Electrolux WAGL4E201 Manuel utilisateur
CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. PRODUCT DESCRIPTION................................................................................... 5
4. CONTROL PANEL...............................................................................................6
5. PROGRAMMES ..................................................................................................8
6. CONSUMPTION VALUES..................................................................................11
7. SETTINGS......................................................................................................... 12
8. OPTIONS...........................................................................................................13
9. BEFORE FIRST USE..........................................................................................14
10. DAILY USE...................................................................................................... 14
11. HINTS AND TIPS............................................................................................. 18
12. CARE AND CLEANING....................................................................................19
13. TROUBLESHOOTING......................................................................................23
14. EMERGENCY DOOR OPENING...................................................................... 25
15. TECHNICAL DATA...........................................................................................26
16. GUARANTEE ..................................................................................................26
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Children of less than 3 years should be kept away
unless continuously supervised.
•Keep all packaging away from children.
•Keep all detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•If the appliance has a child safety device, we
recommend you activate it.
•Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Obey the maximum load volume of 8 kg (refer to the
“Programme chart” chapter).
•The operating water pressure (minimum and maximum)
must be between 0,5 bar (0,05 MPa) and 8 bar (0,8
MPa).
•The ventilation openings in the base (if applicable) must
not be obstructed by a carpet.
ENGLISH 3
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
•Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts. When you move
the appliance again you must block the
drum.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C or where it is exposed to the
weather.
• Make sure that the floor where you
install the appliance is flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
carpet.
• Do not install the appliance where the
appliance door can not be fully
opened.
2.2 Electrical connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Only for UK and Ireland: The appliance
has a 13 amp mains plug. If it is
necessary to change the fuse in the
mains plug, use a 13 amp ASTA (BS
1362) fuse.
• This appliance complies with the E.E.C.
Directives.
www.electrolux.com4
2.3 Water connection
• Make sure not to cause damage to the
water hoses.
• Before you connect the appliance to
new pipes or pipes not used for a long
time, let the water flow until it is clean.
• The first time you use the appliance,
make sure that there is no leakage.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• Use this appliance in a household only.
• Obey the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that you remove all metal
objects from the laundry.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1
2
3
5
6
7
4
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for the appliance level
ENGLISH 5
3.2 How to activate the child
safety device
This device prevents children or pets to be
closed in the drum.
Turn the device clockwise, until the groove
is horizontal.
You cannot close the door.
To close the door, turn the device
anticlockwise until the groove is vertical.
3.3 Fixing plate kit (4055171146)
Available from your authorized dealer.
If you install the appliance on a plinth,
secure the appliance in the fixing plates.
Read carefully the instructions supplied
with the accessory.
4. CONTROL PANEL
4.1 Control panel description
1 2 3
45678910
1On/Off button (Ein/Aus - Marche/Arrêt)
2Programme knob
3Display
4Start Pause button (Start/Pause -
Départ/Pause)
5Delay start button (Zeitvorwahl -
Départ Différé)
6Time save button (Zeit Sparen - Court)
7Extra rinse button (Spülen + - Rinçage
+)
8Stain button (Flecken - Taches)
9Spin reduction button (Schleudern -
Essorage)
10 Temperature button (Temp.)
www.electrolux.com6
4.2 Display
A B C D
A
Temperature area:
Temperature indicator
Cold water indicator.
B
Spin area:
Spin speed indicator
No Spin indicator1)
Rinse Hold indicator
1) Only available for Spin/Drain programme.
C
Display indicators:
Washing phase
Rinses phase
Spin phase
Child safety lock
Door locked
You cannot open the appliance door when the symbol is on.
You can open the door only when the symbol goes off.
Delay start
D
Time area:
Programme duration
Delay start
Alarm codes
Message of error
Programme is completed
ENGLISH 7
5. PROGRAMMES
5.1 Programme Chart
Programme
Temperature
range
Maximum load
Maximum spin speed
Programme description
(Type of load and soil level)
Washing programmes
Koch/Bunt -
Blanc/Couleurs
Cottons
95°C - Cold
8 kg
1400 rpm (WAGL4E201)
1600 rpm (WAGL6E201)
White cotton and coloured cotton.
Normal soil and light soil.
Koch/Bunt +
Vorwäsche -
Blanc/Couleurs +
Prélavage
Cottons + Pre-
wash
95°C - Cold
8 kg
1400 rpm (WAGL4E201)
1600 rpm (WAGL6E201)
White cotton and coloured cotton.
Heavy soil and normal soil.
Extra Leise - Ex-
tra Silence
Extra Silent
95°C - Cold
8 kg White and coloured cotton. Normal
soil and light soil. The programme elimi-
nates all spinning phase to perform a si-
lent cycle. The cycle stops with water in
the tub.
Pflegeleicht -
Synthétiques
Synthetics
60°C - Cold
4 kg
1200 rpm (WAGL4E201)
1200 rpm (WAGL6E201)
Synthetic items or mixed fabric
items. Normal soil.
Leichtbügeln -
Repassage Fac-
ile
Easy Iron
60°C - Cold
4 kg
800 rpm Synthetic items to be gentle washed.
Normal and light soil.1)
Feinwäsche -
Délicats
Delicates
40°C - Cold
4 kg
1200 rpm (WAGL4E201)
1200 rpm (WAGL6E201)
Delicate fabrics as acrylics, viscose,
polyester items. Normal soil.
Wolle/Seide -
Laine/Soie
Wool/Silk
40°C - Cold
1.5 kg
1200 rpm (WAGL4E201)
1200 rpm (WAGL6E201)
Machine washable wool, hand wash-
able wool and delicate fabrics with
«hand washing» care symbol.2)
Daunen - Cou-
ette
Duvet
60°C - 30°C
3 kg
800 rpm
Special programme for one synthetic
blanket, duvet, bedspread and so on.
www.electrolux.com8
Programme
Temperature
range
Maximum load
Maximum spin speed
Programme description
(Type of load and soil level)
Schleudern/
Pumpen - Essor-
age/Vidange
Spin/Drain3)
8 kg
1400 rpm (WAGL4E201)
1600 rpm (WAGL6E201)
To spin the laundry and to drain the wa-
ter in the drum. All fabrics.
Spülen - Rinçage
Rinse
8 kg
1400 rpm (WAGL4E201)
1600 rpm (WAGL6E201)
To rinse and spin the laundry. All fab-
rics.
Outdoor - Blou-
sons
Outdoor
40°C - Cold
2.5 kg
800 rpm
Waterproof, sports and outdoor
items.. Do not use any fabric softener!
20 min -3 kg
20 min.-3Kg
40°C - 30°C
3 kg
1200 rpm (WAGL4E201)
1200 rpm (WAGL6E201)
Cottons and synthetics items with
light soil level or worn only once.
Super Eco
Super Eco
Cold
3 kg
1200 rpm Mixed fabric (cotton and synthetic
items).4)
Baumwolle Eco -
Coton Eco
Cottons Eco5)
60°C - 40°C
8 kg
1400 rpm (WAGL4E201)
1600 rpm (WAGL6E201)
White cotton and colour-fast cotton.
Normal soil. The energy consumption
decreases and the time of the washing
programme is extended.
Steam programmes6)
Steam can be used for dried, washed or worn once laundry. These programmes can
reduce creases and odours and make your laundry more soft.
Do not use any detergent. If necessary, remove stains by washing or using localized
stain removal.
Steam programmes do not perform any hygienic cycle.
Do not set a Steam programme with these types of items:
• items where it is not specified on the care label as being suitable for tumble drying.
• all items with plastic, metal, wooden parts or alike.
Auffrischen - Ra-
fraîchir
Steam Refresh
40°C
1.5 kg Steam programme for cotton and syn-
thetic items. This cycle removes
odours from the laundry.7)
ENGLISH 9
Programme
Temperature
range
Maximum load
Maximum spin speed
Programme description
(Type of load and soil level)
Glätten - Défrois-
sage
Steam Anti-
crease
40°C
1.5 kg Steam programme for cotton and syn-
thetic items. This cycle helps to dew-
rinkle the laundry.
1) To reduce the creases of the laundry, this cycle regulates the water temperature and per-
forms a soft wash and spin phase. The appliance adds some rinses.
2) During this cycle the drum rotates slowly to ensure a gentle washing. It can seem that the
drum doesn't rotate or doesn't rotate properly. Consider this as a normal functioning of the ap-
pliance.
3) Set the spin speed. Make sure it agrees with the laundry. If you set No Spin option the only
drain phase is available.
4) This programme is for daily use and has lowest energy and water consumption maintaining
a good washing performance.
5) Standard programmes for the Energy Label consumption values. According to regu-
lation 1061/2010, these programmes are respectively the «Standard 60°C cotton programme»
and the «Standard 40°C cotton programme». They are the most efficient programmes in terms
of combined energy and water consumption for washing normally soiled cotton laundry.
The water temperature of the washing phase may differ from the temperature de-
clared for the selected programme.
6) If you set a Steam programme with dried laundry, at the end of the cycle the laundry could
be humid. It is better to expose the items to the fresh air for about 10 minutes to let the humid-
ity dry. When the programme is completed, quickly remove the laundry from the drum. After a
steam cycle, items may to be ironed anyway, but with less effort!
7) Steam does not remove animal odours.
Programme options compatibility
Programme
Schle
udern
- Es-
sor-
age
Fleck-
en -
Ta-
ches1)
Spü-
len + -
Rin-
çage
+ 2)
Zeit
Spa-
ren -
Court 3)
Zeit-
vor-
wahl -
Dé-
part
Dif-
féré
Cottons ■ ■ ■ ■ ■ ■
Cottons + Prewash ■ ■ ■ ■ ■ ■
Extra Silent ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■
Easy Iron ■ ■ ■ ■ ■
Delicates ■ ■ ■ ■ ■ ■
www.electrolux.com10
Ce manuel convient aux modèles suivants
1
Table des matières
Langues :
Autres manuels Electrolux Rondelle
Electrolux
Electrolux EWF 148317 W Manuel utilisateur
Electrolux
Electrolux EN6F5922BF Manuel utilisateur
Electrolux
Electrolux EWF 1230 Manuel utilisateur
Electrolux
Electrolux EWF14013 Manuel utilisateur
Electrolux
Electrolux EWF 16487 W Manuel utilisateur
Electrolux
Electrolux EW6S3R07SI Manuel utilisateur
Electrolux
Electrolux EW8F2166MA Manuel utilisateur
Electrolux
Electrolux EWF 887 Manuel utilisateur
Electrolux
Electrolux EW 813 F Guide rapide
Electrolux
Electrolux EWS 1066 SEU Manuel utilisateur
Electrolux
Electrolux EW1220N Manuel utilisateur
Electrolux
Electrolux ews 1042 edu Manuel utilisateur
Electrolux
Electrolux EWF 1445 Manuel utilisateur
Electrolux
Electrolux EWFLW65IRR - 27" Front-Load Washer Manuel utilisateur
Electrolux
Electrolux EIFLS55IIW - 27" Front-Load Steam Washer Instructions d'installation
Electrolux
Electrolux WASL2E202 Manuel utilisateur
Electrolux
Electrolux EWF8024Q5WB Manuel utilisateur
Electrolux
Electrolux EIFLS60JIW1 Manuel utilisateur
Electrolux
Electrolux EWF1481 Manuel d'utilisation
Electrolux
Electrolux MRF 120/35 Manuel utilisateur
