Emerson Research CKS2237 Manuel utilisateur

Jumbo Display

Dual Alarm AM/FM Clock Radio

with SmartSet®

Automatic Time Setting System

OWNER’S MANUAL

CKS2237

Visit our web site at www.emersonradio.com

For future reference, record the serial number in the space provided.

Serial Number :

Congratulations!

And thank you for purchasing the Jumbo Display SmartSet® Clock Radio from

Emerson Research. SmartSet®is the world’s first and only LED clock radio that

will automatically set itself to the correct ‘Year’, ‘Month’, ‘Date’, ‘Day’, and ‘Time’

as soon as you plug it in. The only thing you have to do is tell the SmartSet®what

time zone you are in, and the built in computer does everything else for you

immediately. And not only the first time, but every time the power is interrupted

as well.

We all know how annoying it is to wake up in the morning and see the dreaded

flashing “12:00” display on our clocks or clock radios. But with your SmartSet®

Clock Radio the dreaded flashing “12:00” display is a thing of the past.

The SmartSet®resets itself as soon as the power is restored and gets you up on

time, every time.

And if that isn’t enough, the SmartSet®computer also knows when Daylight Saving

Time begins and ends and it will adjust itself for those changes automatically for

the next 99 years! Leap Years too! And best of all, the long life lithium battery

backup battery is already installed in your radio. You don’t have to remember to

put a new 9-volt battery in your radio every 6 months. Under normal circumstances

the lithium battery can last for up to 5 years, and when it does need to be changed,

a low battery indicator will come on to let you know. The CR2430 lithium battery

is available almost anywhere that batteries are sold and it costs about the same

as a normal 9-volt battery.

The SmartSet®also gives you dual alarms that can be set to go off on weekdays

only, weekends only, or all 7 days. You can set one alarm to wake you up to

buzzer Monday through Friday when you have to get up early, and use the second

alarm to wake you up to soft music on Saturday and Sunday when you can sleep

in.

Someday all clocks and clock radios may be this smart. But today the technology

is only available from Emerson Research. We’re sure you’ll be happy and amazed

by your SmartSet®Clock Radio, and that it will give you many years of enjoyment

and dependable service.

Once again, all of us at Emerson Research thank you for your purchase.

FCC INFORMATION

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference

that may cause undesired operation.

IMPORTANT NOTES

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

DANGEROUS VOLTAGE

Uninsulated Dangerous Voltage, that may be of sufficient magnitude

to constitute a risk of electric shock to persons is present within this

product's enclosure.

ATTENTION

The Owner's Manual contains important operating and maintenance

instructions.

For your safety, it is necessary to refer to the manual.

PREPARATION FOR USE

POWER SOURCE

This radio is designed to operate on normal 110V-120V 60Hz AC power only. Do

not attempt to operate the radio on any other power source. You could cause

damage to the radio that is not covered by your warranty.

This radio should be connected to an AC outlet that is always ‘live’. Do not connect

it to an outlet that is controlled by a wall switch. When the power to the radio is

interrupted, the built in lithium battery takes over to maintain the time and alarm

settings. To maximize the life of the lithium battery keep the radio connected to a

‘live’ AC outlet at all times

You will note that this system is

equipped with a polarized AC power

plug having one blade wider than the

other. This is a safety feature. If this

plug does not fit into your existing AC

outlet, do not try to defeat this safety

feature by filing the wide blade to make

it fit into your outlet. If this plug will

not fit into your outlet, you probably have an out-dated non-polarized AC outlet.

You should have your outlet changed by a qualified licensed electrician.

UNPACKING AND SET UP

•Remove the radio from the carton and remove all packing material from the

radio. We suggest that you save the packing material, if possible, in the unlikely

event that your radio ever needs to be returned for service. The original carton

and packing material is the only safe way to pack your radio to protect it from

damage in transit.

•Remove any descriptive labels or stickers on the front or top of the cabinet.

Do not remove any labels or stickers from the back or bottom of the cabinet.

•Note the serial number on the bottom of your radio and write this number in

the space provided on Page 1 of this manual.

•Place your radio on a level surface such as a table, desk or shelf, convenient

to an AC outlet, out of direct sunlight, and away from sources of excess heat,

dirt, dust, moisture, humidity, or vibration.

•Unwind the AC power cord and extend it to its full length. The FM antenna is

built in to this cord. It must be fully extended to provide the best FM reception.

LOCATION OF CONTROLS AND INDICATORS

Top Panel

1. MONTH/DATE Setting Button.

2. TIME setting Button.

3. ALARM MODE Button.

(weekdays/weekends/everyday alarm)

4. ALM(Alarm) 1 Setting Button.

5. ALM(Alarm) 2 Setting Button.

6. SNOOZE/SLEEP OFF Button.

7. SET - Button.

8. SET + Button.

9. TIME ZONE Button.

10. SLEEP Button.

11. RADIO ON/OFF Button.

Left Side

12. ALARM 1 Selector Switch.

(RADIO/BUZZER/OFF)

13. ALARM 2 Selector Switch.

(RADIO/BUZZER/OFF)

14. Display DIMMER(HIGH/LOW) Switch.

Right Side

15. VOLUME Control.

16. BAND(AM/FM) Switch.

17. TUNING Control.

Front Panel

18. ALM(Alarm) 2 ‘On’ Indicator.

19. ALM(Alarm) 1 ‘On’ Indicator.

20. AM Indicator.

21. Time Display.

22. Day Indicators.

23. BATT. LOW Indicator.

24. Month/Date Display.

25. Lighted Dial Pointer.

Back Panel

26. Back Up Battery Compartment.

27. AC Power Cord.

1 2 3 456 7 8 9 10 11

18 19 20 21 23

OPERATING INSTRUCTIONS

SETTING THE TIME, THE FIRST TIME

IMPORTANT:

The first time you connect your new SmartSet®clock radio to the AC outlet the

internal computer will automatically set the time correctly for the Eastern Time

Zone, which is the initial default setting. The display will scan for a few seconds

and then set the correct month, date, day and time in the Eastern zone. If you live

in the Eastern Time zone, there’s nothing else to do. Your clock is set correctly

and running.

If you do not live in the Eastern Time zone you must change the default zone

display to your own zone. You only do this one time and the SmartSet®will

remember the new default zone setting and will always return to that setting after

a power interruption.

There are 7 time zones programmed into your SmartSet®clock radio as follows:

Zone 01 - Atlantic Time

Zone 02 - Eastern Time

Zone 03 - Central Time

Zone 04 - Mountain Time

Zone 05 - Pacific Time

Zone 06 - Yukon Time

Zone 07 - Hawaiian Time

To change the default time zone display, depress the TIME ZONE button. The

word “ZONE” appears in the main display, and the number “02” will appear on the

month/date display, indicating that the default zone is Zone 02, Eastern Time.

Hold the TIME ZONE button and then press either the SET + or SET – buttons

until your own time zone appears on the display, then release the buttons. The

clock display will change to the correct time in the time zone you selected. The

clock will always return to the correct time in the zone you selected after every

power interruption. If you move to a different time zone, simply change the

default zone display to the new zone and the SmartSet®will remember that setting

for you.

DATE DISPLAY

The correct month and date appear in the small display. The month and date are

expressed numerically in the MM/DD format. For example, May 21st will be

displayed as (5.21). This display adjusts automatically for months of different

lengths. For example, at midnight on February 28th (2.28), the display will

automatically change to March 1st (3.1), unless it is a Leap Year, in which case

the display will change to February 29th (2.29).

YEAR DISPLAY

To see the correct year, depress the TIME and MONTH/DATE buttons together.

The small display changes from ‘month/date’ to ‘year’. When you release the

TIME and MONTH/DATE buttons the small display returns to month and date.

DAYLIGHT SAVING AND LEAP YEAR ADJUSTMENTS

All Daylight Saving and Leap Year adjustments are made automatically

by the SmartSet®internal computer as follows:

•Start of Daylight Saving Time: At 1:59.59 AM on the first Sunday in

April, the clock will automatically advance to 3:00 AM.

•End of Daylight Saving Time: At 2:59.59 AM on the last Sunday in

October, the clock will automatically reset to 2:00 AM.

•Leap Year: At 12 Midnight on February 28th, the calendar display will

change to "2. 29"

MANUAL TIME ADJUSTMENTS

Some people like to set their clocks 5 to 10 minutes fast to make sure that they

will always be on time. Even though the SmartSet®sets the time by itself, you still

have the option of adjusting the time manually if you wish.

To manually adjust the time display depress and hold the TIME button, and press

either the SET + or SET – buttons to adjust the time display ahead or back as

desired. Each press of the SET + or SET – buttons will change the display by one

minute. If you hold the SET + or SET – buttons the display will continue to change.

The display will change slowly at first, one minute at a time. But if you continue

holding the SET + or SET – buttons the display will change rapidly.

Note: If you manually adjust the time, your new setting is entered into the

SmartSet®memory. If the power is interrupted, the display will return to

your new setting, not the original setting, when the power is restored.

ADJUSTING THE WAKE UP TIMES

Your SmartSet®clock radio has two separate alarms that can be set and used

independently. You may use the alarms to wake two people at different times, or

you may use one alarm for weekdays and the other for weekend wake up times.

The procedure for adjusting the wake up time is the same for both Alarm 1 and

Alarm 2.

1. Depress and hold either the ALM 1 or ALM 2 setting button. The main display

will change from the correct time to the Alarm 1 or Alarm 2 wake up time.

2. While holding the ALM 1 or ALM 2 setting button, depress either the SET + or

SET – button to move the display ahead or back to your desired wake up time.

3. When the desired wake up time appears on the display, release all buttons.

Note: Be sure that you have set the wake up time correctly by observing the

AM indicator. If the AM indicator is ‘On’ the wake up time is “AM”. If the

AM indicator is ‘Off’, the wake up time is “PM”.

SELECTING THE ALARM MODE

Your SmartSet®clock radio allows you to select from among three different alarm

operation modes for either alarm. The alarm modes are:

1. Weekdays only - the alarm will only turn on Monday through Friday;

2. Weekends only - the alarm will only turn on Saturday and Sunday;

3. Everyday - the alarm will turn on all 7 days.

To check the Alarm Mode setting for Alarm 1, depress the ALM 1 setting button.

The display will show the Alarm 1 wake up time and the day of the week indicators

will show you which alarm mode is selected.

•If all 7 indicators are ‘On’, the Everyday mode is selected.

•If only the Monday through Friday indicators are ‘On’, the Weekdays only mode

is selected.

•If only the Saturday and Sunday indicators are ‘On’, the Weekends only mode

is selected.

To change the Alarm Mode setting for Alarm 1, hold the ALM 1 setting button and

press the ALARM MODE button until the day indicators show the desired mode

setting, Weekdays only, Weekends only, or Everyday operation. Release the

ALARM MODE and ALM 1 setting buttons and the display will return to the correct

time.

CHECKING THE WAKE UP TIMES AND ALARM MODE

Whenever you want to check the wake up time or the alarm mode settings, simply

press either the ALM 1 or ALM 2 setting buttons. The display will change from

correct time to wake up time and the day indicators will show you which alarm

mode is currently selected.

Release the ALM 1 or ALM 2 setting buttons to return to correct time.

LISTENING TO THE RADIO

•Set the BAND selector to the desired band, AM or FM.

•Set the VOLUME control to a low setting.

•Press the RADIO ON/OFF button to turn the radio ‘On’.

The radio dial pointer wil light.

•Select your desired station with the TUNING control.

•Adjust the VOLUME control to the desired setting.

•When you are finished listening, press the RADIO ON/OFF button to turn the

radio ‘Off’.

The radio dial pointer light goes off.

ANTENNA INFORMATION

AM - The AM bar antenna is inside the cabinet. If AM reception is weak, change

the position of cabinet until the internal antenna picks up the strongest

signal.

FM - The FM antenna is built in to the AC power cord. If FM reception is weak

try varying the position and direction of the power cord until you find the

strongest signal.

WAKE TO RADIO

1. Turn the radio ‘On’ and select the band, station, and volume level that you

wish to hear when the alarm comes on, then turn the radio ‘Off’ again.

2. Reconfirm the wake up time and alarm mode settings for the alarm you are

using, Alarm 1, Alarm 2, or both alarms.

3. Set the ALARM selector switch for one or both alarms to the RADIO position.

The appropriate ALM 1 and/or ALM 2 indicators will light up to confirm that

the alarms are set.

4. At the selected wake up time the radio will turn ‘On’. It will play for one hour

and then shut off automatically.

5. To stop the radio sooner, press either the appropriate ALM 1 or ALM 2 button,

or press the RADIO ON/OFF button. The radio will stop but the alarm remains

set and will turn the radio on again at the same time on the following day

(depending on the Alarm Mode setting).

6. If you do not want the alarm to turn the radio on the following day, set the

appropriate ALARM selector to the ‘Off’ position.

WAKE TO BUZZER

1. Reconfirm the wake up time and alarm mode settings for the alarm you are

using, Alarm 1, Alarm 2, or both alarms.

2. Set the ALARM selector switch for one or both alarms to the BUZZER position.

The appropriate ALM 1 and/or ALM 2 indicators will light up to confirm that

the alarms are set.

3. At the selected wake up time the buzzer will sound. It will continue for one

hour and then shut off automatically.

4. To stop the buzzer sooner, press either the appropriate ALM 1 or ALM 2 button.

The buzzer will stop but the alarm remains set and will turn the buzzer on

again at the same time on the following day (depending on the Alarm Mode

setting). To stop the buzzer and turn on the radio immediately, press the

RADIO ON/OFF button instead of the ALM 1 or ALM 2 button.

5. If you do not want the alarm to turn the buzzer on the following day, set the

appropriate ALARM selector to the ‘Off’ position.

RADIO AND BUZZER OPERATION

You may also set one alarm for wake to radio and the other for wake to buzzer.

Just set the ALARM 1 and ALARM 2 selector switches to the desired positions.

SNOOZE ALARM

After the radio or buzzer alarm sounds in the morning you may press the SNOOZE

bar for a few more minutes sleep. The alarm will stop for approximately 9 minutes

and then turn on again. You may repeat the Snooze operation up to seven times

if desired, but after the seventh time the alarm will not turn on again.

SLEEP TO MUSIC TIMER

You can program the sleep timer to play the radio for up to 90 minutes and then

shut off automatically.

1. Press the SLEEP button. The display will briefly show “10” and the radio will

begin to play. After 10 minutes the radio will shut off automatically. Each time

you press the SLEEP button the sleep timer will start at 10 minutes. This is the

sleep timer default setting.

Autres manuels pour CKS2237

Table des matières

Autres manuels Emerson Research Radio-réveil

Emerson Research

Emerson Research CKS1862 Manuel utilisateur

Emerson Research

Emerson Research SmartSet CKS3528 Manuel utilisateur

Emerson Research

Emerson Research CKS2235 Manuel utilisateur

Emerson Research

Emerson Research CKS2000N Manuel utilisateur

Emerson Research

Emerson Research SmartSet CKS3516 Manuel utilisateur

Emerson Research

Emerson Research CKS2862 Manuel utilisateur

Emerson Research

Emerson Research SmartSet CKD5811 Manuel utilisateur

Emerson Research

Emerson Research CKT9087 Manuel utilisateur

Emerson Research

Emerson Research CKS1855 Manuel utilisateur

Emerson Research

Emerson Research CKS2020 Manuel utilisateur

Emerson Research

Emerson Research CKS3030C Manuel utilisateur

Emerson Research

Emerson Research iC200 Manuel utilisateur

Emerson Research

Emerson Research CKS3088 Manuel utilisateur

Emerson Research

Emerson Research CKD8300 Manuel utilisateur

Emerson Research

Emerson Research CKS5055B Manuel utilisateur

Emerson Research

Emerson Research SmartSet CKD5809 Manuel utilisateur

Emerson Research

Emerson Research SmartSet CKS3095S Manuel utilisateur

Emerson Research

Emerson Research SmartSet CKD5808 Manuel utilisateur

Emerson Research

Emerson Research CKS1850 Manuel utilisateur

Emerson Research

Emerson Research fYi iC172 Manuel utilisateur

Emerson Research

Emerson Research CKT9100 Manuel utilisateur

Emerson Research

Emerson Research iC200 Manuel utilisateur

Emerson Research

Emerson Research CKS2237 Manuel utilisateur

Emerson Research

Emerson Research SMARTSET CKS3029C Manuel utilisateur

Manuels Radio-réveil populaires d'autres marques

Denver

Denver CRQ-105 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Sony

Sony Dream Machine ICF-C763L Manuel utilisateur

Sanyo

Sanyo DMP-P6 Manuel utilisateur

RCA

RCA RPC100 Manuel utilisateur

Yamaha

Yamaha ISX-80 Manuel utilisateur

Pyle

Pyle PLMR20W Manuel utilisateur

Blaupunkt

Blaupunkt CR7BK Manuel utilisateur

Philips

Philips AJ3180 Manuel utilisateur

HoMedics

HoMedics SS-5500-2EU Manuel utilisateur

RCA

RCA RC66i Manuel utilisateur

Versaudio

Versaudio Vers Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR8100 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manuel utilisateur

Roberts

Roberts ChronoDAB Manuel utilisateur

AEG

AEG MRC 4132 BT Manuel utilisateur

Tokai

Tokai TC-155 Manuel utilisateur
