The possibility to set 8 functions:
Timing relay with interrupt option - the load is activated on and
the timing starts immediately after pushing the button. Further
pushing the button in the course of timing deactivates the load.
Delayed switching off (similar to CS3-1) - the load is activated
at the moment of button disconnection, after timing the load is
deactivated.
Multi-timing relay with blocking - the number of pushing the
button increases the time interval set. If you press the button for
approx. 3 s in the course of timing, the load is deactivated.
Delayed switching off without blocking - kthe load is activated
on immediately after pushing the button, but the timing starts after
button is disconnection.
Impulse relay (controlled from more locations) - pressing the
button activates the load, further pressing the button deactivates
the load.
Delayed switching on - when the button is pressed, it times the
set time (delay). Afterwards it activates the load that is activated
up to button disconnecting.
Delayed switching on and off - when the button is pressed, it
times the set time (delay), afterwards the load is activated. After
button disconnecting, the load is deactivated with the same delay.
Flasher - when the button is switched on permanently, it activates
the load in time intervals set 1:1 (illuminated advertisements etc.).
CS3-16CS3-16
TIMING
SWITCH
MULTIFUNCTIONAL FOR HIGHER LOADS
