Electrolux QuickDry N1130 Manuel utilisateur

Operatingmanual

Tumbledryer

QuickDry

TypeN1130

4389096-00/EN

Operatingmanualinoriginallanguage2011.11.03

Contents

1SafetyPrecautions.............................................................................................................5

2Programdescription...........................................................................................................7

2.1General.......................................................................................................................7

2.2Programdescription...................................................................................................7

2.3Load............................................................................................................................8

3Handling.............................................................................................................................9

3.1Tostartthemachine...................................................................................................9

3.2Additionalfunctions....................................................................................................10

3.3Whenprogramhasended..........................................................................................11

4Errorcodes.........................................................................................................................12

5Maintenance.......................................................................................................................13

5.1General.......................................................................................................................13

5.2Everyday....................................................................................................................14

5.3Freshairintake...........................................................................................................15

5.4Machineswithresidualmoisturecontrol(RMC).........................................................15

5.5Condensatemachine..................................................................................................15

5.6Maintenancetobecarriedoutbyqualiedservicepersonnel....................................16

Themanufacturerreservestherighttomakechangestodesignandcomponentspecications.

SafetyPrecautions5

1SafetyPrecautions

Themachineisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor

mentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervisionor

instructionconcerninguseoftheappliancebyapersonresponsiblefortheirsafety.

Childrenshouldbesupervisedtoensurethattheydonotplaywiththemachine.

Themachineisnottobeusedifindustrialchemicalshavebeenusedforcleaning.

Donotdryunwasheditemsinthemachine.

Itemsthathavebeensoiledwithsubstancessuchascookingoil,acetone,alcohol,petrol,kerosene,spot

removers,turpentine,waxesandwaxremoversshouldbewashedinhotwaterwithanextraamount

ofdetergentbeforebeingdriedinthemachine.

Itemssuchasfoamrubber(latexfoam),showercaps,waterprooftextiles,rubberbackedarticlesand

clothesorpillowsttedwithfoamrubberpadsshouldnotbedriedinthemachine.

Fabricsoftenersorsimilarproductsshouldbeusedasspeciedbythefabricsoftenerinstructions.

Thenalpartofadryingcycleoccurswithoutheat(cooldowncycle)toensurethattheitemsareleftata

temperaturethatensuresthattheitemswillnotbedamaged.

Removeallobjectsfrompocketssuchaslightersandmatches.

WARNING.Neverstopthemachinebeforetheendofthedryingcycleunlessallitemsarequicklyremoved

andspreadoutsothattheheatisdissipated.

Adequateventilationhastobeprovidedtoavoidthebackowofgasesintotheroomforappliances

burningotherfuels,includingopenres.

Exhaustairmustnotbedischargedintoauewhichisusedforexhaustingfumesfromappliancesburning

gasorotherfuels.

Themachinemustnotbeinstalledbehindalockabledoor,aslidingdoororadoorwithahingeonthe

oppositesidetothatofthemachine.

Ifthemachinehasalinttrapthishastobecleanedfrequently.

Thelintmustnotbeaccumulatedaroundthemachine.

DONOTMODIFYTHISAPPLIANCE.

Gasheatedtumbledryer:

Beforeinstallation,checkthatthelocaldistributionconditions,natureofgasandpressureandthe

adjustmentoftheappliancearecompatible.

Themachineisnottobeinstalledinroomscontainingcleaningmachineswithperchloroethylene,

TRICHLOROETHYLENEorCHLOROFLUOROCONTAININGHYDROCARBONSascleaningagents.

Ifyoucansmellgas:

•Donotswitchonanyequipment

•Donotuseelectricalswitches

•Donotusetelephonesinthebuilding

•Evacuatetheroom,buildingorarea

•Contactthepersonresponsibleforthemachine

6SafetyPrecautions

AllexternalequipmentwhichisconnectedtothemachinemustbeCE/EMC-approvedandconnectedusing

anapprovedshieldedcable.

Inordertopreventdamagetotheelectronics(andotherparts)thatmayoccurastheresultofcondensation,

themachineshouldbeplacedinroomtemperaturefor24hoursbeforebeingusedforthersttime.

Servicingshallbecarriedoutonlybyauthorizedpersonnel.

Programdescription7

2Programdescription

2.1General

Themachineisequippedwithanumberofprogramsadaptedtotherangeofusetowhichthe

machineisintended.

Itisrecommendettofollowthecarelabellingofthegarmentasfaraspossible.

Forbestpossibledryingresultitisadvisabletodrygarmentsofthesamequalityforeachdrying

cycle.

Note!

Donottumbledrywoolorsilk.

2.2Programdescription

Therearetwotypesofprograms,automaticprogramsandtimeprograms.

Automaticprogramshasmoisturedetectionandwillstopautomatically.

Timeprogramshasnomoisturedetectionandwillstopwhenthepresettimehasended.

Thefollowingprogramscanbeavailable:

AutomaticprogramsDescription

Extradry,Dry

andIrondry

Normaltemp.

Cottonandterry.

Normal/mediumtemperature.

Theprogramwillstopwhenselecteddrynessisachieved(Extradry,DryorIrondry).

Extradry,Dry

andIrondry

Lowtemp.

Synthetic,viscose,polycottonanddelicatefabrics.

Lowtemperature.

Theprogramwillstopwhenselecteddrynessisachieved(Extradry,DryorIrondry).

TimeprogramsDescription

Normaltemp.Cottonandterry

Differentdryingtimescanbeselected.

Theprogramwillstopwhenthetimeisup.

Lowtemp.Synthetic,viscose,polycotton,downanddelicatefabrics.

Differentdryingtimescanbeselected.

Theprogramwillstopwhenthetimeisup.

NoheatingAiringbedspreads,duvetsandbedclothes

Differentdryingtimescanbeselected.

Theprogramwillstopwhenthetimeisup.

8Programdescription

2.3Load

Foranoptimalresultitisrecommendedtoloadthemachinetohalf.

Themaximumloadis6kg.

Handling9

3Handling

Loadthegoodsintothemachineaccordingtorecommendationsandclosethedoor.

Makesurethelteriscleanandcleanifnecessary.

g.7361

①

3.1Tostartthemachine

Selectthedesiredprogrambyturningthecontrolknob.

Therearetwotypesofprograms,automaticprogramsandtimeprograms.

Automaticprogramshasmoisturedetectionandwillstopautomatically.

Timeprogramshasnomoisturedetectionandwillstopwhenthepresettimehasended.

Automaticprograms

Selectthedesiredprogrambyturningthecontrolknob.Startthemachinebypressingthecontrol

knob.

Timeprograms

Selectthedesiredprogrambyturningthecontrolknob.Conrmbypressingthecontrolknob.

Fortimeprogramsitispossibletochangethetimefortheselectedprogrambyturningthecontrol

knob.

Increase/decreasetimebyturningthecontrolknob

Startthemachinebypressingthecontrolknob.

10Handling

3.2Additionalfunctions

Pause

Itispossibletopauseanongoingprogram.

Pressthecontrolknob.Amenywillappearonthedisplay.SelectPAUSEbyturningthecontrol

knobandpressthecontrolknobtoactivate.

Forsomemachinesitisalsopossibletopausedirectlywhenpressingthecontrolknob.

Whenpressingthecontrolknobagaintheprogramwillcontinue.

Changingaprogramafterstart

Itispossibletochangeaprogramafterstart.

Pressthecontrolknob.Amenywillappearonthedisplay.SelectCHANGEPROGRAMbyturningthe

controlknobandpressthecontrolknobtoactivate.

Whenpressingthecontrolknobtheprogrammenuwillbedisplayed.Selectanewprogramand

startbypressingthecontrolknob.

Endaprogram

Itispossibletoendaprogramafterstart.

Pressthecontrolknob.Amenywillappearonthedisplay.SelectENDPROGRAMbyturningthe

controlknobandpressthecontrolknobtoactivate.

Whenpressingthecontrolknobtheprogramwillbeended.

Status

Pressthecontrolknob.Amenywillappearonthedisplay.SelectSTATUSMENUbyturningthe

controlknobandpressthecontrolknobtoactivate.

Thestatusmenushowsthestatusforinletairtemp,outletairtemp,RMCandheatforthemachine.

Statistics

Pressthecontrolknob.Amenywillappearonthedisplay.SelectSTATISTICSbyturningthe

controlknobandpressthecontrolknobtoactivate.

Thestatisticsmenushowstotalrunhoursandtriprunhoursforthemachine.

Changedrumspeed(onlyonmachineswithMCU)

Pressthecontrolknob.Amenywillappearonthedisplay.SelectCHANGEDRUMSPEEDbyturning

thecontrolknobandpressthecontrolknobtoactivate.

Changethedrumspeedwiththecontrolknob.

Note!

Someofthefunctionsmaynotbeavailableoractiveonyourmachine.
