Electrolux GA60PLVC Manuel utilisateur

GA60PLVC

EN Dishwasher User Manual 2

DE Geschirrspüler Benutzerinformation 27

CONTENTS

1. SAFETY INFORMATION....................................................................................3

2. SAFETY INSTRUCTIONS..................................................................................4

3. PRODUCT DESCRIPTION................................................................................ 6

4. CONTROL PANEL............................................................................................. 7

5. PROGRAMMES................................................................................................. 7

6. SETTINGS..........................................................................................................9

7. OPTIONS..........................................................................................................11

8. BEFORE FIRST USE....................................................................................... 13

9. DAILY USE....................................................................................................... 15

10. HINTS AND TIPS........................................................................................... 18

11. CARE AND CLEANING..................................................................................19

12. TROUBLESHOOTING....................................................................................21

13. TECHNICAL INFORMATION......................................................................... 25

14. GUARANTEE ................................................................................................ 26

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible for any injuries or damages that are the

result of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•This appliance is intended to be used in household

and similar applications such as:

–farm houses; staff kitchen areas in shops, offices

and other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and

maximum) must be between 0.5 (0.05) / 8 (0.8) bar

(MPa)

•Obey the maximum number of 13 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

ENGLISH 3

•Put the cutlery in the cutlery basket with the sharp

ends pointing down or put them in the cutlery drawer

in a horizontal position with the sharp edges down.

•Do not leave the appliance with the open door

unattended to avoid stepping accidentally onto it.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•If the appliance has ventilation openings in the base,

they must not be covered e.g. by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must

install this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Follow the installation instruction

supplied with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Make sure that the appliance is

installed below and adjacent to safe

structures.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need to

be replaced, this must be carried out

by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the

E.E.C. Directives.

• UK and Ireland only. This appliance is

fitted with a 13 A mains plug. If it is

necessary to change the mains plug

fuse, use only a 13 A ASTA (BS

1362) fuse.

www.electrolux.com4

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and

clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

• Without electrical power, the water

protection system is not active. In this

case there is a risk of flooding.

• The water inlet hose has a safety

valve and a sheath with an inner

mains cable.

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately close the water tap and

disconnect the mains plug from the

mains socket. Contact the Authorised

Service Centre to replace the water

inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are

dangerous. Obey the safety

instructions on the detergent

packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

complete. Some detergent may

remain on the dishes.

• The appliance can release hot steam

if you open the door while a

programme operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Internal light

WARNING!

Risk of injury.

• This appliance has an internal lamp

that comes on when you open the

door and goes off when the door is

closed.

• The lamp in this appliance is not

suitable for household room

illumination.

• To replace the lamp, contact the

Service.

2.6 Service

• Contact the Authorised Service

Centre to repair the appliance. We

recommend only the use of original

spare parts.

• When you contact the Authorised

Service Centre, ensure that you have

the following information that is

available on the rating plate.

Model :

PNC :

Serial Number :

2.7 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

ENGLISH 5

3. PRODUCT DESCRIPTION

9 67

1Top spray arm

2Upper spray arm

3Lower spray arm

4Filters

5Rating plate

6Salt container

7Air vent

8Rinse aid dispenser

9Detergent dispenser

10 Comfort Lift basket

11 Trigger handle

12 Lower basket handle

13 Upper basket

14 Cutlery drawer

3.1 TimeBeam

The TimeBeam is a display that is shown

on the floor below the appliance door.

• When the programme starts, the

programme duration comes on.

• When the programme is completed,

0:00 and CLEAN come on.

• When the delay start starts, the

countdown duration and DELAY

come on.

• When the appliance has a

malfunction, an alarm code appears.

www.electrolux.com6

When AirDry is activated

during the drying phase, the

projection on the floor may

not be completely visible. To

check the remaining time of

the running programme, look

at the control panel display.

4. CONTROL PANEL

1 2 3 4

6 5

1On/off button

2Navigation key (up)

3Display

4Option key

5OK key

6Navigation key (down)

4.1 Key behaviour

Navigation keys (up and down)

• Use these keys to scroll the lists and

information texts that show on the

display.

Option key

• Short press will enter the option list.

• Short press in the option list takes you

back to the programme list.

• Short press in the settings list takes

you back to the option list.

• Long press (3 sec.) when a delay start

or a programme is running will delete

the delay start, the programme and

options. The display shows the default

programme: ECO.

OK key

• Short press: Confirms the selection of

the programme, options and settings.

• Long press: Starts the MyFavourite

programme.

If no programme has been saved it

will display the setting Set

MyFavourite.

5. PROGRAMMES

Programme Degree of soil

Type of load

Programme pha‐

ses

Options

ECO 50° 1) • Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• ExtraHygiene

• TimeSaver

• XtraDry

ENGLISH 7

Programme Degree of soil

Type of load

Programme pha‐

ses

Options

AutoSense

45°- 70° 2)

• All

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash from 45 °C

to 70 °C

• Rinses

• Dry

• ExtraHygiene

• XtraDry

PROZONE

50°- 65° 3)

• Mixed soil

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash 50 °C and

65 °C

• Rinses

• Dry

• TimeSaver

• XtraDry

Intensive 70° • Heavy soil

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• ExtraHygiene

• TimeSaver

• XtraDry

30 MIN 60° 4) • Fresh soil

• Crockery and

cutlery

• Wash 60 °C

• Rinses

• ExtraHygiene

• XtraDry

Glass 45° • Normal or light

soil

• Delicate crock‐

ery and glass‐

ware

• Wash 45 °C

• Rinses

• Dry

• XtraDry

Extra silent 50° 5)

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• XtraDry

Rinse&Hold 6) • All • Prewash

1) With this programme you have the most efficient use of water and energy consumption

for crockery and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto‐

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) With this programme you can wash a load with mixed soil. Very heavy soil in the lower

basket and normal soil in the upper basket. The pressure and the temperature of the water

in the lower basket are higher than in the upper basket.

4) With this programme you can wash a load with fresh soil. It gives good washing results in

a short time.

5) This is the most silent programme. The pump works at a very low speed to decrease the

level of noise. Because of the low speed, the programme duration is long.

6) With this programme you can quickly rinse dishes to prevent remains of food to bond on

dishes and odours to form in the appliance. Do not use detergent with this programme.

www.electrolux.com8

5.1 Consumption values

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

ECO 50° 11 0.832 232

AutoSense 45°- 70° 7 - 14 0.6 - 1.6 40 - 170

PROZONE 50°- 65° 14 - 16 1.2 - 1.5 160 - 180

Intensive 70° 12.5-14.5 1.4-1.7 170-190

30 MIN 60° 10 0.9 30

Glass 45° 12 - 14 0.7 - 0.9 82-92

Extra silent 50° 9 - 10 1.1 - 1.3 230 - 250

Rinse&Hold 4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the

options and the quantity of dishes can change the values.

5.2 Information for test

institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Settings list

To see the settings list, select Settings in

the option list.

Settings Values Description

MyFavourite List of programmes Set your favourite daily

programme. Refer to spe‐

cific information provided in

this chapter.

AirDry ON (default value)

OFF

Set the automatic door

opening for all programmes

except Rinse&Hold. Refer

to the specific information

provided in this chapter.

End sound ON

OFF

Informs you when the pro‐

gramme is completed.

Factory setting: off.

Key tones Off

Click

Beep

Set the sound of the keys

when pressed.

ENGLISH 9

Settings Values Description

Volume From level 1 to level

10.

Adjustment of the sound

volume.

Brightness From level 0 to level

Change the brightness of

the display.

Contrast From level 0 to level

Change the contrast of the

display.

Water hardness From level 1 to level

10.

Set the level of the water

softener according to the

water hardness in your

area.

Factory setting: level 5.

Rinse aid level From level 0 to level

Level 0 = no release

of rinse aid.

Set the level of the rinse

aid dispenser according to

the necessary quantity of

rinse aid.

Factory setting: level 4.

Languages List of languages. Set the preferred language.

Default language: English.

Display on floor List of colours. Set the colour of the Time‐

Beam

Reset settings Reset Reset the appliance to fac‐

tory settings.

6.2 How to change a setting

with 2 values (ON and OFF)

When a setting is changed it will remain

valid even if the programme is completed

or a running programme is cancelled.

1. Press the Option key.

2. Select Settings.

3. Press the OK key.

4. Select the setting to change.

5. Press the OK key to change the

value from ON to OFF or vice versa.

6. Press repeatedly the Option key until

the display shows the programme

list.

6.3 How to change a setting

with multiple values

When a setting is changed it will remain

valid even if the programme is completed

or a running programme is cancelled.

1. Press the Option key.

2. Select Settings.

3. Press the OK key.

4. Select the setting to change.

5. Press the OK key to enter the next

level.

6. Select the new value.

7. Press the OK key to confirm.

8. Press repeatedly the Option key until

the display shows the programme

list.

6.4 Starting the MyFavourite

programme

1. Press and hold OK for about 3

seconds until the display shows the

MyFavourite setting.

2. Close the appliance door to start the

programme.

www.electrolux.com10

Autres manuels pour GA60PLVC

Table des matières

Langues :

Autres manuels Electrolux Lave-vaisselle

Electrolux

Electrolux ESA47310SW Manuel utilisateur

Electrolux

Electrolux GA55SLICN Manuel utilisateur

Electrolux

Electrolux TW1E Manuel utilisateur

Electrolux

Electrolux EEG68520W Manuel utilisateur

Electrolux

Electrolux Millennium 2G Manuel utilisateur

Electrolux

Electrolux ESL 4126 Manuel utilisateur

Electrolux

Electrolux ESL5335LO Manuel utilisateur

Electrolux

Electrolux Built-In Dishwasher Manuel utilisateur

Electrolux

Electrolux Zanussi DA 4442 Manuel utilisateur

Electrolux

Electrolux GA554IF Manuel utilisateur

Electrolux

Electrolux EIDW6405HT - Fully Integrated Dishwasher Manuel utilisateur

Electrolux

Electrolux Diva EDW 2000 Manuel utilisateur

Electrolux

Electrolux ESF 64010 Manuel utilisateur

Electrolux

Electrolux EES47310IX Manuel utilisateur

Electrolux

Electrolux GA60SLISCN Manuel utilisateur

Electrolux

Electrolux ESL 46010 Manuel utilisateur

Electrolux

Electrolux EIDW1805KS Manuel utilisateur

Electrolux

Electrolux ESL8523RO Manuel utilisateur

Electrolux

Electrolux 534120 Manuel utilisateur

Electrolux

Electrolux GA60IEEVWE Manuel utilisateur

Electrolux

Electrolux ESA47220UW Manuel utilisateur

Electrolux

Electrolux NHT8 Manuel utilisateur

Electrolux

Electrolux EI24ID30QS Manuel utilisateur

Electrolux

Electrolux ESF 43010 Manuel utilisateur

Manuels Lave-vaisselle populaires d'autres marques

KitchenAid

KitchenAid KUDB230B Manuel utilisateur

Brandt

Brandt BDJ424DB Manuel utilisateur

Asko

Asko DSD767UXXL.AU Manuel utilisateur

Beko

Beko DFN26210W Manuel utilisateur

NEFF

NEFF S153ITX00E Fiche technique

Midea

Midea SV 4.45 wi Manuel utilisateur

LG LDF7932 Manuel utilisateur

Gorenje

Gorenje GV63214 Manuel utilisateur

Hotpoint

Hotpoint HDA1100ZWH Manuel de service

Blomberg

Blomberg LDFN2240W Manuel utilisateur

AEG

AEG FFB83836PM Manuel utilisateur

Cylinda

Cylinda DM3220RFD Manuel utilisateur

Atag

Atag DW8214MB Manuel utilisateur

GE GLD8000 Series Manuel utilisateur

Siemens

Siemens SN23HI02KE Fiche technique

Omega

Omega ODW717X Manuel utilisateur

BORETTI

BORETTI BVW-683 Manuel utilisateur

Siemens

Siemens SN 56N591 Manuel utilisateur
