Electrolux EC2830AOW2 Manuel utilisateur
CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. OPERATION........................................................................................................ 6
4. BEFORE FIRST USE............................................................................................7
5. DAILY USE.......................................................................................................... 7
6. HINTS AND TIPS................................................................................................. 8
7. CARE AND CLEANING........................................................................................8
8. TROUBLESHOOTING..........................................................................................9
9. INSTALLATION..................................................................................................12
10. NOISES........................................................................................................... 13
11. TECHNICAL INFORMATION............................................................................14
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children.
•Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices
and other working environments
–By clients in hotels, motels, bed and breakfast and
other residential type environments
•Keep ventilation openings, in the appliance enclosure or
in the built-in structure, clear of obstruction.
•Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the
type recommended by the manufacturer.
•Do not use water spray and steam to clean the
appliance.
ENGLISH 3
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•If the appliance is equipped with an Ice maker or a
water dispenser, fill them with potable water only.
•If the appliance requires a water connection, connect it
to potable water supply only.
•The inlet water pressure (minimum and maximum) must
be between 1 bar (0,1 MPa) and 10 bar (1 MPa)
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before connecting
the appliance to the power supply. This
is to allow the oil to flow back in the
compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too colds, such
as the construction appendices,
garages or wine cellars.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• All electrical connections should be
made by a qualified electrician.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Service or an electrician to change the
electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
www.electrolux.com4
2.3 Use
WARNING!
Risk of injury, burns, electrical
shock or fire.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains isobutane
(R600a), a natural gas with a high level
of environmental compatibility. This gas
is flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure
on the drink container.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are
wet or damp.
• When you remove an ice lolly from the
appliance, do not eat it immediately.
Wait a few minutes.
• Do not freeze again food that has been
thawed.
• Obey the storage instructions on the
packaging of frozen food.
2.4 Internal light
• The type of light bulb or halogen lamp
used for this appliance, is only for
household appliances. Do not use it for
house lighting.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority
for information on how to discard the
appliance correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
ENGLISH 5
3. OPERATION
3.1 Control panel
21 3
1Temperature regulator
2Pilot light
3High temperature alarm light
3.2 Switching on
B
C
A
A) Temperature Regulator
B) Half Loaded position
C) Full Loaded position
1. Insert the plug into the wall socket.
2. Turn the Temperature Regulator to the
Full Loaded position and let the
appliance run for 24 hours to allow the
correct temperature to be reached
before placing food inside.
The pilot light will light up.
3. Adjust the Temperature Regulator
according to the quantity of the stored
foods.
3.3 Switching off
Turn the Temperature regulator to the OFF
position.
3.4 Temperature regulation
The temperature within the appliance is
controlled by the Temperature Regulator
situated on the control panel.
To operate the appliance, proceed as
follows:
• to obtain the minimum coldness, turn
the Temperature Regulator toward
lower settings.
• to obtain the maximum coldness. turn
the Temperature Regulator toward
higher settings.
In case of freezing less food
volumes, the Half Loaded
setting is the most suitable. In
case of freezing much food
volumes, the Full Loaded
setting is the most suitable.
3.5 High temperature alarm
An increase in the temperature in the
freezer (for example due to an power
failure) is indicated by switching on of the
Alarm light
During the alarm phase, don't place food
inside the freezer.
When normal conditions are restored the
Alarm light will switch off automatically.
www.electrolux.com6
4. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
4.1 Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap to
remove the typical smell of a brand-new
product, then dried thoroughly.
CAUTION!
Do not use detergents or
abrasive powders, as these will
damage the finish.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
The maximum amount of food that can be
frozen in 24 hours is specified on the
rating plate. 1
The freezing process lasts 24 hours:
during this period do not add other food
to be frozen.
5.2 Storage of frozen food
When first starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
24 hours Temperature Regulator to the
Full Loaded position.
CAUTION!
In the event of accidental
defrosting, for example due to
a power failure, if the power
has been off for longer than the
value shown in the technical
characteristics chart under
"rising time", the defrosted
food must be consumed
quickly or cooked immediately
and then re-frozen (after
cooling).
5.3 Opening and closing the lid
CAUTION!
Never pull the handle with
immense force.
As the lid is equipped with a tightly closing
seal, it is not easy to reopen it shortly after
closing (due to the vacuum formed inside).
Wait for few minutes before reopening the
appliance.
The vacuum valve will help you to open
the lid.
5.4 Low frost system
The appliance is equipped with Low frost
system (you can see a valve inside the
freezer in the backside) what reduces ice-
build-up in the chest freezer by up to 80
percent.
5.5 Storage baskets
Hang the baskets on the upper edge of
the freezer (A) or place them inside the
freezer (B). Turn and fix the handles for
these two positions as shown in the
picture.
A B
1 Refer to "Technical data"
ENGLISH 7
The following pictures show how many
baskets can be placed inside the various
freezer models.
The baskets will slide into each other.
230
806606 946 1061
1201 1336 1611
You can purchase additional baskets from
your local Service Centre.
6. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Hints for freezing
To help you make the most of the freezing
process, here are some hints:
• The maximum quantity of food which
can be frozen in 24 hours is shown on
the rating plate.
• The freezing process takes 24 hours.
No further food to be frozen should be
added during this period.
• Freeze only top quality, fresh and
thoroughly cleaned foodstuffs.
• Prepare food in small portions to
enable it to be rapidly and completely
frozen and to make it possible
subsequently to thaw only the quantity
required.
• Wrap up the food in aluminium foil or
polythene and make sure that the
packages are airtight.
• Do not allow fresh, unfrozen food to
touch food which is already frozen,
thus avoiding a rise in temperature of
the latter.
• Lean foods store better and longer
than fatty ones; salt reduces the
storage life of food.
• Water ices, if consumed immediately
after removal from the freezer
compartment, can possibly cause the
skin to be freeze burnt.
• It is advisable to show the freezing in
date on each individual pack to enable
you to keep tab of the storage time.
6.2 Hints for storage of frozen
food
To obtain the best performance from this
appliance, you should:
• make sure that the commercially frozen
foodstuffs were adequately stored by
the retailer;
• be sure that frozen foodstuffs are
transferred from the store to the freezer
in the shortest possible time;
• not open the lid frequently or leave it
open longer than absolutely necessary.
• Once defrosted, food deteriorates
rapidly and cannot be refrozen.
• Do not exceed the storage period
indicated by the food manufacturer.
7. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
www.electrolux.com8
7.1 Periodic cleaning
CAUTION!
Unplug the appliance before
carrying out any maintenance
operation.
Do not use detergents,
abrasive products, highly
perfumed cleaning products or
wax polishes to clean the inner
side of the appliance. Prevent
damage to the cooling system.
There is no need to clean the
compressor area.
1. Switch off the appliance.
2. Regularly clean the appliance and the
accessories with warm water and
neutral soap.
Clean the lid seal carefully.
3. Fully dry the appliance.
4. Connect the mains plug to the mains
socket.
5. Switch on the appliance.
7.2 Defrosting the freezer
CAUTION!
Never use sharp metal tools to
scrape off frost as you could
damage the appliance. Do not
use a mechanical device or any
artificial means to speed up the
thawing process other than
those recommended by the
manufacturer. A temperature
rise of the frozen food packs,
during defrosting, may shorten
their safe storage life.
Defrost the freezer when the frost layer
reaches a thickness of about 10-15 mm.
The amount of frost on the walls of the
appliance will be increased by the high
level of the outer environment humidity
and if the frozen food is not wrapped
properly.
The best time to defrost the freezer when
it contains no or only a little food.
1. Switch off the appliance.
2. Remove any stored food, wrap it in
several layers of newspaper and put it
in a cool place.
3. Leave the lid open , remove the plug
from the defrost water drain and
collect all defrost water on a tray. Use
a scraper to remove ice quickly.
4. When defrosting is completed, dry the
interior thoroughly and refit the plug.
5. Switch on the appliance.
6. Set the temperature regulator to
obtain the maximum coldness and run
the appliance for two or three hours
using this setting.
7. Reload the previously removed food
into the compartment.
7.3 Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Switch off the appliance and
disconnect the appliance from
electricity supply.
2. Remove all food
3. Defrost and clean the appliance and
all accessories.
4. Leave the lid open to prevent
unpleasant smells.
If the cabinet will be kept on,
ask somebody to check it once
in a while to prevent the food
inside from spoiling in case of a
power failure.
8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
ENGLISH 9
8.1 What to do if...
Problem Possible cause Solution
The appliance does not op-
erate. The appliance is switched
off. Switch on the appliance.
The mains plug is not con-
nected to the mains socket
correctly.
Connect the mains plug to
the mains socket correctly.
There is no voltage in the
mains socket. Connect a different electri-
cal appliance to the mains
socket. Contact a qualified
electrician.
The appliance is noisy. The appliance is not sup-
ported properly. Check if the appliance
stands stable.
The cushion spacers loca-
ted between the back of the
cabinet and the pipes come
loose.
Put them back in place
again.
Audible or visual alarm is
on. The cabinet has been re-
cently switched on or the
temperature in the appli-
ance is too high.
Refer to "Door Open
Alarm"or "High Tempera-
ture Alarm" and if the prob-
lem still occurs contact a
qualified electrician or con-
tact the nearest Authorized
Service Centre.
Power indicator light is
flashing. An error has occurred in
measuring the temperature. Contact a qualified electri-
cian or contact the nearest
Authorized Service Centre.
The appliance is not work-
ing properly. Contact a qualified electri-
cian or contact the nearest
Authorized Service Centre.
The lid doesn't close com-
pletely. The lid gaskets are dirty or
sticky. Clean the lid gaskets.
There is excessive frost. Eliminate excess frost.
Food packages are block-
ing the lid. Arrange the packages in the
right way, see the sticker in
the appliance.
The lid is difficult to open. The lid gaskets are dirty or
sticky. Clean the lid gaskets.
The valve is blocked. Check the valve.
The lamp does not work. The lamp is in stand-by. Close and open the door.
The lamp is defective. Refer to "Replacing the
lamp".
www.electrolux.com10
Autres manuels pour EC2830AOW2
1
Table des matières
Langues :
Autres manuels Electrolux Congélateur
Electrolux
Electrolux LCB3LE31W0 Manuel utilisateur
Electrolux
Electrolux EUF2047AOW Manuel utilisateur
Electrolux
Electrolux GT1 Push Manuel utilisateur
Electrolux
Electrolux EU 2246C Guide rapide
Electrolux
Electrolux U01327 Manuel utilisateur
Electrolux
Electrolux ECN 1147 Fiche technique
Electrolux
Electrolux ECN 4157 Fiche technique
Electrolux
Electrolux EU 7120/1 C Manuel utilisateur
Electrolux
Electrolux EC 5109N Fiche technique
Electrolux
Electrolux Freezer Single-Door Manuel utilisateur
Electrolux
Electrolux EUN1100FOW Manuel utilisateur
Electrolux
Electrolux EU 6047T Guide rapide
Electrolux
Electrolux EUT10001W Manuel utilisateur
Electrolux
Electrolux LTB1AE24W0 Manuel utilisateur
Electrolux
Electrolux EUT 12003 W Manuel utilisateur
Electrolux
Electrolux ICF100E Manuel utilisateur
Electrolux
Electrolux ENG2913AOW Manuel utilisateur
Electrolux
Electrolux EUC22430W Manuel utilisateur
Electrolux
Electrolux EU 8216C Manuel utilisateur
Electrolux
Electrolux IK309BN Manuel utilisateur
