GENERAL OPERATING SAFETY
Variable Speed
EMERGENCY STOP BUTTON
stops machine and turns
machine off with time delay.
- flip toggle to direction
of desired rotation.
- flip toggle to center to stop.
EMERGENCY
STOP/OFF
STOP
RESET
REVERSE FORWARD
5061-2
WARNING
1. Wear eye protection.
2. Do not wear gloves, a necktie or
loose clothing while working at the
drill press.
3. Clamp workpiece or brace it against
a fixed stop to prevent rotation.
4. Use recommended speeds that are
proper for the drill, workpiece
material and accessories used.
5051-1
(608) 845-6472 • EllisSaw.com
Ellis MFG. CO., INC. • P.O. Box 930219 • Verona, WI 53593
READ INSTRUCTION MANUAL BEFORE
OPERATING THE DRILL PRESS AND
FOLLOW WARNINGS LISTED BELOW
SAFETY AND INFORMATION LABELS
ATTENTION!
Loosen clamp screws prior
to adjusting table height.
5069
HIGH
SPEED
MID-RANGE
TORQUE
HIGH
TORQUE
MUST RUN MOTOR TO SHIFT TORQUE!
ReadandunderstandOwnersManualbefore
operatingthismachine!
5050-1
SAFETY
1. Always wear safety glasses.
2. Do not wear gloves, necktie, loose clothing,
jewelry or other items that may get caught in
moving parts. Long hair should be tied up and
under a cap.
3. Do not hold by hand. Use Safety Drill Press
Vise. Always clamp material to worktable. Utilize
two (2) T-Slots in worktable or base of the drill
press for additional holding points using T-Bolts,
clamps and hold downs. Always use accessories
sold for this machine for accuracy and safety.
4. Use recommended speeds that are proper
for the drill, the material being drilled and
accessories used.
5. Make a habit of removing the chuck key, drift
key and other wrenches after their use.
6. Keep hands and ngers clear of the drill bit
or cutter.
7. Shut off the power by using #4819 Emergency
Stop Button (red in color) before removing or
installing drill bits or cutting tools.
8. Be sure that the head stock and worktable are
securely clamped to the column. Always use
accessories sold for this machine for accuracy
and safety.
9. Be sure the drill bit or cutting tool is securely
clamped in the chuck.
10. Keep cover (of belts and pulleys) in place
and closed.
11. Do not operate the machine beyond its capacity.
12. Maintain the machine regularly, keep it clean,
and keep a maintenance lubrication log.
5050 Shift Speed Label 5069 Attention Label
5062 Operating Label
5051 Warning Label
5061 Forward/Reverse Label
5059 Ellis Logo Label
WARNING
Disconnect Power Cord
From the Wall Outlet
Before Any Maintenance!
