Electrolux 730182 Manuel utilisateur

Electrolux 400 Lt Line

Stainless steel refrigerators & freezers

The Electrolux 400 litre non-gastronorm range is produced for the customer who does not need refrigeration

products suitable for gastronorm containers. This range is exclusive to Electrolux with regards its dimensions

and built quality. The product range comprises of white pre-painted steel models, stainless steel models, glass

door models and wine models. All the internal finishes are commercial grade ABS polystyrene. The models

detailed on this sheet are 5 stainless steel models.

730182

EASY TO INSTALL

• All models require only 1 phase

220/240V supply. They can

therefore be plugged straight into

an existing power socket.

EASY TO CLEAN

• The runners for the shelves are

thermoformed and incorporated in

the inner structure therefore being

easily cleanable.

• The whole interior cell is white

thermoformed polystyrene which

is impact resistant with rounded

corners.

• No joints whatsoever to

eliminate dirt traps.



EASY TO USE

• The models equipped with

roll-bond plate have a plate

installed in the internal backside of

the unit equipped with a special

thermostat to avoid ice formation.

No defrosting phases are required.

• Designed to operate at ambient

temperatures of 43 °C for

refrigerators, 38 °C for freezers

and fish models and 32 °C for

glass models.

• Very quiet operation.

• Fan assisted cooling for even

temperature distribution.

• Digital control panel allowing the

easy and precise setting and

control of the internal temperature.

EASY TO MAINTAIN

• Simple refrigeration system

easily accessible from the rear of

the units.

• All models in range finished in

top quality materials to guarantee

durability.

EASY ON THE ENVIRONMENT

• CFC and HCFC free

environmentally friendly: R134a or

R404a gas in refrigeration circuit.

Gas in foam: Cyclopentane.

• Developed and produced in ISO

9001 and ISO 14001 certified

factory.

Electrolux 400 Lt Line

Stainless steel refrigerators & freezers

Internet: http://www.electrolux.com/foodservice

HAF0102011-11-10Subject to change without notice

PVC CONTAINER W/FALSE BOTTOM FOR

400 LT

881072 881072 881072 881072 881072

PRINTER FOR HACCP BASIC VERSION

REFRIG.

881457 881457 881457 881457 881457

PAIR OF GRIDS (WHITE) FOR 400LT

REFRIG.

880292 880292 880292 880292

2 WHEELS FOR

REFRIGERATORS/REFRIG.TABLES

880539 880539 880539 880539 880539

ACCESSORIES

PVC CONTAINER W/FALSE BOTTOM FOR

400 LT

PAIR OF GRIDS (WHITE) FOR 400LT

REFRIG.

2 2 2

INCLUDED ACCESSORIES

Net weight - kg. 75 75 77 85 77

Noise level - dBA 53.5 57 56 55 56

Internal light ●

installed-electric 0.17 0.38 0.53 0.19 0.35

Power - kW

at evaporation temperature - °C -12 -10 -29 -12 -12

Refrigerant power

Refrigeration power - W 306 339 881 249 339

Refrigerant quantity - g. 240 200 240 240 200

Refrigerant type R134a R134a R404a R134a R134a

N° defrost in 24 hrs. 2x30' 4/20' 2x30' 4/20'

Defrost type Automatic

(air)

Automatic

(electrical)

Manual Automatic

(air)

Automatic

(electrical)

Compressor power - HP 1/5 1/4 1 1/5 1/4

N° and type of basins 1+4,

600x300;

600x400

N° and type of grids (included) 4, 600x400 4, 600x400 600x400 4, 600x400

Door hinges Right Side Right Side Right Side Right Side Right Side

Min/Max internal humidity - % 84% 84% 84% 85%

height 1755 1755 1755 1755 1755

depth/with open doors 620, 1310 620, 1310 620, 1310 620, 1310 620, 1310

width 703 703 703 703 703

External dimensions - mm

Control type Digital Digital Digital Digital Digital

Cooling unit Built-In Built-In Built-In Built-In Built-In

Gross capacity (D.I.N. 8952) - l. 400 400 400 400 400

door Stainless

Steel

Stainless

Steel

Stainless

Steel

Glass Stainless

Steel

panels Stainless

Steel

Stainless

Steel

Stainless

Steel

Stainless

Steel

Stainless

Steel

External material

Operating mode Ventilated Ventilated Static Ventilated Ventilated

Operating temperature - min/max °C 0/10 -2/8 -24/-15 0/10 -6/6

TECHNICAL DATA

R04PVF4

730188

R04NVF4

730182

R04FSF4

730189

R04PVG4

730190

R04NVF4F

730183

Electrolux 400 Lt Line

Stainless steel refrigerators & freezers

Internet: http://www.electrolux.com/foodservice

HAF0102011-11-10Subject to change without notice

EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50

LEGEND

R04PVF4

730188

R04NVF4

730182

R04FSF4

730189

730188, 730189, 730182

700

1755

567

619

665

118.5

398.5101.6

55.5 587 55.5

90 90

518

Electrolux 400 Lt Line

Stainless steel refrigerators & freezers

Internet: http://www.electrolux.com/foodservice

HAF0102011-11-10Subject to change without notice

EI - Electrical connection 230 V, 1N, 50

LEGEND

R04PVG4

730190

700

1755

567

619 25

55.5 587 55.5

118.6398.5101.5

90 518 90

665

Electrolux 400 Lt Line

Stainless steel refrigerators & freezers

Internet: http://www.electrolux.com/foodservice

HAF0102011-11-10Subject to change without notice

EI - Electrical connection 230 V, 1N, 50

LEGEND

R04NVF4F

730183
