Programming Guide
Enter Programming Mode
(One beep, green light flashes
once, red light “On” to confirm
you are in programming mode.)
*→Master code →#
888888 is the factory default master code
After 1min with no button pressed keypad will exit programming mode
Exist from the
programming mode
*Exit is confirmed with flashing red light.
Note: The below changes can only be done while in programming mode.
Change the master code
(Orange light confirms you are in
change mode)
0 →New code →# →New code →#
The master code must be 6 digits long.
Add a user
(Orange light confirms you are in
adding mode. Green light flash
indicates a user has been added.)
1 →user ID number →# →PIN →#
ID number can be between 1- 2000. The PIN is any 4 -
8 digits with the exception of 1234 which is reserved.
Users can be added continuously without existing from
programming mode as follows:
1 →User ID No →# →PIN →# →User ID No 2
→# →PIN →# Press #*to Exit.
Delete a user
(Orange light confirms you are in
delete mode. Green light flash
indicates a user has been deleted.)
2 →User ID number →#
Users can be deleted continuously without existing
programming mode. Press #*to Exit.
Delete All users
Warning : This option will
delete all user’s
2 →0000 →#
(Orange light confirms you are in delete mode. Green light flash
indicates all users have been deleted.)
Change transmission time
4 →1 – 90 →# Press *to Exit. Default is 5 sec
(Orange light confirms you are in time change mode. Green light flash
indicates that time has been changed.)
Note: The below changes can only be done while out of programming mode.
To activate the built-in
PentaCode® transmitter PIN →# (Green light comes “ON” for the transmission time.)
Change a user’s PIN
(Red light “ON” confirms you are
in User Change mode)
*→ID Number →# →Old PIN →# →New PIN
→# →New PIN →#
(Green light comes “ON” when the pin has been changed.)
