EDC804P5WB
EN Tumble Dryer User Manual
CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................5
3. PRODUCT DESCRIPTION................................................................................ 6
4. CONTROL PANEL............................................................................................. 7
5. PROGRAMME TABLE....................................................................................... 8
6. OPTIONS............................................................................................................9
7. SETTINGS........................................................................................................11
8. BEFORE FIRST USE....................................................................................... 12
9. DAILY USE....................................................................................................... 13
10. HINTS AND TIPS........................................................................................... 14
11. CARE AND CLEANING..................................................................................15
12. TROUBLESHOOTING....................................................................................17
13. TECHNICAL DATA.........................................................................................19
14. QUICK GUIDE................................................................................................20
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time. Welcome to
Electrolux.
Visit our website:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
Subject to change without notice.
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
www.electrolux.com2
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•The appliance can be installed as freestanding or
below a kitchen counter with correct space (refer to
the Installation leaflet).
ENGLISH 3
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from being
fully open.
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•CAUTION: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
•Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
•Do not use the appliance if items have been soiled
with industrial chemicals.
•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Do not run the appliance without a filter. Clean the lint
filter before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
www.electrolux.com4
•Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
•WARNING: Never stop a tumble dryer before the end
of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be lower
than 5°C or higher than 35°C.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when it is being moved.
• The rear surface of the appliance
must be put against a wall.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
2.3 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• This appliance is for household
(indoors) use only.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• Only dry fabrics which are suitable for
drying in a tumble dryer. Follow the
instructions on the fabric label.
• If you have washed your laundry with
a stain remover start an extra rinse
cycle before you start the dryer.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and
pets.
• Do not sit or stand on the open door
of the appliance.
• Do not dry dripping wet clothes in a
tumble dryer.
2.4 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
ENGLISH 5
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
1 2
5
3
4
6
7
8
9
1Water container
2Control panel
3Appliance door
4Filter
5Rating plate
6Airflow slots
7Heat Exchanger lid
8Heat Exchanger cover
9Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
www.electrolux.com6
4. CONTROL PANEL
1
89 7 6
3
5
4
2
1Programme knob
2Display
3Time Dry touch button
4Start/Pause touch button
5Delay Start touch button
6Extra Anticrease touch button
7Gentle Dry touch button
8Dryness Level touch button
9On/Off button
Press the touch buttons with
your finger in the area with
the symbol or name of the
option. Do not wear gloves
when you operate the
control panel. Make sure
that the control panel is
always clean and dry.
4.1 Display
Symbol on the display Symbol description
time drying option on
delay start option on
indicator:
check Heat Exchanger
indicator:
clean filter
ENGLISH 7
Symbol on the display Symbol description
indicator:
drain the water container
indicator:
drying phase
indicator:
cooling phase
indicator:
anti-crease phase
child lock on
wrong selection
programme duration
- time Drying duration
- delay start duration
5. PROGRAMME TABLE
Programme Load 1) Properties / Fabric type2)
Favourite
Depends
on a mem‐
orised pro‐
gramme
You can do your configuration of programme
and options and memorise in the appliance
memory (See chapter "
Settings - Favourite
").
Cottons 8 kg Cotton fabrics. /
Mixed 3kg
Cotton and synthetic fabrics.
Low temperature programme.
Delicate programme with warm
air.
/
Bedding 3kg
Bed linen such as single and
double sheets, pillowcases, du‐
vet cover. /
Synthetics 3,5 kg Synthetic and mixed fabrics. /
Energy Saver 8 kg
Cycle to be used to dry cotton
with "cotton cupboard" dryness
level, with maximum energy sav‐
ing.
/
Refresh 1kg Refreshing textiles that were in storage.
Denim 4 kg
Leisure clothing such as jeans,
sweat-shirts of different material
thicknesses (e.g. at the neck,
cuffs and seams).
/
www.electrolux.com8
Programme Load 1) Properties / Fabric type2)
Sports 2 kg Sportswear, thin and light fab‐
rics, microfiber, polyester. /
Easy Iron 1 kg (or 5
shirts)
Easy care fabrics for which a
minimum of ironing is necessary.
The drying results can be differ‐
ent from one type of fabric to an‐
other. Shake the items before
putting them in the appliance.
When the programme has
ended, immediately remove the
items and put them on a hanger.
/
Shirts 1,5kg (or 7
shirts)/
Easy care fabrics for which a
minimum of ironing is necessary.
The drying results can be differ‐
ent from one type of fabric to the
other. Shake the items before
you put them in the appliance.
When the programme is comple‐
ted, Immediately remove the
items and put them on a hanger.
/
Wool 1 kg
Woollen fabrics. Gentle drying for hand-wash‐
able woollens. Remove items immediately
when the programme is completed.
Delicates 4 kg Delicate fabrics such as viscose,
rayon, acrylic, and their blends. /
1) The maximum weight refers to dry items.
2) For fabric mark meaning see chapter
HINTS AND TIPS: Preparing the laundry.
6. OPTIONS
6.1 Dryness Level
This function helps to increase dryness
of the laundry. There are 3 options:
• Extra Dry
• Cupboard Dry
• Iron Dry
6.2 Gentle Dry
With this option you can set a delicate
drying programme that has a low
temperature. Use this option with a
fabrics that have the symbol on the
fabric label (e.g. acrylic, viscose).
6.3 Extra Anticrease
Extends the anti-crease phase by 60
minutes at the end of the drying cycle.
This function reduces creases. The
laundry can be removed during the anti-
crease phase.
6.4 Time Dry
You can set the programme duration,
from a minimum of 10 minutes to a
maximum of 2 hours. The required
duration is related to the quantity of
laundry in the appliance.
ENGLISH 9
We recommend that you set
a short duration for small
quantities of laundry or for
only one item.
TIME DRYING RECOMMENDATION
10 - 20 min
action of cool
air only (no
heater).
20 - 40 min
additional dry‐
ing to improve
dryness after
previous dry‐
ing cycle.
TIME DRYING RECOMMENDATION
>40 min
full drying of
the small laun‐
dry loads up to
4 kg, well spun
(>1200 rpm).
6.5 Options table
Programmes1) Dryness Level Gentle Dry Extra Anti‐
crease Time Dry
Favourite Depends on a memorised programme
Cottons ■ ■ ■ ■ ■ ■
Mixed ■ ■ ■ ■
Bedding ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■
Energy Saver ■ ■
Refresh ■
Denim ■ ■ ■
Sports ■ ■
Easy Iron ■ ■ ■
Shirts ■ ■
Wool ■
Delicates ■ ■ ■
1) Together with the programme you can set 1 or more options. To activate or deactivate
them, press the related touch button.
www.electrolux.com10
Table des matières
Autres manuels Electrolux Séchoir
Electrolux
Electrolux DC6-4 Manuel utilisateur
Electrolux
Electrolux EW8H359SP Manuel utilisateur
Electrolux
Electrolux FGQ332E Manuel utilisateur
Electrolux
Electrolux EIED55HIW - 8.0 cu. Ft. Electric Dryer Guide de démarrage rapide
Electrolux
Electrolux EDV605HQWA Manuel utilisateur
Electrolux
Electrolux QuickDry N1130 Manuel utilisateur
Electrolux
Electrolux EDC804Q5WB Manuel utilisateur
Electrolux
Electrolux EDH804H3WB Manuel utilisateur
Electrolux
Electrolux EIED55HIW - 8.0 cu. Ft. Electric Dryer Manuel utilisateur
Electrolux
Electrolux EW8H259ST Manuel utilisateur
Electrolux
Electrolux EW8H258SP Manuel utilisateur
Electrolux
Electrolux EW7H558E2 Manuel utilisateur
Electrolux
Electrolux Iron Aid EDI97170W Manuel utilisateur
Electrolux
Electrolux EDE 56160W Manuel utilisateur
Electrolux
Electrolux EDR 1000 Manuel utilisateur
Electrolux
Electrolux EIED55IKG - 8.0 cu. Ft. Electric Dryer Manuel utilisateur
Electrolux
Electrolux TWSL5E300 Manuel utilisateur
Electrolux
Electrolux TC2 Manuel utilisateur
Electrolux
Electrolux SEQ7000FS0 Manuel utilisateur
Electrolux
Electrolux 27" Dryers Manuel utilisateur
Manuels Séchoir populaires d'autres marques
BOMANN
BOMANN WT 5019 Manuel utilisateur
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manuel utilisateur
Asko
Asko T793C Manuel utilisateur
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
Frigidaire
Frigidaire CAQE7077KW0 Manuel du propriétaire
Bosch
Bosch WTX8HKM9SN Manuel utilisateur
