M Series Manual Handwheel Gear Actuator

Contents

Introduction 1.................................

Scope of Manual 1.............................

Description 1.................................

Specifications 1...............................

Installation 3..................................

Operation 5...................................

Maintenance 5.................................

Lubrication 6.................................

Parts Ordering 6................................

Introduction

Scope of Manual

This instruction manual includes installation, operation, maintenance, and parts ordering information for M Series

manual handwheel gear actuators. Refer to separate manuals for instructions covering the valves used with these

actuators.

Do not install, operate, or maintain an M Series handwheel gear actuator without being fully trained and qualified in

valve, actuator and accessory installation, operation and maintenance. To avoid personal injury or property damage it

is important to carefully read, understand, and follow all of the contents of this manual, including all safety cautions

and warnings. If you have any questions about these instructions, contact your Emerson sales office before

proceeding.

Description

M Series handwheel gear actuators (figure 1) are totally enclosed, weatherproof, worm gear actuators for reliable

manual operation with Fisher A11, A31A and A41 High Performance Butterfly Valves. The M actuator consists of a

body housing, cover, worm gear, input shaft, and handwheel. The housing is grease packed.

Specifications

Specifications for the M Series manual handwheel gear actuators are shown in table 1.

Instruction Manual

D500237X012

M Series Actuator

February 2019

Instruction Manual

D500237X012

M Series Actuator

February 2019

Table 1. Specifications

Actuator Sizes

See tables 2, 3 and 4

Valve Compatibility

JAccepts A11 valve square‐end shafts from 10.3 to

34.9 mm (13/32 to 1‐3/8 inches), keyed shafts from

38.1 to 44.5 mm (1‐1/2 to 1‐3/4 inches)(1)

JAccepts A31A valve keyed shafts from 44.5 to

57.2 mm (1‐3/4 to 2‐1/4 inches)

JAccepts A41 valve Double D shafts from 12.7 to

44.5 mm (1/2 to 1‐3/4 inches)

Maximum Torque Output

See Bulletin 22.2:M

Handwheel Rotation

Clockwise handwheel rotation closes the valve

(produces clockwise rotation of the valve shaft)

Construction Materials

Housing and Cover: Cast iron

Worm: Steel

Worm Gear: Manganese Bronze

Input Shaft: Steel (303 SST on request)

Handwheel: Cast Iron

Mounting Positions

See figure 2

Dimensions and Approximate Weights

See Bulletin 22.2:M

Options

JLocking plates with padlock for fixed positioning

JStops are typically set every 10_, but can be special

ordered with stops set up to 45_from both ends

JHandwheel extensions

1. As an option, CL600 NPS 10 (with 1‐1/2 inch keyed shaft) and NPS 12 (with 1‐3/4 inch shaft) A11 valves require a keyed connection if being used with size 9KE or 10KE‐6 actuators.

Figure 1. M Series Handwheel Gear Actuator

W4715‐1

Instruction Manual

D500237X012

M Series Actuator

February 2019

Installation

WARNING

To avoid personal injury or property damage resulting from the sudden release of pressure, do not install the actuator

where service conditions could exceed the limits given in this manual or on the appropriate nameplates. Use

pressure‐relieving devices as required by government or accepted industry codes and good engineering practices.

Always wear protective gloves, clothing, and eyewear when performing any installation operations to avoid personal

injury.

Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance section in this

instruction manual.

The M Series gear actuator is normally mounted on a valve at the factory. However, the actuator can be field mounted;

it can be mounted in any position on the A11 or A31A and it can be mounted in positions 1 and 3 on the A41, as shown

in figure 2. Make clearance considerations before mounting the actuator to determine the most suitable mounting

position.

The M Series actuator has a direct stab‐on design. Simply insert the valve shaft into the broached area of the body

housing. Then attach the mounting bracket to the actuator, using the torques listed in table 5, and attach the

mounting bracket to the valve.

Table 2. M Series Gear Actuator for A11 (CL600)

VALVE

SIZE, NPS

VALVE SHAFT

SIZE, INCHES

MAXIMUM

RECOMMENDED

TORQUE(1) ACTUATOR

SIZE

HANDWHEEL

DIAMETER,

INCHES

RIM FORCE(2) NUMBER

OF TURNS

CLOSE(3)

MAXIMUM TORQUE

RATING OF ACTUATOR

nSm lbSin n lb NSm LbfSin

3 13/32 113 1,000(4) 1KE 12 80 18 9.5 452 4,000

4 5/8 303 2,690(4) 1KE 12 209 47 9.5 452 4,000

6 7/8 643

765

5,700

6,780(4)

2KE

5KE 12 445

400

100

9.5

12.5

678

904

6,000

8,000

8 1

643

846

1349

5,700

7,500

11,960(4)

2KE

5KE

7KE

445

436

100

9.5

12.5

13.5

678

904

2,260

6,000

8,000

20,000

1‐3/8

1‐1/2

1354

2144

3520

12,000

19,000

31,160(4)

7KE

9KE

10KE‐6

440

214

13.5

2,260

3,390

8,474

20,000

30,000

75,000

1‐3/8

1‐3/4

1354

2144

3520

12,000

19,000

31,160(4)

7KE

9KE

10KE‐6

440

214

13.5

2,260

3,390

8,474

20,000

30,000

75,000

1. Maximum recommended torque for the valve/actuator combination is based on valve shaft rating, actuator rating and rim force.

2. Rim force required to produce maximum recommended torque.

3. This column shows the number of times the handwheel must be turned to close the valve 90 degrees.

4. Shaft rating of the A11 valve.

Instruction Manual

D500237X012

M Series Actuator

February 2019

Table 3. M Series Gear Actuator for A31A

VALVE

SIZE, NPS

VALVE

SHAFT

SIZE,

INCHES

MAXIMUM

RECOMMENDED

TORQUE(1) ACTUATOR

SIZE

HANDWHEEL

DIAMETER,

INCHES

RIM FORCE(2) NUMBER

OF TURNS

CLOSE(3)

MAXIMUM TORQUE

RATING OF ACTUATOR

nSm lbSin n lb NSm LbfSin

CL150

14 1‐3/16

644

847

1287

5,700

7,500

11,390(4)

2KE

5KE

7KE

445

418

100

9.5

12.5

13.5

271

904

2,260

6,000

8,000

20,000

16 1‐1/4

644

847

1,579

5,700

7,500

13,970(4)

2KE

5KE

7KE

445

512

100

115

9.5

12.5

13.5

271

904

2,260

6,000

8,000

20,000

18 1‐1/2

1356

2188

12,000

19,370(4)

19,370

7KE

9KE

10KE‐6

440

449

133

101

13.5

2,260

3,390

8,474

20,000

30,000

75,000

20 1‐3/4

1356

2147

2555

12,000

19,000

22,620(4)

7KE

9KE

10KE‐6

440

156

13.5

2,260

3,390

8,474

20,000

30,000

75,000

24 2‐1/4 2147

8,474

19,000

75,000

9KE

10KE‐6

440

516

116

3,390

8,474

30,000

75,000

CL300

14 1‐3/4 1356

2555

12,000

22,620(4)

7KE

9KE

440

525

118

13.5

2,260

3,390

20,000

30,000

16 1‐3/4 1356

2555

12,000

22,620(4)

7KE

9KE

440

525

118

13.5

2,260

3,390

20,000

30,000

18 2‐1/4 2147

6,985

19,000

61,830(4)

9KE

10KE‐6

440

423

3,390

8,474

30,000

75,000

20 2‐3/4 2147

8474

19,000

75,000

9KE

10KE‐6

440

516

116

3,390

8,474

30,000

75,000

24 2‐3/4 8474 75,000 10KE‐6 18 516 116 72 8,474 75,000

1. Maximum recommended torque for the valve/actuator combination is based on valve shaft rating, actuator rating and rim force.

2. Rim force required to produce Maximum recommended torque.

3. This column shows the number of times the handwheel must be turned to close the valve 90 degrees.

4. Shaft rating of the A31A valve.

Table 4. M Series Gear Actuator for A41

VALVE

SHAFT SIZE,

INCHES

ACTUATOR

SIZE

SHAFT RATING HANDWHEEL

DIAMETER,

INCHES

RIM FORCE(1) NUMBER OF

TURNS TO

CLOSE(2)

MAXIMUM TORQUE

RATING OF ACTUATOR

nSm lbSin n lb NSm LbfSin

1/2 0KE/D1 58 515 8 441 21

6 271 2,400

5/8 0KE/D2 138 1,230 8 227 51

3/4 0KE/D3 240 2,120 8 391 88

1 2KE/D4 468 4,140 12 325 73 9.5 678 6,000

1‐1/4 6KE/D5 1,110 9,820 24 365 82 10 1,356 12,000

1‐1/2 6KE/D6 1,356 12,000 24 445 100

1‐3/4 9KE/D7 2,658 23,520 36 365 82 16 3,390 30,000

1. Rim force required to produce shaft rating torque.

2. This column shows the number of times the handwheel must be turned to close the valve 90 degrees.

Instruction Manual

D500237X012

M Series Actuator

February 2019

Table 5. M Series Mounting Plate to Gearbox

Type M Actuator Bolt Size Bolt Torque nSmBolt Torque lbSf

A11 and A31A Compatible

1KE 1/2 91 67

2KE 1/2 91 67

5KE 1/2 91 67

7KE 5/8 163 120

9KE 5/8 163 120

10KE‐6 5/8 163 120

A41 Compatible

0KE/D1 5/16 22 16.5

0KE/D2 5/16 22 16.5

0KE/D3 5/16 22 16.5

2KE/D4 3/8 39 29

6KE/D5 3/8 39 29

6KE/D6 5/8 163 120

9KE/D7 3/4 258 190

Operation

After the actuator and control valve assembly are installed, the manual actuator is ready for operation.

CAUTION

Applying too much torque to the actuator and valve parts could cause damage to the parts. To avoid such damage, do not

exceed the rim force listed in table 2, 3 and 4 or any other torque limitation of internal valve parts. Also, do not use

wrenches or other devices on the handwheel or handwheel shaft to increase operating force.

Maintenance

WARNING

Avoid personal injury from sudden release of process pressure. Before performing any maintenance operations:

D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal

injury.

D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the

actuator cannot suddenly open or close the valve.

D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure

on both sides of the valve. Drain the process media from both sides of the valve.

D Vent the power actuator loading pressure and relieve any actuator spring precompression.

D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.

D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the

pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings, or when

loosening the packing box pipe plug.

D Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

Instruction Manual

D500237X012

M Series Actuator

February 2019

If the rim force required to rotate the handwheel exceeds the rim force listed in table 2, 3, or 4, check for the following

conditions:

D Insufficient lubrication

D Seized actuator parts

D Excessive pressure drop across the valve

D Obstruction to the valve disk rotation

If the manual actuator does not seem to control the process fluid, the worm or drive sleeve gear teeth may be broken,

the handwheel pin may be sheared, or the valve parts may be broken. Purchase a replacement manual actuator if

necessary. Refer to the valve instruction manual if valve maintenance is needed.

Lubrication

The interior parts of the M Series actuator should be lubricated on a regular schedule with a quality gear lubricant. The

interior parts should also be lubricated whenever difficulty in handwheel rotation indicates a need for lubrication.

1. Isolate the control valve from the line pressure, release pressure from both sides of the valve body, and drain the

process media from both sides of the valve.

2. Remove the cap screws that secure the gearbox cover plate and remove the gearbox cover plate.

3. Coat the worm, the drive sleeve gear teeth, and the bearing surfaces of the gearbox housing and worm with a

quality gear lubricant.

4. Replace the cover plate and cap screws using the bolt torques listed in table 5.

5. Replace the manual actuator on the valve. Adjust the actuator travel stop to limit the open and closed positions of

the valve disk following the steps in the appropriate valve instruction manual.

Parts Ordering

When corresponding with your Emerson sales office indicate the size of the M Series actuator. The size is stamped on

the gearbox. You should also provide the serial number of the valve.

WARNING

Use only genuine Fisher™replacement parts. Components that are not supplied by Emerson Automation Solutions should

not, under any circumstances, be used in any Fisher valve, because they will void your warranty, might adversely affect the

performance of the valve, and could give rise to personal injury and property damage.

Instruction Manual

D500237X012

M Series Actuator

February 2019

Figure 2. Available Mounting Positions

POSITION 3

POSITION 4

FLOW DIRECTION

FOR RIGHT‐HAND

MOUNTING

POSITION 1

VALVE BODY

FLOW DIRECTION

FOR LEFT‐HAND

MOUNTING

POSITION 2

30B0668‐A

A7133

NOTE:

ONLY POSITIONS 1 AND 3 ARE APPLICABLE TO A41.

Instruction Manual

D500237X012

M Series Actuator

February 2019

Figure 3. Typical M Series Assembly

GEAR BOX

MOUNTING BRACKET

A7139

Emerson Automation Solutions

Marshalltown, Iowa 50158 USA

Sorocaba, 18087 Brazil

Cernay, 68700 France

Dubai, United Arab Emirates

Singapore 128461 Singapore

www.Fisher.com

The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not

to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are

governed by our terms and conditions, which are available upon request. We reserve the right to modify or improve the designs or specifications of such

products at any time without notice.

Fisher is a mark owned by one of the companies in the Emerson Automation Solutions business unit of Emerson Electric Co. Emerson Automation Solutions,

Emerson, and the Emerson logo are trademarks and service marks of Emerson Electric Co. All other marks are the property of their respective owners.

Neither Emerson, Emerson Automation Solutions, nor any of their affiliated entities assumes responsibility for the selection, use or maintenance

of any product. Responsibility for proper selection, use, and maintenance of any product remains solely with the purchaser and end user.

Table des matières

Autres manuels Emerson Contrôleurs

Emerson

Emerson Fisher EZL Manuel utilisateur

Emerson

Emerson DanLoad 6000 Guide rapide

Emerson

Emerson Hytork XL Series Manuel d'installation et d'exploitation

Emerson

Emerson dixell XC10CX Schéma de câblage

Emerson

Emerson Fisher Type 667 size 80 Manuel

Emerson

Emerson EC2-742 Manuel utilisateur

Emerson

Emerson Biffi Morin Series Manuel utilisateur

Emerson

Emerson S402Y Manuel utilisateur

Emerson

Emerson El-O-Matic E Series Manuel d'instructions

Emerson

Emerson Fisher 785C Guide de configuration

Emerson

Emerson Fisher Level-Trol 2502 Series Manuel utilisateur

Emerson

Emerson XWEB300D Manuel utilisateur

Emerson

Emerson COPELAND XC PRO Manuel du propriétaire

Emerson

Emerson dixell XW20LR Schéma de câblage

Emerson

Emerson Fisher 749B Manuel utilisateur

Emerson

Emerson Asco 642 Series Manuel utilisateur

Emerson

Emerson Digistart IS1x0043B series Manuel utilisateur

Emerson

Emerson FloBoss 107 Manuel utilisateur

Emerson

Emerson Tartarini M Series Manuel utilisateur

Emerson

Emerson Fisher FIELDVUE DVC6200 SIS Manuel utilisateur

Emerson

Emerson FISHER SR8 Manuel utilisateur

Emerson

Emerson Fisher Y696VR Series Manuel utilisateur

Emerson

Emerson EC3-XEV02D Manuel utilisateur

Emerson

Emerson Keystone EPI2 63 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

3M MicroTouch EX113 Manuel utilisateur
