Electrolux ZDC 67550W Manuel utilisateur

user manual

ZDC 67550W

Tumble Dryer

125987350.qxp 2007-01-09 15:02 Page 1

125987350.qxp 2007-01-09 15:02 Page 2

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class product from Electrolux, which

hopefully will provide you with lots of pleasure in the future. The

Electrolux ambition is to offer a wide variety of quality products that

make your life more comfortable. You find some examples on the

cover in this manual. Please take a few minutes to study this manual

so that you can take advantage of the benefits of your new

machine. We promise that it will provide a superior User Experience

delivering Ease-of-Mind. Good luck!

125987350.qxp 2007-01-09 15:02 Page 3

4electrolux contents electrolux

Contents

Safety information..............................5

Product description ...........................7

Control panel .....................................7

Use....................................................8

Drying hints ................................12-13

Drying programmes....................14-15

Programme information ...................16

Care and cleaning ...........................17

Something not working ..............20-22

Technical data .................................23

Consumption values ........................24

Installation ..................................25-26

Environment concerns .....................27

Guarantee conditions ......................28

Customer service centres ................29

The following symbols are used in this manual:

Important information concerning your personal safety and information on how

to avoid damaging the appliance.

General information and tips

Environmental information

125987350.qxp 2007-01-09 15:02 Page 4

safety information electrolux 5

Safety Information

In the interest of your safety and to

ensure the correct use, before installing

and first using the appliance, read this

user manual carefully, including its hints

and warnings. To avoid unnecessary

mistakes and accidents, it is important

to ensure that all people using the

appliance are thoroughly familiar with its

operation and safety features. Save

these instructions and make sure that

they remain with the appliance if it is

moved or sold, so that everyone using it

through its life will be properly informed

on appliance use and safety.

General safety

•It is dangerous to alter the

specifications or attempt to modify

this product in any way.

•This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

•Make sure that small pets do not climb

into the drum. To avoid this, please

check into the drum before using.

•Any objects such as coins, safety

pins, nails, screws, stones or any

other hard, sharp material can cause

extensive damage and must not be

placed into the machine.

•In order to avoid danger of fires

caused by excessive drying, do not

use appliance to dry the following

items: Cushions, quilts and the like

(these items accumulate heat).

•Items such as foam rubber (latex foam),

shower caps, waterproof textiles, rubber

backed articles and clothes or pillows

fitted with foam rubber pads should

not be dried in the tumble dryer.

•Always unplug the appliance after

use, clean and maintenance.

•Under no circumstances should you

attempt to repair the machine

yourself. Repairs carried out by

inexperienced persons may cause

injury or serious malfunctioning.

Contact your local Service Centre.

Control panel

Fluff filters

Rating Plate

Condenser unit

Water reservoir

Adjustable feet

125987350.qxp 2007-01-09 15:02 Page 5

6electrolux safety information

Always insist on genuine spare parts.

•Items that have been soiled with

substances such as cooking oil

acetone, petrol, kerosene, spot

removers, turpentine, waxes and

wax removers should be washed in

hot water with an extra amount of

detergent before being dried in the

tumble dryer.

•

Danger of explosion:

Never tumble dry

items that have been in contact with

inflammable solvents (petrol, methylated

spirits, dry cleaning fluid and the

like). As these substance are volatile,

they could cause an explosion. Only

tumble dry items washed with water.

•

Risk of fire

: items that have been

spotted or soaked with vegetable or

cooking oil constitute a fire hazard

and should not be placed in the

tumble dryer.

•If you have washed your laundry

with stain remover you must

execute an extra rinse cycle before

loading your tumble dryer.

•Please make sure that no gas lighters

or matches have accidentally been left

in pockets of garments to be loaded

into appliance

Installation

•This appliance is heavy. Care should

be taken when moving it.

•When unpacking the appliance, check

that it is not damaged. If in doubt, do not

use it and contact the Service Centre.

•All packing and transit bolts must be

removed before use. Serious damage

can occur to the product and to

property if this is not adhered to. See

relevant section in the user manual.

•The final part of a tumble dryer cycle

occurs without heat ( cool down

cycle ) to ensure that the items are

left at a temperature that ensures

that items will not be damaged.

•Any electrical work required to

install this appliance should be

carried out by a qualified electrician

or competent person.

•Care must be taken to ensure that

the appliance does not stand on the

electrical supply cable.

•If the machine is situated on a

carpeted floor, please adjust the feet

in order to allow air to circulate freely

•After having installed the appliance,

check that it is not pressing or

standing on its electrical supply

cable, inlet hose and drain hose.

•If the tumble dryer is placed on top of a

washing machine, it is compulsory to

use the stacking kit (optional accessory).

Use

•This appliance is designed for domestic

use. It must not be used for purposes

other than those for which it was

designed.

•Only wash fabrics which are designed

to be machine dried. Follow the

instructions on each garment label.

•Do not dry unwashed items in the

tumble dryer.

•Fabric softeners, or similar products,

should be used as specified by the

fabric softener instructions.

•Do not overload the appliance. See

the relevant section in the user

manual.

•Clothes which are dripping wet

should not be placed in the dryer.

•Garments which have been in

contact with volatile petroleum

products should not be machine

dried. If volatile cleaning fluids are

used, care should be taken to

125987350.qxp 2007-01-09 15:02 Page 6

product description/Control panel electrolux 7

Product description

Control panel

Programme selector dial

Delicate button

Dryness button

Buzzer button

Indicator lights

1Start/Pause button

Delay Start button

Control panel

Fluff filters

Rating Plate

Condenser unit

Water reservoir

Adjustable feet

125987350.qxp 2007-01-09 15:02 Page 7

8electrolux use

Use

First Use

lEnsure that the electrical connections

comply with the installation

instructions.

lRemove the polystryrene block and

any material from the drum.

lBefore using your tumble dryer for

the first time, were commend that

you to place a few damp cloths

inside the appliance and dry for 30

minutes.

There may be dust inside a brand

new tumble dryer.

Daily Use

Load the laundry

Connect the appliance.

Open the door (see picture).

Place the laundry in the drum, one item

at a time, shaking them out as much as

possible. Close the door.

Please check the laundry does not get

caught between the door and filter.

Select the required programme

Turn the programme selector dial to the

required programme.

The light Start/Pause starts to flash.

The selector dial is divided into following

sections:

•Cottons

•Synthetics

•Time

•Special

Allows you to select electronically

controlled or time controlled drying.

Turn the dial to the required programme

or time.

Electronically controlled drying (automatic)

The appliance runs these programmes

with the help of probes which detect the

degree of dampness of the laundry.

Simply select the programme according

to the type of laundry and degree of

drying required.

The selector dial can be turned either

clockwise or anticlockwise. The lights Drying,

60’

30’

Easy Iron

Mixed

Jeans

Cooling

Time

Special Cottons

Extra

Strong

Cupboard

Damp

Iron

Extra

CupboardIron

Off

Synthetics

125987350.qxp 2007-01-09 15:02 Page 8

use electrolux 9

Cooling and End/Anticrease come on.

At the end of the programme the

selector dial must be turned to position

Off, to switch the machine off.

Attention!

If you turn the programme selector dial

to another programme when the

machine is working, the lights of the

programme progress display start to

flash. The machine will not perform the

new selected programme.

Programme Option buttons

Depending on the programme, different

functions can be combined. These must

be selected after choosing the desired

programme and before depressing the

Start/Pause button.

When these buttons are pressed, the

corresponding pilot lights come on.

When they are pressed again, the pilot

lights go out.

Select Delicate

Pressing this button allows drying to be

performed at a lower temperature, for

delicate items.

The corresponding pilot light comes

on. This option can also be used for

time controlled drying.

DELICATE is only suitable for use with

loads of up to 3kg!

When the programme has finished the

pilot lights End is on.

Select the Dryness

Press the Dryness button repeatedly, to

select the desired option. The relevant

light will light up. Laundry becomes

dryer from MIN to MAX.

Press the Dryness button as many

times as necessary until the small light

at the level of residual dampness

required is illuminated.

When the programme has finished the

pilot lights End is on.

Select the Buzzer

When the drying cycle has finished, an

intermittent audible signal will sound.

By depressing button Buzzer the acou-

stic signal is switched off in the following

cases:

•when selecting the programme

•when depressing the buttons

•when the programme selector dial is

turned to another position during the

programme or when you depress an

option button during the cycle

•at the end of the programme.

The corresponding light comes on

Select the Start/Pause

Start/Pause

Dryness

125987350.qxp 2007-01-09 15:02 Page 9

10 electrolux use

Press this button to start the dryer after

having selected the programme and

the options.

The relevant light will stop flashing.

If the programme selector dial is turned

to another position, when the machine is

running, the buzzer will sound and the

programme phase indicator lights will flash.

The drum turns alternately in both direc-

tions during drying.

All drying programmes end with a 10 minute

cooling phase (light Cooling is on).

You may remove the laundry after this

phase.

The lights End/Anticrease, Filtre and

Empty Tank illuminate and the buzzer

sounds

If the door of the appliance or the small

door at the bottom is opened while the

programme is running, this button must

be pressed again after closing the door

in order to restart the programme from

the point at which it was interrupted.

This button must be depressed also

after a power failure and after having re-

inserted the water reservoir, if it has

been emptied in the middle of a pro-

gramme after lighting up of light Empty

Tank.

In both cases the light of the Start/Pause

button flashes to remind you that the

start button needs to be pressed again.

Select the Delay Start

This button allows you to delay the starting of

the programme by 3, 6 or 9 hours.

Press the button until the light relevant

to the desired delay lights up. This

option must be selected

after

having

selected the programme and

before

pressing START/PAUSE to start the

programme.

The machine begins the countdown,

which is shown by the pilot lights. For

example, if you have chosen a 9-hour

delay (pilot light 9h lit), after 3 hours, 9h

goes out and 6h lights up; after 3 more

hours, 6h goes out and 3h lights up.

When the 9 hours are over (pilot light 3h

off), the drying cycle begins.During the

delayed start period, it is not possible to

change the programme or the selected

delay. If you wish to do so, you must first

cancel everything by rotating the pro-

gramme selector dial to position “

Off

”.

Select the new programme, the options

and the delayed start, then press

START/PAUSE. If you wish to change

only the options, this can be done on

condition that the new option(s) is(are)

compatible with the programme. Set the

machine to PAUSE by depressing the rel-

evant button, select the new option(s) and

depress START/PAUSE button again.

If you wish to add some laundry while the

machine is performing the countdown, after

having done so and having closed the door,

press START/PAUSE again, in order to allow

the machine to complete the remaining

countdown time.

Indicator lights

TThese lights indicate the following

functions:

“

Drying

”

light

This light indicates that the appliance is

in the drying phase

“Cooling” light

This light indicates that the appliance is in the

cooling phase. At the end of drying, there is

a 10 minute cooling phase to cool the

125987350.qxp 2007-01-09 15:02 Page 10

Table des matières

Autres manuels Electrolux Séchoir

Electrolux

Electrolux TC2 Manuel utilisateur

Electrolux

Electrolux EDC 5369 Manuel d'utilisation

Electrolux

Electrolux EDC 504M Manuel utilisateur

Electrolux

Electrolux EDH903BEWA Manuel utilisateur

Electrolux

Electrolux IQ-Touch EIMGD60LT Manuel utilisateur

Electrolux

Electrolux T4900 Manuel utilisateur

Electrolux

Electrolux EDH6370 Manuel d'utilisation

Electrolux

Electrolux 300 Series Manuel utilisateur

Electrolux

Electrolux XDEX75NZHS Manuel utilisateur

Electrolux

Electrolux EIMED55HIW Manuel utilisateur

Electrolux

Electrolux EW8H1968IS Manuel utilisateur

Electrolux

Electrolux EWED65HSS - 27" Electric Dryer Manuel utilisateur

Electrolux

Electrolux T4190 Manuel utilisateur

Electrolux

Electrolux T4130 Manuel utilisateur

Electrolux

Electrolux Zanussi TCE 7245 Manuel utilisateur

Electrolux

Electrolux EDS6051 Manuel utilisateur

Electrolux

Electrolux EDP2074PDW Manuel utilisateur

Electrolux

Electrolux Zanussi TCE 7127 W Manuel utilisateur

Electrolux

Electrolux TK SL5 E Manuel utilisateur

Electrolux

Electrolux TWLEEV300 Manuel utilisateur

Electrolux

Electrolux EDV606E Manuel utilisateur

Electrolux

Electrolux EDE 429E Manuel utilisateur

Electrolux

Electrolux TW SL EEV Manuel utilisateur

Electrolux

Electrolux EDC 5375 Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire

Bosch

Bosch WTX8HKM9SN Manuel utilisateur
