ELSA ECOMO 20LCD9 Manuel utilisateur
ELSA ECOMOTM 20LCD99
User Manual
No. 21601/0699
© 1999 ELSA AG, Aachen (Germany)
While the information in this manual has been compiled with great care, it may not be deemed an assur-
ance of product characteristics. ELSA shall be liable only to the degree specified in the terms of sale
and delivery.
The reproduction and distribution of this handbook and the use of its contents, as well as that of the
software included with the product, is subject to ELSA written authorization. The right to modifications
in the interest of technical progress is reserved.
ELSA is EN-ISO 9001 certified. The accredited TÜV CERT certification authority has confirmed ELSA con-
formity to the worldwide ISO 9001 standard in certificate number 09 100 5069, issued on 16 May 1995.
Trademarks
Windows®, Windows®95, Windows®98, Windows NT®and Microsoft®are registered trademarks of
Microsoft, Corp.
All other names mentioned may be trademarks or registered trademarks of their respective owners. The
ELSA logo is a registered trademark of ELSA AG. Subject to change without notice. No liability for tech-
nical errors or omissions.
ELSA AG ELSA Inc.
Sonnenweg 11 2231 Calle De Luna
52070 Aachen Santa Clara, CA 95054
Germany USA
Internet www.elsa.de Internet www.elsa.com
Aachen, June 1999
Preface
Thank you for placing your trust in this ELSA product. With the
ECOMO 20LCD99
you
have selected one of ELSA's high-end monitors. ELSA products are subject to the high-
est of standards in production and quality control which are the foundation for consis-
tently high product quality. This monitor was especially designed for the demands of
professional users, and distinguishes itself with an extraordinary degree of reliability.
If you have questions to the topics covered in this manual or require additional help, our
online services are at your disposal around the clock. The complete range of support
and services provided by ELSA can be found in the "Advice and Help” chapter.
In very urgent cases the ELSA Hotline can be reached under the following number:
+49-241-606-6135
ECOMO 20LCD99
V
Contents
Introduction ....................................................................................................................1
Monitor Features..................................................................................................... 1
Operating Instructions............................................................................................. 2
Setup and Operation.......................................................................................... 2
Cleaning the Monitor......................................................................................... 2
CE Conformity and FCC Radiation Standard........................................................... 3
Unpacking and Connecting .........................................................................................5
Is it all There?.......................................................................................................... 5
Cable Connections .................................................................................................. 6
Operating and Adjusting ..............................................................................................7
Controls on the Front............................................................................................... 7
The Connections at the Rear................................................................................... 8
The On Screen Display Menu ................................................................................. 8
How to navigate the OSD .................................................................................. 9
Registration and Configuration .................................................................................11
Registration with the Operating System .............................................................. 11
Registration under Windows 95 and Windows 98.......................................... 11
Adjusting the Display............................................................................................ 11
Language.......................................................................................................... 11
Overview of all pages ...................................................................................... 12
Locking the On Screen Display menu .............................................................. 13
Technical Data .............................................................................................................15
The Power Save Function...................................................................................... 15
Factory Default Settings ....................................................................................... 16
The VGA-D-Sub Socket ................................................................................... 17
Graphics connector of the Apple-Macintosh computer................................... 17
Troubleshooting ...........................................................................................................19
Messages on Display............................................................................................ 19
POWER-SAVE Function is 'Off'......................................................................... 20
POWER-SAVE Function is 'On'......................................................................... 20
POWER-SAVE Function either 'On' or 'Off' ...................................................... 20
Appendix .......................................................................................................................21
TCO '99.................................................................................................................. 21
ELSA ServiceDirect ................................................................................................24
Warranty conditions.............................................................................................. 25
ECOMO 20LCD99
VI
Introduction
ELSA ECOMO 20LCD99
1
Introduction
In order to give you a quick overview, this chapter provides you with important opera-
tional advice and general information about your new LCD monitor.
Monitor Features
KThe
ECOMO 20LCD99
is compatible with most analog RGB signals (red, green, blue).
It displays text and graphics in conjunction with VGA, SVGA, XGA (non-interlaced)
and the common Macintosh-compatible color graphics boards.
KAuto-Scanning is performed digitally by a microprocessor. The monitor automati-
cally synchronizes itself to any horizontal frequencies between 31.0kHz and 80.5kHz
and vertical frequencies between 30.0Hz and 85.0Hz. The micro-processor-based
control mechanism allows the monitor to operate in any frequency mode with the
precision of a fixed frequency monitor.
KIn addition to the preprogrammed monitor display standards, the
ECOMO 20LCD99
also provides the option of saving user-specific settings for these and other timings.
KThe
ECOMO 20LCD99
supports a maximum resolution of 1280 horizontal pixels by
1024 vertical lines on IBM-based systems. Therefore, it is ideal also for window-
orientated user interfaces such as Windows.
KThe
ECOMO 20LCD99
includes the DDC1 and DDC2B functions. DDC (Display Data
Channel) is a transmission channel by which the monitor can automatically inform
the computer of its capabilities (e.g. supported graphics modes with the correspond-
ing timings). The system can only perform this function if both the monitor and the
computer (the graphics board) are support with the DDC function.
KThe
ECOMO 20LCD99
has a multilevel power save function which reduces power
consumption when the monitor is not in use.
Introduction
ELSA ECOMO 20LCD99
2
Operating Instructions
Setup and Operation
Please keep the following in mind when setting up and using the monitor:
KTo avoid straining your eyes, do not placing the monitor in front of a bright back-
ground or where sunlight or other light sources shine directly onto the monitor. To
ensure the best ergonomical position, the monitor should be below eye-level.
KDo not cover the monitor's air vents. Make sure that there is sufficient ventilation
so that heat from the monitor can properly dissipate.
KAvoid exposing the monitor to damp and dust as this can cause fire or electric shock
hazard.
KEnsure that neither the monitor, nor any other heavy item is placed on the power
supply cord. A damaged power supply cord can cause fire or short circuits.
KWhen transporting the monitor, handle it with care.
KDo not shake or scratch the monitor because it is fragile.
Cleaning the Monitor
Please follow these guidelines when cleaning the monitor:
KAlways remove the power plug from the socket before cleaning.
KClean the display and the casing with a soft cloth.
KIf the monitor requires more than dusting, clean it with a mild cleaning solution and
a soft cloth.
Do not clean the device with benzene, thinner or other volatile substances because the
surface could get damaged. Never leave the monitor in contact with rubber or vinyl prod-
ucts for an extended time period.
Introduction
ELSA ECOMO 20LCD99
3
CE Conformity and FCC Radiation Standard
CE
This equipment has been tested and found to comply with the limits of the European
Council Directive on the approximation of the laws of the member states relating to elec-
tromagnetic compatibility (89/336/EEC) according to EN 55022 class B.
FCC
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the Federal Communications Commission (FCC) Rules.
CE and FCC
These limits are designed to provide reasonable protection against radio frequency inter-
ference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy. It may interfere with to radio communications if not installed and
used in accordance with the instructions. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause interference
to radio or television reception (this can be determined by turning this equipment off and
on), the user is encouraged to try to correct the interference by one or more of the follow-
ing measures:
KReorient or relocate the receiving antenna.
KIncrease the distance between this equipment and the receiver.
KConnect the equipment to an outlet on a circuit other than that to which the receiver
is connected.
KConsult your dealer or an experienced radio/TV technician.
KCaution: To comply with the limits for an FCC Class B computing device, always use
the signal cable which is supplied to the
ECOMO 20LCD99
.
Caution to the user: The Federal Communications Commission warns the user that
changes or modifications to the unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Introduction
ELSA ECOMO 20LCD99
4
