Thank You....................

for purchasing this Emerson AM/FM Stereo Clock Radio with Compact Disc

Player. In addition to waking to a buzzer alarm, or your favorite AM or FM Stereo

stations, you can also wake to the music of your favorite artists on compact disc.

There are dual alarms that can be set and used independently, a sleep to music

timer that controls both the radio and the CD player, and a Sure Alarm battery

back up system that will wake you to radio or buzzer, even if the power is out at

the wake up time. The large green LED display shows the time, alarm settings,

and CD track numbers, and it can be seen from anywhere in your room. The two

3” dynamic speakers provide excellent sound for such a compact unit. All major

controls are right on the top panel for simple, user-friendly operation.

Please read this manual completely to familiarize yourself with all the features of

your new CD clock radio, and save this manual for future reference. Your

warranty is on the back page of this manual.

The serial number of your unit can be found on the bottom of the cabinet. We

suggest that you record the serial number in the space provided below in case

this information is ever needed at a future date.

Model Number: CKD9908

Serial Number _______________________________________

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE

THIS UNIT TO RAIN OR MOISTURE.

DANGER:

Invisible and hazardous laser radiation when open and

interlock failed or defeated. Avoid direct exposure to beam.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

DANGEROUS VOLTAGE

Uninsulated Dangerous Voltage, that may be of sufficient

magnitude to constitute a risk of electric shock to persons is

present within this product’s enclosure.

ATTENTION

The Owner’s Manual contains important operating and

maintenance instructions.

For your safety, it is necessary to refer to the manual.

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 1

INFORMATION

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

SAFETY PRECAUTIONS

FCC WARNING:

This equipment may generate or use radio frequency energy. Changes

or modifications to this equipment may cause harmful interference

unless the modifications are expressly approved in the instruction

manual. The user could lose the authority to operate this equipment if

an unauthorized change or modification is made.

LASER SAFETY: This unit employs a laser. Only qualified service

personnel should attempt to service this device due to possible eye

injury.

CAUTION: USE OF CONTROLS, ADJUSTMENTS OR

PERFORMANCE PROCEDURE HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 2

LOCATION OF CONTROLS

130

1. CD Compartment Door

2. WAKE (MUSIC/BUZZER)

Switch

3. ALARM1 (OFF/ON) Switch

4. Battery Compartment (bottom

of unit)

5. ALARM2 (OFF/ON) Switch

6. ALM.1 SET Button

7. ALM.2 SET Button

8. SLEEP Indicator

9. CLOCK Button

10. SLEEP Button

11. POWER Button

12. POWER Indicator

13. AM Indicator

14. ALM.1 Indicator

15. FM STEREO Indicator

16. AM/FM Dial Scale and Pointer

17. ALM.2 Indicator

18. Display

19. SNOOZE Button

20. PLAY/PAUSE ( ) Button

21. SKIP/Search/MINUTE ( )

Button

22. SKIP/Search/HOUR ( )

Button

23. STOP (■) Button

24. TUNING Control

25. PROG (Program) Indicator

26. PROG (Program) Button

27. REPEAT Indicator

28. FUNCTION (FM ST./AM/CD)

Switch

29. REPEAT Button

30. VOLUME Control

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 3

INSTALLATION

Unravel the AC cord and connect it to a conveniently located AC outlet having

120V and 60Hz only. The Clock Display will illuminate and “12:00” will appear in

the display.

NOTE: If the AC plug does not fit into a nonpolarized outlet, do not file or cut the

wide blade.

If the AC cord is disconnected or if there is a power failure,

this electronic clock is designed to continue operating

internally (without showing the time on the Clock Display)

with a 9 volt battery (not included). To install the battery,

remove the battery compartment cover and connect the

battery to the terminals of the battery snap inside the

compartment (use of an alkaline battery is recommended)

and install the battery compartment cover back into place.

Be sure to check the condition of the battery periodically by disconnecting the AC

cord and connecting it again 2 or 3 minutes later. The preset times should

continue operating. If the present time resets to “12:00”, it indicates the battery is

dead or not connected properly. A fresh 9 volt battery will keep the internal times

accurately for approximately 30 minutes. If the power is restored after 30 minutes,

the times may need to be reset.

AC Plug

AC Outlet

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries specified.

2. Be sure to follow the correct polarity when installing the batteries as indicated in the

battery compartment. Reversed batteries may cause damage to the device.

3. If the device is not to be used for a long period of time, remove the batteries to prevent

damage or injury from possible battery leakage.

4. Do not try to recharge batteries not intended to be recharged; they can overheat and

rupture. (Follow battery manufacturer’s directions.)

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 4

OPERATION

Press and hold the CLOCK button and

the time will blink in the Display.

While holding the CLOCK button ❶,

press the SKIP/Search/MINUTE

button ❷ to advance the minute and

the SKIP/Search/HOUR button ❸

to advance the hour until the desired

time is shown on the display.

TO SET OR RESET THE ACTUAL TIME

Press and hold the desired Alarm

switch (ALM.1 or ALM.2)

and the

selected alarm time will blink in the

Display.

While holding the desired ALM button

button ❶, press the SKIP/Search/

MINUTE button ❷ to advance the

minute and the SKIP/Search/HOUR

button ❷ to advance the hour until

the desired alarm time is shown on the

display.

TO SET OR RESET THE ALARM TIME(S)

AM (TIME) LED INDICATOR

In the upper left corner of the Display is the AM LED indicator. When the AM LED

indicator is lit, the actual or alarm time shown in the Display is AM hours. When

the indicator is not lit, the time shown is PM hours.

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 5

OPERATION

Set the alarm time as previously

instructed. Turn the unit on and slide

the FUNCTION switch ❶ to the FM

ST. or AM position. Select a radio

station and make sure the VOLUME ❷

is set as desired. Slide the desired

ALARM switch (ALARM1 or ALARM2)

❸ to the ON position.

Turn the unit off and slide the WAKE

switch to the MUSIC position. When

the actual time matches the selected

preset alarm time(s), the unit

automatically turns on.

To shut off the alarm, see TO SHUT

THE ALARM OFF section on the

following page.

TO SET THE ALARM TO WAKE TO RADIO

Set the alarm time as previously

instructed. Insert a CD into the CD

player, turn the unit on and slide the

FUNCTION switch ❶ to the CD

position. Make sure the VOLUME ❷ is

set as desired. Slide the desired

ALARM switch (ALARM1 or ALARM2)

❸ to the ON position.

Turn the unit off and slide the WAKE

switch to the MUSIC position. When

the actual time matches the selected

preset alarm time(s), the unit

automatically turns on and the CD

begins to play.

To shut off the alarm, see TO SHUT

THE ALARM OFF section on the

following page.

TO SET THE ALARM TO WAKE TO CD

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 6

OPERATION

Set the alarm time as previously

instructed. Slide the desired ALARM

switch (ALARM1 or ALARM2) ❶ to the

ON position. Slide the WAKE switch ❷

to the BUZZER position.

When the actual time matches the

selected preset alarm time(s), the unit

automatically turns on. To shut off the

alarm, see TO SHUT THE ALARM OFF

section below.

TO SET THE ALARM TO WAKE TO BUZZER

To shut the alarm off, press the

POWER button ❶ once and the alarm

time will be reset for the next day.

Slide the desired ALARM switch ❷ to

the OFF position to turn off the alarm

and not set it for the next day.

TO SHUT THE ALARM OFF

The alarm can be temporarily turned

off manually by pressing the

SNOOZE button; the alarm will turn

back on automatically 6 minutes

later.

SNOOZE

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 7

OPERATION

Press the POWER button ❶ to turn

the unit on (the POWER indicator will

light). Slide the FUNCTION switch ❷

the desired band (FM. ST or AM).

Tune a station by turning the TUNING

control

❶

. When a strong FM stereo

signal is received while listening to FM,

the FM ST. indicator will light.

Adjust the VOLUME control

❷

desired.

LISTENING TO THE RADIO

Hints for Better Reception

FM - Make sure the FM Antenna wire is uncoiled and extended to its full length.

You may have to vary the direction of the wire to find the strongest signal for each

FM station.

AM - The AM ferrite bar antenna is located inside the cabinet. It may be

necessary to turn the unit slightly so that the internal antenna is pointing in the

direction of the AM transmitter. You may have to experiment to find the position

that provides the strongest reception for each of your favorite AM stations.

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 8

OPERATION

Press the POWER button ❶ to turn

the unit on (the POWER indicator will

light). Slide the FUNCTION switch ❷

to the CD position.

Press the OPEN/CLOSE area of the

CD compartment door and place a CD

on the center spindle, with the printed

label side facing up. Close the CD

compartment door; the total number of

tracks will briefly appear in the Display.

PLAYING COMPACT DISCS - NORMAL PLAYBACK

Remove the paper card from the CD Compartment before inserting a CD.

Press the PLAY/PAUSE () button

❶

to start playback.

Adjust the VOLUME control ❷ as

desired.

When the disc is through playing, it will

stop. Press the STOP (■) button to

stop the disc before it is finished.

NOTES:

• This unit is capable of playing standard CDs or 3” singles; no adapter is

required.

• If a disc is inserted incorrectly, dirty, damaged or not present at all, “no” will

appear in the display.

• To remove the disc, press the OPEN/CLOSE area on the CD Compartment

door, hold the edge of the CD and lift it out.

• The maximum time of a CD is 74 minutes for this unit.

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 9

OPERATION

During CD playback, if you wish to

pause the disc momentarily, press the

PLAY/PAUSE () button

again.

Playback stops but the disc continues

to spin and the track number flashes

in the Display.

Press the

PLAY/PAUSE () button

again to release Pause and resume

normal CD playback. The sound

returns and the track number in the

Display stops flashing.

CD PAUSE CONTROL

After you insert the disc into the CD

player and the total number of tracks

appear on the display, you may press

either the SKIP/Search ( ) or

SKIP/Search ( ) buttons to select a

specific track for playback.

When the desired track number

appears in the display, press the CD

PLAY/PAUSE () button

. Playback

will begin on the track you selected.

TO BEGIN PLAYBACK FROM A SPECIFIC TRACK

CKD9908 O/M.QXD 1/29/01 2:43 PM Page 10

Table des matières

Autres manuels Emerson Radio-réveil

Emerson

Emerson GirlPower GP816 Manuel utilisateur

Emerson

Emerson CK5048 Manuel utilisateur

Emerson

Emerson CKS1800 Manuel utilisateur

Emerson

Emerson CKD1100, CKD1100BL, CKD1100GN, Manuel utilisateur

Emerson

Emerson SMARTSET CKS1708 Manuel utilisateur

Emerson

Emerson CKS9031 Manuel utilisateur

Emerson

Emerson SmartSet ER100103 Manuel utilisateur

Emerson

Emerson CK9902 Manuel utilisateur

Emerson

Emerson girlpower GP808 Manuel utilisateur

Emerson

Emerson CKS2288 Manuel utilisateur

Emerson

Emerson CKD3630C Manuel utilisateur

Emerson

Emerson CK5859 Manuel utilisateur

Emerson

Emerson SmartSet CKSW0555 Manuel utilisateur

Emerson

Emerson CKS3029 Manuel utilisateur

Emerson

Emerson CK5238 Manuel utilisateur

Emerson

Emerson CKD1612 Manuel utilisateur

Emerson

Emerson SMARTSET CKS1708 Manuel utilisateur

Emerson

Emerson CK5038 Manuel utilisateur

Emerson

Emerson SmartSet CKS1702 Manuel utilisateur

Emerson

Emerson Dora the Explorer DTE810 Manuel utilisateur

Emerson

Emerson SmartSet ER100202 Manuel utilisateur

Emerson

Emerson RET66TQ Manuel utilisateur

Emerson

Emerson SmartSet ER100104 Manuel utilisateur

Emerson

Emerson SmartSet CKS1900 Manuel utilisateur

Manuels Radio-réveil populaires d'autres marques

Denver

Denver CRQ-105 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Sony

Sony Dream Machine ICF-C763L Manuel utilisateur

Sanyo

Sanyo DMP-P6 Manuel utilisateur

RCA

RCA RPC100 Manuel utilisateur

Yamaha

Yamaha ISX-80 Manuel utilisateur

Pyle

Pyle PLMR20W Manuel utilisateur

Blaupunkt

Blaupunkt CR7BK Manuel utilisateur

Philips

Philips AJ3180 Manuel utilisateur

HoMedics

HoMedics SS-5500-2EU Manuel utilisateur

RCA

RCA RC66i Manuel utilisateur

Versaudio

Versaudio Vers Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR8100 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manuel utilisateur

Roberts

Roberts ChronoDAB Manuel utilisateur

AEG

AEG MRC 4132 BT Manuel utilisateur

Tokai

Tokai TC-155 Manuel utilisateur
