Dash Cam Manual
Model EM10
2
Table of Contents
Dash Cam Diagram 3
Installation Guide 4
Features 6
Basic Functions of the Dash Cam 8
Power On/Off | Turn On/Off screen | Reset
UI of the Dash Cam 9
Camera DVR 11
FM Transmitter 12
App List 13
Camera Playback 14
Settings 15
Product Specifications 18
3
Dash Cam Diagram
1: Sim card port
2: SD card port
3: Reset
4: Angle Tighten Knob
5: Power button
6: Touch screen
7: Second camera port
8: USB connection
9: GPS antenna
1
2
3
5
6
7
8
9
4
4
Installation Guide
1. Turn off the engine of the vehicle
2. Unit comes with a 64GB SD Card which will be already in
the SD card slot
[Note] If the user needs to replace this SD card, please take
out the current SD card and insert new card into the SD card
port. Please use a high-speed SD card (Class 10 or higher). The
storage should be 2GB or more, and up to 128 GB
3. Clean the windshield glass from inside the truck with an
alcohol wipe or the cleaning rag provided in the package
4. Remove the Plastic Film over the 3M sticker, and place the
Dash Cam near the rear-view mirror of the truck. Hold for 5
seconds to keep in place
5. Connect the ACC cable with the Automotive Fuse Box
[Note] When wiring, the charging extension line can be laid
along the edge of the car windshield
[Optional] Dash Cam can also be connected with the cigarette
lighter charger to the USB port of the dash cam with a
5
charging extension cable. This is Not Recommended. Using it
this way could lead to permanent damage to the unit.
6. Adjust the lens position to ensure that the lens is level with
the ground
7. Tighten the dash cam position by using the Angle tighten
Knob (4 in diagram above) to get the desired angle of the dash
cam
8. Install the second camera on the rear of the vehicle, side of
the vehicle, or facing the driver. The wiring can be laid along
the roof of the vehicle if needed. After installation, connect the
plug to the second camera port of the Dash Cam
6
Features
Automatic Locked Files
A file is automatically locked and sent to the portal if the
collision sensitivity is met. The upload will happen on the
background as long as the camera is powered on. Even if
powered off- the moment it gets power the locked file will start
uploading again. Each minute of locked file video is
approximately 100MB and can take the appropriate time to
upload.
All locked files will be automatically uploaded on secure servers
which can be accessed from anywhere in the world for over a
period of 2 years.
Fleet Management Functionality
The GPS antenna of the dash cam can be used to do near live
tracking of the truck. Ensure that the GPS Antenna is facing
upwards. Full Telematics on near real time basis will be
available to fleet manager or back office team. This includes
geofencing, custom alerts, reports, full breadcrumb, and
location sharing. Additionally, the dash cam can provide video
of hard breaking, hard acceleration, or any collision.
Both features above require a monthly subscription
7
Loop Recording
Once the memory of the dash cam has been reached new video
is automatically saved over the oldest video files.
1080P Front Camera & AHD for Second Camera
High quality video footage saved.
Standalone 4G LTE Dash Cam
This dash cam does not require any use of smart phone in
order to view video files. All files can be viewed and locked
directly on the dash cam.
Google Maps
Dash Cam has inbuilt google maps which can be used for
navigation purposes. Our sim card is required for this
feature.
Other features are detailed in this manual.
8
Basic Functions of the dash cam
Power on/off function
A: In the powered-on state, long press the power button and
hold for 3 seconds, the unit will automatically save the current
video file and shut down;
B: In the power-off state, long press the power button and hold
for 3 seconds for turning on the unit.
Turn on/off the screen
Short press the power button, and the unit will enter HUD
mode with the screen off. Short press the power button again
to light on the screen. If short pressed the dash cam will
continue to take video files even if the screen is off.
Reset button
Short press the reset button to restore the dash cam to factory
default settings.
9
The UI of the dash cam
The dash cam is touchscreen. Use a finger for navigation and
clicking. The above UI is the home screen. The items on the
home screen are described further below:
Enters the recording interface which shows what
is currently being recorded by the dash cam
Lists out the current videos that are available on
the dash cam
Enters Radio FM
Opens Google maps.
Opens Music.
Enters into the full list of apps that are
downloaded on the dash cam.
10
means the video is being recorded with a voice
recording, while clicking on it again toggles it to which
means the video is not doing a voice recording.
Takes the user to the settings below:
to go back to the home page
to go back to the previous page
