this manual with the appliance.

CONSUMER:

Retain this manual for future reference.

WARNING

If not installed, operated and maintained in

accordance with the manufacturer's instruc-

tions, this product could expose you to sub-

stances in fuel or from fuel combustion which

can cause death or serious illness.

INSTALLATION INSTRUCTIONS

AND OWNER’S MANUAL

Please See Our Website For Log Assembly Videos.

LOG SET FOR UNVENTED

GAS LOG HEATER OR VENTED

DECORATIVE APPLIANCE

MODELS

LS18CD-1 LS24CD-1 LS30CD-1

GAS-FIRED

LS24CD Shown

38616-0-0218Page 2

TABLE OF CONTENTS

Section Page

Important Installation Guidelines..................................................................................................................................3

General Information .....................................................................................................................................................3

Requirements for Canada............................................................................................................................................4

LS(18,24,30)CD Log Sets............................................................................................................................................5

Log Identication LS18CD ...........................................................................................................................................6

Log Placement LS18CD........................................................................................................................................7 - 16

Log Identication LS24CD .........................................................................................................................................17

Log Identication LS30CD .........................................................................................................................................18

Log Placement LS(24,30)CD ..............................................................................................................................19 - 30

Ember Placement LS(18,24,30)CD............................................................................................................................31

Valve Operation LS(18,24,30)CD...............................................................................................................................32

Appliance Service History ...................................................................................................................................33 - 34

Master Parts Distributor List.......................................................................................................................................35

How To Order Repair Parts ........................................................................................................................................35

38616-0-0218 Page 3

Proper Log Placement

Log placement is critical to proper burner performance. Logs must

be correctly positioned onto the burner. The photos in this manual

show the proper pinned position for logs on this set. Owners need to

be shown proper log placement and instructed not to move the logs.

Logs must t rmly onto the burner when positioned as shown in the

photos. Malformed logs or logs with sloppy pin holes must be replaced.

Proper Placement of Rock Wool and Decorative Lava Rock

Rock wool can be added to burners for a glowing ember effect. Place

on the front portion of the burner only. The photos in this manual

show the proper placement of rock wool.

Never place decorative lava rock or small wood pieces on the burner.

Place them on the oor of the replace or rebox only.

Proper Primary Airow into Burner

For proper burner operation and ame appearance, the ow of

primary air into the venturi tube, located on the rear of the burner,

must not be reduced. Air ow may be reduced if dirt, lint or other

obstructions build-up around or inside the venturi. Any obstruction

must be removed. Air ow into the venturi is also reduced if the gas

orice isn’t centered in the venturi inlet or is not aligned with the

venturi. Correct any misalignment of the burner orice by bending

the shutter cap holding the orice to the inlet of the venturi tube.

Ceiling Fans, Portable Fans or Logs Installed Near Cold Air Returns

Ceiling fans or oscillating fans need to be monitored during the

operation of this vent-free burner. If air blows directly into the ame

causing it to impinge on the log set, or rebox, turn off or redirect the

fan. Ceiling fans may be reversed to eliminate ame impingement.

Upon installation, be aware of any cold-air returns or vents in the

proximity of the burner. Any draft created around a vent-free burner

can cause ame impingement and create soot.

WARNING

Do not allow fans to blow directly into the replace. Avoid

any drafts that alter burner ame patterns.

WARNING

Do not use a blower insert, heat exchanger insert or other

accessory not approved for use with this heater.

Candles

Avoid the use of scented or decorative candles while the log set is

in operation. Candles produce a residue in the air that creates a

soot-like substance. Burning candles while the burner is operating

magnies the problem. Candles in general produce soot. The

amount of time burned and the quantity of candles will determine

the amount of soot produced.

Make Owners Aware of Proper Log Set Operation

Properly installed and properly maintained log sets do not deposit

soot on the logs. If users see soot on a log, they should call for

service. Do not continue to operate the log set.

Sunken Fireplace

If installing this unit into a sunken replace, raise the oor to ensure

adequate airow and guard against sooting. Raise replace oor

using a non-combustible material, which is secure.

Glass Doors

Keep glass doors open during all operations of the logset. The

opening of the glass door frame should be the dimension used for

the minimum front opening of the rebox.

Wood-Burning Fireplaces

The interior of the rebox and the chimney must be cleaned and free

of all creosote before installing a gas log set. Creosote will soften

when heated and can drop onto the logset causing odors and soot.

WARNING

Before installing in a solid-fuel burning replace, the chimney

ue and rebox must be cleaned of soot, creosote, ashes

and loose paint by a qualied chimney cleaner.

Initial Operation

Once the installation is complete and the logs and embers are

in place, light the burner and operate it on high for a minimum of

three continuous hours. This will burn off any foreign materials,

such as dust or paint overspray, that might cause odors during

normal operation. Open windows or doors as needed to allow

odors and excess heat to escape.

Qualied Installing Agency

Installation and replacement of gas piping, gas utilization equip-

ment or accessories and repair and servicing of equipment shall be

performed only by a qualied agency. The term "qualied agency"

means any individual, rm, corporation, or company that either in

person or through a representative is engaged in and is responsible

for (a) the installation, testing, or replacement of gas piping or (b) the

connection, installation, testing, repair, or servicing of equipment;

that is experienced in such work; that is familiar with all precautions

required, and that has complied with all the requirements of the

authority having jurisdiction.

The installation must conform with local codes or, in the absence of

local codes, with the National Fuel Gas Code,ANSI Z223.1/NFPA54.*

*Available from the American National Standards Institute, Inc. 11 West

42nd St., New York, N.Y. 10018.

Commonwealth of Massachusetts: The installation must be

made by a licensed plumber or gas tter in the Commonwealth of

Massachusetts. Sellers of unvented propane or natural gas-red

supplemental room heaters shall provide to each purchaser a

copy of 527 CMR 30 upon sale of the unit. In the Commonwealth

of Massachusetts, unvented propane and natural gas-red space

heaters shall be prohibited in bedrooms and bathrooms.

IMPORTANT INSTALLATION GUIDELINES

GENERAL INFORMATION

38616-0-0218Page 4

REQUIREMENTS FOR CANADA

This unit cannot be installed in a UNVENTED application,

this unit can only be installed as a VENTED application

with these requirements.

IMPORTANT SAFETY INFORMATION

This unit complies with ANSI Z21.60and CGA 2.26 Decora-

tive Gas Appliances For Installation In Solid Fuel Burning

Fireplaces. Do not burn wood or solid fuels in a replace

where a decorative gas log set is installed. This appliance is

for installation only in a solid fuel burning replace, masonry

replace or manufactured replace.

Warning: Any modication to this gas log set can be dan-

gerous. Improper installation or use of the gas log set can

cause serious injury or death from re, burns, explosion or

carbon monoxide poisoning.

1. Please follow all local codes regarding installation,

combustion and ventilation air or in the absence of

local codes follow the National Fuel Gas Code ANSI

Z223.1(U.S. installation), or CAN/CGA-B149, Installa-

tion Code (Canada installation).

2. Proper installation, burner location and log placement

is important to achieve optimum look and performance

of your gas log set. The logs have been designed for

easy location and placement on the grate and must be

followed for proper operation.

3. Do not operate the burner with glass doors in the closed

position. A replace screen must be in place when the

burner is burning. Adequate combustion air must be

provided for proper venting. All ames should go up and

out the top of the rebox into the ue vent. If any ames

oat or curl forward into the room do not operate appli-

ance. Check for an open ue and adequate combustion

air into the room. A damper clamp must be installed on

the rebox damper to maintain an open ue vent condi-

tion. Refer to replace owners manual INSTALLING

DAMPER CLAMP section.

4. Young children must be carefully supervised when they

are in the same room as an operating vent-free burner.

Do not place stockings, clothing or any ammable ma-

terial above or near the replace.

5. Do not substitute or use materials other than those sup-

plied for use with the log set.

6. Also refer to IMPORTANT SAFETY INFORMATION in

the replace Owner's Manual.

WARNING; DO NOT OPERATE THIS GAS LOG SET

WITH GLASS DOORS CLOSED

• Clothing or other ammable material should not be

placed on or near the appliance.

• Do not place debris or other articles on the log set dur-

ing operation.

• A window should be opened during the initial bake out

period.

• Installation and repair should be done by a qualied

service person. The appliance should be inspected

before use and at least annually by a qualied service

person. More frequent cleaning may be required due to

excessive lint from carpeting, bedding materials, etc. It

is imperative that control compartments, burners and

circulating air passageways of the appliance be kept

clean.

• Do not use this appliance if any part has been under

water. Immediately call a qualied service technician

to inspect the appliance and to replace any part of the

control system and any gas control which has been un-

der water.

• Never burn solid fuels in replace where a gas log set is

installed.

• This unit complies with ANSI Z21.60 Decorative Vented

Appliances for Solid Fuel Burning Fireplaces. State or

local codes may only allow operation of this appliance

in a vented conguration. Check your state or local

codes.

38616-0-0218 Page 5

LS(18,24,30)CD - LOG SETS

LS24CD - LOG SET

LS30CD - LOG SET

LS18CD - LOG SET

38616-0-0218Page 6

PART NUMBER

& DESCRIPTION TOP VIEW FRONT VIEW

R12544

Rear Left

(Log A)

R12545

Rear Right

(Log B)

R12546

Front Left

(Log C)

R12547

Center

(Log D)

R12548

Front Right

(Log E)

R12549

Side Left

(Log F)

R12550

Top Left

(Log G)

R12551

Side Right

(Log H)

LOG IDENTIFICATION - LS18CD

38616-0-0218 Page 7

Before you begin: Do not, handle these logs with your bare hands!

Always wear gloves to prevent skin irritation. After handling logs,

wash your hands gently with soap and water.

All Logs

The positioning of the logs is critical to the safe and clean operation

of this heater. Sooting and other problems may result if the logs are

not properly and rmly positioned in the appliance.

Refer to Figure 1 for the following warning.

WARNING

Failure to position the parts in accordance with this diagram

or failure to use only parts specically approved with this

appliance may result in property damage or personal injury.

LS18CD

Figure 1

ATTENTION: Do not use Figure 1 to order replacement logs. Refer

to Log Identication LS18CD on Page 5 log to order logs for your

appropriate model number.

The following WARNING applies when log set is installed onto an

unvented gas burner assembly.

WARNING

This appliance is equipped for natural or propane gas. Field

conversion is not permitted.

Apply glowing embers per the ember placement section of this

manual on page 30. Replace glowing embers with appropriate part

number from the table below from Empire Comfort Systems, Inc.

Application of excess glowing embers may adversely affect perfor-

mance of the heater.

WARNING

All previously applied loose material must be removed prior

to reapplication.

Replacement Loose

Material (Glowing Embers) Part Number

LS18CD 15999

Platinum Bright Embers PE-20-1

NOTE: A single layer of embers is to be used when applying

Platinum Bright Embers (alone or in combination with production

embers) to the burner. As you add platinum embers, remove a like

amount of standard embers. The total amount of embers must not

exceed the amount provided with the burner. Tear the embers into

dime-size pieces and pull them open to reveal as much surface

area as possible.

LOG PLACEMENT LS18CD

Please See Our Website For Log Assembly Videos.

38616-0-0218Page 8

1. Place Log (B) onto right rear pin on rear log support.

LOG PLACEMENT LS18CD (CONT'D)

TOP VIEW

FRONT VIEW

38616-0-0218 Page 9

2. Place Log (A) onto left rear pin on rear log support.

LOG PLACEMENT LS18CD (CONT'D)

TOP VIEW

FRONT VIEW

38616-0-0218Page 10

3. Place Log (C) onto two (2) left front pins on burner pan.

LOG PLACEMENT LS18CD (CONT'D)

TOP VIEW

FRONT VIEW

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Empire Comfort Systems Accessoires de cheminée

Empire Comfort Systems

Empire Comfort Systems DVP32NKR Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems 37506 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems 41052 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems FIAMMA BX18MTN-1 Guide de démarrage rapide

Empire Comfort Systems

Empire Comfort Systems DVP50PFB Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems DVP20CCKR-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems LS-24-1 EF Guide de démarrage rapide

Empire Comfort Systems

Empire Comfort Systems HMFA-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems LK6-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems FBB21 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems EBL50TK Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems DFB30CCBL-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems LS18WRS-1 Guide de démarrage rapide

Empire Comfort Systems

Empire Comfort Systems EBL34TK Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems DFB20CCBL-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems EMBF-1S-C-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems DG36MX-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems DVVK4F-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems BVX2BL-1 Manuel du propriétaire

Empire Comfort Systems

Empire Comfort Systems LK7-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems LS40STB Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems LS24WRR-1 Guide de démarrage rapide

Empire Comfort Systems

Empire Comfort Systems DVP30CPKR-1 Manuel utilisateur

Empire Comfort Systems

Empire Comfort Systems LS24CB Guide de démarrage rapide

Manuels Accessoires de cheminée populaires d'autres marques

Valor

Valor L2 1700K Manuel utilisateur

Exodraft

Exodraft Xzense Manuel utilisateur

Whalen

Whalen Ruso MNFP62BF23-6 Manuel utilisateur

Lopi

Lopi Hearthview 864 Manuel utilisateur

Woodstock Soapstone

Woodstock Soapstone Fireview 201 Manuel utilisateur

EdilKamin

EdilKamin SERBATOIO 250 Guide de démarrage rapide

Bronpi

Bronpi KIT-1 Manuel utilisateur

Town & Country Fireplaces

Town & Country Fireplaces 22150051 Manuel utilisateur

Travis Industries

Travis Industries 33 DVI Manuel utilisateur

Superior

Superior ASD3628-TI Manuel utilisateur

pleasant hearth

pleasant hearth OFP28WG Manuel utilisateur

IHP

IHP Astria Series Manuel utilisateur

Firegear

Firegear FG-H-2110SS Manuel utilisateur

Nibe

Nibe Contura C i31 Manuel utilisateur

kozy heat

kozy heat KZK-052 Manuel utilisateur

SimpliFire

SimpliFire SF-WM36 Manuel utilisateur

Bluegrass Living

Bluegrass Living BC18NR Guide de démarrage rapide

pleasant hearth

pleasant hearth IRIS SCROLL Manuel utilisateur
